Vitec Multimedia HDMI2SDI User manual

HD MI2SDI UP/DOWN
SCALING CONVERTER
User Manual

Content
Feature ....................................................................................3
Front Panel ...............................................................................4
Rear Panel ................................................................................4
Side Panel.................................................................................5
Button/LED Indicate.....................................................................6
Installation................................................................................9
Package Contents........................................................................9
Specifications .......................................................................... 10
Firmware Upload ...................................................................... 12

Features
SDI Supports HD formats :
720p50 & 60
1080i50 & 60
1080p24, 25, 30, 50 & 60
SDI Support 525i & 625i SD D1 format
Auto 3G/HD/SD-SDI detection
One HDMI input source can split to two 3G-SDI displays simultaneously.
Frame rate conversion(1.000/1.001)
External Button Configuration
Firmware is upgradable in the field using the integrated USB port
The converter is Plug-and-Play
Support VESA Mode

Front Panel
NO
Component
Function
1
SDI Output Port
Connect to your SDI Display or Device plug
2 Ouputs Provided
2
LEDs indicate
The LED's indicate Output Format
(SD/HD/3G/HDCP)
3
Mode Buttons
Select Format/TV Wall/TV Ratio
Rear Panel
NO
Component
Function
1
Power Jack
Connect the Power adapter plug here.
2
HDMI Input Port
Connect your HDMI Source to this input.
3
Power/Locked LED
This LED indicates Power and Lock status.
1
2
3
1
2
3

Side Panel
NO
Component
Function
1
USB Connector
Upgrade Firmware/Control Box by PC
1

Buttons/LED Indicators
1. Button Mode:
a. Format Mode:
First press the #1 button to set the Output Format Mode (Resolution).
Then change the Frame Rate by pressing buttons#2 and #3 as needed.
RES
FRAME RATE
FRACTION
By Pass
720x480
59.94i
720x576
50i
1280x720
60p
59.94p
50p
30p
25p
1920x1080i
60i
59.94i
50i
1920x1080p
60p
59.94p
50p
30p
29.97p
25p
24p
23.97p
: is default format at change button 1 after.
SD LED
HD LED
3G LED
BY PASS
●
●
●
720 x 480
●
○
○
720 x 576
○
●
○
1280 x 720
●
●
○
1920 x 1080i
○
○
●
1920 x 1080p
●
○
●
●: LED ON
○: LED OFF

b. TV Wall Mode:
Pressing the #2 (Rate) button , will put the converter into the TV Wall Mode.
You can change the window view by pressing the #3 (Fraction) button.
Turn OFF
Divide
Windows
To 2x2
Divide
Windows
To 3x3
Divide
Windows
To 4x4

c. Aspect Ratio Mode: Push Button 3 to change TV Ratio
↓：Display is 4:3
↑：Display is 16:9
2. LED Mode:
a. Output Mode:
Resolution
SD LED
HD LED
3G LED
HDCP LED
NTSC(720x480) /
PAL(720x576)
●
○
○
○
720p / 1080i /
1080 [24p, 25p, 30p]
○
●
○
○
1080 [50p,60p]
○
○
●
○
HDCP Content
○
○
○
●
b. Input Singal Mode:
POWER/SIGNAL LED
SINGAL LOCKED
●
SIGNAL UN-LOCKED
●
3. FIRMWARE Mode:
Press and hold the 3 and 2 buttons, to display the firmware version in the upper left
corner of the sdi output video.
4. DEFAULT Mode:
Press all buttons(1, 2 and 3) at the same time, the box auto reset to default.
FIRMWARE VERSION
0.1.0.1

Installation
HDMI2SDI-Up/Down Scaler installation consists of the following:
1. Disconnect +12DC adaptor to converter.
2. Connect Video Source (HDMI) to the HDMI Connector.
3. Connect SDI Equipment to the BNCs connector
4. Connect the +12DC adaptor to the converter.
Package Contents
The HD2SDI-S package contains the following items:
User Manual x 1
+12 DC Adapter x 1
HD2SDI-S Converter x 1

Specifications
DESCRIPTION
SDI Format
SD-SDI, HD-SDI & 3G-SDI
SDI Transition Rate
2.970Gb/s, 10485Gb/s and 270Mb/s
Audio Support
Stereo 2-Channel
Audio Sample
Auto Ra-sample to 48Khz (For Stereo)
Coaxial Cable Type
RG6/RG59(75Ω)
Cable Equalization
3G: 120m of RG6/ 100m of RG59
HD: 200m of RG6/ 140m of RG59
SD: 400m of RG6/ 280m of RG59
*1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275 Cable
*2 Cable Length Performance: Depending on SDI Signal and
Cable Quality
Firmware Updates
Via Mini-USB
Input
1 x HDMI
Output
2 x BNC [SDI]
BNC Connector
3G 75 Ωinter-locked socket
HDMI Connector
TYPE A [19-pin female]
USB Connector
Mini-USB
Bottom
Output Format/TV Wall/TV Ratio
Housing
SECC
Dimension
L:104mm x W:63.3mm xH:26mm
Power Source
Power Adapter: AC 100 ~ 240 V/DC (+6 ~ 15 V)
Operation Temperature
0~50°C [32~114°F]
Storage Temperature
-20~+60°C

Support CEA-861/VESA Format
720x480i60
720x576i50
720x480 p60
720x576 p50
1280x720p60/59.94
1280x720p50
1920x1080i60/59.94
1920x1080i50
1920x1080p24/23.98
1920x1080p25
1920x1080p30/29.97
1920x1080p60/59.94
1920x1080p50
640x350p85
640x400p85
720x400p85
640x480p60
640x480p72
640x480p75
640x480p85
800x600p56
800x600p60
800x600p72
800x600p75
800x600p85
848x480p60
1024x768p50
1024x768p59
1024x768p60
1024x768p70
1024x768p75
1024x768p85
1152x864p70
1152x864p75
1280x768pRB
1280x768p60
1280x768p75
1280x768p85
1280x800p60
1280x800p75
1280x800p85
1280x960p60
1280x960p75
1280x960p85
1280x1024p60
1280x1024p75
1280x1024p85
1360x768p60
1366x768p50
1366x768p60
1400x1050p50
1400x1050p59
1400x1050p60
1400x1050p75
1440x900p60
1440x900p75
1440x900p85
1600x1200p50
1600x1200p59
1600x1200p60
1600x1200pRB
1680x1050pRB
1680x1050p60
1920x1200pRB
2048x1052p60
2048x1080p50
2048x1080p59
2048x1080p60

Firmware Upload
Firmware is upgradable in the field using the integrated USB port
How to Firmware upgrade:
Step 1.
Open Upload Firmware Program tools.exe and connect box to PC by USB
Cable.
Step 2.
Plug and un-plug “DC adapter”to power on/off the converter box (the
connection check status will be changed to “Connect”)

Step 3.
Plug and un-plug “DC adapter”again (the connection check status will be
changed to “Connected”) and Please click the Open File button to select
the firmware bin file.
Step 4.
Please click “Start’Button to proceed with new firmware programming.
The PASS message will appear when the procedures finished.
Step 5.
Close Upload Firmware Program tools
