Viessmann Vitosol-F Series User manual

Installation instructions
for contractors
VIESMANN
Vitosol-F/-FM
Type SVK, SVKF
Flat-plate collector for pitched roofs, above roof installation for 1 collector
VITOSOL-F/-FM
5698368 GB 1/2018 Dispose after installation.

2
Please follow these safety instructions closely to
prevent accidents and material losses.
Safety instructions explained
!Please note
This symbol warns against the risk of material
losses and environmental pollution.
Note
Details identified by the word "Note" contain additional
information.
Target group
These instructions are exclusively intended for author-
ised contractors.
■Work on electrical equipment must only be carried
out by a qualified electrician.
Regulations to be observed
■National installation regulations
■Statutory regulations for the prevention of accidents
■Statutory regulations for the protection of the envi-
ronment
■Codes of practice of the relevant trade associations
■All relevant safety regulations as defined by DIN, EN,
DVGW, VDE and locally applicable standards
aÖNORM, EN and ÖVE
cSEV, SUVA, SVTI, SWKI and SVGW
Working on the system
■Isolate the system from the power supply (e.g. by
removing the separate fuse or by means of a mains
isolator) and check that it is no longer 'live'.
■Safeguard the system against reconnection.
Safety instructions
5698368

3
1. Information Disposal of packaging ............................................................................ 4
Symbols ................................................................................................. 4
Intended use .......................................................................................... 5
2. Installation sequence Installation with rafter hooks .................................................................. 6
■Components ....................................................................................... 6
■Fitting the rafter hooks ........................................................................ 6
■Fitting the mounting rails .................................................................... 9
Installation with rafter flange .................................................................. 9
■Components ....................................................................................... 9
■Fitting the rafter flange ........................................................................ 10
■Fitting the mounting rails .................................................................... 11
Installation with roof hooks .................................................................... 12
■Components ....................................................................................... 12
■Fitting the roof hooks .......................................................................... 13
■Fitting the mounting rails .................................................................... 16
Installation with mounting brackets ........................................................ 16
■Components ....................................................................................... 16
■Fitting the mounting brackets ............................................................. 17
■Fitting the mounting rails .................................................................... 18
Installation with rafter anchors ............................................................... 18
■Components ....................................................................................... 18
■Fitting the rafter hooks ........................................................................ 19
■Fitting the mounting rails .................................................................... 22
Installing and connecting the collectors ................................................. 22
Fitting the collector temperature sensor ................................................ 24
Covering the collector array ................................................................... 25
3. Installation ................................................................................................................ 27
4. Commissioning ................................................................................................................ 29
Index
5698368

4
Disposal of packaging
Please dispose of packaging waste in line with statu-
tory regulations.
DE: Use the disposal system organised by
Viessmann.
AT: Use the ARA statutory disposal system (Altstoff
Recycling Austria AG, licence number 5766).
CH: Packaging waste is disposed of by the HVAC
contractor.
Symbols
Symbol Meaning
Reference to other document containing
further information
1.
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■Component must audibly click into place.
or
■Acoustic signal
■Fit new component.
or
■In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
Disposal of packaging
5698368

5
The appliance is only intended to be installed and
operated in sealed unvented systems that comply with
EN 12828 / DIN 1988, or solar thermal systems that
comply with EN 12977, with due attention paid to the
associated installation, service and operating instruc-
tions. DHW cylinders are only designed to store and
heat water of potable water quality. Heating water buf-
fer cylinders are only designed to hold fill water of pot-
able water quality. Only operate solar collectors with
the heat transfer medium approved by the manufac-
turer.
Intended use presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than heating the building or DHW shall be deemed
inappropriate.
Any usage beyond this must be approved by the man-
ufacturer for the individual case.
Incorrect usage or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and results in an exclusion of liability.
Incorrect usage also occurs if the components in the
system are modified from their intended use (e.g.
through direct DHW heating in the collector).
Adhere to statutory regulations, especially concerning
the hygiene of potable water.
Intended use
5698368

6
For tiled roof cover
Components
1 432
5 6
Fig. 1
1Rafter hook
2Support bracket
3Screws
4Mounting rail
5Mounting plate
6Clamping bracket
Fitting the rafter hooks
2 adjacent rafters are used to fit the rafter hooks. ■Version I:
Fitting rafter hook 1 onto counter batten C with
support bracket 2
■Version II:
Fitting rafter hook 1 directly onto rafter B
■Trim the roof tiles with an angle grinder, for example
by removing drip tabs.
Installation with rafter hooks
5698368

7
!Please note
Take care to avoid breaking tiles.
The rafter hook must not rest on the roof tiles.
Observe the dimensions.
B
C
1.
2.
B75
C
20
B
3.
1
2
1
2
1
5
4.
Fig. 2
Installation with rafter hooks (cont.)
5698368

