Victron Energy and Discover AES Batteries
The Discover AES range of Lithium Iron Phosphate batteries is compatible with Victron products in
various systems.
These instructions are intended to be used in conjunction with the product manual(s) supplied by
Discover Battery.
These instructions are current as of 2019-07-23. More recent updates to Victron device firmware or
Discover Battery, LYNK or Edge Card device firmware may alter set up instructions.
For the latest product details, installation and operation manuals, visit the Discover Battery website
https://discoverbattery.com » Solutions » Solar » Resources or use this direct link
https://solar.discoverbattery.com/aes-lifepo4-batteries-renewable-energy/
1. Introduction
The Discover AES LiFePO4 Battery includes a Battery Management System (BMS) within each battery
pack. The BMS interfaces with the Victron GX device and can support multiple batteries connected in
parallel.
These instructions provide information about the integration of Discover AES Lithium batteries with
Victron Energy devices in a Closed Loop configuration using the AES LYNK Communication Gateway
with installed AES LYNK Edge Card for Victron. AES batteries can be use in an Energy Storage System
(ESS) for self consumption, Grid backup and Off-grid applications. These instructions apply to an off-
grid application.
NOTE: In a Victron networked system the charging variables will be managed automatically by the

Last update:
2020-08-14 00:44 battery_compatibility:discover https://www.victronenergy.com/live/battery_compatibility:discover?rev=1597358648
https://www.victronenergy.com/live/ Printed on 2020-11-12 10:43
AES battery BMS and the Venus GX / Color Control GX device. Discharging variables are managed by
the set up of the Victron inverter.
2. Documentation
Victron Energy Reference Documents:
Quattro Inverter Charge Manual
MultiPlus Inverter Charge Manual
SmartSolar / BlueSolar Charge Controller Manual
Venus GX (VGX) / Color Control GX (CCGX) Manual
Discover Reference Documents:
Discover Energy 808-0004 42-48-6650 Data Sheet
Discover Energy 808-0005 44-24-2800 Data Sheet
Discover Energy 805-0015 AES LiFePO4 Battery 44-24-2800 42-48-6650 Manual
Discover Energy 805-0017 AES LYNK Communication Gateway User Manual
Discover Energy 805-0020 LYNK Edge Card Victron User Manual
Certain configuration, installations, service, and operating tasks should only be performed by qualified
personnel in consultation with local utilities and/or authorized dealers. Qualified personnel should
have training, knowledge, and experience in:
Installing electrical equipment
Applying applicable installation codes
Analyzing and reducing hazards involved in performing electrical work
Installing and configuring batteries
No responsibility is assumed by Discover for any consequences arising out of the use of
this material. Read AES Battery Manual and Safety instructions before installing the
battery. Read Victron manuals for guidance on product features, functions, parameters
and how to use the product safely.
WARNING: HAZARD OF ELECTRICAL SHOCK AND FIRE
Connect LYNK to only Safety Extra Low Voltage (SELV) circuits and power sources.
All wiring must be completed by qualified personnel to ensure compliance with applicable
installation codes and regulations.
Failure to follow these instructions can result in death or serious injury.
CAUTION: HAZARD OF EQUIPMENT DAMAGE
Do not install LYNK outdoors.
Do not connect any port of the LYNK to a network with power over Ethernet (POE) or to a public
telecommunication network.
Do not run CAT5 cables or other cables connected to LYNK through conduit that could be
exposed to lightning strikes.

