Vertiv Geist BR Series Installation and maintenance instructions

Geist™
Basic Rack PDU
Installer/User Guide

Vertiv™ | Basic Rack PDU Installer/User Guide
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent
section of this manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.VertivCo.com/en-us/support/ for additional assistance.
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution
has been taken to ensure the accuracy and completeness of this document,
Vertiv assumes no responsibility and disclaims all liability for damages
resulting from use of this information or for any errors or omissions. Refer to
other local practices or building codes as applicable for the correct methods,
tools, and materials to be used in performing procedures not specifically
described in this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use
or disclosure of it without the written permission of Vertiv is strictly
prohibited.
Names of companies and products are trademarks or registered trademarks
of the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.

TABLE OF CONTENTS
1 Overview 1
1.1 Environmental 2
1.1.1 Electrical 2
1.1.2 Regulatory Compliance 3
2 Installation 5
2.1 Mounting 6
2.1.1 Optional surge suppression 16
2.1.2 Optional local metering 16
3 Appendices 19
Appendix A: Rack In-line Power Measurement Unit 19
Appendix B: Troubleshooting 21
i

Vertiv™ | Basic Rack PDU Installer/User Guide
ii
This page intentionally left blank

1 OVERVIEW
The following rack power distribution units (rPDUs) are covered in this document.
MODEL INPUT INPUT PLUG TYPE
AC MAIN
RATINGS
(CURRENT)
AC MAIN
RATINGS
(VOLTAGE)
OVERCURRENT
PROTECTION TYPE (IF
APPLICABLE)
BR
Single Phase NEMA Straight Blade, NEMA Twist Lock 15-20 AMPS 125V Single Pole Thermal
NSV
SP
SVR
VRT
VSS
BRE
Single Phase IEC C20 16-20 AMPS 125V, 250V Single Pole Thermal or
Hydraulic Magnetic
VRTE
J
Single
Phase/Three
Phase
NEMA Straight Blade, NEMA Twist Lock,
IEC, Hardwired 10-20 AMPS 100-120V None
MJ Single Phase NEMA Straight Blade, NEMA Twist Lock 15-20 AMPS 100-120V None
VHV
Single
Phase/Three
Phase
NEMA Straight Blade, NEMA Twist Lock,
IEC, IEC Splashproof, Hardwired,
Schuko, British
10-20 AMPS 120/208V WYE,
200V, 208-240V None
BRD Single Phase NEMA Twist Lock 30 AMPS 125V Single Pole Thermal
VRE Single Phase NEMA Twist Lock 30 AMPS 125V, 250V Single Pole Thermal
VRTD Single Phase NEMA Twist Lock 30 AMPS 125V Single Pole Thermal
XP
Single
Phase/Three
Phase
NEMA Straight Blade, NEMA Twist Lock,
IEC Splashproof 30 AMPS
100-120V,
120/208V WYE,
200V, 208-240V
Hydraulic Magnetic
Y Three Phase NEMA Twist Lock, IEC Pin & Sleeve,
Hardwired 16-32 AMPS 208-240/360- 415V WYE Hydraulic Magnetic
ZP
Single
Phase/Three
Phase
CS8365, IEC Pin & Sleeve, Hardwired 35-120 AMPS
100-120V,
120/208V WYE,
200V, 208-240V
Hydraulic Magnetic
Table 1.1 rPDU Model Series Descriptions
NOTE: Global Versions of the VHV Series are intended to be connected to a 16 Amp AC Main Branch
Circuit. Global Versions of the XP Series are intended to be connected to a 32 Amp AC Mains Branch
Circuit.
1

1.1 Environmental
The operational environmental limits pertaining to Temperature, Humidity and Elevation are as defined in
the following tables.
MODEL SERIES OPERATING
MINIMUM
OPERATING
MAXIMUM
STORAGE
MINIMUM
STORAGE
MAXIMUM
BR, BRE, J, L, NSV, SP, SVR, VHV, VRE, VRT, VRTE,
VSS, XP, Y, ZP 10°C (50°F) 45°C (113°F) -40°C (-40°F) 70°C (158°F)
BRD, MJ, VRTD 10°C (50°F) 25°C (77°F) -40°C (-40°F) 70°C (158°F)
Table 1.2 Temperature Limits
MINIMUM MAXIMUM
Operating 5% 95% (non-condensing)
Storage 5% 95% (non-condensing)
Table 1.3 Humidity Limits
MODEL SERIES OPERATING
MINIMUM
OPERATING
MAXIMUM
STORAGE
MINIMUM
STORAGE
MAXIMUM
BR, BRD, BRE, NSV, SP, SVR, VRE, VRT, VRTD,
VRTE, VSS 0 m (0 ft) 2,000 m (6561 ft) 0 m (0 ft) 15,240 m
(50,000 ft)
J, L, MJ, VHV, XP,Y, ZP
Table 1.4 Elevation Limits
1.1.1 Electrical
Electrical product characteristics and performance are defined in the following tables. Please see the
product nameplate for additional rating limits.
Vertiv™ | Basic Rack PDU Installer/User Guide
2

