ACCUVAC Basic
Aspirator
WM 10700
Service and Repair Instructions

2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 3
1. Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Description . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Purpose . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Function . . . . . . . . . . . . . . . . . . . . . . 5
3. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4. Operating and Display Elements . . . . . . . . . . 7
5. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.1 Disposal . . . . . . . . . . . . . . . . . . . . . 7
6. Functional checks . . . . . . . . . . . . . . . . . . . . . 8
6.1 Intervals . . . . . . . . . . . . . . . . . . . . . . 8
6.2 Performing the functional check . . . . . . . 8
7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . 10
8. Repairs: Information and Instructions . . . . . . 12
8.1 General . . . . . . . . . . . . . . . . . . . . . 12
8.2 Opening the device . . . . . . . . . . . . . 12
8.3 Closing the device . . . . . . . . . . . . . . 13
8.4 Replacing release catch . . . . . . . . . . 13
8.5 Replacing membrane keyboard . . . . . 14
8.6 Changing power pack . . . . . . . . . . . 16
8.7 Changing fuse F1 or F2 . . . . . . . . . . 17
8.8 Check connector between circuit board
and power pack . . . . . . . . . . . . . . . 18
8.9 Fitting new circuit board WM 10780 . 18
8.10 Fitting new pressure gage . . . . . . . . . 20
8.11 Fitting new vacuum regulator . . . . . . . 20
8.12 Fitting new pump . . . . . . . . . . . . . . . 21
8.13 Changing fuse in vehicle plug . . . . . . 22
8.14 Changing the muffler . . . . . . . . . . . . 22
8.15 Electrical circuit diagram . . . . . . . . . . 23
9. Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . 24
9.1 Spare parts list . . . . . . . . . . . . . . . . 24
10. Tools and Test Equipment . . . . . . . . . . . . . . 26
11. Technical Changes . . . . . . . . . . . . . . . . . . . 26
12. Technical Data . . . . . . . . . . . . . . . . . . . . . . 27
12.1 Safe distances . . . . . . . . . . . . . . . . . 28
13. Repair and Test Report . . . . . . . . . . . . . . . . 29
© Copyright WEINMANN GmbH & Co. KG.
The content and presentation are copyright protected and may only be used by authorised WEINMANN Service Partners in
the course of their service operations. The content must not be reproduced or passed on to third parties. The complete documents
must be returned on termination of the cooperation with WEINMANN.

Introduction 3
Introduction
For decades WEINMANN has been developing,
manufacturing and marketing appliances for emer -
gency medical treatment, oxygen therapy and
inhalation therapy.
In 1986 WEINMANN launched the first
ACCUVAC aspirator on the market.
The improved ACCUVAC Basic aspirator pro -
vides users with an appliance that is an indispen -
sable aid in many emergency health care situa -
tions. The ACCUVAC Basic is primarily intended
for oral or transtracheal aspiration of secretion.
Aspiration is indicated in particular for tracheoto -
my patients undergoing respiration.
The indications include:
• Neuromuscular disorders, e.g. paraplegia,
amyotrophic lateral sclerosis (ALS)
• Late symptoms of polio
• Muscular dystrophies
• Cystic fibrosis
• Kyphoskoliosis and posttubercular syndrome
•Chronic obstructive lung diseases, e.g. severe
chronic bronchitis
• Pulmonary fibrosis, e.g. silicosis
•Other forms of alveolar hypoventilation
Using the ACCUVAC Basic aspirator gives the
user more time to look after the patient and perform
other measures.
The purpose of these Service and Repair Instruc-
tions is to make sure you as an expert specialist are
familiar with the ACCUVAC Basic aspirator: its
functionality and technology and how to repair it.
Combined with training you have already re-
ceived from WEINMANN, this makes you a mem-
ber of the “authorized expert personnel” category,
which means you can give your customers proper
instruction, remedy faults independently, perform
the final checks specified in the Operating Instruc-
tions, and carry out any repairs in accordance with
these Service and Repair Instructions.
In the event of a warranty claim the ACCUVAC Basic
aspirator is to be sent to WEINMANN.
So that we can process warranty claims or re-
quests for generous treatment of complaints,
please send the purchase receipt (invoice) with the
appliance.
Repairs may only be carried out by WEINMANN
or by expert personnel.
You are responsible for any repairs you make and for
the relevant warranty!
Only original WEINMANN spare parts must be used
for repairs.
Please remember:
Your customer trusts you and relies on your quality,
just as you rely on WEINMANN.
Note:
For the following information, please consult the
ACCUVAC Basic Operating Instructions:
•Safety information
•Fitting accessories
• Operation
• Hygienic preparation
• Warranty

