Viavi SmartClass OLT-85 User manual

OLT-85/OLT-85P
SmartClass™ Fiber
Optical Loss Test Meter
Operating manual
BN 2325/98.21
2019.12
English

Please direct all inquiries to your local Viavi sales company. The
addresses can be found at:
www.viavisolutions.com/en-us/contact-sales-expert
A description of additional instrument features can be found at:
www.viavisolutions.com/en-us/products/network-test-and-certification
Notice
Every effort was made to ensure that the information in this document
was accurate at the time of printing. However, information is subject to
change without notice, and Viavi reserves the right to provide an
addendum to this document with information not available at the time
that this document was created.
General Public License
This product includes Qt 4.8.3 software licensed under the GNU LGPL
v. 2.1, and barebox 2012.02.0 and linux 3.1.0-rc8 software licensed under
the GNU GPL v. 3. To request a copy of the source code for this software,
please write to:
Open Source Request • Viavi Legal Department •
430 N. McCarthy Blvd. • Milpitas, CA 95035 USA
Copyright
© Copyright 2019 Viavi Solutions Inc. All rights reserved. Viavi and the
Viavi logo are trademarks of Viavi Solutions Inc.
All other trademarks and registered trademarks are the properties of
their respective owners.
Viavi Solutions Deutschland GmbH
Arbachtalstraße 5, D-72800 Eningen u. A.
Order no.: BN 2325/98.21
Version: 2019.12
Previous version: 2019.06
Notes:
Changes may be made to specifications, descriptions, and delivery
information.

OLT-85/OLT-85P 3
CONTENTS
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
OLT-85/OLT-85P Loss Test Set . . . . . . . . . . . . . . . . . . . . . . . . 6
Loss test sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating manual update. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Symbols used in this operating manual . . . . . . . . . . . . . . . . 7
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warning symbols on the unit . . . . . . . . . . . . . . . . . . . . . . . . . 9
Proper usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Battery operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PS4 Universal AC/DC Power Supply . . . . . . . . . . . . . . . . . . 11
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Unpacking the instrument. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting optical cables . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Switching the instrument on/off . . . . . . . . . . . . . . . . . . . . . 23
Operator control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Menus and display elements . . . . . . . . . . . . . . . . . . . . . . . . 24
Navigating in the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Displaying application information . . . . . . . . . . . . . . . . . . . 27
Changing System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 28
WiFi menu (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Bluetooth menu (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Installing a software option . . . . . . . . . . . . . . . . . . . . . . . . . 32
Updating the firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Creating screenshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
MANAGING PROJECTS . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Creating a new project. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Editing a project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Deleting a project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Activating a project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
LOSS TEST OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . 38
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Selecting a port and wavelength . . . . . . . . . . . . . . . . . . . . . 39
Selecting the measurement mode. . . . . . . . . . . . . . . . . . . . 39
Referencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4 OLT-85/OLT-85P
CONTENTS
Pass/Fail indication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Switching on/off the laser. . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Performing the measurement . . . . . . . . . . . . . . . . . . . . . . . 41
Viewing test results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Saving Loss test results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
POWERMETER OPERATION . . . . . . . . . . . . . . . . . . . . . . . 44
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting and selecting wavelengths . . . . . . . . . . . . . . . . . . . 44
Selecting and changing the power display mode . . . . . . 48
Displaying relative power level . . . . . . . . . . . . . . . . . . . . . . 48
Saving Powermeter test results . . . . . . . . . . . . . . . . . . . . . . 49
SOURCE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Selecting an output port and wavelength . . . . . . . . . . . . . 53
About Auto- mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Selecting a modulation or Auto- mode . . . . . . . . . . . . . . 54
Setting the power level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Switching on/off the laser. . . . . . . . . . . . . . . . . . . . . . . . . . . 56
MEASURING LOSS WITH SOURCE/POWERMETER . . . . . . . . 57
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Performing the measurement . . . . . . . . . . . . . . . . . . . . . . . 57
Viewing test results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Saving Loss test results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
PROBE/PCM OPERATION . . . . . . . . . . . . . . . . . . . . . . . . 61
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Patch Cord Microscope (PCM) . . . . . . . . . . . . . . . . . . . . . . . 61
FMAE series adapters for the PCM . . . . . . . . . . . . . . . . . . . 62
Features available with the P5000i Digital Probe . . . . . . . 62
QuickCapture™ key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
File toolbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Configuring the Digital Probe . . . . . . . . . . . . . . . . . . . . . . . 65
Saving Probe/PCM results . . . . . . . . . . . . . . . . . . . . . . . . . . 69
DATA MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Saving results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Data management of Loss and Powermeter tests . . . . . . 71
Data management of Probe and PCM tests . . . . . . . . . . . 74
Exporting results to USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Making a report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

