VEVOR NP08001SEC User manual

POPCORN MACHINE
INSTRUCTION MANUAL

01
POPCORN MACHINE
NP08001SEC&NP08001SE
&NP16T
NEED HELP? CONTACTUS!
Have product questions? Need technical suppo? Please feel free to contact us:
CustomerSe[email protected]
This is the original manual, please read all the instructions carefully before operating.
VEVOR resees the right to interpret this user manual. The appearance of the product shall be subject to the
product you received. Product technology or fuher software updates are subject to change without notice.
MODEL NO.: NP08001SE
MODEL NO.: NP16T
MODEL NO.: NP08001SEC

02
IMPORTANT SAFEGUARDS
1.Please read ALL the instructions before using your popcorn machine.
2.Do not touch the hot suace directly with your hands. Always operate with handles or knobs.
3.To prevent electrical shock, do not immerse the cord or plug into water or other liquids.
4.Do not let children and minors get close to or touch the machine.
5.When the machine is not in use or before cleaning, unplug the main power cord from the outlet.
6.Allow HOT pas to cool down before operation.
7.Do not operate the device with damaged cord or plug, malfunction or with any mechanical damage. Send the device
to your nearest authorized seice centre for examination and repair (ONLY technicians should open up the unit).
8.Using any accessories or attachments that are not provided or recommended
by the manufacturer may cause inju.
9.Do not use this machine outdoors.
10.Do not pop the kernel with a d pot (without oil).
11.Do not immerse the popping pot set into water.
12.Since the pot suace is hot during popping or just after use, do not
touch it directly with your hands.
13.If the machine will not used for a long time, unplug, clean and cover the
unit and store it in a d and safe place.
14.Do not leave the power cord hanging over the edge of table or counter
or allow it come into contact with any hot suaces.
15.Do not place the unit on or near a hot gas, electric burner, or a heated oven.
16.Extreme care must be taken if moving the unit when it contains hot oil or other hot liquids.
17.Turn ALL the switches to 'OFF' position before disconnecting the power plug from the wall
supply outlet.
18.Do not apply this unit to any other purposes than the indicated usage.
19.To avoid overheating, always add oil before putting the kernels in.
20.Extreme care must be taken when unloading popcorn.
21.Always place the unit on the table so that so that it will not cause burns when the remaining hot
oil or water owing out.
21. KEEP OUT OF REACH OF CHILDREN.
22. DO NOT CLEAN USING ANY ABRASIVE MATERIAL.
23. NEVER FORCE ANY PARTS OR BRACKETS INTO POSITION.
24. NO PARTS ARE INTENDED FOR THE DISHWASHER.
25. A popper that is plugged into ar outlet should not be left unattended.
26. This popper will not shut o automatically To avoid overheating, add corn and oil before
operating.
27. Extreme caution must be used when ulnloading popcorn. Always turn the unit over a
counter-topso that residual hot oil or water running out will not cause burns.

03
IMPORTANT SAFEGUARDS
Model No.
NP08001SE
NP08001SEC
NP16T
AC120V~ 60Hz
AC120V~ 60Hz
AC120V~ 60Hz
Voltage Input Power
850W NO
NO
YES
850W
1440W
Ca
PRODUCT PARAMETERS
Sho Cord Instruction
A sho power-supply cord is to be provided to reduce the risk resulting from becoming entangled
in or tripping over a longer cord.
Extension cords are available and maybe used if care is exercised in their use. If a extension cord is
used:
1.The marked electrical rating of extension cord should be at least as great as the electrical rating
of the appliance;
2.the extension cord should be a grounding3-wire cord; and
3.The longer cord should be arranged so that it does not drape over the counteop or table top
where it can be pulled on by children or tripped over unintentionally.
SAVE THESE INSTRUCTIONS FOR NP08001SEC
1.The model NP08001SEC for commercial use.
2.CAUTION-Risk of electric shock. Replace only with Type A lamp.
3.ATTENTION-Risque d'electrocution.Rempllacez uniquement avec une lampe de type A. Rated
120V,60Hz,E26,Max.150W
Thank you using this product. In order to make sure that you can operate the machine properly,
please read this instruction carefully before operation and keep it for future reference. Please be
sure to read the precautions and safety rules in this page to ensure your safe use.

