Vuzix M400 Quickstart Guide
VR Expert [email protected]
Demkaweg 11 030 7116158
3555HW, Utrecht

In the box
●1x M400 Viewer with 1x
adjustable display screen
●1x Battery
●1x USB-A to USB-C power
cable
●1x USB-A to Micro USB cable
●1x M-Series Lens-less
frames
●1x Soft case for storage
Hardware
Vuzix M400 - Guide
Before you start
●Clean the viewer and battery with a damp
cloth and mild detergent if necessary. Do not
use all-purpose cleaners as these may
damage the seals and impair the water
resistance.
Back button
Center button
Front button
Camera
Flashlight
Recording
LED
Power Button
Touchpad
USB-C Port

How to put on the Vuzix M400
1. Take the M400 ‘viewer’ and put it on either the left side or right side of the
frame depending on which eye you would like to use. You do this by sliding
the mounting tail onto the temple mount on the frames.
2. Do the same thing with the battery but now on the opposite side of the
viewer.
3. Plug the USB-C to USB-C cable into the viewer and the battery to connect
them.
4. Press the button on the battery for 2 seconds to turn on the system.
5. Put on the Vuzix M400 if it is ready by lifting the cable over your head to your
shoulder, while putting the smart glasses on like a pair of glasses
How to connect Wi-Fi
QR code setup
1. Go to vuzix.com/wifiQR to create QR code from your phone or computer.
2. Open the scanner in the Vuzix M400.
3. Point the M400 at the phone or computer screen that is displaying the QR
code.
4. The Vuzix M400 is now connected to your Wi-Fi.
Manual setup
1. Go to settings at the main screen by going left or right with the front and
center button.
2. Click on Network & Internet with the back button.
3. Turn on Wi-Fi and it will automatically start searching for network.
4. Click on the network you want to connect with.
5. Fill in the password and confirm.
6. This can also be done by speech command.
Vuzix M400 - Guide
Mounting tail
Temple mount

Vuzix M400 - Guide
VR Expert Tips
How to install applications
1. Register your device by logging in to your Vuzix App Store account from the
computer or phone at vuzix.com/appstore.
2. Follow the instructions on the website
3. Once registered, you will see the serial number of your Vuzix M400 under your
account.
Application can be installed through the Vuzix App Store. The vuzix app Store will
install and manage applications through the OTA mechanism and will require Wi-FI
connectivity. (Visit www.vuzix.com/support)
How to use developers mode
1. Navigate to “System” from the main screen of your M400 device.
2. Go to “About glasses” and then “Build nummers”.
3. Tap on the build number 7 times
4. A new menu will now appear. Navigate to Settings-> System -> Developer
option
5. Scroll down until you see USB debugger mode and turn the switch on.
How to install by using own APK
1. Turn on developers mode. (See section above).
2. Disconnect to battery from the viewer.
3. Connect the viewer with the computer with an USB-C cable.
4. On the Vuzix M400, open Settings -> Connected devices -> USB and change
the mode to “Transfer files”. The Vuzix M400 should now appear on your
computer.
5. Drag the APK from your computer you would like to install to the virtual SD
card on the Vuzix M400.
6. Go back to the viewer and open Files from the main screen and locate the file
you copied.
7. Highlight the APK and click on it back button to install the application.

To do To say
Back Go back
Down Go down
Up Go up
Confirm Confirm
Scroll Scroll down/up
Stop the scrolling Stop
Cancel Cancel
More speech commands Speech commands
VR Expert tips
Navigation
To navigate: , Use the front and center button to go up and down, left and
right.
To confirm: Use the back button on the Vuzix M400 viewer.
To go back: double click with 2 fingers on the touchpad.
To scroll: swipe on the touchpad horizontally.
Speech commands
●To activate speech command, always start with “Hello Vuzix”.
●After that the most important commands are:
Vuzix M400 - Guide
