WebGate 480L User manual

-16CH HDVR(480L) / 8CH HDVR(240M) / 4CH
HDVR(120H),
16CH HDVR(240C) / 8CH HDVR(240L)
Install & User’s Guide
English

Install&User Manual
1
Introduction
Thank you for purchasing a Hunt digital video recorder.
This manual is for 16CH HDVR(480L), 8CH HDVR(240M), 4CH HDVR(120H), 16CH
HDVR(240C), 8CH HDVR(240L). Before product installation and operation, please become
thoroughly familiar with this user manual and other manuals referenced by this manual.
This user manual and the software and hardware described here are protected by copyright law.
With the exception of copying for general use within fair use, copying and reprinting the user
manual, either partially or in entirety, or translating it into another language without the consent
of Hunt Inc. is strictly prohibited.
This specification may change without prior notice for improvement of product performance.
Product Warranty and Limits of Responsibility
The manufacturer does not assume any responsibility concerning the sale of this product and
does not delegate any right to any third party to take any responsibility on its behalf. The
product warranty does not cover cases of accidents, negligence, alteration, misuse or abuse.
No warranty is offered for any attachments or parts not supplied by the manufacturer.
 Malfunctions due to negligence by the user
 Deliberate disassembly and replacement by the user
 Connection of a power source other than a properly rated power source
 Malfunctions caused by natural disasters (fire, flood, tidal wave, etc.)
 Replacement of expendable parts (HDD, FAN, etc.)
※ The warranty period for the HDD and Fan is one year after purchase.
This product is not for exclusive use of crime prevention but for assistance in cases as
fire or theft. We take no responsibility for damage from any incident.

Install&User Manual
2
Caution
As this equipment undergone EMC registration and suitable for business purpose, distributors
and users are aware of this point.
FCC Compliance Statement
Caution : Any changes or modifications in construction of this device which are not expressly
approved the party responsible for compliance could void the user's authority to operate the
equipment.
NOTE : This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications, Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Warning
This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures
Warning
1. Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries
According to the Instructions
2. In case of changing built-in lithum battery, it should be replaced as same or kindred one to
prevent a danger of explosion. Since old batteries could be a factor of environment
contamination, be cautios to treat them.
3. Do not throw the batteries to fire or heating. Neither short circuiut or disassembly is
prohibited.
4. Do not charge the batteries provided with Remote Controller

Install&User Manual
3
Important Notice
1. Do not place heavy objects on the top of the product.
2. This equipment is indoor use and all the communication wiring are limited to inside of the
building
3. Product is for indoor use. It is not weatherproof. Use product with referring to its
environmental specifications (Temperature & Humidity). To clean the product, gently wipe the
outside with a clean dry cloth.
4. Product uses AC power of 110V ~ 240V. Be cautious not to cause electric damages to
product.
5. Be careful not to drop the product. Physical shocks may harm the product including internal
HDD. In addition, be sure the product is secured after installation.
6. Product is made of metal. Therefore you can hurt human beings if you throw it to them or hit
on them. When installing product, be cautious to locate on safe places where children are
unreachable.
7. If Product does not operate properly, please contact the closest WEBGATE distributor for
after sales service. Tampering or disassembling the product will void the warranty.
8. Security surveillance laws may differ for each country. Therefore, please contact the local
region first to avoid any surveillance law violations.
9. "Rack Mount Instructions - The following or similar
rack-mount instructions are included with the installation instructions:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the

Install&User Manual
4
operating ambient temperature of the rack environment may be greater than room ambient.
Therefore, consideration should be given to installing the equipment in an environment
compatible with the maximum ambient temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such that the amount
of air flow required for safe operation of the equipment is not compromised.
C) Mechanical Loading - Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideration should be given to the connection of the equipment to
the supply circuit and the effect that overloading of the circuits might have on overcurrent
protection and supply wiring. Appropriate consideration of equipment nameplate ratings
should be used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connections to
the branch circuit (e.g. use of power strips)."
Experience and technical skills are needed for the installation of this product as an improper
installation may cause fire, electric shocks, or defects. Any installation job should be performed
by the vendor you purchased this product from.
The content of this manual can differ according to firmware or Software upgrading, and the
standard and appearance of products may be changed for the improvement of quality without
an advance notice.

