1About this document
1.1Function
This operating instructions manual has all the information you need for
quick mounting and setup of a replacement module.Please read this
manual before you start setup.
1.2Target group
This operating instructions manual is directed to trained qualified
personnel.The contents of this manual should be made available to
these personnel and put into practice by them.
1.3Symbolism used
Information,tip,note
This symbol indicates helpful additional information.
Caution:If this warning is ignored,faults or malfunctions can
result.
Warning:If this warning is ignored,injury to persons and/or serious
damage to the instrument can result.
Danger:If this warning is ignored,serious injury to persons and/or
destruction of the instrument can result.
Exapplications
This symbol indicates special instructions for Ex applications.
lList
The dot set in front indicates a list with no implied sequence.
àAction
This arrow indicates a single action.
1Sequence
Numbers set in front indicate successive steps in a procedure.
Electronics module •VEGACAP series 60 3
1About this document
30174-EN-120124

2For your safety
2.1Authorised personnel
All operations described in this operating instructions manual must be
carried out only by trained specialist personnel authorised by the plant
operator.
During work on and with the device the required personal protective
equipment must always be worn.
2.2Appropriate use
Electronics module CP60 is a replacement module for VEGACAP
series 60 level switches.
2.3Safety instructions for Ex areas
Please note the Ex-specific safety information for installation and
operation in Ex areas.These safety instructions are part of the
operating instructions manual and come with the Ex-approved
instruments.
2.4Environmental instructions
Protection of the environment is one of our most important duties.That
is why we have introduced an environment management system with
the goal of continuously improving company environmental protection.
The environment management system is certified according to DIN
EN ISO 14001.
Please help us fulfil this obligation by observing the environmental
instructions in this manual:
lChapter "Packaging,transport and storage"
lChapter "Disposal"
4Electronics module •VEGACAP series 60
2For your safety
30174-EN-120124

3Product description
3.1Structure
The scope of delivery encompasses:
lElectronics module for VEGACAP series 60 (CP60)
lDocumentation
-this operating instructions manual
3.2Principle of operation
The electronics module CP60 is suitable for replacement in VEGACAP
series 60 capacitive level switches.
3.3Packaging,transport and storage
Your instrument was protected by packaging during transport.Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
The packaging of standard instruments consists of environment-
friendly,recyclable cardboard.For special versions,PE foam or PE foil
is also used.Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out under consideration of the notes on the
transport packaging.Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt.Ascertained transit damage or
concealed defects must be appropriately dealt with.
Up to the time of installation,the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated,the packages must be stored only under
the following conditions:
lNot in the open
lDry and dust free
lNot exposed to corrosive media
lProtected against solar radiation
lAvoiding mechanical shock and vibration
lStorage and transport temperature see chapter "Supplement -
Technical data -Ambient conditions"
lRelative humidity 20 …85 %
Scope of delivery
Application area
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature
Electronics module •VEGACAP series 60 5
3Product description
30174-EN-120124

4Mounting
4.1Instructions for installation
If the electronics module is defective,it can be replaced by the user.
InExapplications only one instrument and one electronics module with
respective Ex approval may be used.
4.2Mounting preparations
In general,all electronics modules of series CP60 can be inter-
changed.If you want to use an electronics module with a different
signal output,you can download the corresponding operating
instructions manual from our homepage under Downloads.
4.3Mounting steps
To exchange the electronics module,proceed as follows:
1Switch offpower supply
2Unscrew the housing cover
3Lift the opening levers of the terminals with a screwdriver
4Pull the connection cables out of the terminals
5Loosen the two screws with a screw driver (Torx size T10 or slot 4)
2
1
Fig.1:Loosening the holding screws
1Electronics module
2Screws (2pcs.)
6Pull out the old electronics module
7Compare the new electronics module with the old one.The type
label of the electronics module must correspond to that of the old
electronics module.This applies particularly to instruments used in
hazardous areas.
Mounting steps
6Electronics module •VEGACAP series 60
4Mounting
30174-EN-120124

8Compare the settings of the two electronics modules.Set the
adjustment elements of the new electronics module to the same
setting of the old one.
Information:
Make sure that the housing is not rotated during the electronics
exchange.Otherwise the plug may be in a different position later.
9Insert the electronics module carefully.Make sure that the plug is
in the correct position.
10 Screw in the two holding screws and tighten them
11 Insert the wire ends into the open terminals according to the wiring
plan
12 Press down the opening levers of the terminals,you will hear the
terminal spring closing
13 Check the hold of the wires in the terminals by lightly pulling on
them
14 Check cable gland on tightness.The seal ring must completely
encircle the cable.
15 Mount the probe into the vessel.Make sure that the probe is
uncovered.
2
1
Fig.2:Compensation key
1Measuring range selection switch (compensation key)
2Control lamp
16 Push the measuring range selection switch (1)as long as the
control lamp (2)flashes green.
17 Hence the probe is compensated to the modified length.
18 Carry out the adjustment again.See chapter "Set-up,adjustment
elements".
19 Screw the housing cover back on
The electronics exchange is now finished.
As a rule,an exchange of electronics must be documented internally
when Ex applications are involved.
Electronics module •VEGACAP series 60 7
4Mounting
30174-EN-120124

5Setup
5.1Setup
Make sure that all adjustment elements are set to the settings of the
old electronics module.Hence the sensor is immediately ready for
operation.
In general,all oscillators of series CP60 can be interchanged.
If you want to use an electronics module with a different signal output,
you can download the corresponding operating instructions manual
from our homepage under Downloads.
Setup
8Electronics module •VEGACAP series 60
5Setup
30174-EN-120124

6Maintaining
6.1Instrument repair
If a repair is necessary,please proceed as follows:
You can download a return form (23 KB)from our homepage at www.
vega.com under:"Downloads -Forms and certificates -Repair form".
By doing this you help us carry out the repair quickly and without
having to call back for needed information.
lPrint and fill out one form per instrument
lClean the instrument and pack it damage-proof
lAttach the completed form and,if need be,also a safety data
sheet outside on the packaging
lPlease ask the agency serving you for the address of your return
shipment.You can find the respective agency on our website
www.vega.com under:"Company -VEGA worldwide"
Electronics module •VEGACAP series 60 9
6Maintaining
30174-EN-120124

7Dismounting
7.1Dismounting steps
Take note of chapters "Mounting"and "Connecting to power supply"
and carry out the listed steps in reverse order.
7.2Disposal
The replacement module consists of materials which can be recycled
by specialised recycling companies.We have purposely designed the
electronic modules to be easily separable.
WEEE directive 2002/96/EG
This instrument is not subject to the WEEE directive 2002/96/EG and
the respective national laws (in Germany e.g.ElektroG). Pass the
instrument directly on to a specialised recycling company and do not
use the municipal collecting points.These may be used only for
privately used products according to the WEEE directive.
Correct disposal avoids negative effects on humans and the environ-
ment and ensures recycling of useful raw materials.
Materials:see chapter "Technical data"
If you have no way to dispose of the replacement module properly,
please contact us concerning return and disposal.
10 Electronics module •VEGACAP series 60
7Dismounting
30174-EN-120124

8Supplement
8.1Technical data
Technical data
are stated in the operating instructions manual of the respective sensor.
Electronics module •VEGACAP series 60 11
8Supplement
30174-EN-120124
