vollara CLASSIC AIR User manual

CAUTION: Read manual carefully for proper
procedures and operation.
USER’S MANUAL
100, 110, and 220 Volt Systems
Installation | Operation | Specifications | Warranty
CLASSIC
AIR ELECTRONIC AIR PURIFICATION

2
CONTENTS
Notable Features ...................................................... 3
Specifications ........................................................ 3
Principles of Operation ................................................ 4
Pre-Installation / Inspection ............................................ 4
Purification Plate/Lint Screen Install .................................... 5
Placing the Unit ....................................................... 6
Setting/Adjusting Controls ............................................. 7
Maintenance ......................................................... 8
Troubleshooting ....................................................... 9
Warranty ............................................................. 12
Please record the serial number of your ClassicAir:
Serial # ______________________________________________________________
Please record the name and phone of your Vollara Independent Business Owner:
Name _______________________________________________________________
Phone _______________________________________________________________
To reduce the risk of electric shock, this equipment has a grounding type plug that has a
third (grounding) pin. This plug will only fit into a grounding type power outlet. If the plug
does not fit into the outlet, contact qualified personnel to install the proper outlet. Do not
alter the plug in any way.
WARNING! - Do not operate this unit without one or all purification plate(s) properly
installed. Doing so may void the warranty.
CAUTION! - Disconnect power cord before servicing.
100 and 110 volt models - use 1.0 Amp slow blow fuse.
220 volt models - use 0.5 Amp slow blow fuse.
Location for Protective Earth Line.

3
NOTABLE FEATURES
• Compact • Portable • No Duct Work Required
• No Chemicals • Low Maintenance • Low Electrical Use
• Complete User Control • No Residual Contamination
• Plugs into 110 (100 or 220) volt outlet
SPECIFICATIONS
• Positive/Negative Ion Generation Technology
• Ozone Generation
Features:
• Adjustable fan speed control
• Washable lint screen filter
• Adjustable ozone control
Electrical:
• 100 volt 50/60Hz, 110 volt 60Hz, or 220 volt 50Hz AC line
operation depending on model
• 30 watts power consumption
• 24 to 30 KV, 20-30 Khz ion generation pulsator
• Fixed 6 KV DC needle ion generator
Mechanical:
• 400 CFM fan
Size:
• Height: 11"; Width: 8"; Depth: 9 3/4"
• Weight: 19 pounds
Ozone Output:
• 0-360 mg per hour

4
PRINCIPLES OF OPERATION
Nature cleanses the air with lightning and rain. Lightning bolts produce ozone, as well as
positive and negative ions which cleanse the air naturally. Rain helps bring the ozone and
ions closer to the earth's surface. They are then attracted to atmospheric contaminants
that are either removed from the air and attached to grounded objects or are oxidized.
The ClassicAir reproduces the natural conditions found in the outdoors. It is not
designed to create an artificial environment. The re-establishment of a natural
environment takes place out in the air, rather than inside the unit. It changes the quality
of the air, rather than filtering it, masking the symptoms, or attempting to dilute it.
PRE-INSTALLATION AND INSPECTION
1. Remove unit from shipping carton
2. Remove all protective materials
3. Check for shipping damage and loose or broken parts
4. Read Owners Manual thoroughly prior to installation
5. Remove purification plate from the box and install
6. OPTIONAL: Plug the unit into a 110 volt (100 or 220 volt) outlet, place in shipping box
with unit on and purifier knob set to maximum for at least one hour to remove traces
of manufacturing odor.
7. Determine placement location for the unit with best air flow. Plug the unit into 110 volt
(100 or 220 volt) outlet and adjust controls according to the application.
Lint Screen
Power
Switch
Power Cord
Purifier Control Fan Control
Front Grill
Fuse
Normal/Low Switch
(100 & 110 volt models
only)

PURIFICATION PLATE
INSTALLATION
The ClassicAir utilizes one
purification plate.
1. Rotate the Lint Screen retainer out of the way.
2. Remove the Lint Screen.
3. Fully insert purification plate (a) between the
guide-grooves in the top and bottom of the plate
cage (between the posts and clips) making sure
the metal clip on each side of
the plate is in contact with the metal screen on
the plate.
4. Reinstall Lint Screen as shown below.
LINT SCREEN INSTALLATION
1. Always install bottom of Lint Screen first.
2. The Lint Screen tab should depress the safety
switch arm towards the bottom of the unit.
Unit will not operate if safety switch is not
depressed.
3. Fit top of Lint Screen into cabinet.
4. Secure with retainer.
5
Filter
Ta b
1
2,3
4
3
2
1

