35
Super Finish 23 Pro
Translation of the original operating instructions
GB
1Never bring ngers, hands or other body parts into contact with the spray jet!
Never point the spray gun at yourself, other persons or animals.
Never use the spray gun without spray jet safety guard.
Do not treat a spray injury as a harmless cut. In case of injury to the skin by coating material
or solvents, consult a doctor for quick and correct treatment. Inform the doctor about the
coating material or solvent used.
2The following points are to be observed in accordance with the operating manual
before every start-up:
1. Faulty units may not be used.
2. Secure a Wagner spray gun with the securing lever at the trigger guard.
3. Ensure earthing.
4. Check the permissible operating pressure of the high-pressure hose and spray gun.
5. Check all the connecting parts for leaks.
3Instructions for regular cleaning and maintenance of the unit are to be observed
strictly.
Observe the following rules before any work on the unit and at every working
break:
1. Relieve the pressure from the spray gun and high-pressure hose.
2. Secure a Wagner spray gun with the securing lever at the trigger guard
3. Switch the unit o.
WARNING!
Attention, danger of injury by injection!
Airless units develop extremely high spray pressures.
Ensure safety!

36
Super Finish 23 Pro
GB
CONTENTS
Contents
1 SAFETY REGULATIONS FOR AIRLESS SPRAYING 37
1.1 Flash point_________________________________ 37
1.2 Explosion protection_________________________ 37
1.3 Danger of explosion and re from sources of
ignition during spraying work _________________ 37
1.4 Danger of injury from the spray jet _____________ 37
1.5 Secure spray gun against unintended operation __ 37
1.6 Recoil of spray gun __________________________ 37
1.7 Breathing equipment as protection against
solvent vapors______________________________ 37
1.8 Prevention of occupational illnesses ____________ 37
1.9 Max. operating pressure______________________ 38
1.10 High-pressure hose _________________________ 38
1.11 Electrostatic charging
(formation of sparks or ames) ________________ 38
1.12 Use of units on building sites and workshops_____ 38
1.13 Ventilation when spraying in rooms ____________ 38
1.14 Suction installations _________________________ 38
1.15 Earthing of the object________________________ 38
1.16 Cleaning the unit with solvents ________________ 38
1.17 Cleaning the unit ___________________________ 38
1.18 Work or repairs at the electrical equipment ______ 38
1.19 Work at electrical components_________________ 38
1.20 Setup on an uneven surface___________________ 38
2 GENERAL VIEW OF APPLICATION ____________ 39
2.1 Application ________________________________ 39
2.2 Coating material ____________________________ 39
2.2.1 Coating materials with sharp-edged additional
materials __________________________________ 39
2.2.2 Filtering ___________________________________ 40
3. DESCRIPTION OF UNIT _____________________ 40
3.1 Airless process______________________________ 40
3.2 Functioning of the unit_______________________ 40
3.3 Explanatory diagram_________________________ 41
3.4 Adjusting the handle ________________________ 42
3.5 Technical data ______________________________ 42
4 STARTUP _________________________________ 43
4.1 Unit with suction system _____________________ 43
4.2 Unit with upper hopper ______________________ 43
4.3 High pressure hose and spray gun______________ 43
4.4 Connection to the mains network ______________ 43
4.5 Cleaning preserving agent when starting-up of
operation initially ___________________________ 44
4.6 Ventilate unit (hydraulic system) if the sound of
inlet valve is not audible______________________ 44
4.7 Taking the unit into operation with
coating material ____________________________ 44
5 SPRAYING TECHNOLOGY ___________________ 45
6 HANDLING THE HIGHPRESSURE HOSE _______ 46
7 INTERRUPTION OF WORK ___________________ 46
8 CLEANING THE UNIT _______________________ 47
8.1 Cleaning the unit from the outside _____________ 48
8.2 Suction lter _______________________________ 48
8.3 High-pressure lter __________________________ 48
8.4 Cleaning the Airless spray gun_________________ 49
9 SERVICING ________________________________ 49
9.1 General servicing ___________________________ 49
9.2 High-pressure hose__________________________ 49
10 REPAIRS AT THE UNIT ______________________ 50
10.1 Inlet valve _________________________________ 50
10.2 Outlet valve ________________________________ 51
10.3 Pressure control valve________________________ 51
10.4 Replacing the power cable ___________________ 52
10.5 Typical wear parts ___________________________ 52
10.6 Connection diagram_________________________ 53
10.7 Remedy in case of faults ______________________ 54
11 SPARE PARTS AND ACCESSORIES ____________ 55
11.1 Super Finish 23 Pro accessories ________________ 55
11.2 Spare parts list Super Finish 23 Pro _____________ 60
11.3 Spare parts list high-pressure lter _____________ 62
11.4 Spare parts list hopper _______________________ 62
11.5 Spare parts List Trolley _______________________ 63
11.6 Spare parts list suction system ________________ 63
Testing of the unit ________________________________ 64
Important information on product liability_____________ 64
Note on disposal__________________________________ 64
Guarantee declaration _____________________________ 64
CE - declaration___________________________________ 65
European service network _________________________ 132

