Viking DDBB536RSS Technical manual

Side Panel Support Instructions
Viking Part Number-F90752
Released-1/20/2005, Revision-1 Page 1
NOTE: This instruction sheet only refers to the PSSPL3 and
DSSPL3 series side panel kits.
1) Align side panel support with top and bottom cabinet edges.
Side panel support aligned with top cabinet edge
Side panel support aligned with bottom cabinet edge

Side Panel Support Instructions
Viking Part Number-F90752
Released-1/20/2005, Revision-1 Page 2
NOTE: The Side Panel Support is manufactured to fit on the left rear
corner of the unit. The Side Panel Support should be aligned with the
rear of the unit.
2) Using the side panel support holes as a template, drill (7) holes
into the side of the unit with a 9/64” (.36 cm) diameter drill bit.
3) Attach side panel support to the unit with #8 sheet metal screws
provided.
Side panel support aligned with rear of the unit

Side Panel Support Instructions
Viking Part Number-F90752
Released-1/20/2005, Revision-1 Page 3
4) Position and engage side panel with the side trim toward the front
of the unit. Position rear of side panel with the rear of the unit.
Hole location for side panel support
Hole location for side panel support
Side Trim (Professional Shown)

Side Panel Support Instructions
Viking Part Number-F90752
Released-1/20/2005, Revision-1 Page 4
5) Attach rear of side panel into pre-drilled holes on side panel
support.
Pre-drilled holes for attaching side panel
