VISIONARY DESIGNS MOD-1212 User manual

www.classicexhibits.com
Step 1
Page 1 of 3
866.652.2100
© 2011
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
Order #XXXXX - MOD-1212 Assembly
Item
1
2
3
4
5
6
7
Description
32” Vertical Extrusion
28.77” Curve Horizontal Extrusion
13.6” Curve Horizontal Extrusion
28.77” Curve Horizontal Extrusion
13.6” Curve Horizontal Extrusion
32” Vertical Extrusion w/ Door Stop
32” Vertical Extrusion w/ Door Hinges
Quantity
2
2
2
2
2
1
1
Steps:
1) Attach lower horizontal extrusions [2 and 3] between vertical
extrusions [1, 6 and 7] as shown.
2) Place inserts and attach door where indicated.
3) Attach upper horizontal extrusions [2 and 3] between vertical
extrusions [1, 6 and 7] as shown.
4) Attach extrusion legs to underside of floor,
5) Attach short pins to lower horizontal extrusions where indicated in ,
then place assembled base on floor.
6) Velcro shelf supports to inside of assembled base, then set shelf atop supports.
7) Connect 2 counters together using standoff extrusions.
8) Attach short pins to upper horizontal extrusions where indicated in,
then place assembled counters atop pins.
Door
Hinges
1
1
7
6
2
2
3
4
3
4
5
5
Door
Stop
Door
*
*
*
*
*
*
*
**
*
*
*
*
*
*
**
= Indicates pin location
***
*
Counter Top
Upper Counter
Standoff
Extrusions
Extrusion Legs
Door
Hinge
Hinge
Door Attachment
Slide pin into
hinge attached
to vertical.
Slide door
hinge atop pin.
13.94” x 28.9”
Lam Insert and
Perf Insert Panels
*

www.classicexhibits.com
Step 2
Page 2 of 3
866.652.2100
© 2011
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
Order #XXXXX - General Instruction
The Tool Typical Connection
Horizontal Inline Connection (remove only one setscrew)
Base Plate Connection Vertical Connection
(remove only two setscrews)
Most Visionary Designs exhibits can be
assembled with the supplied Hex Key Tool.
Occasionally, a flat head screwdriver may
be required.
Most horizontal extrusion connections have a patented expandable lock. This lock inserts into
the groove of an opposing extrusion. Tightening the lock with the Hex Key Tool expands the lock
and creates a strong positive connection.
Remove only (1) setscrew when disassembling. Replace setscrew in
extrusion after assembling it. Before packing, replace setscrew in
extrusion to avoid losing it.
Attach base plate to round or square
vertical extrusion using the bolt provided.
Be careful not to strip the threads.
When vertical extrusions are packed in
portable cases rather than crates or
tubs, they must broken down into
smaller sections which then require
assembly.
Remove only (2) setscrews when
disassembling. Replace setscrews in
extrusion after assembling it. Before
packing, replace setscrews in extrusion
to avoid losing them.
Using Your Setup Instructions
The Visionary Designs Setup Instructions are created specifically for your
configuration. They are laid out sequentially, including an exploded view of
the entire display, and then a logical series of detailed steps to assemble the
main structure and components. We encourage you to study the instructions
before attempting to assemble your exhibit.
Each page reminds you to tighten the setscrews after disassembling your
exhibit to prevent loss of the locks and setscrews (see below in RED).
This is VERY IMPORTANT.
Cleaning and Packing Your Display
1) Use care when cleaning aluminum extrusion or acrylic inserts. Use only
non-abrasive cleaners.
2) When cleaning laminate inserts or countertops, use mild cleansers and a
soft material such as cotton.
3) Keep all display components away from extreme heat and long exposure
to sunlight to avoid warping and fading.
4) Retain all packing material. It will make re-packing much easier and will
reduce the likelihood of shipping damage.
Typical Connection (cont’d)
Numbered Label
Each extrusion contains a numbered label which
corresponds with setup instructions.
The label is located within a groove of the extrusion
(when possible). With Visionary Designs the labels
contain Black numbers unless otherwise specified.
Detail C EliateDDliateDDetail B
Detail A
Setscrews
