VISIONARY DESIGNS MOD-1300 Manual

© 2018
Order #XXXXX
*
Assembled
Door
1
2
3
4
5
5
6
6
7A
7B
8
8
Floor
Infill
Infill
Pedestal Top
Pedestal Base Assembly
Completed Assembly
Item
1
2
3
4
5
6
7A,7B
8
Qty.
1
1
1
1
2
2
1,1
2
Setups:
1) Connect verticals [1] [2] [3] and [4] with horizontals [5] and [6].
2) Insert infills between [1 and 2] [1 and 4] [3 and 4] then secure with horizontals [7A] [7B] and [8].
3) Attach door to vertical [3]. See Door Attachment detail.
4) Place floor on lip of horizontals [5] and [6]. See Extrusion Lip detail.
5) Attach Velcro on shelf supports to infills, inside assembled pedestal base.
6) Place shelf on shelf supports.
7) Attach pedestal top to horizontals [7A] and [7B]. See Pedestal Top Attachment detail.
Shelf
Shelf
Support
Velcro
Door
Hinge
Hinge
Slide pin into
hinge attached
to Vertical.
Slide Door
hinge over pin.
Door Attachment
*
**
*
*
*
*
*
Align hole with pin Rotate pin. Spring
will push pin into hole.
Pedestal Top Attachment
12
*
Pin
Hole
Infill
Extrusions [5] and [6] have
a lip for the floor to rest upon.
Lip
Extrusion Lip
*
Description
40.232” S40 Curved Vertical Extrusion
38” S40 Vertical Extrusion w/ Stoppers
38” S40 Vertical Extrusion w/ Hinges
40.232” S40 Curved Vertical Extrusion
11” Z45 Horizontal Extrusion w/ Lip
23” Z45 Horizontal Extrusion w/ Lip
14.567” Z45 Horizontal Extrusion
23” Z45 Horizontal Extrusion
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
MOD-1300 Pedestal

© 2018
Order #XXXXX General Information
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all setscrews
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED

© 2018
Case 1 of 1
Order #XXXXX Case Packing