37
Super Finish 23 Pro
GB
1 SAFETY REGULATIONS FOR
AIRLESS SPRAYING
All local safety regulations in force must be observed.
The following sources are just a sample of those containing
safety requirements for Airless spraying.
a) The European Standard„Spray equipment for coating ma-
terials – safety regulations„ (EN 1953).
The following safety regulations are to be observed in order
to ensure safe handling of the Airless high-pressure spraying
unit.
1.1 FLASH POINT
Only spray coating materials with a ash point
of 21 °C or higher.
The ash point is the lowest temperature at
which vapors develop from the coating ma-
terial. These vapors are sucient to form an
inammable mixture over the air above the
coating material.
1.2 EXPLOSION PROTECTION
Do not use the unit in work places which are
covered by the explosion protection regula-
tions. The unit is not designed to be explo-
sion protected. Do not operate the device in
explosive areas (zone 0, 1 and 2). Explosive ar-
eas are, for example, places where paints are
stored and locations in direct proximity to the
object being sprayed. Keep the device at least
3 m from the object you are spraying.
1.3 DANGER OF EXPLOSION AND FIRE FROM
SOURCES OF IGNITION DURING SPRAYING
WORK
There must be no sources of ignition such as,
for example, open res, lit cigarettes, cigars or
tobacco pipes, sparks, glowing wires, hot sur-
faces, etc. in the vicinity.
1.4 DANGER OF INJURY FROM THE SPRAY JET
Attention, danger of injury by injection!
Never point the spray gun at yourself, other
persons or animals.
Never use the spray gun without spray jet
safety guard.
The spray jet must not come into contact
with any part of the body.
In working with Airless spray guns, the high
spray pressures arising can cause very dan-
gerous injuries. If contact is made with the
spray jet, coating material can be injected
into the skin. Do not treat a spray injury as a
harmless cut. In case of injury to the skin by
coating material or solvents, consult a doctor
for quick and correct treatment. Inform the
doctor about the coating material or solvent
used.
1.5 SECURE SPRAY GUN AGAINST UNINTENDED
OPERATION
Always secure the spray gun when mounting or dismounting
the tip and in case of interruption to work.
1.6 RECOIL OF SPRAY GUN
When using a high operating pressure, pull-
ing the trigger guard can eect a recoil force
up to 15 N.
If you are not prepared for this, your hand can
be thrust backwards or your balance lost. This
can lead to injury.
1.7 BREATHING EQUIPMENT AS PROTECTION
AGAINST SOLVENT VAPORS
Wear breathing equipment during spraying work.
A breathing mask is to be made available to the user.
SAFETY REGULATIONS
1.8 PREVENTION OF OCCUPATIONAL ILLNESSES
Protective clothing, gloves and possibly skin protection cream
are necessary for the protection of the skin.
Observe the regulations of the manufacturer concerning coat-
ing materials, solvents and cleaning agents in preparation,
processing and cleaning units.

