Vaxcel T0321 Instruction manual

Page 1/4
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
T0321
WARNING:
TOAVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
Fixture
Back Plate
Ball Nut (G)
Rubber Pad (H)
Features
1. Energy saving fixture.
2. Use the dim-to-bright illumination option where
you want some minimum illumination through out
the night, such as at your front entrance or garage
door. Use the dark-to-bright illumination option
where you do not need minimum brightness, such
as the backyard or back porch.
3. When in manual override mode, use wall switch
to keep the light ON till dawn.
Important to Know
1. Read all instructions carefully before installation and
operation.
2. If you are not familiar with state and local electrical codes,
it is recommended that you consult with a qualified
electrician.
3. Before installation, shut off power at the main fuse or
circuit breaker box. Be aware that simply turning off the
wall switch is not sufficient to prevent an electrical shock.
4. This fixture requires a 120 VAC, 60 Hz power source.
5. Do not attempt to take the lantern apart; there are no
serviceable parts inside.
6. To avoid sensor damage by lightning or electrical surge,
make sure the grounding wire is securely connected.
7. For general safety and to avoid any possible damage to
the sensor, be sure the power is switched "off" before
replacing the bulb.
Maximum Wattage: 11W Dimmable LED Bulb
Work Temperature: - 4°F~104°F
Hardware Package (included)：
Mounting Screw (B)
Green Grounding
Screw (E) Wire Nut (F)
Lock Nut (D)
Ball Nut (G) Rubber Pad (H)
Cross Bar(A) Headless Screw (C)
Green Grounding Screw (E)
Outlet Box
Wire Nut (F)
Headless Screw (C)
Cross Bar (A)
Mounting Screw (B)
Lock Nut (D)
House Grounding Wire
Fixture Grounding Wire Fixture Wire
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read and save these instructions.
161028

Page 2/4
Installation steps
1. Thread two headless screws through the cross bar, and then secure them with four lock nuts (two on each side of the
cross bar). Adjust the length of the headless screws if necessary.
Note: Make sure that the headless screws are lined up horizontally to make the fixture level.
2. Attach cross bar to outlet box using two mounting screws.
3. Pull out the source wires from the outlet box. Make wire connections using wire nuts as follows:
---Connect the hot wire (usually black insulation) from the fixture to the black wire from the power source.
---Connect the neutral wire (usually white insulation) from the fixture to the white wire from the power source.
---Attach the fixture grounding wire (usually green insulation or bare wire) to the cross bar with the green grounding
screw, and then connect it to the house grounding wire with the wire nut.
Carefully put all of the wires back into the outlet box.
4. Attach the fixture to the cross bar by inserting headless screws into holes on back plate, and then secure it with two
rubber pads and two ball nuts.
CAUTION:With silicone caulking compound, caulk completely around where the back plate meets with the
wall surface to prevent water from seeping into the outlet box.
Turn off the power at fuse or circuit box.
Turn on the power at fuse or circuit box.
Function and Operation
MODES OF OPERATION
Choose a mode by sliding the switch on the back of the sensor. when power is first applied, the light
will turn on immediately. Wait for 100 seconds to allow the sensor to warm up.
1. TEST MODE (daytime and nighttime operation)
● The light will turn to low-level brightness (0%~50% brightness). The light will turn to high-level brightness (100%
brightness) when motion is detected, and stay on as long as the motion is continuing. The light will revert to
low-level brightness about 5 seconds after motion is no longer detected.
2. 3H MODE (nighttime operation only)
● At dusk, the light will turn to high-level brightness (100% brightness). The light will turn to low-level brightness (0%
~50% brightness) automatically after 3 hours. The light will turn to high-level brightness (100% brightness) when
motion is detected, and stay on as long as the motion is continuing. When motion is no longer detected, the light
will remain on for the predetermined time you set (5~180 seconds), and then revert to low-level brightness you set.
● Light will turn off automatically at dawn, and return to 3 H mode at dusk.
3. 6H MODE (nighttime operation only)
● At dusk, the light will turn to high-level brightness (100% brightness). The light will turn to low-level brightness (0%
~50% brightness) automatically after 6 hours. The light will turn to high-level brightness (100% brightness) when
motion is detected, and stay on as long as the motion is continuing. When motion is no longer detected, the light
will remain on for the predetermined time you set (5~180 seconds), and then revert to low-level brightness you set
● Light will turn off automatically at dawn, and return to 6 H mode at dusk.
4. 0 MODE (nighttime operation only)
● The light will turn to low level brightness (0%~50% brightness) at dusk. The light will turn to high-level brightness
(100% brightness) when motion is detected, and stay on as long as the motion is continuing. When motion is no
longer detected, the light will remain on for the predetermined time you set (5~180 seconds), and then revert to
low level brightness you set.
● Light will turn off automatically at dawn, and return to 0 H mode at dusk.
5.Manual Override MODE (nighttime operation only; on at dusk,off at dawn)
● In 3, 6 or 0 mode, to shift to manual override mode, turn off the wall switch in 3 seconds and then turn it on again,
the light will turn to high-level brightness at dusk, and turn off automatically at dawn. To return to the previous
settings, turn off the wall switch in 3 seconds and then turn it on again. (See Fig.1)
● The lights will turn off automatically at dawn.
161028

