VISIONARY DESIGNS LTK-1115 Manual

© 2018
Order #XXXXX
*
Completed Assembly
Back View of Counter Base Front View of Counter Attachments
Screw
Cap
Side
Panel
Side
Panel
Back Panel
with Door
Front Panel
Large Counter Top
Wing Nut
Assembled
Counter Base
Post
Small Counter Top
Floor Shelf
Steps:
1) Use screw caps to secure the front panel and back panel to the side panels.
2) Place the floor onto pins inside of side panels.
3) Connect shelf supports to Velcro on inside of side panels, then place shelf
on top of supports.
4) Slide large counter top over post, then attach to assembled counter base.
See Counter Top Attachment detail.
5) Attach flange plate to top of post, using screw.
6) Insert fixed screws on small counter top into the holes of flange plate, then
secure using wing nuts.
Align hole with pin Rotate pin. Spring
will push pin into hole.
Counter Top Attachment
12
*
Pin
Shelf Support
NOTE: Remove pins for Floor from
Side Panels, when packing.
*
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
LTK-1115 Counter

© 2018
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all setscrews
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information
