VAS XL50-2MC User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
VAS Furniture Mfg. Inc. Factory No. 56-12089 Page 1
50”3-in-1 TV Console
This item is designed to be 3-in-1 configuration. Please choose which of the 3 options suits
your needs. For ease of assembly, we prepared the Assembly Instructions separately for
each option. Use only the instructions that correspond to the option you choose.
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional
videos for assembling and installing your product. Enter the following
product number on the ShowUhow homepage.
MODEL # XL50-2MC
LOT NUMBER:
DATE OF PURCHASE: / /
Option 1
With Swinging Floater
XL50-2MC

Model # XL50-2MC
Please call for replacement parts or assistance: 1-866-942-5362
VAS Furniture Mfg. Inc. Factory No. 56-12089 Page 2
Parts and Hardware Master List
Please read completely through the instructions and verify that all parts listed are
present before beginning assembly.
A- Top Shelf Frame (1) B- Middle Shelf Frame (1)
C- Bottom Shelf Frame (1) D- Long Spine (1) D1- Short Spine (1)
E- Left Leg (1) F- Right Leg (1) G- Top Glass (1)
H- Glass Shelf (2) I- Front Left Support (1) J- Front Right Support (1)
K- Back Left Support (1) L- Back Right Support (1) M- Swiveling Bracket (1)
N- XYZ Mounting Frame (1) O- Monitor Bracket (2) P- Safety Bar (1)

Model # XL50-2MC
Please call for replacement parts or assistance: 1-866-942-5362
VAS Furniture Mfg. Inc. Factory No. 56-12089 Page 3
Parts and Hardware Master List
Please read completely through the instructions and verify that all parts listed are present
before beginning assembly.
(1)- Suction Cup (12+1 extra) (2) - 3/4” Bolt (40+2 extra) (3) - 1 1/4” Bolt (6+1 extra)
(4)- Nut (5) - Lock Washer (6) - Flat Washer (7) - 2 1/2” Lag Bolt
(4+1 extra) (46+2 extra) (50+2 extra) (6pcs)
(8)- Large Flat Washer (9) - 1 3/4” Concrete Anchor (10) - Glass Raiser
(6pcs) (6pcs) (8+1 extra)
Open Wrench Allen Wrench Touch-Up Pen Tipping Restraint Hardware Kit (1)
(1) (2) (1) (Inside Plastic Bag)
TV Mounting Kit
M4 x 12 Bolt (4) M4 x 30 Bolt (4) M5 X 12 Bolt (4) M5 x 30 Bolt (4)
M6 x12 Bolt (4) M6 x 35 Bolt (4) M8x16 Bolt (4) M8 x40 Bolt (4)
M4 Lock Washer (4) M5 Lock Washer (4) M6 Lock Washer (4) M8 Lock Washer (4)
Large Spacer (4) Small Spacer (4) M4/M5 Flat Washer (8) M6/M8 Flat Washer (4)

Model # XL50-2MC
Please call for replacement parts or assistance: 1-866-942-5362
VAS Furniture Mfg. Inc. Factory No. 56-12089 Page 4
This unit can be configured into three different options, so you can use with most of the TV
options that you will find currently in the market.
Please do not discard any of the hardware or parts that you will not use on your set option,
this will give you the opportunity to use this TV Console for different configurations in case
you decide to upgrade your TV set in the future.
Furniture Tipping Restraint
Young children may be injured by tipping furniture and the use of a tipping restraint is highly
recommended. This hardware, when properly installed, could provide protection against the
unexpected tipping of furniture due to improper use.
Warning: This product is only a deterrent and is not a substitute for proper adult
supervision.
Follow instruction printed on the plastic bag inside the hardware package of this unit. You
must install the hardware with the product in use.
Care and Maintenance
We use only top quality materials. To preserve the luster and beauty we recommend you
treat this furniture regularly with quality cleaning Oil.
Compare this furniture and you will find we offer one of the Best Values in the marketplace
today.
We hope you enjoy your purchase for many years.