6
PLACING THE UNIT
Place the unit as high as possible to insure
complete purification.
If raised placement is not available, place unit
as high as possible and elevate front of unit
so fan blows towards ceiling. Some pollutants
rise, such as smoke, and an elevated unit
can oxidize the pollutants more effectively. A
ceiling fan can also aid in distribution of air.
The ClassicAir is most effective when placed
in a position that allows the ions and ozone
to be mixed evenly and thoroughly with the
polluted air.
Suggested locations listed in the order
of preference:
1. Nearest the source of the worst pollution.
2. Near a cold air return to thoroughly circulate the benefits of ClassicAir
throughout the area.
3. In the area most heavily used to achieve maximum effectiveness.
Note:
• For maximum control the unit should be placed where easy access to the
controls is possible.
• The rear of the unit should always have at least one inch of open area to allow
unrestricted airflow.
• Be sure power cord is not accessible to small children to prevent injury.
EcoHelp HEPA-LIKE FILTRATION
With the optional EcoHelp on the unit, ClassicAir placed in
a room will remove vast amounts of pollen quickly, allowing
the user some immediate benefit in that room, while
keeping the unit clean. The same holds true for dust, and
the mites riding on that dust. In a smaller confined area,
EcoHelp can give faster results.
EcoHelp Item # 70233

SETTING AND ADJUSTING CONTROLS
1. FAN CONTROL
The disbursement of treated air is best accomplished with good air circulation. The FAN
control should be set as high as reasonably possible without creating an undesirable
noise level. This will be determined by personal preference and the distance you wish the
cleansing properties to be dispersed.
Note: A ceiling fan can also aid in distribution of cleansing properties.
2. PURIFIER CONTROL
PURIFIER control: Set the control at the nine o'clock position for one hour.
Adjust the PURIFIER control up or down after one hour based on the
following criteria:
1. In normal conditions, it is not necessary to turn the PURIFIER control indicator above
the square footage of the environment.
2. Keeping in mind the previous statement (#1), adjust the purifier so that the scent of
ozone fades into the background 15-30 seconds after entering the environment.
3. NORMAL/LOW SWITCH (100 & 110 volt models only)
For better purifier control in small areas (under 300 square feet), set the NORMAL/LOW
switch to LOW. The purifier output will be effective for 1/10th of the area indicated by the
current purifier control setting (for example: 3000 sq. ft. setting = 300 sq. ft. coverage).
For all other applications, set the switch to NORMAL.
4. REDUCING CONTAMINANTS IN AN AREA
7
For maximum effectiveness in reducing
contaminants in an unoccupied area, turn the unit
on high for 3-4 hours.
Caution: Always be sure a room or area is
UNOCCUPIED before performing the above
described procedure. “Unoccupied areas”
includes pets. Some pets, like humans, may
experience adverse reactions from exposure
to increased levels of ozone and should not be
present during this procedure
Air out room by opening a door and/or window.
Purifier
Control
Fan
Control
Normal/Low
Switch
(100 & 110 volt
models only)

8
MAINTENANCE
Periodic maintenance is required to insure that the ClassicAir operates properly. A
severely polluted environment can foul a purification plate in as little as two weeks or
as long as a year. Shown here are basic maintenance procedures that should be carried
out to keep your unit running at top performance.
CAUTION: Disconnect power before performing any maintenance procedures.
Lint Screen Cleaning:
You have two options to clean the lint screen:
• When visibly dirty, simply remove the lint screen and with a hand-held vacuum
remove the heavy particulate from the screen. This method will extend the life of the
lint screen. -OR-
• When visibly dirty, remove the lint screen
from the back of the unit and wash in hot
water, brushing gently with a toothbrush
to remove particulate. Allow to dry prior to
reinstalling the lint screen.
Purifier Plate:
Remove the rear lint screen . Carefully
remove the purifier plate from the card cage
by grasping the middle of the edge nearest
to you, and slowly pull it straight out.
If you are in an environment where there are fats, oils, or grease, such as in a kitchen,
start by cleaning with denatured alcohol and a soft bristle brush. This will cut the
grease
without leaving a residue.
For all applications - Clean with a mixture of one part water and one part ammonia
to remove contaminants. Place the plate into a shallow dish and pour enough of the
water/ammonia solution into the dish to just cover plate. Allow the plate to soak for no
more than 10 minutes.
CAUTION: Damage may result from soaking the purifier
plate longer than 10 minutes.
Remove plate and scrub with a soft bristle brush. Rinse
thoroughly. Let air dry for 24 hours or use a blow dryer to dry
thoroughly.
Plate Card Cage
Also be sure to clean the white stand-offs at the corners of the
plate card cage. (A cotton swab with alcohol works well.)

