Venjakob V-Plus 6.0 User manual

Assembly instruction for wall shelf V-Plus 6.0
Lenghth: 64 cm
Verpackungsinhalt
1 wall shelf 640 x 200 x 49mm
2 shelf bearing
4 plastic dowel 8mm
4 wood screw 5 x 50mm
Montage
1. Wall shelves are fitted by concealed shelf bearings.
2. Define the position of the shelf on the wall.
3. Mount the shelf bearings onto the wall. Please note that the closed side of the shelf
bearing must be up. The distance between the 2 shelf bearings should be
340 mm
(indicated dimensions are in relation to middle of shelf bearing!).
IMPORTANT: The provided fittings( screws and plastic dowels) are only for cement and/or
solid brickwork. If the consistency of the wall is different you must use suitable fittings that
can hold the load.
4. Push the wall shelf onto the shelf bearings. Straighten the wall shelf by use of water
level: Horizontal adjustment can be made by moving the baseplate and by using the
lower hight-adjusting screw (dip). Edgewise adjustment can be made by moving the
pin support. PLEASE NOTE: All hanging fittings must be equally loaded and adjusted.

Assembly instruction for wall shelf V-Plus 6.0
Lenghth: 132 cm
Verpackungsinhalt
1 wall shelf 1320 x 200 x 49mm
3 shelf bearing
6 plastic dowel 8mm
6 wood screw 5 x 50mm
Montage
1. Wall shelves are fitted by concealed shelf bearings.
2. Define the position of the shelf on the wall.
3. Mount the shelf bearings onto the wall. Please note that the closed side of the shelf
bearing must be up. The distance between the 3 shelf bearings should be
510 mm
(indicated dimensions are in relation to middle of shelf bearing!).
IMPORTANT: The provided fittings( screws and plastic dowels) are only for cement and/or
solid brickwork. If the consistency of the wall is different you must use suitable fittings that
can hold the load.
4. Push the wall shelf onto the shelf bearings. Straighten the wall shelf by use of water
level: Horizontal adjustment can be made by moving the baseplate and by using the
lower hight-adjusting screw (dip). Edgewise adjustment can be made by moving the
pin support. PLEASE NOTE: All hanging fittings must be equally loaded and adjusted.

Assembly instruction for wall shelf V-Plus 6.0
Lenghth: 200 cm
Verpackungsinhalt
1 wall shelf 2000 x 200 x 49mm
4 shelf bearing
8 plastic dowel 8mm
8 wood screw 5 x 50mm
Montage
1. Wall shelves are fitted by concealed shelf bearings.
2. Define the position of the shelf on the wall.
3. Mount the shelf bearings onto the wall. Please note that the closed side of the shelf
bearing must be up. The distance between the 4 shelf bearings should be
567 mm
(indicated dimensions are in relation to middle of shelf bearing!).
IMPORTANT: The provided fittings( screws and plastic dowels) are only for cement and/or
solid brickwork. If the consistency of the wall is different you must use suitable fittings that
can hold the load.
4. Push the wall shelf onto the shelf bearings. Straighten the wall shelf by use of water
level: Horizontal adjustment can be made by moving the baseplate and by using the
lower hight-adjusting screw (dip). Edgewise adjustment can be made by moving the
pin support. PLEASE NOTE: All hanging fittings must be equally loaded and adjusted.
