vollara FRESH AIR CUBE User manual

PURIFIES UP TO 1,500 SQUARE FEET
FRESH
AIRCUBE
READ MANUAL CAREFULLY FOR PROPER PROCEDURES AND OPERATION.
Electronic Air Purier

2
Congratulations on your new FreshAir Cube
Your FreshAir Cube comes with a detachable power cord (9950099)
and remote control (9950100).
________________________________________ ________________________________________
Vollara Independent Business Owner Name Phone Number
WELCOME

3
rear cover
front grill
control pad rear lter
power in
Meet your FreshAir Cube
INTRODUCTION

4
Where to put your FreshAir Cube
For best results, place your FreshAir Cube
as high up as possible, with at least 2 inches
of clearance on either side. You can also
place your FreshAir Cube in trouble areas
for extra eectiveness.
PLACEMENT
CAUTION: Do not operate the FreshAir Cube near heat source, open flames,
or combustible vapors or gases.

5
Plug power supply into the back
of the FreshAir Cube and into a
standard wall outlet.
POWER SUPPLY
Electrical:
• 100 - 240VAC
• 21 watts power consumption
• 3-speed fan
Size:
• Dimensions:
6.5” wide x 6.5” high x 7” deep
(16.5cm wide x 16.5cm high x 17.8cm deep)
• Weight: 2.99 lbs (1.36 kg)
SPECIFICATIONS
85203-CHN-001

6
CONTROL PAD AND LED LIGHTS
Red LED solid = Away Mode (returns to Normal Mode after 2 hours or user input is
detected, whichever comes rst)
Green LED solid = scalable ozone setting
The control pad is
conveniently located
on the right side of
your FreshAir Cube
on/o power
fan speed +
fan speed -
away mode
green & red LED

7
CAUTION: Away Mode is intended for unoccupied spaces only. Please be sure all
people and pets have vacated the area when Away Mode is in use.
Press the POWER button to turn the unit on and o.
Press the FAN buttons to adjust the 3 speed fan.
Push the “AWAY MODE” button once and the unit
will go into Away Mode.
Indicator light will be illuminated red.
Push the “AWAY MODE” button a second time and the
unit goes into the scalable ozone mode.
When the unit is in the scalable ozone mode, the
indicator light will be illuminated green.
Push the “AWAY MODE” button a second time and the unit goes into the scalable ozone mode.
When the unit is in the scalable ozone mode, the indicator light will be illuminated green.
In the scalable ozone mode, the FreshAir Cube unit will operate in a 20%-on, 80%-o mode, over
a one minute total cycle time. This means the unit will continuously cycle the ozone plate on, at
maximum output, for 12 seconds and then transition to ozone plate o for 48 seconds ... then repeat.
Push the button again, and the unit will revert to the “Normal” operation mode (ActivePure only).
Operating your FreshAir Cube
CONTROL PAD INFORMATION
control panel

8
The FreshAir Cube remote control gives you the convenience of control from anywhere in the
room. Before use, remove paper tab from the bottom of the remote. When replacing battery,
choose a 3 Volt lithium cell CR2025.
on/o power
Away Mode
+ fan speed
- fan speed
REMOTE CONTROL

9
Replacement parts
If your unit fails to operate properly or you have questions, contact your Vollara
Independent Business Owner for further assistance.
power cord
9950099
ActivePure® (RCI) Cell
9950097
remote control
9950100
rear lter
9950098
PARTS
shown with rear cover removed
purier plate
9950096

Caring for your FreshAir Cube
Upkeep
Periodically vacuum or wipe the front grill with
a soft towel. You can vacuum or wash the rear
lter in warm water and let dry completely before
reinstalling (replace if necessary). Wipe down the
outside with a damp (not wet) cloth. Reassemble
when nished.
MAINTENANCE
CAUTION: Always unplug the power cord from the back of your FreshAir Cube
before servicing. Removing cover may expose ultraviolet light source. To
protect against eye damage, always unplug before servicing.
NOTE: Improper maintenance or failure to maintain the FreshAir Cube according to
these instructions may damage the unit or cause the unit to operate incorrectly.
every month every year every 3 years part numbers
clean front grill
clean rear lter 9950098
clean purier plate 9950096
replace ActivePure (RCI) Cell 9950097
replace purier plate 9950096

How to change the cell
Unplug unit. (1) Remove the back panel screws and (2) back panel. (3) Press latches and (4)
unplug the power connector to the ActivePure®(RCI) Cell.
(5) Pull the ActivePure Cell straight out to remove. Reverse order to replace cell.
REPAIR AND UPKEEP
1
2
3
4
5
CAUTION: Always unplug the power cord from the back of your FreshAir Cube
before servicing. Removing cover may expose ultraviolet light source. To
protect against eye damage, always unplug before servicing.

REPAIR AND UPKEEP
How to change purier plate
Unplug unit. (1) Remove the back panel screws and (2) back panel.
(3) Press latches and (4) unplug the power connector to the purier plate.
(5) Remove the purier plate from its slot. Reverse order to replace purier plate.
1
2
3
4
5
CAUTION: Always unplug the power cord from the back of your FreshAir Cube
before servicing. Removing cover may expose ultraviolet light source. To
protect against eye damage, always unplug before servicing.

REPAIR AND UPKEEP
Unplug unit. (1) Remove the back panel screws and (2) back panel. (3 - 5) Remove the purier
plate from its slot. (6) Clean purier plate by wiping with a cotton swab dipped in denatured
alcohol. Allow purier plate to dry completely before reinstalling.
How to clean the purier plate
1
23
4
6
5
CAUTION: Always unplug the power cord from the back of your FreshAir Cube
before servicing. Removing cover may expose ultraviolet light source. To
protect against eye damage, always unplug before servicing.