38
Super Finish 23 Pro
GB
SAFETY REGULATIONS
1.9 MAX. OPERATING PRESSURE
The permissible operating pressure for the spray gun, spray
gun accessories, unit accessories and high-pressure hose
must not fall short of the maximum operating pressure of 25
MPa (250 bar or 3625 psi).
1.10 HIGHPRESSURE HOSE
Attention, danger of injury by injection! Wear
and tear and kinks as well as usage that is not
appropriate to the purpose of the device can
cause leakages to form in the high-pressure
hose. Liquid can be injected into the skin
through a leakage.
High-pressure hoses must be checked thoroughly before
they are used.
Replace any damaged high-pressure hose immediately.
Never repair defective high-pressure hoses yourself!
Avoid sharp bends and folds: the smallest bending radius
is about 20 cm.
Do not drive over the high-pressure hose. Protect against
sharp objects and edges.
Never pull on the high-pressure hose to move the device.
Do not twist the high-pressure hose.
Do not put the high-pressure hose into solvents. Use only
a wet cloth to wipe down the outside of the hose.
Lay the high-pressure hose in such a way as to ensure that
it cannot be tripped over.
Only use WAGNER original-high-pressure
hoses in order to ensure functionality, safety
and durability.
1.11 ELECTROSTATIC CHARGING FORMATION OF
SPARKS OR FLAMES
Electrostatic charging of the unit may occur
during spraying due to the ow speed of
the coating material. These can cause sparks
and ames upon discharge. The unit must
therefore always be earthed via the electrical
system. The unit must be connected to an
appropriately-grounded safety outlet.
An electrostatic charging of spray guns and the high-pressure
hose is discharged through the high-pressure hose. For this
reason the electric resistance between the connections of the
high-pressure hose must be equal to or lower than 1 MΩ.
1.12 USE OF UNITS ON BUILDING SITES AND
WORKSHOPS
The unit may only be connected to the mains network via a
special feeding point with a residual-current device with INF
≤ 30 mA.
1.13 VENTILATION WHEN SPRAYING IN ROOMS
Adequate ventilation to ensure removal of the solvent vapors
has to be ensured.
1.14 SUCTION INSTALLATIONS
The are to be provided by the unit user in accordance with the
corresponding local regulations.
1.15 EARTHING OF THE OBJECT
The object to be coated must be earthed.
(Building walls are usually earthed naturally)
1.16 CLEANING THE UNIT WITH SOLVENTS
When cleaning the unit with solvents, the
solvent should never be sprayed or pumped
back into a container with a small opening
(bunghole). An explosive gas/air mixture can
arise. The container must be earthed.
1.17 CLEANING THE UNIT
Danger of short-circuits caused by water in-
gression!
Never spray down the unit with high-pres-
sure or high-pressure steam cleaners.
1.18 WORK OR REPAIRS AT THE ELECTRICAL
EQUIPMENT
These may only be carried out by a skilled electrician. No li-
ability is assumed for incorrect installation.
1.19 WORK AT ELECTRICAL COMPONENTS
Unplug the power plug from the outlet before carrying out
any repair work.

39
Super Finish 23 Pro
GB
SAFETY REGULATIONS/ GENERAL VIEW OF APPLICATION
2 GENERAL VIEW OF APPLICATION
2.1 APPLICATION
SF 23 Pro is an electric driven unit for the airless atomization of
dierent painting materials. Also it is able to feed the internal
feeded paint roller, which is available as accessory.
SF 23 Pro is made for jobs in the workshop and on the build-
ing site.
The SF 23 Pro’s device output is designed so that dispersions
can be processed indoors and outdoors for small to medium-
sized objects.
When painting, the device is suitable for all kinds of typical
painting jobs, e.g.:
doors, door frames, balustrades, furniture, woodencladding,
fences, radiators (heating) and steel parts.
We recommend using the top container for paintwork.
2.2 COATING MATERIAL
Diluting lacquers and paints or those containing solvents, two-
component coating materials, dispersion and latex paints.
No other materials should be used for spraying without WAG-
NER‘s approval.
Pay attention to the Airless quality of the
coating materials to be processed.
The unit is able to process coating materials with up to
20,000 mPas. If highly viscous coating materials cannot be tak-
en in or the performance of the unit is to low, the paint must
be diluted in accordance with the manufacturer‘s instructions.
Attention: Make sure, when stirring up with
motor-driven agitators that no air bubbles
are stirred in. Air bubbles disturb when spray-
ing and can, in fact, lead to interruption of
operation.
2.2.1 COATING MATERIALS WITH SHARPEDGED
ADDITIONAL MATERIALS
These particles have a strong wear and tear eect on valves
and tips, but also on the heating hose and spray gun. This im-
pairs the durability of these wearing parts considerably.
1.20 SETUP ON AN UNEVEN SURFACE
The front end must always point downwards in order to avoid
sliding away.
If possible do not use the unit on an inclined surface since the
unit tends to wander through the resulting vibrations.