Install&User Manual
5
Contents
INTRODUCTION ............................................................................... 1
KEY FEATURES .............................................................................. 10
INSTALL MANUAL.......................................................................... 13
1. FEATURE .................................................................................... 13
1.1 Supplied Accessories .................................................................................................... 13
1.1.1. 16CH HDVR(480L)/8CH HDVR(240M)/4CH HDVR(120H) Series .......................... 13
1.1.2. 16CH HDVR(240C)/8CH HDVR(240L) Series ........................................................ 14
1.2. Description & Function .................................................................................................. 15
1.2.1. Front ...................................................................................................................... 15
1.2.2. Rear ...................................................................................................................... 19
1.2.3. REMOTE CONTROLLER ...................................................................................... 22
2. INSTALLATION ........................................................................ ２４
2.1 Installation and Connection ........................................................................................ ２４
2.1.1 Connecting & Running ........................................................................................ ２４
2.2 Running OSD menu................................................................................................... ２６
2.2.1 OSD menu configuration ..................................................................................... ２６
2.2.2 Setting remote controller ..................................................................................... ２７
2.2.3 Install examples .................................................................................................. ２８
2.2.4 Basic Setting ...................................................................................................... ３１
2.3 Connecting and configuring DIO ports........................................................................ ３５
2.3.4 HDD ................................................................................................................... ４６
2.3.5 Remote monitor and control ................................................................................ ４７
USER MANUAL ........................................................................... ４９

Install&User Manual
6
3 MENU USE .............................................................................. ４９
3.1 Menu Structure .......................................................................................................... ４９
3.2 Function Menu ........................................................................................................... ４９
3.3 Factory Reset ............................................................................................................ ５０
4 MONITORING .......................................................................... ５６
4.1 Basic Screen ............................................................................................................. ５６
4.2 Single Fll Screen Mode .............................................................................................. ５６
4.3 Multi Screen Mode ..................................................................................................... ５６
4.4 Screen Description .................................................................................................... ５７
4.5 Auto Switch Mode ...................................................................................................... ５７
4.5.1 System Standard Mode ...................................................................................... ５７
4.5.2 User Sequence Mode ......................................................................................... ５８
4.6 Event Screen ............................................................................................................. ５９
4.7 Zoom Screen Mode ................................................................................................... ６０
4.8 Pause Live Screen .................................................................................................... ６０
4.9 PTZ Control ............................................................................................................... ６１
4.9.1 Pan/Tilt .................................................................................................................... ６２
4.9.2 Zoom/Focus............................................................................................................. ６２
4.9.3 Load Preset ............................................................................................................. ６２
4.9.4 Save Preset ............................................................................................................. ６２
4.9.5 Auxiliary On ............................................................................................................. ６２
4.9.6 Auxiliary Off ............................................................................................................. ６３
4.9.7 Menu ....................................................................................................................... ６３
5 PLAYBACK ............................................................................. ６４

