SPECIFICATIONS:
Direct steam, stainless steel, 2/3jacketed floor mounted steam
kettle, Vulcan-Hart Model No. ___________. Fully welded
hemispheric bottom kettle with type 304 stainless steel
jacket and lining (316 stainless steel liner, 20 & 40 gallon).
Jacket tested to 35 psi (2.4 kg/cm2). Counterbalanced hinged
stainless steel cover with drop down lift handle (60 - 100 gallon
spring assist). 2" compression tangent draw-off valve with
perforated strainer. Tubular stainless steel legs with flanged
feet. Operates with 5 psi (0.4 kg/cm2) through 35 psi
(2.4 kg/cm2) direct steam. Steam control assembly includes
nickel plated steam supply control valve, nickel plated
condensate return line strainer and steam trap.
NSF listed. Meets ASME code.
VDL SERIES
DIRECT STEAM FLOOR MOUNTED
STATIONARY 2/3JACKETED KETTLE
MODELS: VDL SERIES Direct Steam Floor Mounted Stationary 2/3Jacketed Kettle
■■VDL20 20 gallon capacity
■■VDL40 40 gallon capacity
■■VDL60 60 gallon capacity
■■VDL80 80 gallon capacity
■■VDL100 100 gallon capacity
STANDARD FEATURES
■Direct steam, stainless steel, 2/3jacketed floor mounted
steam kettle.
■Fully welded hemispheric bottom kettle with type 304 stain-
less steel jacket and lining. (316 stainless steel liner for 20 &
40 gallon models.)
■One piece counterbalanced hinged stainless steel cover with
drop down lift handle (60 - 100 gallon spring assist).
■2"compressiontangentdraw-offvalvewithperforatedstrainer.
■Faucet bracket.
■Tubular stainless steel legs with flanged feet.
■Operates with 5 psi (0.4 kg/cm2) through 35 psi (2.4 kg/cm2)
direct steam, includes safety valve.
■Steam control assembly includes nickel plated steam supply
control valve, nickel plated condensate return line strainer
and steam trap.
■One year limited parts and labor warranty.
OPTIONS
■■Spring assist cover (20 - 40 gallon).
■■Two-piece hinged cover.
■■3" compression draw-off valve with perforated strainer.
■■Correction facility package:
a. Security type tamper resistant fasteners with tack welds.
b. Stainless steel step cover over draw-off valve with chain.
c. Type 316 liner (60 - 100 gallon).
■■50 psi (3.4 kg/cm2) operation.
■■Second year extended limited parts and labor warranty.
ACCESSORIES
■■Contour measuring strip.
■■Perforated stainless steel basket assembly (single - 20 gal.)
(triple - 20 through 100 gallon).
■■Clean-up kit, includes draw-off brush, clean-up brush and
paddle scraper with 40" handle.
■■Stainless steel 48" whip.
■■Solid disk.
■■(12") (18" double jointed) single pantry faucet.
■■(12") (18" double jointed) double pantry faucet.
■■Double pantry washdown hose with 16" add-on faucet with
backflow preventer.
■■Double pantry washdown hose with backflow preventer.
■■Double pantry pot filler and backflow preventer.

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-31640 (6-05)
VDL SERIES
DIRECT STEAM FLOOR MOUNTED
STATIONARY 2/3JACKETED KETTLE
SERVICE CONNECTIONS:
Steam supply: 3/4" IPS (19 mm).
Condensate return: 1/2" IPS (13 mm).
NOTE:
•Dimensions which locate the above connections have a toler-
ance of + or -3" (+ or -77 mm).
•Installation of backflow preventers, vacuum breakers and
other specific code requirements is the responsibility of the
owner and installer. It is the responsibility of the owner and
installer to comply with local codes.
•This appliance is manufactured for commercial installation
only and is not intended for home use.
DIRECT STEAM DATA:
Steam supply to the kettles must:
1. Maintain a steady 13 psi flow under operating conditions.
2. Have a minimum flow (see chart) of dry steam.
3. Be adequately trapped to provide dry steam. (See ball float
trap.)
STEAM FLOW RATE AT 10 PSIG AT THE KETTLE
Fast Boil Medium Boil Slow Boil
lbs/hr kg/hr lbs/hr kg/hr lbs/hr kg/hr
20 gallon 48 22 32 15 24 11
40 gallon 88 40 70 32 44 20
60 gallon 132 60 105 48 66 30
80 gallon 179 87 127 58 96 44
100 gallon 191 81 143 65 110 50
BRIMFUL CAPACITIES (in 4 oz. servings):
Working capacity 70% to 80% of brimful depending on model.
80 quarts/20 gallons/76 liters/640 servings
120 quarts/40 gallons/152 liters/1,280 servings
160 quarts/60 gallons/227 liters/1,920 servings
240 quarts/80 gallons/303 liters/2,560 servings
400 quarts/100 gallons/379 liters/3,200 servings
MODEL CAPACITY A B C D E F(2") F(3") G(2") G(3") H J K
VDL20 20 gallons 21 18 37 22.75 16 12.75 14 17 16.5 25.88 59.75 17.5
76 liters 533 457 940 578 406 324 356 432 419 657 1518 445
VDL40 40 gallons 26 22.5 37 27.88 18.5 14.25 16.5 12.5 12 23.88 64.88 22.5
152 liters 660 572 940 708 470 362 419 318 305 606 1648 572
VDL60 60 gallons 29.5 26 40.5 31.38 17.75 15.5 17.25 12.5 12 24.69 72.88 25.75
227 liters 749 660 1029 822 451 394 438 318 305 627 1851 654
VDL80 80 gallons 33 28 40.5 34.75 19.5 17.5 19.25 10.5 10 23.88 75.25 29.25
303 liters 838 711 1029 883 495 445 489 267 254 606 1911 743
VDL100 100 gallons 35.5 30 44.5 37.25 20.75 17 19.25 12.5 12 26.63 81.75 31.75
379 liters 902 762 1130 946 527 432 489 318 305 676 2076 806