40
Super Finish 23 Pro
GB
GENERAL VIEW OF APPLICATION
2.2.2 FILTERING
Sucient ltering is required for fault-free operation. To this
purpose the unit is equipped with a suction lter (Item 1) and
an insertion lter in the spray gun (Item 2). Regular inspec-
tion of these lters for damage or soiling is urgently recom-
mended.
A high-pressure lter (Item 3) -available as accessory- is rising
up the ltering surface and will make the work more comfort-
able.
3. DESCRIPTION OF UNIT
3.1 AIRLESS PROCESS
The main area of application are thick layers of highly viscous
coating material.
At the SF 23 Pro unit a diaphragm pump takes in the coating
materials and transports it via a high-pressure hose to the
spray gun with the airless tip. Here the coating material at-
omizes since it is pressed through the tip core at a maximum
pressure of 25 MPa (250 bar, 3625 psi). This high pressure has
the eect of micro ne atomisation of the coating material.
As no air is used in this process, it is described as an AIRLESS
process.
This method of spraying has the advantages of nest atomisa-
tion, cloudless operation (depending of a correct unit adjust-
ment) and a smooth, bubblefree surface. As well as these, the
advantages of the speed of work and convenience must be
mentioned.
3.2 FUNCTIONING OF THE UNIT
The following section contains a brief description of the tech-
nical construction for better understanding of the function:
SF 23 Pro is an electrically driven high-pressure paint spraying
equipment.
The electric motor (1) drives the hydraulic pump via planetary
gears (2). A piston (3) is moved up and down so that hydraulic
oil is moved under the diaphragm (4) which then moves.
In detail:
The downwards movement of the machine opens the disk in-
let valve (5) automatically and coating material is sucked in.
During the upwards movement of the diaphragm, the coating
material is displaced and the outlet valve opens while the inlet
valve is closed.
The coating material ows under high pressure through the
high-pressure hose to the spray gun and is atomized when it
exists from the tip.
The pressure control valve limits the set pressure in the hy-
draulic oil circuit and thus also the pressure of the coating
material.
A pressure change when the same tip is used also leads to a
change in the amount of paint atomized.
13
5
4
2
1
2
3

41
Super Finish 23 Pro
6
1
2
3
7
9
10
8
4
5
12
9
14
11
4
15 16
13
GB
DESCRIPTION OF UNIT
3.3 EXPLANATORY DIAGRAM
1 Tip guard with airless tip*
2 Spray gun*
3 High-pressure hose*
4 Connection for high-pressure hose
5 Pressure gauge*
6 Pressure control valve
7 ON / OFF switch
8 Pressure relief valve
=
Spraying
=
Circulation
9 Return hose*
10 Suction hose*
11 Hopper*
12 Outlet valve
13 Oil dipstick
14 Cleaning Container
15 Hose bracket
16 Gun holder
17 Tool bag (no g.)
*Accessory. The actual scope of the delivery
depends on how the Spray Pack is congured.

42
Super Finish 23 Pro
GB
DESCRIPTION OF UNIT
3.4 ADJUSTING THE HANDLE
Swing the handle (1) upwards (the sleeves fall downwards and
secure the handle in the terminal position).
Push the sleeves (2) upwards in order to swing the handle
down again if necessary.
2
1
Transportation in vehicle
Secure the unit in the vehicle by means of suitable fasteners.
The device can be placed on its side if necessary. In this case,
please ensure that no attachments can be damaged. Atten-
tion: Paint or solvent residues can escape from the connec-
tions!
3.5 TECHNICAL DATA
Voltage : 230 -240 V AC, 50 Hz
Fuses : 16 A time-lag
Unit connecting line : 6 m long, 3 x 1.5 mm²
Max. current consumption: 7.0 A
Degree of protection : IP 54
Rated input of device: 1.3 kW
Max. operating pressure : 25 MPa (250 bar)
Max. volume ow : 2.6 l/min
Volume ow at 12 MPa
(120 bar) with water : 2.3 l/min
Max. temperature of the
coating material : 43 °C
Max. viscosity : 20,000 mPas
Empty weight : 27 kg
Hydraulic oil lling
quantity :
Hydraulics housing
Gears (grease)
1.3 liter
45 g
Max. vibration at the spraygun : lower than 2.5 m/s²
Max. sound pressure level: 75 dB (A)*
*Place of measurement: 1 m distance from unit and 1.60
m above oor, 12 MPa (120 bar) operating pressure,
reverberant oor