Install&User Manual
7
5.1 Playback Mode .......................................................................................................... ６４
5.1.1 Playback on Standard monitor (16 / 9 / 4 division) ............................................... ６４
5.1.2 Playback function ............................................................................................... ６４
5.2 SEARCH MODE ........................................................................................................ ６５
5.2.1 Time Search ....................................................................................................... ６５
5.2.2 Schedule Search ................................................................................................ ６５
5.2.3 Event Search ...................................................................................................... ６６
5.2.4 Thumbnail Search............................................................................................... ６７
5.3 Copy.......................................................................................................................... ６８
5.3.1 CD/DVD ............................................................................................................. ６８
5.3.2 RE4 .................................................................................................................... ６９
5.3.3 AVI ..................................................................................................................... ７０
6. CONFIGURATION .................................................................... ７２
6.1 Recording Structure ................................................................................................... ７２
6.2 System Setup ............................................................................................................ ７２
6.2.1 Date/Time ........................................................................................................... ７２
6.2.2 Disk .................................................................................................................... ７５
6.2.3 User Setup ......................................................................................................... ７７
6.2.4 Utility .................................................................................................................. ７９
6.3 Network ..................................................................................................................... ８１
6.3.1 xDSL .................................................................................................................. ８３
6.3.2 WRS ................................................................................................................... ８３
6.4 Device Setup ............................................................................................................. ８４
6.4.1 Camera Setup .................................................................................................... ８５
6.4.2 Monitor Setup ..................................................................................................... ８６
6.4.3 Audio Setup ........................................................................................................ ８７
6.4.4 Text Setup .......................................................................................................... ８８
6.4.5 Serial Setup ........................................................................................................ ８９
6.5 Event Setup ............................................................................................................... ９０
6.5.1 Event Check ....................................................................................................... ９１

Install&User Manual
8
6.5.2 Sync Event ......................................................................................................... ９２
6.5.3 Motion Detection ................................................................................................. ９４
6.5.4 Sensor ................................................................................................................ ９５
6.5.5 Preset ................................................................................................................. ９５
6.6 Recording setup ........................................................................................................ ９７
6.6.1 Program setup .................................................................................................... ９７
6.6.2 Manual/Schedule recording setup ....................................................................... ９９
7. WEB VIEWER ....................................................................１０３
7.1 System requriement............................................................................................... １０３
7.2 Login ..................................................................................................................... １０３
7.3 User Setup ............................................................................................................ １０４
7.4 Browser available .................................................................................................. １０４
7.5 Monitor .................................................................................................................. １０５
7.5.1 Screen division and changing video position ................................................... １０５
7.5.2 Move to Playback ........................................................................................... １０６
7.5.3 Channel On/Off ............................................................................................... １０７
7.5.4 Sensor Indication ............................................................................................ １０７
7.5.5 Relay opeartion .............................................................................................. １０７
7.5.6 Using microphone ........................................................................................... １０７
7.5.7 Event data ...................................................................................................... １０８
1.2.1. Video Recording & Save saving ...................................................................... １０８
7.5.8 Using PTZ ...................................................................................................... １０９
7.5.9 Using Audio .................................................................................................... １１０
7.5.10 Closing Video Channel ................................................................................... １１０
7.6 Playback................................................................................................................ １１１
1.2.2. Video Division & Changing Channel ................................................................ １１１
7.6.1 Image recording .............................................................................................. １１１
7.6.2 Printing ........................................................................................................... １１２
7.6.3 Backup ........................................................................................................... １１２
7.6.4 Web Monitor ................................................................................................... １１３

Install&User Manual
9
7.6.5 Channel On/Off ............................................................................................... １１３
7.6.6 Saving time & Checking Rec. Capacity ........................................................... １１３
7.6.7 Searching Calander ............................................................................................. １１３
7.6.8. Functional function at the buttom of monitor .................................................... １１４
8. USER MANUAL FOR MOBILE VIEWER .........................１１５
8.1 Log-In page ........................................................................................................... １１５
8.2 Monitoring page ..................................................................................................... １１５
TROUBLE SHOOTING .............................................................１１７
AVAILABLE HDD ......................................................................１１９
COMPATITABLE CD/DVD LIST ...............................................１２０
SPECIFICATION........................................................................１２０
-16CH HDVR(480L), -8CH HDVR(240M), -4CH HDVR(120H) .......................................... １２０
16CH HDVR(240C), 8CH HDVR(240L) ............................................................................ １２３
PRODUCT SIZE ........................................................................１２６