RECEPTACLE TYPE RATINGS
NEMA 5-15R or L5-15R 12A, 125VAC
NEMA 5-20R or L5-20R 16A, 125VAC
NEMA 6-20R or L6-20R 16A, 250 VAC
NEMA L6-30R 24A, 250VAC
NEMA L15-20R 3-phase, 16A @ 250VAC
NEMA L15-30R 3-phase, 24A @ 250VAC
IEC-60320 C13 10A, 250VAC (UL & CSA 12A, 250VAC)
IEC-60320 C19 16A, 250VAC (UL & CSA 16A, 250VAC)
Table 1.5 Receptacle Ratings
1.1.2 Regulatory Compliance
Vertiv products are regulated for Safety, Emissions, and Environment Impact per the below agencies and
policies.
Underwriter Labratory (UL)
UL Standards are used to assess products; test components, materials, systems and performance; and
evaluate environmentally sustainable products, renewable energies, food and water products, recycling
systems and other innovative technologies.
The UL standards specific to this equipment (if applicable) are as noted on the device nameplate.
Federal Communications Commission (FCC)
The Federal Communications Commission (FCC) regulates interstate and international communications
by radio, television, wire, satellite, and cable in all 50 states, the District of Columbia and U.S. territories. An
independent U.S. government agency overseen by Congress, the commission is the United States'
primary authority for communications laws, regulation and technological innovation.
The FCC standards specific to this equipment are:
This Class A device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
WARNING! Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
1 Overview 3

ROHS/WEEE
RoHS, also known as Lead-Free, stands for Restriction of Hazardous Substances. RoHS, also known as
Directive 2002/95/EC, originated in the European Union and restricts the use of six hazardous materials
found in electrical and electronic products. All applicable products in the EU market after July 1, 2006
must pass RoHS compliance. RoHS impacts the entire electronics industry and many electrical products
as well.
WEEE stands for Waste from Electrical and Electronic Equipment. WEEE Directive 2002/96/EC mandates
the treatment, recovery and recycling of electric and electronic equipment (90% ends up in landfills). All
applicable products in the EU market must pass WEEE compliance and carry the Wheelie Bin sticker.
See product label for RoHS/WEEE compliance marks.
Vertiv™ | Basic Rack PDU Installer/User Guide
4

2 INSTALLATION
Use the following images in the mounting section to install your rack PDU.
NOTE: Please visit http://www.VertivCo.com/ComplianceRegulatoryInfo for important safety
information prior to installation.
To install your unit:
1. Using appropriate hardware, mount the unit to the rack.
2. Plug the rPDU into an appropriately-rated and protected branch-circuit receptacle.
3. Plug in the devices to be powered by the rPDU.
4. Turn on each device connected to the rPDU.
NOTE: It is recommended that all connected equipment is powered on in a sequential manner to avoid
high inrush current.
NOTE: XP Series rPDUs may optionally be configured as Isolated Ground units. All Isolated Ground
units will be shipped with an enclosure grounding cable. This cable must be connected between the
enclosure and a reliable safety ground.
5

2.1 Mounting
Optional mounting brackets are sold separately.
Figure 2.1 Full-length Bracket
Vertiv™ | Basic Rack PDU Installer/User Guide
6

Figure 2.2 Mini L Bracket
2 Installation 7

Figure 2.3 Vertical Extension Bracket
Vertiv™ | Basic Rack PDU Installer/User Guide
8

Figure 2.4 Tool-less Mounting Hardware
2 Installation 9

Figure 2.5 Tool-less Full-length Bracket
Vertiv™ | Basic Rack PDU Installer/User Guide
10

Figure 2.6 Single Side-mount Unit Brackets
2 Installation 11

Figure 2.7 Offset Side-mount Brackets
Figure 2.8 7" Extension Brackets (XB-7)
Vertiv™ | Basic Rack PDU Installer/User Guide
12

Figure 2.9 Flush Mount Brackets (FM)
Figure 2.10 Adjustable Mount Brackets (AM)
2 Installation 13

Figure 2.11 Panel Mount Brackets (PM)
Figure 2.12 23" Conversion Mounting Brackets (23-RM)
Vertiv™ | Basic Rack PDU Installer/User Guide
14

Figure 2.13 19" Horizontal/Panel Mount Brackets (7938)
Figure 2.14 Top and Bottom Mounting Clips (9083C & 9084C)
2 Installation 15

NOTE: Mounting clips are only intended for use with NSV and VSS Series rPDUs. Using the top and
bottom mounting clips, attach the rPDU to the rack as shown.
2.1.1 Optional surge suppression
The SP, SVR, and VSS Series rPDUs include a surge suppression circuit that is designed to prevent
voltage surges on the input power line from reaching devices powered by the rPDU. The surge
suppression circuit uses Metal Oxide Varistors (MOVs) connected between line, neutral, and ground wires
to prevent voltage surges from damaging connected devices.
Figure 2.15 Surge Suppression LEDs
NUMBER DESCRIPTION
Protection Modes Line-Line, Line-Neutral, Neutral-Ground
Maximum Clamping Voltage 340V
Energy Absorption 720 Joules
Green Light Indicator Power On
Red Light Indicator Surge Protection Active
Table 2.1 Surge Protection Ciruit Rating
2.1.2 Optional local metering
Power meter
The Geist PM-1 power meter is a low-power, high accuracy meter capable of measuring true RMS Current,
Voltage, Power, and Power Factor. These values are individually shown on a 4-digit LED Display, which
continuously scrolls through the four different measured values. Each one of these displayed parameters
is defined below. The power meter automatically cycles through the displayed values when the rPDU is
connected to AC Mains power.