2020-11-12 10:43 3/11 Victron Energy and Discover AES Batteries
Victron Energy - https://www.victronenergy.com/live/
Failure to follow these instructions can damage equipment
3. Overview
3.1 System Overview
The AES LYNK Communication Gateway unlocks the full potential of a Discover AES LiFePO4 Battery
by enabling the internal Battery Management System (BMS) to optimize the charge and discharge
configurations of the world’s best inverter chargers and solar charge controller systems in a closed
loop configuration.
AES LiFePO4 batteries must be set up to work with Power Conversion and Monitoring
devices in either an Open Loop or Closed Loop configuration.
AES LiFePO4 battery charge and discharge settings in a Open Loop configuration are set up manually
through the controller for the Power Conversion device at the time of installation. This is commonly
referred to as a ‘lead acid drop-in replacement’ configuration. For information on Open Loop set up
with Victron devices please visit the Discover Battery web site www.discoverbattery.com » Solutions »
Solar » Resources » Application Note »> Discover-AES-Lithium-Open-Loop-Integration-Victron-Energy.
In a Closed Loop configuration the battery charge and discharge rates and settings are dynamically
controlled by the BMS of the AES LiFePO4 Battery over a connection with the power conversion
devices in the network. These instructions are for a Closed Loop configuration.
To connect with the communication network of a specific brand of inverter charger or solar charge
controller, the LYNK Communication Gateway requires an AES LYNK Edge Card with the appropriate
communication port.
3.2 Minimum Battery Capacity
Battery charge and discharge rates are managed automatically by the AES LiFePO4 Battery and
Victron CCGX device. Using very large solar arrays with battery banks that are too small can exceed
the operating limits of the battery to charge and possibly lead to the BMS triggering over-current
protection. Battery capacity must be sized to accept the maximum charge current of the system, or
the the charging devices must be curtailed to charge below the operating limit of the installed
batteries. This value is derived by adding together the charge capacities of all inverter/chargers and
solar charge controllers in the system. Additionally, battery peak capacity must be sized to support
the surge requirements demanded by the load attached to the inverter. Match the sum of all inverter
peak power values with the sum of all battery peak battery current values.
Model Inverter Peak* Charger 1-Phase Min
42-48-6650
3-Phase Min
42-48-6650
MultiPlus 48/3000/35 136 Adc 35 Adc 1 2
MultiPlus / Quattro 48/5000/70 226 Adc 70 Adc 1 3
Quattro 48/8000/110 362 Adc 110 Adc 2 4
Quattro 48/10000/140 452 Adc 140 Adc 2 5
Quattro 48/15000/200 566 Adc 200 Adc 2 6

Last update:
2020-08-14 00:44 battery_compatibility:discover https://www.victronenergy.com/live/battery_compatibility:discover?rev=1597358648
https://www.victronenergy.com/live/ Printed on 2020-11-12 10:43
*92% Efficiency at 48V
Model Inverter Peak* Charger 1-Phase Min 44-44-2800
MultiPlus / Quattro 24/3000/70 271 Adc 70 Adc 1
MultiPlus / Quattro 24/5000/120 452 Adc 120 Adc 2
MultiPlus / Quattro 24/8000/200 724 Adc 200 Adc 3
*92% Efficiency at 24V
4 Configuring Victron Products
4.1 Powering Up Equipment
Make sure none of the Discover AES communication cables are installed.
Connect MultiPlus/Quattro, GX device, MPPT etc to the batteries in a safe way in accordance
with the local electrical requirements/code.
Connect all Victron communication cables at this time.
Turn ON the Discover AES Battery press and hold switch on the battery/batteries for 2-3
seconds.
Turn on Multi/Quattro
If this is the initial set up of the MultiPlus or Quattro apply power to Victron Equipment and update
firmware to the devices listed to:
MultiPlus / Quattro - version 459 or later.
GX device to include Color Control/ Venus/Octo/Cerbo- version 2.40 or later.
VE.Direct MPPT - version 1.42 or later.
This will also presume the VE Bus has already set up if required, such as:
Dual Phase/Split Phase 180 degrees out
3 Phase
4.2 VE.Configure Settings
This section presumes familiarity with VEConfigure software. These settings are for an off-grid
application. These parameters once set will become the default values used if communication with
the AES battery is interrupted for some reason. During normal operation the charge characteristics
are governed automatically by the CCGX via DVCC, with instructions from the connected AES battery.
However it is necessary to set the discharging parameters for DC input low shut-down found under
the Inverter Tab. After setting the parameters, ‘send’ all parameters to the inverter and CCGX. Restart
the CCGX after completion.
If the system is in a off-grid setting the max charge current would be dependent on generator size,.
Also keep in mind the settings below are for 1 unit only. If the system is a multiple inverter/charger
configuration, determine the max charge current for all units installed does not exceed the Discover
battery charge current limit .