Page 3/4
AUTO Mode Manual
Override
Mode
Manual Override Operation Diagram
Turn wall switch OFF-ON
in 3 Seconds
Turn wall switch OFF-ON
in 3 Seconds again
FIG.1
CUSTOMIZATION OPTIONS:
FIG.2
Shut-off Delay
The Shut-off delay is the length of time the light will stay at high-level brightness after motion has ceased to
be detected. This Shut-off delay can be set when operation is in 3, 6 or 0 Mode by using the “TIME” knob
located on the left side of the panel at the back of the sensor lens (See Fig.2) . To increase the
shut-off delay, turn the knob clockwise. To decrease shut off delay, turn the knob counterclockwise. The
delay may be adjusted from a minimum of 5 seconds to a maximum of 3 minutes. The light will stay on as
long as motion is detected continuously and will automatically turn to low-level brightness when no more
motion is detected after the delay time has passed.
Sensitivity of Motion Sensor
The sensitivity of the motion sensor can be adjusted by using the “Sens” knob located on the right side of the panel at
the back of sensor lens (See Fig.2). To increase sensitivity, turn the knob clockwise. To decrease sensitivity, turn the
knob counterclockwise. The sensitivity may be adjusted from a minimum of 5 feet to a maximum of 40 feet.
Troubleshooting
---The light does not come on at all:
1. Make sure the wall switch and circuit breaker are on.
2. Make sure the wiring is correct.
3. Make sure the bulb is not burned out.
4. Cover the sensor with your palm to verify that the ambient light level is not too high.
----In Test Mode, the light stays on full brightness after 5 seconds:
1. If during daytime, make sure the slide switch is at the TEST position.
2. Whether the motion is detected at all time.
On the back of the sensor
Time Low Level Sens
Test 3H 6H 0
NOTE:
1. The sensitivity of the motion sensor will increase as the
environmental temperature gets cooler. For best performance,
gently clean the lens with a soft cloth every 1 or 2 months to
assure maximum sensitivity.
2. For best performance, install fixture at least 6 feet above
the ground. At such a height, the fixture will provide a
detection distance of up to 40 feet at 77 degrees
Fahrenheit. (See Fig.3)
3.The sensor detects across a detection range of 180 degrees.
(See Fig.4)
4. The sensor will be more sensitive to motion across its
detection path than motion directly towards it. (See Fig.5)
5`
6`
10`
40`
Where you install your lantern is important:
Be sure the light is mounted straight on the wall;
otherwise, the detection distance may be limited.
Fig. 3 Fig. 4
180˚
5. To reduce possible nuisances, do not mount the fixture
near a heat source like an air conditioner, vent or furnace
exhaust, or in a direction facing any reflecting object or
other light source.
Motion
Least sensitive
Motion
Most sensitive
Sensor
Fig. 5
161028

Page 4/4
Spare Parts List:
Assembly Kit
Glass shade (1pc)
9738CS
5398MM (1 SET)
The following parts are available for re-order if damaged or missing.
Mounting Screw (B)
Green Grounding
Screw (E) Wire Nut (F)
Lock Nut (D)
Ball Nut (G) Rubber Pad (H)
Cross Bar(A) Headless Screw (C)
Ball Nut (G) Rubber Pad (H)
---In 3H or 6H Mode, the light is still on full brightness, even though it has been 3 hours or 6 hours
after dusk, respectively:
1. Make sure no motion could be picked up by the sensor.
2. Make sure that mode entry is not in manual override.
---After performing 3H or 6H Mode, the light stays on full brightness after 3 minutes:
1. Make sure there is no movement that could be picked up by the sensor.
2. Adjust the time knob counterclockwise to reduce the delay shut-off time.
----In 3H or 6H Mode, the light turns off completely, instead of low level brightness, after 3 minutes:
1. Make sure the bulb is not burned out.
2. make sure the low level is not at the 0% position.
-- The light blinks:
1. Make sure the light is not mounted near a barbecue, air conditioner or other heat source.
2. Adjust the sensitivity knob counterclockwise to avoid unnecessary triggering like a passing car or
reflecting objects.
5-YEAR LIMITED WARRANTY:
All products are warranted to be free of defects in material and workmanship for five (5) years from date of
purchase. This warranty is limited to the correction of any such defect, or the replacement of any such defective
item(s), provided that: (a) we are properly notified and consent to return of the item(s) in question:(b) the item (s)
is / are returned with proof of purchase date; and (c) it is found upon inspection by us that the item (s) is / are defective
as noted above. This warranty dose not cover labor costs, consequential damages, nor dose it apply to any item(s) that
have been improperly installed, overloaded, altered, or otherwise abused by the customer, its agent(s) or emplyee(s).
Finishes are specially excluded from the terms of this warranty since they are subject to environmental maintenance
deemed beyond our control. Other than the described obligation, we assume no further liability with respect to the sale
or use of our products.We make no warranty, express or implied, and disclaim any warranty of merchantability or fitness
for a particular purpose.
A: 5-1/2"
B: 10-1/4"
C: 6-1/4"
Assembly Kit
5400BB (1 SET)
AC
B
161028