43
Super Finish 23 Pro
GB
STARTUP
4 STARTUP
4.1 UNIT WITH SUCTION SYSTEM
1. Ensure that the sealing surfaces of the connections are
clean.
Ensure that the red inlet (1) is inserted in the coating ma-
terial inlet (4).
2. Use the enclosed 41 mm wrench to screw the union nut
(2) at the suction hose (3) onto the coating material inlet
(4) and tighten it.
3. Screw the union nut (5) at the return hose (6) to the con-
nection (7) (22mm).
4.3 HIGH PRESSURE HOSE AND SPRAY GUN
1. Screw the high pressure hose (9) onto the hose connec-
tion
2. Screw the spray gun (10) onto the high pressure hose
3. Tighten all union nuts on high pressure hose so that no
coating material can escape.
4. Screw the tip holder with the selected tip onto the spray
gun, align tip and tighten union nut.
When unscrewing the high pressure hose,
hold rmly on the hose connection with a
22mm wrench.
4.2 UNIT WITH UPPER HOPPER
1. Ensure that the sealing surfaces of the connections are
clean. Ensure that the red inlet (1) is inserted in the coat-
ing material inlet (4).
2. Screw the union nut (5) on the return pipe (6) onto the
connection (7).
3. Screw the upper hopper (8) onto the coating material in-
let (4).
4.4 CONNECTION TO THE MAINS NETWORK
Connection must always be carried out via
an appropriately grounded safety outlet with
residual-current-operated circuit-breaker.
Before connecting the unit to the mains supply, ensure that
the line voltage matches that specied on the unit’s rating
plate.
Press the inlet valve inside the coating mate-
rial inlet (4) downwards before starting the
operation. This ensures that the valve is not
blocked or clogged.
1
4
2
3
5
6
7
1
4
5
6
7
8
99
10 10

44
Super Finish 23 Pro
GB
STARTUP
4.5 CLEANING PRESERVING AGENT WHEN
STARTINGUP OF OPERATION INITIALLY
Unit with suction tube
1. Immerse the suction system into a container lled with a
suitable cleaning agent (recommendation: water).
Unit with hopper
2. Fill up hopper with a suitable cleaning agent (recommen-
dation: water).
3. Set pressure relief valve (1) to ( circulation).
4. Switch the device on (Pos. I) using the ON/OFF switch (2).
5. Slowly turn the pressure regulating knob (3) to the right.
6. Wait until you can hear the sound of the inlet valve and
cleaning agent ows from the return hose.
7. Turn the pressure regulating knob (3) back approx. one
rotation.
8. Set pressure relief valve (1) to (spray).
Pressure is rising up inside the high pressure hose (visible
at pressure gauge (4)).
9. Point the tip of the spray gun to inner wall of an open and
empty metal container and pull the trigger at the spray
gun.
10. The pressure is increased by turning the pressure regulat-
ing knob (3) to the right. Set approx. 10 MPa (100 bar) at
the pressure gauge.
11. Spray the cleaning agent out of the unit for approx.
1 - 2 min. (~5 litres) into the open collecting container. 4.7 TAKING THE UNIT INTO OPERATION WITH
COATING MATERIAL
Unit with suction tube
1. Immerse the suction system into a container lled with
coating material.
Unit with hopper
2. Fill coating material into the hopper.
3. Set pressure relief valve (1) to ( circulation).
4. Switch the device on (Pos. I) using the ON/OFF switch (2).
5. Slowly turn the pressure regulating knob (3) to the right.
When the noise of the valves changes, the unit is bled and
takes in coating material.
6. If coating material exits from the return hose, turn the
pressure regulating knob (3) back approx. 1 rotation.
7. Set pressure relief valve (1) to (spray).
Pressure is rising up inside the high pressure hose (visible
at pressure gauge (4)).
8. Pull the trigger of the spray gun and spray into an open
and empty container in order to remove the remaining
cleaning agent from the unit. When coating materials ex-
its from the tip, close the spray gun.
9. Adjust the spraying pressure by turning the pressure reg-
ulating knob (3).
10. The unit is ready to spray.
4.6 VENTILATE UNIT HYDRAULIC SYSTEM IF THE
SOUND OF INLET VALVE IS NOT AUDIBLE
1. Switch the device on (Pos. I) using the ON/OFF switch (2).
2. Turn pressure regulating knob (3) approx. three revolu-
tions to the left.
3. Set pressure relief valve (1) to (circulation). The hy-
draulic system is ventilated. Leave the unit on for two to
three minutes.
4. Then slowly turn pressure regulating knob (3) to the right
until you can hear the sound of the inlet valve.
5. If not, repeat points 2 and 4
1
2
4
3
4

45
Super Finish 23 Pro
GB
SPRAYING TECHNIQUE / HANDLING THE HIGHPRESSURE HOSE / INTERRUPTION OF WORK
5 SPRAYING TECHNIQUE
•
The key to a high-quality result is the even coating of the
entire surface. Move your arm at a uniform speed and hold
the spray gun at a constant distance from the surface. The
ideal distance is around 30 cm between the spray nozzle and
the surface. (Fig. A)
•
Hold the spray gun parallel to the surface. Move the gun using
your entire arm, not just the wrist. (Fig. B)
•
Hold the spray gun at right angles to the surface. Otherwise the
coating will be thicker at one end than the other. (Fig. C)
•
Pull the trigger guard once you have started the movement.
Release the trigger again before you nish the movement.
(Fig. D) Avoid interruptions within the spray surface.
•
Allow each stripe to overlap by around 30%. This will ensure
even coating. (Fig. E)
•
Use the lowest possible pressure setting to create the desired
spray pattern in order to minimise spray mist.
•
To achieve perfect surfaces at varnishing works, special
accessories are available at Wagner, e.g. FineFinish tips. Your
Wagner dealer will advise you.
30 cm
A)
B)
C)
30 cm
30 cm30 cm
D)
30% overlap
E)