NP08001SE & NP08001SEC：
NP16T：
04
ELECTRICAL SCHEMATIC DIAGRAM

05
PARTS
For Tabletop Models Only:
A: Main Unit x 1 pc B: Kettle x 1 pc
C: Popcorn Scoop x 1 pc D: Kernel Scoop + Oil Scoop Set x 1 pc
Assemble the kettle (B) on the suppoers which are built into the main unit (A), and then connect the socket.

06
For Ca Models Only:
Rubber Feet (A) x 2 pcs
SuppoLegs (B) x 2
pcs
Suppo Stands (C) x 2
pcs
Wheels (D) x 2 pcs
Horizontal SupposBase (E)
x2 pcs
Horizontal Suppos
with Screws(F) x 2 pcs
Cabinet Base (G) x 1 pc Cabinet Front with Door
(H) x 1 pc
Cabinet Back (I) x 1 pc Working Platform (J) x 1 pc Working Platform
Brackets (Large) (K) x 2
pcs
Push Handle (L) x 1 pc

07
HEADWEAR
Screwdriver (1 pc) and Wrench (2 pcs) are also included.
Wheel Bolt M8x (O) x 2 pcs Nyloc Nut M8 (P) x 2
pcs
Nut M8 (Q) x 12 pcs Washer (R) x 18pcs
Bolt M8x60(S) x 4 pcs Bolt M8x35 (T) x 2 pcs Bolt M8x16 (U) x 8
pcs
ScrewM4x8 (V) x 8 pcs

08
EXPLODED VIEW OF THE CART

09
POPCORN CART ASSEMBLY
STEP 1:
Screw one of the RUBBER FEET (A) into the bottom of each SUPPORT LEG (B).
Tighten both rubber feet.
STEP 2:
Inse one WHEEL BOLT (O) into the bottom holes located on each
side of the SUPPORT STAND (C).
NOTE: Inse the bolt from the inside out, then secure the wheel
bolts with one NUT (Q) on each side and tighten them with the
wrench.
STEP 3:
Hang one WHEEL (D) onto one WHEEL BOLT (O) and secure it
with one NYLOC NUT (P). Tighten them with the wrench. Then,
repeat this step for the other wheel.
NOTE: Do not over tighten. Make sure both wheels can spin freely.

POPCORN CART ASSEMBLY
STEP 4:
Attach both HORIZONTAL SUPPORTS-BASE (E) to the same
SUPPORT STAND (C) with two BOLTS (T) and one WASHER (R)
each. Tighten them with the wrench.
STEP 5:
Inse two BOLTS (U), each with one WASHER(R),into each
SUPPORTLEG(B).Attach SUPPORT LEG (B) to the SUPPORT
STAND(C) on the opposite side of the wheels. Tighten with wrench.
STEP 6:
Inse both HORIZONTAL SUPPORTS-WITH SCREWS (F) into the
grooves at the ends of each SUPPORT STAND (C) ,as shown.
STEP 7:
Inse the CABINET BASE (G).
NOTE: Place the lipped side facing down and line the cabinet base
up between the SUPPORT STANDS (C).
10

11
STEP 8:
Conrm the CABINET BASE (G) is locked in place. Secure the
SUPPORT STANDS (C) with the SCREWS (V) as shown in the gure
below. Tighten the screws with the screwdriver.
STEP 9:
NOTE: Before assembling the front and back panels, determine which
side you want the cabinet door facing outward.
Inse the CABINET FRONT (H) and CABINET BACK (I). Secure both
panels to the SUPPORT STANDS (C) with SCREWS (V) as shown in
the gure. Tighten the screws with the screwdriver.
POPCORN CART ASSEMBLY

12
POPCORN CART ASSEMBLY
STEP 10:
Remove the pre-assembled screws from the PUSH HANDLE (L).
Attach one of the WORKING PLATFORM BRACKETS (K) to one end of
the handle.
Inse the WORKING PLATFORM (J) to the same bracket using the
pre-installed posts. Inse the screw and tighten them.
Repeat the steps above to attach the remaining bracket on the other
side.
STEP 11:
Remove the pre-assembled screws from the HANDRAIL (N). Attach
one of the HANDRAIL BRACKETS (M) to one end of the handle. Inse
the screw and tighten them.
Repeat the steps above to attach the remaining bracket on the other
side.