1. Overview
-1,0
-0,8
-0,6 -0,4
-0,2
0
ACCUVAC Basic from front with disposable collection canister
7Disposable
canister
2Vacuum control
3Voltage indicator
8Motor unit
6Release catch
4On/Off
switch
9Tube holder plate
1Pressure gauge
5Membrane keyboard
ACCUVAC Basic from rear without collection canister
13 Muffler
(hidden)
11 Adapter/charger
plug
14 Suction port 12 Power socket
(hidden) 10 Loops for
accessory bag
Accessories
ACCUVAC Basic interior
18 Plug X100 17 Power pack
15 Fuse F100 16 Fuse F101 (hidden)
27 Vent tab 28 Filter cover 29 Bacteria filter 30 Locking tab 32 Secretion cover 33 Ball (overfill guard) 37 Collection canister
36 Aspiration tube
35 Fingertip
26 Re-usable collection canister WM 15269
34 Sealing ring
31 Bracing
38 Holder set WM 15271
Connection cable WM 10650
Accessory bag WM 10655
Wall bracket WM 15208
Disposable collection canister
24 Collection canister 21 Disposable bag 19 Aspiration tube with
Fingertip
22 Vacuum
tube
20 Intermediate tube
25 Holder
11 Adapter/charger plug
23 T-piece
Mains / charger unit FW7405M/14, complete WM 2610

Description 5
2. Description
2.1 Purpose
ACCUVAC Basic is a mobile and portable electri-
cally powered aspirator (suction pump).
It is used for:
•aspirating accumulations of blood, secretions
and food from the oral cavity, the nose and
throat region and the bronchial system;
• deflating vacuum mattresses and inflatable
splints.
ACCUVAC Basic:
•can when used by a skilled operator eliminate
obstruction of the respiratory tract and hence
the risk of respiratory failure;
• cuts energy consumption by reducing power
output on reaching the necessary vacuum;
•can optionally be powered by a rechargeable
internal power pack;
•or by an external DC source supplying 12.0 -
13.8 V;
• is also suitable for use in wards.
ACCUVAC Basic must not be used:
•in medical rooms where potential equalization
is necessary (e.g. heart surgery);
• in explosion-risk areas.
2.2 Function
An electrically operated diaphragm pump generates
the vacuum necessary for aspiration.
Use the vacuum control 2to set the desired vacuum,
which is continuously variable between –0.05 bar
and –0.8 bar. You can read off the set value on the
pressure gage 1.
The aspirated material passes via the aspiration tube
36 into the disposable collection canister 7.
Disposable collection canister
The disposable collection canister 7consists of the
collection canister 24 itself, the disposable collection
bag 21 with intermediate tube 20, the aspiration tube
with fingertip 19, the T-piece 23 and the vacuum tube
22.
The disposable collection canister 7is inserted in the
holder 25 screwed on the side of the motor unit 8.
The vacuum tube 22 of the disposable canister 24 is
pushed onto the suction port 14 of the motor unit 8.
-1,0
-0,8
-0,6 -0,4
-0,2
0

6Description
The aspirated material passes through the aspira-
tion tube 19 into the disposable collection bag 21.
The disposable collection bag is intended for
once-only use. When it is full, you can remove it
from the collection canister 24 and dispose of it
complete with contents.
An overflow valve filter is integrated in the
disposable collection bag 21. This prevents secre-
tions and liquid from finding their way into the motor
unit 8and passing into the environment via the
muffler 13.
Power supply
Power for operating the appliance and charging
the power pack can be drawn from:
• the built-in power pack 17.
• a 12-volt electrical cable system, using the
connecting cable WM 10650 which is
available as an accessory.
•the mains and charger unit WM 2645 which
is available as an accessory.
Important!
The AC adapter/charger plug 11 supplied with the
appliance is only designed for charging the power
pack with the appliance switched off. It must not be
used to operate the appliance itself, as this will over-
load it and cause it to overheat.
The voltage indicator 3shows the charge status of
the power pack.
Charging of the power pack starts automatically
as soon as the appliance is switched off and con-
nected to an external power supply (see ”12.
Technical Data“ on page 27).

