VISIONARY DESIGNS MOD-1524 Manual

www.classicexhibits.com
Step 1
Page 1 of X
866.652.2100
© 2015
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
Order #XXXXX -
Steps:
1) Connect verticals [2] & [3] together.
See Q125 Connector detail.
2) Attach base plate [1] to assembly [2/3].
3) Connect curved base plates [1A] to verticals [4].
4) Attach assemblies [1A/4] to the bottom side of counter top.
See Counter Support Leg Attachment detail.
5) Secure counter top to vertical [3].
See Counter Attachment detail.
6) Connect Monitor Mount to vertical [3].
See Monitor Mount Attachment detail.
7) Install Graphic Wings to A10 clips on vertical extrusions.
See A10 Clamp detail
Item
1
1A
2
3
4
Description
Oval Base Plate
Curved Base Plates
41”h Square Vertical Extrusion
41”h Square Vertical Extrusion
38” Round Vertical Extrusion
Qty.
1
2
1
1
2
1
2
3
Canopy
1A 1A
4
4
Counter Top
When assembled
*
*
Counter Attachment
Washer
Thumbscrew
Use thumbscrew & washer
to attach to vertical extrusion.
*
*
**
*
*
Counter Support
Leg Attachment
Insert screws located
on underside of counter
into holes on flange plate
and secure with wing nuts. Wing Nut
*
Monitor Mount Attachment
Attach monitor mount to vertical
extrusions after assembly.
Slide Mount
into Groove of
Vertical Extrusion.
Tighten
Setscrew Attach top
Plate and
tighten screws
Knob to attach graphics
Setscrew
1) Slide Connector of A10
into extrusion groove.
2) Tighten setscrew when
A10 is in desired location.
3) Insert Infill into Clamp
4) Tighten knob on A10 to
secure wing in place.
A10 Clamp Detail
Screws
Connector
Q914
Connector
Silde extrusion
over connector;
secure with screws.
**To prevent product loss,
Keep all screws attached
to connector piece after
disassembling
MOD-1524 - General Layout

www.classicexhibits.com
Step 2
Page 2 of X
866.652.2100
© 2015
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
Order #XXXXX - MOD-1524 - General Information
The Tool Typical Connection
Horizontal Inline Connection (remove only one setscrew)
Base Plate Connection Vertical Connection
(remove only two setscrews)
Most Visionary Designs exhibits can be
assembled with the supplied Hex Key Tool.
Occasionally, a flat head screwdriver may
be required.
Most horizontal extrusion connections have a patented expandable lock. This lock inserts into
the groove of an opposing extrusion. Tightening the lock with the Hex Key Tool expands the lock
and creates a strong positive connection.
Remove only (1) setscrew when disassembling. Replace setscrew in
extrusion after assembling it. Before packing, replace setscrew in
extrusion to avoid losing it.
Attach base plate to round or square
vertical extrusion using the bolt provided.
Be careful not to strip the threads.
When vertical extrusions are packed in
portable cases rather than crates or
tubs, they must broken down into
smaller sections which then require
assembly.
Remove only (2) setscrews when
disassembling. Replace setscrews in
extrusion after assembling it. Before
packing, replace setscrews in extrusion
to avoid losing them.
Using Your Setup Instructions
The Visionary Designs Setup Instructions are created specifically for your
configuration. They are laid out sequentially, including an exploded view of
the entire display, and then a logical series of detailed steps to assemble the
main structure and components. We encourage you to study the instructions
before attempting to assemble your exhibit.
Each page reminds you to tighten the setscrews after disassembling your
exhibit to prevent loss of the locks and setscrews (see below in RED).
This is VERY IMPORTANT.
Cleaning and Packing Your Display
1) Use care when cleaning aluminum extrusion or acrylic inserts. Use only
non-abrasive cleaners.
2) When cleaning laminate inserts or countertops, use mild cleansers and a
soft material such as cotton.
3) Keep all display components away from extreme heat and long exposure
to sunlight to avoid warping and fading.
4) Retain all packing material. It will make re-packing much easier and will
reduce the likelihood of shipping damage.
Typical Connection (cont’d)
Numbered Label
Each extrusion contains a numbered label which
corresponds with setup instructions.
The label is located within a groove of the extrusion
(when possible). With Visionary Designs the labels
contain Black numbers unless otherwise specified.
Detail C EliateDDliateDDetail B
Detail A
Setscrews