POPCORN CART ASSEMBLY
13
STEP 12:
Install the assembled WORKING PLATFORM on the right side of the
ca (same side as wheels) with four BOLTS (U), WASHERS(R) and
NUTS (Q).
STEP 13:
Install the assembled HANDLE on the left side of the ca (opposite
the wheels) with four BOLTS (U), WASHERS (R) and NUTS (Q).

14
USING YOUR POPCORN MACHINE
1.Make sure the popcorn maker is unplugged before you do any of the following.
2.Before operation, please check carefully if its voltage is suitable to your count. (Please check if the voltage is
matching with rating label specied next to the power cord).
3.Clean the internal suace of the kettle and the external suace of the main unit.
4.The main unit has 3 function switches as follows:
5.Hook up the kettle onto the hanger of the main unit.
6.Plug in the power cord to the popcorn maker.
7.Switch on the light and heater (I & III), and then ll in suitable amount of butter or oil (Shown as Fig. 1). You
can ll the amount of oil (Max. 15g) subject to your own preference.
8.The kettle should be pre-heated for 3 to 4 minutes with oil (until steam comes out from it). Please prepare
kernels with sugar. You can measure the amount of kernels with the measuring scoop provided and amount of
sugar subject to your own preference. Liquid sugar and honey are prohibited.
9.Open the lid and then pour in pre-mixed kernel and sugar (Shown as Fig. 2). Caution: The lid might be hot and
it is recommended to use an oven mitten.
10.Switch on the Stirrer (II) to let it sta stirring (Shown as Fig. 3).
11.Close the door carefully.
12.Popcorn stas popping out through the lid after about 2 minutes (Shown as Fig. 4).
13.Switch o the stirrer & heater (II & III) when popping completed (no more popping sound from kettle). Rotate
the roller bar of the kettle and pour out all remaining popcorn from kettle.
14.Keep heater switch (III) o if the unit is not continuously running. Keep the spot light and warmer on to keep
the popcorn warm, d and tasty.
15.See your popcorn with popcorn scoop provided.
16.Remove plug from power supply if the unit is not being used for a long time.
17.Repeat steps 7 to 10 for continuous popping.
Spot Light and Warmer (I)
Stirrer (II)
Stainless Steel Kettle Heater (III)
Fig.1 Fig.2 Fig.3 Fig.4

15
CLEANING AND MAINTENANCE
1.Wipe the doors, glass and metal suace with a clean damp cloth. DO NOT use any acidic, citrus based cleaners
or abrasive cleaners on the aclic doors as they might cause scratching or dullness.
2.Frequently empty the catch tray of unpopped popcorn kernels and clean it with soap and water. D it
thoroughly afterwards.
3.Frequent cleaning of the popcorn kettle is strongly recommended. This will help prevent burning of excess oils
on the bottom of the kettle.
4.Let the unit cool down before cleaning.
5.Clean the kettle suace inside and out with wet cloth.
To thoroughly clean the popcorn kettle, turn o the unit and add 1-1/2 to 2 cups of hot water into the kettle (no
detergent is necessa), then place a towel at the bottom of the main unit and place a large bowl or container on
the towel (the container must be large enough to easily pour water from the popcorn kettle). Turn on the Stirrer
& Heater (2) and boil the water for 1 to 2 minutes. After that, turn o the stirrer and heater and carefully pour
the water from the popcorn kettle to the bowl or container. Repeat same procedure 2 to 3 times for the best
cleaning eect.
CAUTION:
1.Kettle and water will be HOT!
2.Never immerse the kettle into water or place it in the dishwasher.
Manufacturer: FOSHAN EDEN ELECTRICAL CO, LTD.
Address: No .4 West Street, Panxie Vilage, Zhongbian, Dali Town, Nanhai District, Foshan City, Guangdong
Province, China

E-mail: CustomerSe[e-mail]