Operation 7
3. Operation
ACCUVAC Basic may only be used by trained staff in-
structed in aspiration techniques. Incorrect use can
cause serious bodily harm.
Operation is described in the operating
instructions.
4. Operating and Display Elements
5. Maintenance
The ACCUVAC Basic needs no maintenance, but
please be sure to observe the intervals specified for
regular final checks (see ”6.1 Intervals“ on
page 8).
In the interests of maintaining power pack opera-
tion and life, we recommend you to calibrate the
power pack every 8 weeks as described in
Section 8.1.2 of the instructions for use. This in-
cludes the required discharging and recharging of
the power pack.
We recommend that you have any servicing, such
as inspections and repair work, carried out by the
manufacturer – WEINMANN – or by expert per-
sonnel.
5.1 Disposal
Do not dispose of the unit with domestic waste. For proper waste disposal of the equipment, please
contact an approved and certified waste disposal site for electronic goods. Ask your Environmental
Officer or town council for the address.
-1,0
-0,8
-0,6 -0,4
-0,2
0
2 Vacuum control 3 Voltage indicator 4 On/Off switch1 Pressure gauge

8Functional checks
6. Functional checks
If the final check reveals defects or deviations from
the specified values, ACCUVAC Basic must not be
used again until the faults have been rectified.
We therefore recommend that you always keep a
stock of the following:
• Disposable collection bag 21 WM 10732
• Aspiration tube with
fingertip 19 WM 10733
6.1 Intervals
To ensure that a properly functioning ACCUVAC Basic is always available, it is essential to observe the fol-
lowing intervals.
Before every use
• Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
After every use
• Clean, disinfect and/or sterilize the unit and
its parts (see operating instructions ”5.
Cleaning and disinfecting“);
• Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
Every 3 months
•Check the charge level of the power pack 17
by switching on ACCUVAC Basic and read-
ing the voltage indicator 3. If the top LED of the
voltage indicator does not light up, the power
pack should be recharged (see operating in-
structions ”4.4 Charging ACCUVAC Basic“).
At least every 6 months
• Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
• Make a visual inspection of the muffler for
clogging. If it is clogged, fit a new muffler (see
”8.14 Changing the muffler“ on page 22).
After all repairs
• Clean, disinfect and/or sterilize the unit and
its parts (see operating instructions ”5.
Cleaning and disinfecting“);
• Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
6.2 Performing the functional check
1. Assemble ACCUVAC Basic ready for use.
2. Check that all tubes and the individual parts of
the disposable collection canister 7are in per-
fect condition. Any damaged or worn parts
must be replaced.
3. Check that all tubes are securely connected
and the disposable collection bag 21 is firmly
installed.
4. Switch on ACCUVAC Basic.
5. Check the charge level on the voltage indica-
tor 3. Always recharge the power pack with-
out delay if the yellow LED on the voltage
indicator lights up (see operating instructions
”4.4 Charging ACCUVAC Basic“).

Functional checks 9
6. Battery test
A battery test should always be performed
when there are doubts about the performance
of the rechargeable battery, however at the
latest two years after the battery was last
changed.
Procedure
Charge the ACCUVAC Basic for 8 hours us-
ing the WM 2610 mains / charger unit
FW7405M/14, complete or for 14 hours us-
ing the WM 10750 plug-in power supply
unit. Set a short interval timer to 20 minutes
and start the ACCUVAC. After an operating
time of 20 minutes the red LED should not be
lit up and the ACCUVAC should be in opera-
tion.
If the red LED lights up after 20 minutes, or the
ACCUVAC is no longer working, the battery
is spent and must be replaced. In this case
please replace the battery as described in sec-
tion 8.6.
7. Insert the stopper in the fingertip 19.
8. Use your thumb to hold the suction nozzle
closed.
9. Switch on the aspirator and select the maxi-
mum vacuum of –0.8 bar by turning vacuum
control 2fully to the right. ACCUVAC Basic
must reach this vacuum in not more than
20 seconds.
If the aspirator takes longer than 20 seconds
to reach this vacuum, this means its suction
capacity is reduced. Check for possible faults
(see ”7. Troubleshooting“ on page 10).
10. Attach the test pressure gauge 0 to –1 bar
WM 15294 to the fingertip.
11. Check the maximum vacuum for accuracy with
test pressure gauge 0 to –1 bar. The vacuum
must be –0.8 bar, tolerance +/– 0.04 bar.
12. Remove the test pressure gauge from the
fingertip.
13. Switch ACCUVAC Basic off again.
Fingertip
Stopper
Suction tube
bar
O
2
-1,0
-0,8
-0,6 -0,4
-0,2
0

