Uplift Desk O-Leg Seated Height Table Frame FRM405-BLK User manual

For assembly assistance,
call 800-349-3839 or email [email protected]
355 lb
two person
assembly
©2020 UPLIFT Desk®. All Rights Reserved
O-Leg Seated Height Table Frame
®

Thank you for choosing UPLIFT Desk.

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com
3
SAFETY AND WARNINGS
Count all pieces before disposing of any carton or packing material. Use a padded or carpeted area
for assembly to avoid damage. For ease and safety, we recommend two people for assembly.
355 lb
355 lb
You’ll need:
tape measure,
and Phillips head
screwdriver
COMPONENTS
PACKAGE CONTENTS
O-Leg assembly
(qty 2)
Crossbar rail
(qty 2)
Crossbar end
(qty 2)
WARNING: Designed for use in dry work environments only. Use only indoors.
Please read this manual carefully. Inappropriate use of this table can cause property damage or bodily injury.
Under no circumstances does the manufacturer accept warranty or liability claims for damages caused from
improper use or handling of this table. Provide this manual to any new user.
CONFIGURATION
C4C3C2C1
HARDWARE
M6
Washer
(qty 16)
Spacer bracket
(qty 4)
needed for 80’’ tops only
#10
Washer
(qty 14)
M8x8
Set screw
(qty 16)
H1 H2
H4 H5 H6 H7
C4
C3
C2
C1
H1
H2
H5
H6
H3 bH3 a #10-24x3/4’’
Machine screw
(qty 8)
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
#10x3/4’’
Wood screw
(qty 14)
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
Crossbar receiver
(qty 2)
M6x10
Machine screw
(qty 16)
4mm
Allen wrench
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com 4
ASSEMBLY INSTRUCTIONS
Step 1
With the O-legs (C1) upside down as shown, attach
the Crossbar receivers (C2) using four M6x10 screws
(H1) and four M6 Washers (H2) per Crossbar receiver.
Note the orientation of Crossbar receiver so it is not
attached upside down.
Note:
If you are attaching the frame to an 80” wide UPLIFT
Desk table top, attach two Spacer brackets (H6) to
each O-leg assembly using two M6x10 screws (H1)
and two M6 Washers (H2) per Spacer bracket. You
will not use these brackets on non-UPLIFT brand
table tops.
Do NOT completely tighten these screws until Step 4.
Step 3
Insert the Crossbar rails (C4) into the Crossbar ends
of one of the O-leg assemblies with the Center indica-
tor marks facing up. Then slide the other O-leg assem-
bly onto the opposite ends of the Crossbar rails.
Collapse the assembly as far as possible to make it
easier to lift onto the table top in the next step.
Center Indicator Marks
Step 2
Slide a Crossbar end (C3) into each of the Crossbar
receivers as shown, with the four set screw holes visible.

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com
5
Added stability on 80’’ UPLIFT Desk Table Tops
* For added stability you can also install Wood screws
in each O-Leg hole. To make this easier, mark these
hole locations, move the frame a bit and pre-drill the
hole locations with a 1/8” diameter drill bit.
Note: DRILL NO DEEPER THAN 1/2”. To ensure
this, we recommend wrapping a piece of tape
around your drill bit 1/2” from the tip. Stop drill-
ing just before the tape touches the desktop.
Step 4
- Align the Frame assembly with the table top.
Place your table top on a carpet or blanket with the
bottom side facing up. Set the frame assembly onto
the table top and move the legs right up to the edges
of the table top.
Next, slide the Crossbar ends towards the center of
the table top until the the slot in the Crossbar end is
aligned with rst pre-drilled hole or threaded insert it
reaches (there may be more than one per side).
- Note where you will need to attach the Frame.
The arrows in Fig. A show the attachment locations for
42” to 72” wide table tops (three screws in each O-leg
and one screw in each Crossbar end).
The arrows in Fig. B show the attachment locations for
80” wide UPLIFT Desk table tops (one screw in each
Spacer bracket, one screw in each Crossbar receiver,
and one screw in each Crossbar end).
Fig. A. 42-72’’ wide table tops
Fig. B. 80’’ wide table tops
Step 5
- Determine which type of screw to use.
If your table top does not have metal threaded inserts,
use the #10x3/4’’ Wood Screws (H3a).
If your pre-drilled table top does have metal threaded
inserts, use the #10-24x3/4’’ Machine Screws (H3b).
Make sure all of the frame holes are aligned with the table
top holes and install eight of the screws selected (H3a or
H3b) and eight Washers (H4).
Make sure all screws are started before tightening
completely. Be careful not to over-tighten to avoid
stripping.
If applicable, at this point you can now tighten the
screws in the Spacer brackets from Step 1 using the
4mm Allen wrench (H7).
or
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
H4
H3 b
H3 a
1/2’’

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [e-mail] • upliftdesk.com 6
Step 7
If you have purchased casters for your table, install
them now. Unscrew the pre-installed leveling glides
from the legs and screw in the casters in their place.
With a person at each end of the assembled table,
grab the table top with one hand and the O-leg as-
sembly with the other hand as shown.
Support both the frame and the table top equally, and
gently rotate the table 90 degrees onto its side.
Readjust your grip and rotate another 90 degrees,
so that your table is right-side up. Adjust the leveling
studs or casters as needed to make the table level on
your oor.
Step 8
Position your table where you’d like it to be.
If you installed casters: Moving is easy! Make sure the
casters are unlocked and roll it to the desired location.
If you did not install casters: Using two people, lift
your desk (do not drag it) by holding onto the part of
the Leg assembly that is secured to the desktop.
Note: Never lift by holding on to the Desktop itself, as
this will put undue stress on the screws.
Step 6
Insert four of the M8x8 Set screws (H5) into the four
holes in each of the Crossbar receivers and tighten us-
ing the 4mm Allen wrench (H7).
Slide each Crossbar rail (C4) until the Center indicator
mark is centered between the two Crossbar ends. Then
insert four M8x8 Set screws (H5) into the holes in each
Crossbar end and tighten using the Allen wrench.

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Notes

512-614-3152
800-349-3839
[email protected]
upliftdesk.com
Work Better. Live Healthier
Copyright Notice: This guide is a component of the UPLIFT Desk™. This guide is a part of the scope of delivery, even if the item is resold. This guide
is also available on the UPLIFT Desk website: upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in any other published
form without the prior written consent of UPLIFT Desk. These instructions are subject to United States copyright law.
©
90.014.01.1109v.A - AI-FRM405-1.0
SAVE THESE INSTRUCTIONS
Study this manual carefully. If this desk is sold, please provide this
manual to the buyer, installers, or support personnel operating the product.
®
