Frequency Inverter
CFW701 V1.2X
Addendum to the Programming and Troubleshooting Manual V1.2X

Addendum to the Programming and Troubleshooting
Manual V1.2X
Series: CFW701
Language: English
Document Number: 10001962167 / 00
Software Version: 1.25
Publication Date: 10/2012

Contents
CONTENTS
ABOUT............................................................................................................ 4
1. V1.25 CHANGES..................................................................................... 5
1.1. MODIFIED PARAMETERS..............................................................................................................5
1.2. CORRECTIONS TO THE MANUAL................................................................................................7

About
CFW701 | 4
ABOUT
This addendum presents the changes implemented on software version V1.25 compared to version V1.21 and
should be used with the CFW701 Programming and Troubleshooting Manual V1.2X.

V1.25 Changes
CFW701 | 5
1. V1.25 CHANGES
1.1 MODIFIED PARAMETERS
These parameter exist in version V1.21 but have its characteristics changed on version V1.25.
P0206 – Secondary Display Parameter Selection
A
djustable
Range:
0 to 1199
Factory
Setting:
3
Properties:
Access groups .HMI.. .
via HMI:
Description:
For details check the item “5.4 – HMI” on the Programming and Troubleshooting Manual V1.2X.
P0212 – Secondary Display Decimal Point
A
djustable
Range:
0 = wxyz
1 = wxy.z
2 = wx.yz
3 = w.xyz
4 = Reserved
5 = Reserved
6 = Reserved
7 = Reserved
Factory
Setting:
1
Properties:
Access groups .HMI... .
via HMI:
Description:
For details check the item “5.4 – HMI” on the Programming and Troubleshooting Manual V1.2X.
P0235 – AI1 Filter
P0240 – AI2 Filter
P0245 – AI3 Filter
A
djustable
Range:
0.00 to 16.00 s Factory
Setting:
0.15 s
Properties:
Access groups .I/O.. .
via HMI:
Description:
For details check the item “13.1.1 – Analog Inputs” on the programming and troubleshooting manual V1.2X.

V1.25 Changes
CFW701 | 6
P0275 – DO1 (RL1) Function
P0276 – DO2 Function
P0277 – DO3 Function
A
djustable
Range:
0 = Not Used
1 = N* > Nx
2 = N > Nx
3 = N < Ny
4 = N = N*
5 = Zero Speed
6 = Is > Ix
7 = Is < Ix
8 = Torque > Tx
9 = Torque < Tx
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No F070
15 = No F071
16 = No F006/21/22
17 = No F051
18 = No F072
19 = 4-20 mA OK
20 = P0695 Value
21 = Forward
22 = Ride-Through
23 = Pre-Charge OK
24 = Fault
25 = Enabled Time > Hx
26 = SoftPLC
27 = N>Nx/Nt>Nx
28 = F > Fx (1)
29 = F > Fx (2)
30 = STO
31 = No F160
32 = No Alarm
33 = No Fault and No Alarm
34 = Application Function 1
35 = Application Function 2
36 = Application Function 3
37 = Application Function 4
38 = Application Function 5
39 = Application Function 6
40 = Application Function 7
41 = Application Function 8
42 = Self-tuning
Factory
Setting:
P0275=11
P0276=24
P0277=0
Properties: cfg
A
ccess groups
via HMI:
.I/O.. .
Description:
They program the functions of the digital outputs, according to the options presented previously. For details
check the item “13.1.4 – Digital Outputs / Relays” on the Programming and Troubleshooting Manual V1.2X.

V1.25 Changes
CFW701 | 7
P0590 – Energy Saving Min. Speed
A
djustable
Range:
0 to 18000 rpm
Factory
Setting:
600 rpm
Properties:
V
/
f
Access groups .HVAC .
via HMI:
Description:
For details check the item “19.3 – Energy Saving Mode” on the Programming and Troubleshooting Manual
V1.2X.
1.2 CORRECTIONS TO THE MANUAL
This alarm has not description on the Programming and Troubleshooting Manual V1.2X.
Fault/Alarm Description Probable Causes
A159:
Incompatible HMI
Incompatible HMI Another product’s HMI is connected to
the CFW701.