DEEP CLEANING
How to disassemble your FreshAir Cube for cleaning
Unplug unit. (1) Remove back cover. (2) Remove ActivePure Cell (see page 11).
(3) Remove purier plate (see page 12). (4) Remove the four front grill screws and the front
grill. You can now access the inside of the unit and the fan for cleaning.
12
34
CAUTION: Always unplug the power cord from the back of your FreshAir Cube
before servicing. Removing cover may expose ultraviolet light source. To
protect against eye damage, always unplug before servicing.

LIMITED ONE (1) YEAR WARRANTY
Customer should not repackage and ship the FreshAir Cube unit due to
possibility of irreparable damage. For warranty service, please contact
Vollara Customer Service at 800.989.2299, or your Vollara Independent
Distributor, for the address of the nearest service center.
WHAT IS COVERED BY THIS WARRANTY
We warrant the FreshAir Cube to the Customer, subject to the
conditions below, against defects in workmanship or material, provided
that the products are returned to a service location within one (1) year
from the date of purchase.
INSTALLATION AND MAINTENANCE REQUIREMENTS
This warranty is expressly conditioned upon proper installation,
operation, cleaning and maintenance, all in accordance with the
User’s Manual. Failure to meet any of these requirements will void this
warranty. Servicing of your FreshAir Cube by parties other than our
authorized service center and/or using parts other than genuine parts
will also void this warranty.
HOW TO OBTAIN WARRANTY SERVICE
Customer must contact Vollara Customer Service and provide proof of
purchase within the above time period. We will repair or replace and
return the product, without charge and within a reasonable period of
time, subject to the conditions herein, if its examination shall disclose
any part to be defective in workmanship or material. If we, in our
discretion, are unable to repair the product after a reasonable number
of attempts, we will provide either a refund of the purchase price or a
replacement unit, at the company’s option.
WHAT IS NOT COVERED BY THIS WARRANTY
This product is intended for household use only. Ordinary wear and
tear shall not be considered a defect in workmanship or material.
These warranties do not apply to lters nor for loss or damage caused
by accident, re, abuse, misuse, improper installation, leaking,
modication, misapplication, commercial use or by any repairs other
than those provided by our authorized Service Center. This warranty is
non-transferable.
MISSING SERIAL NUMBERS & UNAUTHORIZED CHANNELS
If a valid serial number is missing from the product, the warranty will
be voided. Vollara products are authorized for sale through Vollara
Independent Distributors only. Warranties are voided if a product is
purchased through unauthorized channels. This includes websites that
are not authorized to use Vollara’s trademarked names, images and
logos as well as Internet auction sites (e.g. ebay and Craigslist). The only
approved Internet presence for Vollara products is www.vollara.com.
To conrm warranty coverage prior to purchasing a product, contact
Vollara at 800.989.299 with the serial number located on the back of
the unit.
EXCLUSION OF OTHER WARRANTIES & CONDITIONS
EXCEPT AS PROVIDED HEREIN, WE MAKE NO REPRESENTATION OR
WARRANTY OF ANY KIND. ALL OTHER WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, ARE HEREBY EXPRESSLY DISCLAIMED, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
LIMITATION OF LIABILITY FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES
WE SHALL NOT IN ANY CASE BE LIABLE FOR SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES ARISING FROM BREACH OF
EXPRESSED OR IMPLIED WARRANTIES, CONDITIONS, GUARANTEES
OR REPRESENTATIONS, BREACH OF CONTRACT, NEGLIGENCE OR ANY
OTHER LEGAL THEORY. Such excluded damages include, but are not
limited to, loss of prots or revenue, and loss of the use of the products,
and any loss caused by leaks or other water damage. This warranty is
provided by:
Vollara, LLC
300 East Valley Drive
Bristol, VA 24201.
SERVICE
Every eort is made to ensure customers receive an up-to-date
instructions manual on the use of our products; however, from time
to time, modications to our products may without notice make the
information contained herein subject to alteration. For the latest
information, please visit our website.
LIMITED ONE 1 YEAR WARRANTY
Customer should not repackage and ship the FreshAir Cube unit due to possibility of irreparable damage.
For warranty service, please contact your Independent Distributor or Vollara Customer Service for the address of the
nearest service center.

16
Name: Vollara, LLC
Model: FreshAir Cube
This device complies with
Part 18 of the FCC Rules.
RESPONSIBLE PARTY
Signature:________________________
Printed Name: Andy Eide
Title: Vice President, Product
Development & Manufacturing
Date: 10/15/2018
Vollara, LLC
300 East Valley Drive
Bristol, VA 24201
This equipment has been tested and found to
comply with the limits for Industrial, Scientic,
and Medical Equipment (ISM), pursuant to
Part 18 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses,
and can radiate radio frequency energy, and if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio
or television, which can be determined by
turning the equipment o and on, the user is
encouraged to try to correct the interference by
one or more of the following measures: Reorient
or relocate the receiving antenna. Increase
the separation between the equipment and
receiver. Connect the equipment into an outlet
on a circuit dierent from that to which the
receiver is connected.
Consult the Distributor or an experienced radio/
TV technician for help.
FCC DECLARATION OF CONFORMITY
65-00733 VA-01268
© 2018 Vollara, LLC. All Rights Reserved.
FAC_OM _65- 00733_VA-01268_1018
