VEVOR JS-75-GD-01 User manual

01
VEVOR
JS-75-GD-01
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
[e-mail]
This is the original instruction. Please read all manual instructions carefully before operating
VEVOR reserves clear interpretation of our user manual. The appearance of the product shall be subject to
the product you received. Please forgive us that we won't inform you again if there are any technology or
software updates on our product
BUTTON MAKER
INSTRUCTION
MACHINE
MANUAL

SAFETY REMINDER
02
1. This badge machine is only applied for the intended purpose. Don't apply in other applications which
exceed safety considerations.
2. Children cannot operate this product unless accompanied by an adult.
3.Pay attention to safety during operation, and avoid crushing fingers.
COMPONENTS
Connector,
Flexible Core
Down Mold (Left)
Revolve Plate

03
1. Tin Up Cover
2.Plastic Back Plate
3.White Paper
(The paper thickness needs to
be in the range of 127g-159g,
and the paper diameter should
be the same as the transparent
film diameter)
4. Transparent Film
5.Metal Back Plate
6 Plastic
(Only
back
Washer
required when
plate.)
metal
using
.

04
MANUFACTURE PROCESS
1.Revolve and twist handle in
2.Put "Tin up cover"--"Paper"
(pattern levelly placed)--
“Transparent plastic film”into
the right mold in sequence, then
anticlockwise revolve the down
mold to bottom till the up and
down mold aligned
3. Use one hand to hold the
machine body first then stable the
machine body by the handle
another hand press the machine
handle till down press to be
bottom. (Special attention: this
time down pressed up mold hinge
is in a separate state.)
4. Put the plastic back plate into the
eft mold (Attention: The pin should
be level without protruding. The
upside words upward placed
according to the mold side triangle
indication mark), rotate the down
mold clockwise to the bottom until
the up and down mold aligned
5.Hand holds the machine
body, right hand down press the
handle until up and down mold
merged to bottom, now the
upper mold hinge is in merged
state, and the pin passes
through the hole.
6.Manufacture finished
Special Attention: If use the metal
back plate, the left mold groove
needs to place the plastic washer

05
FAILURE AND TROUBLESHOOTING
Failure Appearance
Possible Reasons
Troubleshooting
First time downward press iron cover
and not absorbed to up mold
1. Unsuitable operating method
2. Too much lubricating oil in the
up mold
1.First time downward press up mold
hinge is in a separate state
2. Use clean cloth or tissue completely
wipe it if found too much lubricating
oil on the up mold
3. The up and down mold must be on
the same vertical line when closing
Second downward press part
not wrapped in
1. Unsuitable operating method
2.High mold friction force
3. Unsuitable paper thickness
4. Up mold screws loosen
1.The up and down mold must be on
the same vertical line when closing
2. Evenly coat lubricating oil in the up
and down mold internal holes
3. Use the stipulated thickness paper
4. Place the up mold on the machine
body, use the complimentary Allen
key to fix the screws in the up mold
internal hole center.
Not tightly press the badge,
pressed in but not firm
1. The downward press is not in place,
not press to the bottom
2. Paper is thinner
3. (75mm) Configured metal back
consumables must place the washer
1. Need press to the bottom when
downward pressing
2. Change to use a slightly thicker
paper
3.Right side mold place 2mm
thickness washer when using
the metal back consumables
Noise during pressing manufacture
High friction force between molds
Evenly coat lubricating oil in the up
and down mold internal holes
Up mold unable to lift up after
pressing manufacture, blocked
1. Up and down mold position deviated
2. The paper is incorrectly cut round or
blocked by a foreign object.
Use a sharp tool (such as a straight
screwdriver) to align to middle merge
position clearance which is between
up and down mold, and pry open with
the object like a hammer (Attention:
Just tap it, generally, it will not be too
tightened)

06
MODEL AND PARAMETER
Product Mode
Model
JS-75-GD-01
Manufactured Badge
Specification
φ75
Machine Body Color
Gold
Paper Requirements
127-157g
Copper Plate Paper
Accessories With
Machine
1. φ75 Iron Bottom Back Plate *50 Pieces
2. φ75 Plastic Bottom Back Plate* 50 Pieces
3. φ75 Tin Up Cover *100 Pieces
4. φ75 Blank Round Paper* 50 Pieces
5. φ75 Transparent Film*100 Pieces
6. φ75 Round Cutter*1 Piece
7.Allen Key* 2 Pieces
8.Magic Book *1 Set
9.Washer * 2 Pieces
10.Instruction *1 Set