2020-11-12 10:43 5/11 Victron Energy and Discover AES Batteries
Victron Energy - https://www.victronenergy.com/live/
General Tab 44-24-2800 42-48-6650
Overruled by remote (1) Enable Enable
Enable battery monitor Enable Enable
SoC when Bulk finished (2) 95% 95%
Total battery capacity (per battery installed) installed x 110 Ah installed x 130 Ah
Charge efficiency (2)| 95% |95%|
Inverter Tab 44-24-2800 42-48-6650
DC input low shut-down (3) 24.0 V 48.0 V
DC Input low restart (4) 26.0 V 52.0 V
DC input low pre-alarm (5) 25.5 V 51.0 V
Enable AES (6) Disable Disable
Charger Tab 44-24-2800 42-48-6650
Enable charger Enable Enable
Battery Type (2) Blank Blank
Lithium batteries (2) Enable Enable
Charge curve (2) Select: Fixed Select: Fixed
Absorption voltage (2) 27.2 V 54.4 V
Float voltage (2) 26.8 V 53.6 V
Charge current per battery installed
(Recommended < Maximum) installed x (78 A < 110 A) installed x (92 A < 130 A)
Repeated absorption time (2) (7) 1.0 < 3.0 Hr 1.0 < 3.0 Hr
Repeated absorption interval (2) 7.0 Days 7.0 Days
Absorption time (2) (7) 1.0 < 3.0 Hr 1.0 < 3.0 Hr
(1) Enabled is recommended. (2) Precautionary setting as they are ignored during normal operation
and communication with AES Battery. (3) The lowest operating voltage allowed, increase voltage as
required. (4) Restart voltage after DC input low shut-down, recommended to be set to the minimum
value (minimum varies according to the DC Input low shut-down value). (5) 51.0 V value
(approximately 15% SoC) will trigger low battery warning, increase or decrease as preferred. (6)
‘Enable AES’ has no relation to the AES Battery, refer to Victron manuals for information on setting
and function. (7) The recommended minimum is 1.0 hour. A longer period of time may be required to
compensate for multiple batteries to achieve a smooth completion of charge.
NOTE: Confirm the Float Voltage after completing the installation of any Victron ‘Assistants’, and if
necessary reset the Float Voltage back to 26.8 V / 53.6 V.
4.3 VE.Direct MPPT Settings
During normal operation the MPPT charge characteristics are governed by the CCGX via DVCC, with
instructions from the connected AES battery. The settings below are precautionary. This section
presumes familiarity with VictronConnect (Bluetooth App) used to configure, monitor and diagnose
Victron MPPT products which feature Blue-tooth, or are equipped with a VE.Direct Port. NOTE: VE.Can
MPPTs cannot be used and are not yet supported
The max charge current is dictated by the size of MPPTs installed. If multiple MPPTs are installed
verify all combined controllers would not exceed the battery limit.

Last update:
2020-08-14 00:44 battery_compatibility:discover https://www.victronenergy.com/live/battery_compatibility:discover?rev=1597358648
https://www.victronenergy.com/live/ Printed on 2020-11-12 10:43
MPPT Charge Controller Settings 44-24-2800 42-48-6650
Battery voltage 24 V 48 V
Max current per battery installed
(Recommended < Maximum) (9)
installed x (78 A < 110
A)
installed x (92 A < 130
A)
Charger enabled Enabled Enabled
Battery preset User Defined User Defined
Absorption voltage 27.2 V 54.8 V
Maximum absorption time (10) v 1.0 < 3.0 Hr 1.0 < 3.0 Hr
Float voltage 26.8 V 54.0 V
Equalization voltage 26.8 V 54.0 V
Auto equalization Disabled Disabled
Temperature compensation Disabled Disabled
Low temperature cut off 5 C 5 C
(9) May be set to lower value if necessitated by charger controller size. (10) Duration of absorption
period after the bulk charge interval. The recommended minimum is 1.0 hour. A longer period of time
may be required to compensate for multiple batteries to achieve a smooth completion of charge.
Turn OFF all Victron equipment. Turn OFF the Discover AES Battery press and hold switch on the
battery/batteries for 2-3 seconds
5. Installing LYNK and Connecting LYNK to the Victron
Network
5.1 Installing the LYNK Edge Card
The LYNK Edge Card for Victron is a Slot 0 Type which only inserts into the left side slot on the bottom
of the LYNK Communication Gateway.
NOTE: The LYNK Edge Card type to be used is determine by the brand of power conversion
equipment.
If LYNK Edge Card is in the wrong slot, it will not function.
If LYNK Edge Card is not firmly seated, it will not function.