Install&User Manual
10
KEY FEATURES
Monitoring Screen
Supprots real live video with high resolution per each channel and variable display mode.
 Real H.264 Video
 Varianble display mode
-16CH HDVR(480L) : 1/4/9/10/16 channel mode
-8CH HDVR(240M) : 1/4/9 channel mode
-4CH HDVR(120H) : 1/4 channel mode
-16CH HDVR(240C) : 1/4/9/10/16 channel mode
8CH HDVR(240L) : 1/4/9 channel mode
 Auto Switching
-16CH HDVR(480L) : Composite x 2, DVI x 1
-8CH HDVR(240M) : Composite x 2, DVI x 1
-4CH HDVR(120H) : Composite x 2, DVI x 1
-16CH HDVR(240C) : Composite x 2, VGA x 1
- 8CH HDVR(240L) : Composite x 2, VGA x 1
Audio Recording
Supprots real-time audio input and recording
 Simultaneous 4ch audio input & recording available
 Input : 4Ch, Output : 1ch (Rear)
 Simultaneous audio recording and playback available

Install&User Manual
11
Recording
It supports max. 480ips/-16CH HDVR(480L), 240ips/-8CH HDVR(240M), -16CH
HDVR(240C), 120ips/8CH HDVR(240L), -4CH HDVR(120H) recording at High-Resolution
(H.264) and available to record max. 5 seconds before triggering an event. Also, convert
function is available protecing privacy.
 H.264 Video recording with High-Quality
-16CH HDVR(480L) : CIF(360x240) 480ips
-8CH HDVR(240M) : 2CIF(704x240) 240ips
-4CH HDVR(120H) : D1 (704x480) 120ips
-16CH HDVR(240C) : CIF(360x240) 240ips
- 8CH HDVR(240L) : CIF(360x240) 240ips
 Supprots manual & schedule recording
 Video loss detection
 Supprots archiving event list(Sensor, Video Loss,
Motion detection, Text)
 Available record Max 5 seconds before triggering an event per
each channel
Search/ Playback
It supports variable and convenient functions for search & playback
 Play back by time, date, Channel
 Easy and convenient search using mouse
 Pre/post search from a freeze frame
 Play back by Event (Sensor, Video Loss, Motion Detection, Text)
 Easy & convenient search using Remote Controller & Jog/
Shuttle (except -16CH HDVR(240C), 8CH HDVR(240L))

Install&User Manual
12
Back up device
It is available to backup to DVD-R, CD-R, USB memory by user’s choice.
(-16CH HDVR(240C), 8CH HDVR(240L) is available as an option.)
 Supprots various back up device : DVD-R, CD-R, USB memory
 Extention HDD Storage (External extention Storage device)
Network
It supports variable network like LAN, XDSL and easily control from remote site using PC
cliet viewer.
 E-mail notification thru. TCP/IP, DHCP in case of triggering an
event
 Live monitoring form remote site (Whole screen or available to
select quad screen)
 Available to playback, recording, search and DVR management
thru. network viewer in PC
 Available to record, search & playback by time from remote site.
 Supprots 10/100Mbps Ethernet/xDSL
 Multiple DVR connection
Etc.
 Supports User friendly GUI and mouse function
 Easy and simple firmware upgrade thru. USB memory
 Recorded data back up thru. USB port
 PTZ Control (SPEED DOME), PRESET fucntion
 Available to control up to 16 DVRs with one remote controller

Install&User Manual
13
Install Manual
1. Feature
1.1 Supplied Accessories
Unpack and check all the items as below
1.1.1. 16CH HDVR(480L)/8CH HDVR(240M)/4CH HDVR(120H) Series
AC Cord, Remocon, Setup CD, SATA Cable, HDD Fixing Screw, Quick Guide