46
Super Finish 23 Pro
GB
SPRAYING TECHNIQUE / HANDLING THE HIGHPRESSURE HOSE / INTERRUPTION OF WORK
6 HANDLING THE HIGHPRESSURE
HOSE
The unit is equipped with a high-pressure hose specially suit-
ed for diaphragm pumps.
Danger of injury through leaking high-
pressure hose. Replace any damaged high-
pressure hose immediately.
Never repair defective high-pressure hoses
yourself!
The high-pressure hose is to be handled with care. Avoid sharp
bends and folds: the smallest bending radius is about 20 cm.
Do not drive over the high-pressure hose. Protect against
sharp objects and edges.
Never pull on the high-pressure hose to move the device.
Make sure that the high-pressure hose cannot twist. This can
be avoided by using a Wagner spray gun with a swivel joint
and a hose system.
When using the high-pressure hose while
working on scaolding, it is best to always
guide the hose along the outside of the scaf-
folding.
The risk of damage rises with the age of the
high-pressure hose.
Wagner recommends replacing high-pres-
sure hoses after 6 years.
Only use WAGNER original-high-pressure
hoses with internal heating in order to ensure
functionality, safety and durability.
7 INTERRUPTION OF WORK
1. Set pressure relief valve to (pressure relief, circulation).
2. Switch the unit o using the ON/OFF switch (Pos. 0).
3. Pull trigger of the spray gun to decrease the pressure of
the high pressure hose and the spray gun.
3. Secure the spray gun, refer to the operating manual of the
spray gun.
4. Remove tip from tip holder and store the tip in a small ves-
sel with suitable cleaning agent.
5. Leave the suction system immersed in the coating mate-
rial or immerse it in the corresponding cleaning agent.
The suction lter and unit should not dry out.
6. Cover the material container in order to prevent the paint
from drying.
In using quick-drying or two-component
coating materials, do not fail to rinse unit
through with a suitable cleaning agent dur-
ing the processing period.

47
Super Finish 23 Pro
GB
DISPLAYS AT THE UNIT / CLEANING THE UNIT
8 CLEANING THE UNIT
A clean state is the best method of ensuring operation with-
out problems. After you have nished spraying, clean the unit.
Under no circumstances may coating material rests dry and
harden in the unit. The cleaning agent used for cleaning (only
with a ash point above 21 °C) must be suitable for the coat-
ing material used.
Warm water improves the cleaning eect in
the case of water-dilutable coating materials.
• Secure the spray gun, refer to the operating manual of
the spray gun.
Remove and clean the tip and tip holder.
• Unit with suction system
1. Set pressure relief valve to (circulation).
2. Switch the device on (Pos. I) using the ON/OFF switch.
3. Remove the suction system from the material container.
The return pipe hose remains over the material container
until barely any coating material comes out.
4. Immerse the suction system into a container lled with a
suitable cleaning agent
5. Turn the pressure control valve back in order to set a mini-
mal spraying pressure.
6. Set pressure relief valve to (spray).
7. Pull the trigger of the spray gun in order to pump the
remaining coating material from the suction hose, high-
pressure hose and the spray gun into an open container (if
appropriate, increase the pressure at the pressure control
valve slowly in order to obtain a higher material ow).
The container must be earthed in case of
coating materials which contain solvents (e.g.
by using a metal container).
Caution! Do not pump or spray in container
with small opening (bunghole)!
See safety regulations.
8. Set pressure relief valve to (circulation).
9. Pump suitable cleaning agent in the circuit for several
minutes.
The cleaning eect is increased by alterna-
tively opening and closing the spray gun.
10. Set pressure relief valve to (spray).
11. Pump the remaining cleaning agent into an open contain-
er until the pump is empty.
12. Set pressure relief valve to (circulation).
13. Switch the unit o using the ON/OFF switch (Pos. 0).
• Unit with upper hopper
1. Set pressure relief valve to (circulation).
2. Switch the device on (Pos. I) using the ON/OFF switch.
3. Turn the pressure control valve back in order to set a mini-
mal spraying pressure.
4. Set pressure relief valve to (spray).
5. Pull the trigger of the spray gun in order to pump the re-
maining coating material from the hopper, high-pressure
hose and the spray gun into an open container (if appro-
priate, increase the pressure at the pressure control valve
slowly in order to obtain a higher material ow).
The container must be earthed in case of
coating materials which contain solvents (e.g.
by using a metal container).
Caution! Do not pump or spray in container
with small opening (bunghole)!
See safety regulations.
6. Fill up hopper with suitable cleaning agent.
7. Set pressure relief valve to (circulation).
8. Pump suitable cleaning agent in the circuit for several
minutes.
9. Set pressure relief valve to (spray).
10. Pump the remaining cleaning agent from the hopper,
high-pressure hose and the spray gun into an open con-
tainer
11. Set pressure relief valve to (circulation).
12. Switch the unit o using the ON/OFF switch (Pos. 0).