OLT-85/OLT-85P 5
CONTENTS
Cleaning the test port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Cleaning the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
APPENDIX - REFERENCING METHODS . . . . . . . . . . . . . . . 79
Loopback and Remote Referencing. . . . . . . . . . . . . . . . . . . 79
REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
ENVIRONMENTAL COMPLIANCE . . . . . . . . . . . . . . . . . . . . 86
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Power meter specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Laser specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Loss Test specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . 92
OLT-85/OLT-85P stand alone units . . . . . . . . . . . . . . . . . . . 92
Included items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

6 OLT-85/OLT-85P
1 INTRODUCTION
OLT-85/OLT-85P LOSS TEST SET
1INTRODUCTION
OLT-85/OLT-85P Loss Test Set
The SmartClass™ Fiber OLT-85 (P) (optical loss test set) is a high-
performance, easy-to-use instrument with a two or four
wavelength light source combined with a power meter. It is a
universal instrument for singlemode and multimode fibers,
installation, maintenance, and troubleshooting.
Loss can be measured simultaneously at up to four wavelengths.
Quick referencing for all built-in wavelengths can be effected
independent of the current measurement mode. Just connect
the source and power meter with a fiber patch cord.
Loss test sets
A loss test set combines a power meter and a light source in the
same instrument. It is a highly accurate tool and is used to
determine the total amount of loss or attenuation of a fiber link.
With traditional light sources and power meters, the instruments
must either be transferred from one end of the link to the other
or a light source and a power meter are required at both ends of
the link. The technician requires a total of four instruments in
order to perform measurements in both directions. With a loss
test set at each end of the link, tests can be performed in both
directions using only two instruments and without the need to
transfer them from one end to the other.
Operating manual update
Continuing enhancement and further development of the
SmartClass family may mean that this operating manual does
not cover all the latest functions of your instrument.
If the operating instructions about features supported by your
instrument are missing, please visit the Viavi web site to check if
additional information is available.

OLT-85/OLT-85P 7
1 INTRODUCTION
SYMBOLS USED IN THIS OPERATING MANUAL
To download the latest user manual:
1. Visit the Viavi web site at http://updatemyunit.net.
2. Select your SmartClass™ Fiber model from the product line.
3. Open the download area and download the latest user
manual.
Symbols used in this operating manual
Various elements are used in this operating manual to draw
attention to special meanings or important points in the text.
Symbols and terms used in warnings
The following warnings, symbols, and terms are used in this
document in compliance with the American National Standard
ANSI Z535.6-2011:
NOTICE
Follow the instructions carefully to avoid damage to or
destruction of the instrument.
CAUTION
Follow the instructions carefully to avoid a low or medium risk
of injury to persons.
WARNING
Follow the instructions carefully to avoid severe injury to
persons.
DANGER
Follow the instructions carefully to avoid death or severe
injury to persons.
High voltage
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to high
voltage.
Laser
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to laser
radiation. Information specifying the laser class is also given.

8 OLT-85/OLT-85P
1 INTRODUCTION
SYMBOLS USED IN THIS OPERATING MANUAL
Warning format
All warnings have the following format:
The following elements are used in this operating manual:
WARNING
Type and source of danger
Consequences of ignoring the warning.
JAction needed to avoid danger.
IRequirement
This requirement must be met first; e.g.
IThe system is switched on.
J
1.
2.
Instruction
Follow the instructions given (the numbers indicate the order
in which the instructions should be followed); e.g.
JSelect mode.
Italics Result
Indicates the result of following an instruction; e.g.
The page opens.
Boldface Pages, controls, and display elements
Screen pages, controls, and display elements are indicated in
boldface.
Text in
blue
Cross references
Cross references are indicated in blue type. When using the
PDF version, just click on the blue text to skip to the cross
reference.
[G]Instrument keys
Instrument keys are indicated within square brackets.
[More]Touchscreen buttons
Touchscreen buttons are indicated within blue square brackets.

OLT-85/OLT-85P 9
2 SAFETY INFORMATION
WARNING SYMBOLS ON THE UNIT
2SAFETY INFORMATION
Warning symbols on the unit
Proper usage
This instrument is intended for measurements on optical fiber
devices and systems.
JPlease make sure the instrument is not operated outside the
permitted ambient conditions.
JAlways make sure that the instrument is in proper working
order before switching it on.
Warning symbols indicating a potential hazard
JIn all cases where the unit is labeled with a warning symbol,
the operating manual must be consulted to learn more
about the nature of the potential hazard and any action that
must be taken.