Install&User Manual
14
1.1.2. 16CH HDVR(240C)/8CH HDVR(240L) Series
AC Cord, Remocon, Setup CD, SATA Cable, HDD Fixing Screw, Quick Guide

Install&User Manual
15
1.2. Description & Function
1.2.1. Front
1.2.1.1. 16CH HDVR(480L)/8CH HDVR(240M)/4CH HDVR(120H) Series Front
Item Description
1 DVD-Multi (For
Back up)
Back up use for recorded data by DVD/CD media
2 Channel Button To select video input channel
3
REC LED Displays recording status
COPY LED Displays copy status
HDD LED Displays HDD running.
NETWORK LED Displays network connection
EVENT LED Displays event detection
4 Power Turn on/ off power
5 USB port Use connecting USB memory or Mouse
6 REC To start or stop manual recording
7 Multi To change DVISION in live or playback mode
8 SEQ To run or stop user sequence
9 Copy To enter copy mode
10 Search To enter search mode
11 PTZ To start PTZ function or stop
12 Func To enter function mode
13 Relay Manual On/Off button for relay

Install&User Manual
16
14 Mon To change Monitor/ Stop
15 Menu To enter menu
16 ESC To escape from menu or close pop-up window
17
Enter/Play To enter playback mode or select menu
18 ◀/REW To move or select in menu and change replay speed to
reverse direction in playback mode
19 ▶/FWD To move or select in menu and change replay speed to
forward direction in playback mode
20 ▲/Pause To move or select in menu and pause live/ replay video
21 ▼/Stop To stop replay in playback mode
22 Jog/ Shuttle STEP function control, Playback direction change,
Playback speed control

Install&User Manual
17
1.2.1.2. 16CH HDVR(240C)/8CH HDVR(240L) Series Front
Item Description
1 DVD-Multi (For
Back up)
Back up use for recorded data by DVD/CD media
2 Channel Button To select video input channel
3
REC LED Displays recording status
COPY LED Displays copy status
HDD LED Displays HDD running.
NETWORK LED Displays network connection
EVENT LED Displays event detection
4 Power Turn on/ off power
5 USB port Use connecting USB memory or Mouse
6 REC To start or stop manual recording
7 Multi To change DVISION in live or playback mode
8 SEQ To run or stop user sequence
9 Copy To enter copy mode
10 Search To enter search mode
11 PTZ To start PTZ function or stop
12 Func To enter function mode
13 Relay Manual On/Off button for relay
14 Mon To change Monitor/ Stop
15 Menu To enter menu
16 ESC To escape from menu or close pop-up window
17
Enter/Play To enter playback mode or select menu

Install&User Manual
18
18 ◀/REW To move or select in menu and change replay speed to
reverse direction in playback mode
19 ▶/FWD To move or select in menu and change replay speed to
forward direction in playback mode
20 ▲/Pause To move or select in menu and pause live/ replay video
21 ▼/Stop To stop replay in playback mode

Install&User Manual
19
1.2.2. Rear
1.2.2.1. 16CH HDVR(480L)/8CH HDVR(240M)/4CH HDVR(120H) Series
REAR
번호
Input/ Output name Descrtiption
1 Ground Ground between DVR & external device
2 CH1~16 BNC input for camera connection
16CH HDVR(480L) : 16EA, 8CH HDVR(240M) : 8EA,
4CH HDVR(120H) : 4EA
3 Loop out BNC output(Loop) for camera connection
4 Monitor/ Spot BNC connection for monitor output
5 Audio Input(RCA) RCA connection for Audio input
6 Audio Output Speaker output terminal
7 Ethernet For network connection (RJ-45)
8 eSATA eSATA external storage connection
9 DVI OUTPUT Output for DVI monitor connection
10
RS-232C D-Sub Text equipment, Keyboard connection
11
Termination Ohm Termination Ohm for Com2, Com3
12
Relay/Serial Connection for Relay and Serial(RS-485)
13
Sensor IN Input for external sensor
