Vingtor Stentofon Turbine Mini SIP Station Guide

Mounting Manual
Turbine Mini SIP Station
1 Turbine Mini SIP Station
This document describes the dimensions, mounting procedure, and connections of the TMIS-1SIP Turbine Mini SIP
station.
Item Number Type Item Name
1008216010 TMIS-1SIP Turbine Mini SIP Station
1008140020 TA-2 Turbine Flush Mount 2-Gang Double-Depth Back-Box
1008140030 TA-3 Turbine Flush Mount 2-Gang Back-Box
2 Flush Mount 2-Gang Back-Boxes - TA-2 & TA-3
TA-2 TA-3
LIt is recommended to utilize back-boxes with weep holes at the bottom.
96 mm / 3.78?
48 mm
25 mm
23 mm
89 mm / 3.50?
89 mm / 3.50?
96 mm / 3.78?
46 mm
SIDE
SIDE
22 mm
1.81? 0.98?
0.90?
0.87?
1.89?
+5
1
2
3
4
5
6
Prod.date:
Serial no:
Designed and developed by
Zenitel in Norway
Assembled in Poland
-
+
+24
COM
NO
NC
QR
1008116010 . 0100
TMIS-1
[yyyyww]
[yywwxxxx]
www.zenitel.com
39 mm
117 mm
117 mm
33.5 mm
48 mm
25 mm
23 mm
46 mm
SIDE
SIDE
22 mm
96 mm / 3.78?
96 mm / 3.78?
0.87?
1.81? 0.98?
64 mm / 2.52?
64 mm / 2.52?
1.89?
0.90?

3 Flush Mounting Procedure
1. Mount the Back-Box into the wall
2. Fasten the Station to the Back-Box with four #6-32 UNC countersunk-head screws
4 Connections
The TMIS-1SIP station has a RJ-45 PoE/LAN port, and 6-pin & 10-pin external connectors.
Ethernet /
Power
10/100 Mbps Ethernet RJ-45 port for LAN (uplink) connection.
Supports PoE (802.3af). Draws power from either spare line or
signal line.
Secondary
Power
24 VDC (16 – 48 V) secondary power is provided from an
external adapter.
Relays There is one Double Throw relay contact with 60W
switching power. COM, NO, NC contacts are provided. Max:
250VAC/220VDC, 2A, 60W.
Input/Output 6 I/Os are available. Each I/O can be configured as either input,
output, or LED driver.
Audio Line Out A balanced 600 ohm audio line out
LUse cables crimped with ferrules for terminal block connectors
• When the TMIS-1SIP station is connected to the network, its IP address is automatically obtained from a
DHCP server or an IP address in the range 169.254.x.x will be assigned.
• To make the intercom speak its IP address, press the call button on the station.
1
5
4
3
2
1
6
10
5
4
3
2
9
8
7
RJ-45
PoE
port
24 VDC for external secondary power
if PoE is not used. Pin 1 is positive.
- 5.3V (LED driver)
- GND
- Input/Output 5
- COM relay
- NC relay
- NO relay
- Input/Output 1
- Input/Output 2
- Input/Output 3
- Input/Output 6
- 600 ohm balanced line out +
- 600 ohm balanced line out -
- Input/Output 4
Ethernet Connection
Flush Mount 2-Gang Back-Box
TMIS-1SIP Station
#6-32 UNC Screws
#6-32 UNC Screws