10 OLT-85/OLT-85P
2 SAFETY INFORMATION
LASER SAFETY
Laser safety
Battery operation
WARNING
Dangerous laser radiation
Laser radiation can cause irreparable damage to eyes and
skin.
The maximum permitted power for the OLT-85 means that the
optical input signals can reach hazard level.
Bear this in mind when using the OLT-85.
JThis device is a Class 1 laser product according to
DIN EN 60825-1:2007.
JAlways be aware of the hazard level of the instrument to be
connected.
JConnect all optical fibers before switching on the radiation
source.
JSwitch off the laser source before disconnecting the optical
fibers.
JNever look directly into the unconnected port of the
instrument, the output of a laser source, or an optical fiber
connected to a source or a system.
JAlways cover unused ports.
JBe aware that the emitted light is not visible.
JHeed the normal precautions for working with laser radiation
and consider local regulations.
WARNING
Explosion danger
Short-circuiting the batteries can result in overheating,
explosion, or ignition of the batteries and their surround-
ings.
JNever short-circuit the battery contacts by touching both
contacts simultaneously with an electrical conducting object.
JOnly use AA size dry batteries or rechargeable batteries.
JMake sure the batteries are inserted with the correct polarity.

OLT-85/OLT-85P 11
2 SAFETY INFORMATION
VENTILATION
Ventilation
PS4 Universal AC/DC Power Supply
Safety class
The PS4 Universal AC/DC Power Supply unit has a protective
isolation that conforms with IEC 60950.
Environmental conditions
NOTICE
Insufficient ventilation
Insufficient ventilation can damage the instrument or
adversely affect its function and safety.
JEnsure adequate ventilation when operating the instrument.
NOTICE
Ambient temperature too high/low
Temperatures outside the operating range of 0 to +40 °C
can damage the PS4 Universal AC/DC Power Supply or
adversely affect its function and safety.
JOnly operate the PS4 Universal AC/DC Power Supply
indoors.
The PS4 Universal AC/DC Power Supply must only be
operated at ambient temperatures between 0 and +40 °C.
NOTICE
Insufficient ventilation
Insufficient ventilation can damage the PS4 Universal AC/
DC Power Supply or adversely affect its function and safety.
JEnsure adequate ventilation when operating the PS4
Universal AC/DC Power Supply.

12 OLT-85/OLT-85P
2 SAFETY INFORMATION
PS4 UNIVERSAL AC/DC POWER SUPPLY
NOTICE
Condensation
Operation in the presence of condensation can damage the
PS4 Universal AC/DC Power Supply or adversely affect its
function and safety.
JDo not operate the PS4 Universal AC/DC Power Supply if
condensation has formed.
JIf condensation cannot be avoided, such as when the PS4
Universal AC/DC Power Supply is cold and is moved to a
warm room, wait until the PS4 Universal AC/DC Power
Supply Unit is dry before plugging it into the AC power line.

OLT-85/OLT-85P 13
3 GETTING STARTED
UNPACKING THE INSTRUMENT
3GETTING STARTED
Unpacking the instrument
Packing material
We suggest that you keep the original packing material. It is
designed for reuse (unless it is damaged during shipping). Using
the original packing material ensures that the instrument is
properly protected during shipping.
Checking the package contents
JUnpack the instrument and check the package contents. For
more information see “Included items” on page 92.
Checking for shipping damage
After you unpack the instrument, check to see if it was damaged
during shipping. This is particularly likely if the packaging is
visibly damaged. If there is damage, do not attempt to operate
the instrument. Doing so can cause further damage. In case of
damage, please contact your local Viavi sales company.
Addresses can be found at www.viavisolutions.com.
Recovery following storage/shipping
Condensation can occur if a instrument that is stored or shipped
at a low temperature is brought into a warm room. To prevent
damage, wait until no more condensation is visible on the
surface of the instrument before powering it up. Do not operate
the instrument until it has reached its specified temperature
range and wait until it has cooled down if the instrument was
stored at a high temperature (see “Ordering Information” on
page 92).

14 OLT-85/OLT-85P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Instrument overview
Fig. 1 Front view OLT-85
1Connector interface
2Test head cover (green for APC connectors)
33.5 inch touchscreen
4Key pad (operator control panel)
5Battery compartment and stand (on rear of instrument)
6USB 2.0 device port (Type Micro-B)
7USB 2.0 host port (Type A) and external power supply connector
8Ethernet port (RJ-45)

OLT-85/OLT-85P 15
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Connector panel
Fig. 2 Connector panel
Fig. 3 External power supply connector and communication inter-
faces
1 Optical connector 1
2 Optical connector 2
3 Input port for broadband measurement
1 Ethernet port (RJ-45)
2 External power supply connector
3 USB 2.0 host port (Type A)
4 USB 2.0 device port (Type Micro-B)

16 OLT-85/OLT-85P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Power supply
The following power sources can be used to operate the
OLT-85:
• Eight 1.5 V dry batteries
(Mignon AA size, alkaline type recommended)
• Eight 1.2 V NiMH rechargeable batteries
(Mignon AA size, no internal charge)
• PS4 Universal AC/DC Power Supply (optional)
• RBP2 Li-Ion Battery Pack (optional)
NOTE: Best Measurement accuracy is achieved when the measurements
are performed in battery mode (w/o AC adapter).
Battery operation
WARNING
Dangers when handling batteries
Handling batteries may be dangerous. Please note the fol-
lowing safety instructions.
JPlease note the battery operation safety information in the
chapter “Battery operation” on page 10.
Replacing batteries
JDo not replace individual batteries. Always change all eight
batteries at the same time.
JAlways use eight batteries of the same type; i.e. do not mix
rechargeable and non-rechargeable batteries.