7. Troubleshooting
Fault Cause Localize fault Remedy Appliance does not start, O/I indicator and voltage indicator show ready for operation
Faulty pump Connect pump to functioning circuit board and
switch on. If pump does not run, … … fit new pump (8.12, page 21)
Circuit board defective Connect circuit board to functioning pump and
switch on. If pump does not run, … … fit new circuit board (8.9, page 18)
Appliance does not start, O/I indicator does not show ready for operation
Fuse F100 or F101 in appliance defective Fit new fuse (8.7, page 17) Fuse in vehicle plug defective Fit new fuse (8.13, page 22) Power pack fully discharged
Perform several charge/discharge cycles. If unsuccessful, fit new power pack (8.6, page 16)
Incorrect polarity of vehicle power socket Correct polarity and if necessary replace fuse
F1 (8.7, page 17)
Snap-in connection between circuit board and power pack not properly engaged Make sure connection snaps in
Appliance does not reach maximum vacuum of –0.8 bar in 20 seconds, but voltage indicator shows ready for operation
Leak in suction side of appliance
Disconnect secretion container from pump unit. Switch on pump and run at a setting of 0.8 bar. Hold thumb over suction port. The maximum vacuum is reached within 5 sec. and the pump stops. If the pumps starts up again within 10 to 20 sec., the leak is in the pump unit.
Check that all tubes are firmly connected and disposable bag is securely installed
Power pack not sufficiently charged
Connect mains / charger unit FW7405M/14, complete WM 2610. If the pump now runs much more “powerfully” than with the power pack, you must …
… charge power pack (operating instructions 4.4, page 16)
Fault in pump Connect pump to functioning circuit board and
switch on. If pump does not run, … … fit new pump (8.12, page 21)
Muffler clogged Fit new muffler (8.14, page 22)
No vacuum is generated Vacuum regulator defective Fit new vacuum regulator (8.11, page 20) No reading on pressure gage

Troubleshooting 11
Battery does not recharge
Inadequate external power supply External power supply must be between 12.0 V
and 13.8 V
Fuse F100 or F101 defective Fit new fuse (8.7, page 17) Fuse in vehicle plug defective Fit new fuse (8.13, page 22) Snap-in connection between circuit board and power pack not properly engaged Make sure connection snaps in (8.8, page 18)
Power pack is not fully charged up despite charging for 14 hours (top LED in voltage indicator does not light up)
Charger does not meet specifications Use AC adapter/charger plug WM 10750 or
charger WM 2610 (accessory)
Vehicle electrical system is not supplying 12.0 – 13.8 V Check vehicle electrical system Power pack damaged by being fully discharged Fit new power pack (8.6, page 16) Power pack at end of service life
Top LED of voltage indicator lights up after charging, but pump does not run when powered by power pack
Internal connection faulty
Check internal connection between printed circuit board (X100) and power pack (8.8, page 18)
Fuse F101 defective Fit new fuse (8.7, page 17)
Fuse F2 frequently blows
Pump is often switched on under vacuum conditions Do not switch on pump under vacuum Pump defective fit new pump (8.12, page 21)
Fault Cause Localize fault Remedy

12 Repairs: Information and Instructions
8. Repairs: Information and Instructions
8.1 General
An ESD workplace is essential for making repairs to
the ACCUVAC Basic.
No work should be performed on the appliance
without a detailed knowledge of the Operating In-
structions and the Service and Repair Instructions,
which must always be complied with.
ACCUVAC Basic is only intended for the purpose
described (see ”2.1 Purpose“ on page 5).
When replacing components or individual parts,
be sure to use only original WEINMANN parts.
A functional check (see ”6.2 Performing the func-
tional check“ on page 8) must be performed after
every repair.
When ordering the rear part of the case, please
state the appliance type, appliance number and
year of manufacture.
8.2 Opening the device
Tools and equipment required:
• Phillips screwdriver size 2
1. Switch off ACCUVAC Basic.
2. Disconnect the aspirator from the external
power supply.
3. Remove collection canister 7and any
accessories.
4. Unscrew the holder 25 for the disposable col-
lection canister 7.
5. Open the case by unscrewing the 6 cross-
head screws 52. When opening the case, be
careful not to damage the silicone sealing
cord.
6. Carefully pull the front and rear case elements
apart.
52

