WE-EF RMT320 LED User manual

WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Street and Area Lighting Luminaire
RMT320 LED
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.

1
IP66, IK09, Class I, ta = 40°C
Street and Area Lighting Luminaire
RMT320
(or ø 60 x 80)

2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-
pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO
Warning: Do not open luminaire while mains supply is switched on.

3
Installation
The product must be installed and maintained by a
VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW
building/construction and/or electrical regulations and
relevant legislation.
The supply cable must be installed inside the pole and
not be exposed to the outside environment.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
Attention: The luminaire is factory-sealed and does
not need to be opened during installation.
The installation on site must comply with local and/or
national health and safety regulations.
Installation Procedure
1) Switch off mains electrical supply.
2) Check that rating shown on luminaire label con-
forms with mains electrical supply.
3) Feed mains cable Cinto column G, while setting
luminaire in position by following the orientation
indicators M. Tighten all six screws H.
For 2-circuit version: Observe circuit indicator O
for L1 and L2.
4) Trim mains cable Cto the desired length and con-
nect the leads to their respective terminals at the
base of the pole:
a) ON/OFF (L = Phase, N = Neutral, = Earthing)
b) ON/OFF 2-circuits (L1 = Phase 1, L2 = Phase 2,
N = Neutral, = Earthing)
c) 1-10 V/DALI(L = Phase, N = Neutral, =
Earthing, DA/DA = DALI control line, D-/D+ = 1-10
V
control line).

4
Installation to a pole
L
N
Supply cable

5
direction of light
type of light distribution
*
*
Circuit L1*
Circuit L2*
*only for version with two circuits

www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LUMIERE
France
Tel [phone]
Fax [phone]
[e-mail]
WE-EF HELVETICA
Switzerland
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
Thailand
Tel [phone]
Fax [phone]
LQIRDVLDSDFLƂF#ZHHIFRP
WE-EF LIGHTING
Australia
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
United States of America
Tel [phone]
Fax [phone]
[e-mail]
TO9202W0620 © WE-EF 2020
7HFKQLFDOVSHFLƂFDWLRQVDUH
subject to change.