OLT-85/OLT-85P 17
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Replacing batteries
Fig. 4 Replacing the batteries
The battery compartment is on the back of the instrument.
1. Press down the latch to release and to open the lid of the
battery compartment.
2. Insert new batteries in the tray or remove the used batteries
from the tray and replace all eight with fresh ones.
NOTE: Take care to insert the batteries correctly. The correct polarity is
indicated by a diagram inside the battery compartment.
– or –
Insert new or replace the RBP2 Li-Ion Battery Pack.
– or –
Switch from non-rechargeable batteries to rechargeable ones
by replacing the battery tray with a new battery pack (or vice
versa).
3. Close the battery compartment.
4. Press the [E] key to switch on.
Recharging the batteries
The rechargeable RBP2 Li-Ion Battery Pack recharges when the
PS4 Universal AC/DC Power Supply is used to power the
instrument. The instrument switches to trickle charging
automatically as soon as the RBP2 Li-Ion Battery Pack is fully
charged.
1 RBP2 Li-Ion Battery Pack
2Latch lock
3 AA battery tray

18 OLT-85/OLT-85P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
NOTE: Rechargeable AA batteries will not be recharged in the
instrument. For AA-type rechargeable batteries please use an
external charger.
It is not possible to charge the rechargeable AA batteries or the
RBP2 Li-Ion Battery Pack via the USB interface.
The instrument is powered by the PS4 Universal AC/DC Power
Supply if the PS4 Universal AC/DC Power Supply and the USB
interface are both connected.
Deep discharge
A rechargeable battery that appears to be dead (unit will not
turn on even when connected to external power) may well be in
a deep discharge state. It can be fully charged with the following
charging cycle:
1. Plug in the power cord for 1–1.5 hours.
Battery should be partly charged now.
2. Switch the power on.
If the instrument starts: Let the battery fully charge.
– or –
If the instrument does not start:
Unplug power cord, plug it back in and repeat steps 1 and 2.
NOTE: If the battery is completely deep-discharged, this cycle might
need to be repeated up to 3 times.
General tips on using batteries
• Always handle batteries with care.
• Do not drop or damage the batteries or expose them to
excessively high temperatures.
• Do not store the batteries for more than one or two days at
very high temperatures (e.g. in a vehicle), either separately or
inserted in the instrument.
• Do not leave discharged batteries in the instrument for a long
time if it is not being used.

OLT-85/OLT-85P 19
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Other basic safety precautions are as follows:
• Do not use PS4 Universal AC/DC Power Supply outdoors or in
wet or damp locations.
• Connect the PS4 Universal AC/DC Power Supply to the correct
mains voltage, as indicated on the rating label.
• Do not allow anything to rest on the power cord, and do not
place the product where people can walk on the power cord.
• Avoid using this product during electrical storms. There may
be a remote risk of electric shock from lightning.
• Do not use this product in the vicinity of a gas leak or in any
explosive environment.
• Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous, high-voltage
points, and other hazards. Contact qualified service personnel
for all service.
Environmental protection
Please dispose of any unwanted dry batteries and rechargeable
batteries carefully. They should also be removed from the
instrument if it is to be discarded. If facilities in your country exist
for collecting such waste or for recycling, please make use of
these rather than throwing the batteries out with normal trash.
You will often be able to return used batteries to the place where
you purchase new ones. Any dry or rechargeable batteries that
you purchased from Viavi can be returned to one of our Service
Centers for disposal.

20 OLT-85/OLT-85P
3 GETTING STARTED
UNPACKING THE INSTRUMENT
Operation from AC power
NOTE: Only the PS4 Universal AC/DC Power Supply may be used to
operate the OLT-85 from AC power.
To fit the AC line plug adapter:
1. Select the appropriate AC line plug adapter.
2. Slide the AC line plug adapter into the slot.
The PS4 Universal AC/DC Power Supply is ready for use.
Fig. 5 PS4 Universal AC/DC Power Supply
To change the AC line plug adapter:
1. Squeeze both sides of the PS4 latch lock (see Fig. 5).
2. Push the AC line plug adapter upwards.
3. Slide a different AC line plug adapter into the slot (see Fig. 6).
Fig. 6 PS4: Changing the AC line plug adapter