2020-11-12 10:43 7/11 Victron Energy and Discover AES Batteries
Victron Energy - https://www.victronenergy.com/live/
Choose a clean, dry, easily accessible indoor location. All the communication ports on the LYNK are
accessible from the bottom of the device when mounted on a wall or DIN rail. Clearance of at least 50
mm (2 inches) below the device is needed to allow for the bend radius of cables connected to LYNK.
With LYNK disconnected from all devices remove cover and insert the LYNK Edge Card in the correct
slot. This card has a RJ45 terminal built into the card. Ensure it is firmly seated into the internal
connecting slot. Replace with provided slotted Edge Card cover after mounting LYNK Edge Card.
Install and network the AES LiFePO4 batteries as described in the 805-0015 AES LiFePO4 Battery
Manual. Connect the AES LYNK Communication Gateway to the AES LIFePO4 Battery and power up as
described in the 805-0017 LYNK Communication Gateway Users Manual.
CAUTION: HAZARD OF EQUIPMENT DAMAGE
Do not plug the AEBus RJ-45 cable terminator into the 10/100 Ethernet port of the LYNK.
Do not connect a CAT5 cable from the 10/100 Ethernet port of the LYNK to the WAN or MODEM
port of a network router.
Turn OFF all devices before connecting cables or inserting an Edge Card.
Failure to follow these instructions can damage equipment.
NOTE: Power electronics are not AEBus devices and should not be connected to AEBus.
5.2 Connecting LYNK to the Victron Network
Before connecting LYNK to the Victron Network ensure that the firmware for all Victron devices is up
to date.
Insert one end of a CAT5 communication cable into the LYNK Edge Card port and the other end into
one of the two VE.Can ports on the back of the Color Control GX (CCGX). Use the terminator provided
with the CCGX to terminate the network by plugging it into the second VE.Can port. See diagram
below.
NOTE: Discover DC Power Converter and Lynk Gateway are internally terminated

Last update:
2020-08-14 00:44 battery_compatibility:discover https://www.victronenergy.com/live/battery_compatibility:discover?rev=1597358648
https://www.victronenergy.com/live/ Printed on 2020-11-12 10:43
6. System Set Up
6.1 Synchronizing the Victron System with the AES Battery
Turn the Discover AES battery to ON press and hold switch on the battery/batteries for 2-3
seconds.
Turn on all Victron equipment.
Through the VRM or a physical CCGX access the System Setup menu in the Remote Console. Scroll
down to select each item and then set as indicated.
* Select “CAN-bus (1)”
* Select “CAN-bus Profile” to edit

2020-11-12 10:43 9/11 Victron Energy and Discover AES Batteries
Victron Energy - https://www.victronenergy.com/live/
* Within the “CAN-bus Profile” choose “VE CAN & CAN-bus”
* “VE CAN-bus & CAN-bus BMS (250 kbit/s)” should appear on the “CAN-bus(1) menu

Last update:
2020-08-14 00:44 battery_compatibility:discover https://www.victronenergy.com/live/battery_compatibility:discover?rev=1597358648
https://www.victronenergy.com/live/ Printed on 2020-11-12 10:43
Return to the Device List and the CCGX should display Discover AES as one of the devices along with
the battery SoC, Voltage and Amps. If you have multiple batteries a single entry will show up, which
represents all batteries.
NOTE: If Discover does not appear on the Device List, confirm that the CAT5 communication cable is
a normal patch type and not a cross over type. Use manufactured cables to avoid bad crimps and
reduce the risk of a poor connection.
The parameters option within the battery page shows the actual battery charge limits. If you have
multiple batteries a single entry will show up, which represents all batteries.
NOTE: Battery Low Voltage value displayed is the BMS value, the actual discharge voltage limit is
governed by the DC input low shut-down setting.
Once the VE.Can and CAN-bus bit rate is set, communication of the AES battery parameters will be
automatic.
During normal operation, the charge parameter limits are set by the BMS of the AES battery and
communicated through the system by the CCGX to the inverter/charger and MPPT.
Navigate from the Device List screen > Settings > System Setup>DVCC From the System Setup
menu scroll down to select each item and verify the system automatically updated in the DVCC. Note
this was accomplished by the v2.40 Venus OS firmware upgrade to include.
DVCC - Distributed Voltage and Current Control is forced “ON”
Within the DVCC menu verify:
Limit Charge Current is “ON” Note If off-grid or have a generator you might want to turn “ON”
Max charge current: Installed number of AES batteries x (42-48-6650: 92A < 130A) or
(44-24-2800: 78 A < 110 A (8)
SVS - Shared voltage sense: Forced “OFF”
STS - Shared temperature sense: Forced “OFF”
SCS - Shared Current Sense: 'On“

2020-11-12 10:43 11/11 Victron Energy and Discover AES Batteries
Victron Energy - https://www.victronenergy.com/live/
SCS Status - Should show “Disabled (External Control)
(8) Limit charge current works across the whole system. MPPTs are automatically prioritized over the
mains. In case the AES BMS requests a maximum charge current that is different from the user-
configurable setting, the lower of the two will be used. NOTE: To avoid conflicting network
information and data, do not use a Victron BMV battery monitor when using AES LYNK Communication
Gateway.
* Reboot the GX device after completion of all steps
From:
https://www.victronenergy.com/live/ - Victron Energy
Permanent link:
https://www.victronenergy.com/live/battery_compatibility:discover?rev=1597358648
Last update: 2020-08-14 00:44