9
TROUBLESHOOTING
Indicators of Operation
Operation of the ion indicator lamps:
Turn the unit on and check that the small red-orange lamp is illuminated. The lamp
is located inside the unit and is viewed by looking into the unit through the front
grill. Illumination of the internal lamp verifies that the frequency type ionizer and
needlepoint ionizer are functioning properly. The lamp should stay illuminated as long
as the unit is turned on.
REPLACING THE FUSE
A fuse holder is located on the back
of the unit next to the power cord. To
replace or check the fuse, unscrew
the fuse holder cap by turning it
counterclockwise then remove the cap
and fuse.
If the fuse is blown, replace with a new
slow blow type fuse. Insert the new fuse
into the fuse holder and replace the fuse
holder cap.
If the fuse holder cap is not installed
correctly, the unit will not operate.
Fuse
CAUTION! - Disconnect power cord before servicing.
100,110 volt models - use 1.0 Amp slow blow fuse.
220 volt models - use 0.5 Amp slow blow fuse
Fan Blade and Front Grill
Wipe off fan blade and front grill, if dirty, with damp washcloth. The fan requires no
maintenance (with the exception of the first time it is used, when it may be necessary
to give it a gentle push to get it started). If the fan squeaks, a drop of lightweight oil may
be needed on the fan shaft.

10
TROUBLESHOOTING - What to look for first.
1. I have plugged in the unit, turned "ON" the power switch, and nothing happens…
what's wrong?
• Make sure the electrical outlet is capable of providing power to the unit.
• Check the Lint Screen located at the back of the machine to ensure that the safety switch
activator clip depresses the safety switch.
• Check to see if the proper fuse is installed and that it is serviceable.
• Ensure that the fuse cap is completely seated and secured in its receptacle.
2. The fan is operating although the unit won't produce any ozone…what's wrong?
• Check the purification plate for serviceability. If it is cracked or broken, the plate will
require replacement. Ensure maintenance procedures required for the plate have been
performed according to the "Maintenance" section (page 8) of this Owner's Manual.
Order new plates from your Dealer.
• Electrical stainless steel contacts are not contacting the screen portion of the purification
plate. Inspect the unit for any loose connections.
• Do not attempt to disassemble the unit, due to the Limited Warranty of the product.
3. How am I able to know if the Frequency-Type Ionizer is working?
• Current models with the FT Ionizer system have a neon light bulb mounted on the base of
the FT antenna. When the power switch to the unit is turned ON, the neon light bulb will
illuminate, indicating that the FT Ionizer is functioning normally (see page 9, “Indicators of
Operation”).
4. The purification plate is making a noise, has a burning smell, and/or appears to arc or
spark. What is the problem?
• The purification plate is most likely cracked. Refer to the answers for question
# 2, as they apply to this question also.
5. What are the most typical application problems?
• Symptom: A belief that the proper equipment is placed in the environment and the
equipment appears unsuccessful.
Problem: Lack of air movement, improper placement of the unit.
• Symptom: Strong odors still remain within the environment after placement.
Problem: Lack of ozone, improper placement of the unit.
• Symptom: A strong odor of ozone is present within the environment.
Problem: Too much ozone accumulation within the environment, as a result of improper
purifier control setting, and/or lack of air movement.
•Symptom: Visual haze of smoke and/or particulate remain within the environment.
Problem: Lack of ionization and/or air movement.

11
6. Unit does not operate -
• Is the unit plugged in?
• Are you sure the outlet is active?
• Is the unit turned on?
• Is the lint screen installed properly to depress the safety switch downward?
7. Air flow is restricted or reduced -
• Is the unit properly placed away from objects that may obstruct air flow?
• Are the filter and fan housing clean?
If your unit fails to operate properly after performing troubleshooting, contact your Vollara
Independent Business Owner for further assistance, contact us at the address located on
the front of the manual, or visit www.vollara.com for additional technical support.
This equipment has been tested and found to
comply with the limits for Industrial, Scientific
and Medical Equipment (ISM), pursuant to
Part 18 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses,
and can radiate radio frequency energy, and if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio
or television, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the Dealer or an experienced radio/TV
technician for help.
FCC DECLARATION OF CONFORMITY
Name: Vollara
Model: ClassicAir
This device complies with Part 18
of the FCC Rules.
RESPONSIBLE PARTY
Vollara, LLC
5420 LBJ Freeway, Suite 1010
Dallas, TX 75240
Ph: [phone]
Signature:___________________________
Printed Name: Andy Eide
Title: Director of Product Engineering
Date: 1/02/10
Did you forget to register your ClassicAir?
By registering, you’ll activate your warranty, and your privacy is guaranteed. Just fill out
your warranty card and drop it in the mail.