48
Super Finish 23 Pro
GB
CLEANING THE UNIT
8.1 CLEANING THE UNIT FROM THE OUTSIDE
First unplug the power plug from the outlet.
Danger of short-circuits caused by water
ingression! Never spray down the unit with
high-pressure or high-pressure steam clean-
ers.
Do not put the high-pressure hose into sol-
vents. Use only a wet cloth to wipe down the
outside of the hose.
Wipe down unit externally with a cloth which has been im-
mersed in a suitable cleaning agent.
8.2 SUCTION FILTER
Clean lters always ensure maximum volume,
constant spray pressure and problem-free
functioning of the unit.
Unit with suction system
1. Unscrew the lter (Item 1) from the suction tube.
2. Clean or replace the lter.
Carry out cleaning with a hard brush and a corresponding
cleaning agent.
8.3 HIGHPRESSURE FILTER
1. Set pressure relief valve to (pressure relief, circulation).
2. Switch the unit o using the ON/OFF switch (Pos. 0).
3. Open the high-pressure lter and clean the lter insert. To
do so:
4. Unscrew the lter housing (1) by hand.
5. Remove the lter insert (2) and pull out the bearing spring
(3).
6. Clean all the parts with the corresponding cleaning agent.
If compressed air is available – blow through the lter in-
sert and bearing spring.
7. When mounting the lter ensure that the bearing ring (4)
in the lter insert is positioned correctly and check the O-
ring at the lter housing for damage.
8. Screw on the lter housing by hand until it stops (a higher
tightening force only impedes later dismantling).
1
2
suction system hopper
Unit with hopper
1. Release screws with a screwdriver (Item 2).
2. Lift and remove lter disk with a screwdriver
3. Clean or replace the lter disk.
Carry out cleaning with a hard brush and a corresponding
cleaning agent.
1

49
Super Finish 23 Pro
GB
CLEANING THE UNIT / SERVICING
9.1 GENERAL SERVICING
We strongly recommend having an annual
check carried out by technicians for safety
reasons. Please observe all the applicable na-
tional regulations.
Minimum check before every startup:
1. Check the high-pressure hose, spray gun with rotary joint,
power supply cable with plug for damage.
2. Check whether the pressure gauge can be read.
Check at periodical intervals:
1. Check inlet and outlet valve according wear. Clean it and
replace worn out parts.
2. Check all lter inserts (spray gun, suction system) clean it
and replace if necessary.
9 SERVICING
9.2 HIGHPRESSURE HOSE
Inspect the high-pressure hose visually for any notches or
bulges, in particular at the transition in the ttings. It must be
possible to turn the union nuts freely. A conductivity of less
than
1 MΩ must exist across the entire length.
Have all the electric tests carried by the Wag-
ner Service.
The risk of damage rises with the age of the
high-pressure hose.
Wagner recommends replacing high-pres-
sure hoses after 6 years.
8.4 CLEANING THE AIRLESS SPRAY GUN
1. Rinse the Airless spray gun with a suitable cleaning agent
under lower operating pressure.
2. Clean the tip thoroughly with a suitable cleaning agent so
that no suitable coating material rests remain.
3. Do not store the tip in solvent because this reduces the
durability considerably.
4. Clean the outside of the Airless spray gun thoroughly.
1. Unclip the top of the trigger guard (1) from the gun head.
2. Using the bottom of the trigger guard as a wrench, loosen
and remove the handle assembly (2) from the gun head.
3. Pull the old lter (3) out of the gun head. Clean or replace.
4. Slide the new lter, tapered end rst, into the gun head.
5. Thread the handle assembly into the gun head. Tighten
with the trigger wrench.
6. Snap the trigger guard back onto the gun head.
Insertion lter in the Airless spray gun
1
3
2

