Vivo DESK-E3CVB User manual

DESK-E3CVB/C/D/N/W Controller
Instruction Manual
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-e3cvb
SKU: DESK-E3CVB/C/D/N/W Controller
[email protected]om www.vivo-us.com 309-278-5303
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2 3
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualified technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or
inappropriate use.
Reset Mode
If the desk must be reset, first lower the desk until it stops, then restart the system by unplugging for at
least 5 seconds and plugging back in. Press and hold the down button until “RES” is displayed. Continue
holding until the desk lowers completely, then moves up slightly.
WARNING!
ELECTRICAL SAFETY INSTRUCTIONS
THIS PRODUCT IS POWERED BY ELECTRICITY. IN ORDER TO AVOID BURNS, FIRE AND ELECTRIC
SHOCK, PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY.
• DO NOT CLEAN PRODUCT WHILE POWER IS CONNECTED.
• DO NOT DISASSEMBLE OR REPLACE COMPONENTS WHILE POWER IS CONNECTED.
• NEVER OPERATE THE SYSTEM WITH A DAMAGED CORD OR PLUG. PLEASE CONTACT YOUR
SELLER TO REPLACE DAMAGED PARTS.
• NEVER OPERATE SYSTEM IN DAMP ENVIRONMENTS OR IF ANY ELECTRICAL COMPONENTS HAVE
MADE CONTACT WITH LIQUIDS.
• ALTERATIONS OF THE GIVEN POWER UNIT ARE NOT ALLOWED.
• OUTDOOR USE IS PROHIBITED.
OPERATING INSTRUCTIONS: When the system is powered on, the existing desktop height will be
displayed on the control panel.
Upward and Downward Movement
Press and hold the up or down arrow until the desk reaches the desired height.
Memory Mode
To store a certain height in the controller’s memory, first press “S”. The interface will flash. Now press “1”,
“2” or “3”. Release the button to store the current height in memory. Each number can store a dierent
height. Once in memory, you can recall any of the three height settings by pressing the corresponding
button.
Power-Saving Mode
When no actions are made for over 30 seconds, the system will enter power-saving mode, touch any
button to enter operation mode.
Switch the Displayed Unit of Measurement
The preset measurement shown on the display is cm. If you would like to change cm to inch, press and
hold the "S" button for 5 seconds until "S--" begins to flash on the display. Press "S" again until "Un" is
displayed. Press "S" to select. Press the up or down arrow to select "SI" (metric), or "In" (imperial). Hold
"S" for 2 seconds to save the setting.
Collision Force Detection (CF)
Long press the "S" button until “S--”shows and flashes. Press "S" button again for the display to show
“Un”. Press the up or down arrow to switch “CF”. Press "S" button to select. Press the up or down arrow to
switch between “OFF”, Low (L), Normal (N) or Heavy (H) Collision Force Detection. Press "S" button to
save your choice.
NOTES
• If you install a new control panel, you must perform a reset for the desk to function properly
• Over-current protection mode: While operating, should the load on the desk exceed rated
specifications, the system will enter into over-current protection mode to protect the system
from damage. When this happens, the desk will move downward approximately 30mm and
come to a stop with the current height displayed.
• Do NOT remove or reconnect power to reset the unit when in a protective or “HOT” state, as
this may damage the electronics.
OPERATING CONTROL PANEL
TROUBLESHOOTING
HOT
E10
Let the desk rest for at least 20 minutes before operating.
Signal Loss. Method 1: Perform a reset operation. Method 2: Disconnect desk power,
disconnect the motor, reconnect the motor, then reconnect power.
E20 Desk weight limit exceeded. Decrease desk load before operating. If error appears aer
reducing weight, the AC adapter may need to be replaced.
E02
E31
E32
Obstacle protection. Desk will automatically move back 4cm aer collision
Low voltage alarm. The voltage is lower than required to power the desk. Check the
connection between the AC adapter and power cable.
High voltage alarm.The voltage is higher than required to power the desk,Check the
connection between the AC adapter and power cable
Error Code Description/Resolution

LAST UPDATED: 11/04/2022
REV1