Repairs: Information and Instructions 13
8.3 Closing the device
Tools and equipment required:
• Phillips screwdriver size 2
1. Carefully put the front and rear case elements
together again.
2. Screw the case together again, making sure
the silicone sealing cord is correctly inserted
and is not jammed or otherwise damaged.
3. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
8.4 Replacing release catch
Tools and equipment required:
• Phillips screwdriver size 2
• Screwdriver, size 1 ;
• Flat or pointed pliers.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Place the ACCUVAC Basic on its front.
3. Push out retaining pins 64 from release catch
63 and remove them.
4. Remove the old or defective release catch 63.
To do so, use a flat / blunt object to press
down snap lock 66, which is located below
release catch 6.
5. Take the new release catch 63 and insert it in
the rear wall of the case.
6. Take O-ring 65 and locate it in the rear wall of
the case between the loops of the release
catch and the rear wall attachment point.
7. Take the retaining pins 64 and insert them in
the bushing from outside to inside until you
hear them click into place.
8. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
9. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
52
64
65
63
66

14 Repairs: Information and Instructions
8.5 Replacing membrane keyboard
Tools and equipment required:
• Phillips screwdriver size 1;
• 7mm open-end wrench.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Carefully disconnect the power pack connec-
tor 18 (X100)from the circuit board.
3. Unscrew the power pack holder (4 cross-head
screws 41).
4. Detach both leads from the power pack 17.
5. Remove the power pack.
6. Carefully remove cap 45 of knob 44, p.ex. à
using a razor blade (for example).
7. Slightly loosen the nut on the adjuster knob
and pull the adjuster knob off the regulator
unit.
8. Carefully pull tube 58 off regulator unit 46.
9. Use a 7mm open-end wrench to unscrew the
tube connection from the pressure gauge.
10. Cut open cable tie 43 (locking strip).
X100
17
41
45
44
50
46
59 586061
43

Repairs: Information and Instructions 15
11. Carefully push pressure gauge 1upward out
of resilient ring 42.
12. Remove resilient ring 42.
13. Disconnect the electrical power pack connec-
tors X100, X101 and X103 from the board.
14. Detach the front keyboard from inside through
the front of the case, by pressing the mem-
brane keyboard out upwards and carefully
pulling it off.
15. Clean the old adhesive area until no adhesive
residues are left.
16. Take the new membrane keyboard 5and re-
move the protective layer from the adhesive
surface. Run the ribbon cable through the
opening in the case front.
Take care when inserting the ribbon cable
through the opening in the housing; it must be
properly routed without any kinks.
17. Stick the new membrane keyboard 5in the
correct position on the case.
18. Pull the protective film off the new membrane
keyboard.
19. Insert resilient ring 42 in the front of the case
again.
20. Using a little methylated spirits, carefully insert
the new pressure gauge 1downwards into the
resilient ring 42 (making sure to align it correct-
ly). Roll the rubber cuff onto the pressure gauge
with your fingers.
21. Secure the pressure gage by fitting cable tie
43 around the resilient ring.
22. Insert the board again and screw it up firmly.
23. Carefully restore the electrical connections
X100, X101 and X103.
24. Carefully push tube 58 onto the regulator unit.
25. Attach the tube connector to the pressure gage
using a 7mm open-end wrench.
26. Insert the power pack again and screw it firmly
in place.
42
1
42
1
43