50
Super Finish 23 Pro
GB
REPAIRS AT THE UNIT
10 REPAIRS AT THE UNIT
Switch the unit o.
Before all repair work: Unplug the power
plug from the outlet.
10.1 INLET VALVE
Disassembly
1. Place the enclosed 30 mm wrench on the housing (1).
2. Loosen the housing (1) with light blows of a hammer on
the end of the wrench.
3. Screw out the housing with the inlet valve (2) from the
paint section.
4. Pull of the clasp (3) using the enclosed screwdriver.
5. Place the enclosed 30 mm wrench on the inlet valve (2).
Turn out the inlet valve carefully.
6. Clean the valve seat (4) with a cleaning agent and brush
(ensure that no brush hairs are left behind).
7. Clean the seals (5, 6) and check for damage. Replace, if
necessary.
8. Check all the valve parts for damage. In case of visible
wear replace the inlet valve.
Installation
1. Insert the inlet valve (2) into the housing (1) and secure
with the clasp (3). Ensure that the (black) seal (5) is mount-
ed in the housing.
2. Screw the unit from the housing and the inlet valve into
the paint section. The same (black) seal (6) has to be
mounted in the paint section.
3. Tighten the housing with the 30 mm wrench and tight-
en with three light blows of the hammer on the end of
the wrench. (Corresponds to approx. 90 Nm tightening
torque).
1
3
2
5
6
4

51
Super Finish 23 Pro
GB
REPAIRS AT THE UNIT
10.3 PRESSURE CONTROL VALVE
Only have the pressure control valve (1) re-
placed by the customer service.
The max. operating pressure has to be reset
by the customer service.
1
10.2 OUTLET VALVE
1. Use a 22 mm wrench to screw the outlet valve from the
paint section.
2. Carefully remove the clasp (1) using the enclosed screw-
driver. The pressure spring (2) pushes out ball (4) and
valve seat (5).
3. Clean or replace the components.
4. Check the O-ring (7) for damage.
5. Check the installation position when mounting the spring
support ring (3) (clipped onto spring (2)), outlet valve seat
(5) and seal (6), refer to gure.
Please also pay particular attention to the following notes:
1. Use some light hammer blows on the end of the wrench
(20mm) to fully tighten outlet valve in the paint section
(this corresponds to approx. 90 Nm tighting torgue).
2. During normal operation, check regularly whether the
outlet valve has become loose.
3. Always also replace the seal (6) if you have dismantled the
outlet valve, regardless of which component you want to
replace. Note: The seal (6) is located unside the paint sec-
tion.
4. The groove in the seal (6) points outwards when replaced.
1
7
2
3456

52
Super Finish 23 Pro
GB
REPAIRS AT THE UNIT
10.4 REPLACING THE POWER CABLE
This may only be carried out by a skilled elec-
trician. No liability is assumed for incorrect
installation.
Switch the unit o.
Before all repair work: Unplug the power
plug from the outlet.
1. Remove the cover (1) by loosening the screws.
2. Loosen the cable threaded joint (2).
3. Loosen the wires (3).
4. Replace the unit connecting line.
(only an approved power cable with the designation H07-
RNF with a splash-proof plug may be used).
5. Connect the green/yellow wire to the contact with the PE
sign.
6. Remount the covers carefully (do not squeeze any cables!)
10.5 TYPICAL WEAR PARTS
Despite the use of high-quality materials the highly abrasive
eect of the paints means that wear can occur at the follow-
ing parts:
Inlet valve
For replacing refer to Section 10.1
(failure becomes noticeable through performance loss and/or
poor or no suction)
Outlet valve
For replacing refer to Section 10.2
(failure becomes noticeable through performance loss and/
or poor suction) The outlet valve is usually considerably more
durable than the inlet valve. Thorough cleaning may already
help here.
1
2
3

53
Super Finish 23 Pro
POWER CABLE 230V / 50Hz
TERMINAL STRIP
green/yellow
blue
light blue
brown
MOTOR
WITH TEMPERATURE SWITCH
M
1~
Z2 U2
OPERATION CAPACITOR
C = 25µF 400V
black
155°C
N
L
Z1
red
green/yellow
blue
black
N
MOTOR SWITCH 8A
b
U<
P1
P2 6
3
light blue
blue
black
340380
254518
254519
b
GB
REPAIRS AT THE UNIT
10.7 CONNECTION DIAGRAM