8
5.
7.
5
6.
Fig. 3
9.
8.
Fig. 4
Installation with rafter hooks (cont.)
5698368

9
Fitting the mounting rails
1600-1800
93 923 93
11.
90°
10.
x
y
Fig. 5 Maximum deviation from dimensions x and y
10 mm
Continue with chapter "Installing and connecting the
collectors" on page 22.
Installation with rafter flange
For plain tiled and slate roofs
Components
43
5 6
1 2
Fig. 6
Installation with rafter hooks (cont.)
5698368

10
1Rafter flange
2Seal
3Screws
4Mounting rail
5Mounting plate
6Clamping bracket
Fitting the rafter flange
2 adjacent rafters are used to fit the rafter flanges.
1.
1
3
Fig. 7
3.
2.
2
Fig. 8
Installation with rafter flange (cont.)
5698368

11
Fitting the mounting rails
x
y
1600-1800
160 790 160
90°
4.
5.
Fig. 9 Maximum deviation from dimensions x and y
10 mm
Continue with chapter "Installing and connecting the
collectors" on page 22.
Installation with rafter flange (cont.)
5698368

12
For tiled, plain tiled, slate and corrugated sheet roof
covers
Components
qW
75
4
68 9
qP qQ
119
280
325
94
385
1 2 3
Fig. 10
1Timber
■38 x 58 x 2430/1570 mm
■30 x 100 x 2430/1570 mm
2Roof hook for tiled roof cover
3Zinc-plated countersunk chipboard screw (Spax-S)
6 x 80 mm
4Zinc-plated countersunk chipboard screw (Spax-S)
5 x 30 mm
5Roof hook for slate roofs
6Zinc-plated countersunk chipboard screw (Spax-S)
6 x 30 mm
7Roof hook for plain tile roofs
8Roof hook for corrugated sheet profiles 5 and 6
9Roof hook for corrugated sheet profile 8
qP Mounting rail
qQ Mounting plate
qW Clamping bracket
Installation with roof hooks
5698368

13
Fitting the roof hooks
Tiled roof cover
2066
x
160 160
y1600-1800 x
Fig. 11 x according to the width of the tile head. y =
440 mm
Dimensions for horizontal fitting of roof hooks, see
page 16.
Example: plain tiled roof
2066
y1600-1800
Fig. 12
Dimensions for horizontal fitting of roof hooks, see
page 16. Roof cover y in mm
Slate 348
Plain tile 380
Corrugated sheets 207
Installation with roof hooks (cont.)
5698368

14
Tiled roof cover
2. 5.
42
1
1
30x100
38x58
3
3.
4.
160
1.
Fig. 13
Continue with "Fitting the mounting rails" on page 16.
Slate roof cover
5
6
1.
2.
Fig. 14
Note
Fit commercially available lead flashing to protect
against the ingress of moisture.
Continue with "Fitting the mounting rails" on page 16.
Installation with roof hooks (cont.)
5698368

15
Plain tiled roof cover
74
2.
1.
Fig. 15
30
Fig. 16
Note
Trim tiles; cut off approx. 30 mm with an angle grinder.
Continue with chapter "Fitting the mounting rails" on
page 16.
Corrugated sheet roof
,
A
Ø8
B
8 9
Fig. 17
ASealing washer (on site)
BExisting roof batten
Installation with roof hooks (cont.)
5698368

16
Fitting the mounting rails
1033
93 923 93
x
y
1.
2.
Fig. 18 Maximum deviation from dimensions x and y
10 mm
Continue with chapter "Installing the collectors" on
page 22.
Installation with mounting brackets
For sheet metal roofs
Components
421 3
Fig. 19
1Mounting bracket
2Mounting rail
3Mounting plate
4Clamping bracket
Installation with roof hooks (cont.)
5698368

17
Fitting the mounting brackets
103 1600-1800
2066
Fig. 20
Dimensions for horizontal fitting of mounting brackets,
see page 18.
Use on-site fixings A to secure the mounting brack-
ets.
The installation of the mounting brackets is shown
using standing seam profiles as an example.
A
1.
2.
Fig. 21 Screws supplied on site.
Installation with mounting brackets (cont.)
5698368

18
Fitting the mounting rails
1033
160 790 160
x
y
3.
4.
Fig. 22 Maximum deviation from dimensions x and y
10 mm
Installation with rafter anchors
For tiled roof cover
Components
4 5 6
2240
1 2 3
Fig. 23
1Rafter anchor
2Mounting rail
3Seal
4Mounting plate
Installation with mounting brackets (cont.)
5698368

19
5Clamping bracket
6Plastic replacement tile, if the existing tiles are not
to be cut.
Use only on roofs with a pitch of at least 12°.
Fitting the rafter hooks
~40
1.
2.
~40
C
B
1600-1800
Fig. 24
BRafter
CBatten
2 adjacent rafters are used to fit the rafter anchors.
Installation with trimmed tiles
3.
4.
Fig. 25
Installation with rafter anchors (cont.)
5698368

20
6.
5.
Fig. 26
7.
Fig. 27
Continue with step 9 (see page 22)
Installation with plastic replacement tiles
4.
5.
3.
Fig. 28
Installation with rafter anchors (cont.)
5698368