16 Repairs: Information and Instructions
27. Make the electrical connections to the power
pack.
28. .When replacing the knob, ensure that the
gap between knob and keyboard membrane
(with the spindle screwed in) is approx.
1.0 mm.
29. Use a 10 mm tubular wrench to tighten the nut
securing knob 44.
30. Insert cap 45 (slit in cap must match ridge in
knob).
31. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
32. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
8.6 Changing power pack
ACCUVAC Basic is fitted with a high-grade lead cell power pack.
Tools and equipment required:
• Phillips screwdriver size 2.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Carefully disconnect the power pack connec-
tor 18 (X100)from the circuit board.
3. Unscrew the power pack holder (4 cross-head
screws 41).
4. Detach both leads from the power pack 17.
5. Remove the faulty power pack.
Help protect the environment!
Don’t throw the old power pack in the gar-
bage can – take it to a local collection point
for environment-friendly disposal.
1mm
45
44
X100
17
41

Repairs: Information and Instructions 17
6. Attach the two cables to the connections on
the new power pack: red to plus; black to
minus.
If you accidentally reverse the connections, the
electronic system will be protected by fuse 16
(F2), which will then have to be replaced.
7. Fit the new power pack with its holder, making
sure you do not jam any cables.
8. Carefully push power pack connector 18
(X100) onto the circuit board until it snaps into
place.
9. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
10. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
8.7 Changing fuse F1 or F2
Important!
Avoid touching the electronic components on the cir-
cuit board, as this could damage them (electrostatic
charge).
Tools and equipment required:
• Phillips screwdriver size 2.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Remove the faulty fuse 15/16. The fuses are
identified on the circuit board.
3. Insert a new fuse. Always use approved fuses
(see ”12. Technical Data“ on page 27).
4. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
5. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
X100

18 Repairs: Information and Instructions
8.8 Check connector between circuit board and power pack
Tools and equipment required:
• Phillips screwdriver size 2.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Check connector X100.
3. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
4. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
8.9 Fitting new circuit board WM 10780
Tools and equipment required:
• Phillips screwdriver size 2.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Carefully remove the electrical power pack
connectors X100 and X101 of wiring harness
53 from the circuit board.
3. Carefully open up cable grip of ribbon cable
connector X103. Then carefully remove ribbon
cable (do not touch the ribbon cable contacts
with your fingers, as this can cause oxidation).
X100
X101 X100
53
X103 X101 X100

Repairs: Information and Instructions 19
4. Unscrew circuit board (3 screws
52
).
5. Insert the new circuit board in reverse order.
Important!
The lengths of tubes WM 10766 and WM 10765 are not compatible with all circuit boards. The over-
view below shows you the cases in which you will have to adapt the length of the tubes:
Carefully connect electronic power pack con-
nector
X101
. Then route connecting cable so
it does not come into contact with the pump.
Important:
• Do not connect electrical power pack
connector
X100
yet.
• Wait half a minute to allow the capacitors on the
circuit board to discharge.
6. Carefully connect the electrical power pack
connector
X100
.
7. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
8. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
Old circuit board New circuit board Action
WM 10780 Index
≤ C WM 10780 Index ≤ C No modification required
WM 10780 Index ≤ C WM 10780 Index > C
Use tubes with new lengths:
– WM 10766 Index > a (42 mm instead of 50 mm)
– WM 10765 Index > a (208 mm instead of
200 mm)
WM 10780 Index > C WM 10780 Index > C No modification required
52

20 Repairs: Information and Instructions
8.10 Fitting new pressure gage
Tools and equipment required:
• Phillips screwdriver size 2.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Use a 7mm open-end wrench to unscrew the
tube connection from the pressure gauge.
3. Cut open cable tie 43.
4. Carefully push faulty pressure gauge upward
out of resilient ring 42.
5. Using a little methylated spirits, carefully insert
the new pressure gauge 1downwards into the
resilient ring 42 (making sure to align it correct-
ly). Roll the rubber cuff onto the pressure gauge
with your fingers.
6. Secure the pressure gage by fitting cable tie
43 around the resilient ring.
7. Attach the tube connector to the pressure
gauge using a 7mm open-end wrench.
8. Close the device (see ”8.3 Closing the de-
vice“ on page 13).
9. Perform a functional check (see ”6.2 Perform-
ing the functional check“ on page 8).
8.11 Fitting new vacuum regulator
Tools and equipment required:
• Phillips screwdriver size 2,
• Tubular wrench, 10 mm.
1. Open the device (see ”8.2 Opening the de-
vice“ on page 12).
2. Carefully remove cap 45 of knob 44, using a
razor blade (for example).
3. Use a 10 mm tubular wrench to unscrew the
knob.
43
42
1
43
45
44