Part No. 65-00375
LIMITED 3 YEAR WARRANTY
WHAT IS COVERED BY THIS
WARRANTY
We warrant the ClassicAir (excluding
filters) to the consumer, subject to
the conditions below, against defects
in workmanship or material, provided
that the products are returned to a
service location within the following
time periods:
• ClassicAir within three (3) year of
date of purchase.
INSTALLATION AND MAINTENANCE
REQUIREMENTS
This warranty is expressly conditioned
upon the following installations
and maintenance requirements: (i)
the ClassicAir must be installed in
accordance with the Owner’s Manual;
(ii) the ClassicAir must be used and
maintained in accordance with the
Owner’s Manual. Failure to meet any
of these requirements will void this
warranty. Servicing of your ClassicAir
by parties other than our authorized
representative and/or using parts
other than genuine parts will also void
this warranty.
HOW TO OBTAIN WARRANTY
SERVICE
Customer must contact our
Independent Business Owner and
provide proof of purchase within
the above time periods. We will
repair or replace and return the
product, without charge and within
a reasonable period of time, subject
to the conditions in the above
paragraphs, if its examination shall
disclose any part to be defective in
workmanship or material. If we, in our
discretion, are unable to repair the
product after a reasonable number
of attempts, we will provide either
a refund of the purchase price or a
replacement unit, at the company’s
option.
WHAT IS NOT COVERED BY THIS
WARRANTY
This product is intended for household
use only. Ordinary wear and tear
shall not be considered a defect in
workmanship or material. These
warranties do not apply to filters
nor for loss or damage caused by
accident, fire, abuse, misuse, improper
installation, modification,
misapplication, commercial use,
or by any repairs other than
those provided by our authorized
Service Center.
MISSING SERIAL NUMBERS
AND UNAUTHORIZED
CHANNELS
If a valid serial number is missing
from the product, the warranty
will be voided. Vollara products
are authorized for sale through
Vollara Independent Business
Owners only. Warranties are
voided if a product is purchased
through unauthorized channels,
this includes websites that are
not authorized to use Vollara’s
trademarked names, images
and logos as well as Internet
auction sites (e.g. ebay and
Craigslist). The only approved
Internet presence for Vollara
products is www.vollara.com. To
confirm warranty coverage prior
to purchasing a product, contact
Vollara at 800.989.2299 with the
serial number located on the back
of the unit.
EXCLUSION OF OTHER
WARRANTIES
AND CONDITIONS
EXCEPT AS PROVIDED HEREIN,
WE MAKE NO REPRESENTATION
OR WARRANTY OF ANY KIND.
ALL OTHER WARRANTIES OF
ANY KIND, EXPRESS OR IMPLIED,
ARE HEREBY EXPRESSLY
DISCLAIMED, INCLUDING
ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
LIMITATION OF LIABILITY FOR
SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES
WE SHALL NOT IN ANY
CASE BE LIABLE FOR
SPECIAL, INCIDENTAL
OR CONSEQUENTIAL
DAMAGES ARISING FROM
BREACH OF EXPRESSED
OR IMPLIED WARRANTIES,
CONDITIONS, GUARANTEES OR
REPRESENTATIONS, BREACH
OF CONTRACT, NEGLIGENCE
OR ANY OTHER LEGAL THEORY.
Such excluded damages include,
but are not limited to, loss of profits
or revenue, and loss of the use of
the product.
FOR U.S. APPLICATION ONLY
This warranty gives you specific
legal rights, and you may also have
other rights which vary from state
to state. Some states do not allow
limitations on warranties, or on
remedies for breach. In such states,
the above limitations may not apply
to you.
FOR CANADIAN APPLICATION
ONLY
Exclusion of Subsequent Owners:
Except as otherwise required
by applicable legislation, this
warranty is not transferable.
This warranty gives you specific
legal rights and you may also
have other rights which vary
from province to province. Some
provinces and territories do not
allow limitations on warranties, or
on remedies for breach. In such
provinces or territories, the above
limitations may not apply to you.
If any provision of this warranty
or part thereof is held by a court
of competent jurisdiction to be
invalid, illegal, or unenforceable, the
validity, legality and enforceability
of the remaining provisions or
parts thereof will not in any way
be affected or impaired within
the jurisdiction of that court. This
entire warranty shall continue to
be valid, legal and enforceable in
any jurisdiction where a similar
determination has not been made.
This warranty is provided by
Vollara, LLC
5420 LBJ Freeway, Suite 1010
Dallas, TX 75240.
SERVICE
Every effort is made to ensure
customers receive an up-to-date
instructions manual on the use
of our products; however, from
time to time, modifications to our
products may without notice make
the information contained herein
subject to alteration. For the latest
information, please visit our web
site.
CA_OM_65-00375-VA-00147-0510
