Weslo MOMENTUM CT 5.0 User manual

www.wesIo.com
Model No. WLEL32910.0
Serial No.
Write the serial number in the
space above for reference.
\
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
iMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-866-699-3756
Mon.-Fri., 6 a.m.-6 p.m. MT
Sat. 8 a.m.-4 p.m. MT
ON THE WEE}:
www.wesloservice.com
AUAL

TABLE OF CONTENTS
WARNING DECAL PLACEMENT .............................................................. 2
IMPORTANT PRECAUTIONS ................................................................ 3
BEFORE YOU BEGIN ...................................................................... 4
ASSEMBLY ............................................................................... 5
HOW TO USE THE ELLIPTICAL ............................................................. 15
MAINTENANCE AND TROUBLESHOOTING ................................................... 19
EXERCISE GUIDELINES ................................................................... 21
PART LIST .............................................................................. 22
EXPLODED DRAWING .................................................................... 23
ORDERING REPLACEMENT PARTS .................................................. Back Cover
LIMITED WARRANTY .............................................................. Back Cover
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
•Misuse ofthis machine
may result in serious
injury,
• Read user's m I
p.ort...... _f_o_ffw
all warnings and
instructions.
• Do not allow children
on or around machine,
•Pedals continue to
spin when you stop
pedaling,
•Spinning pedals can
cause injury.
"Reduce pedal speed
in a contromedmanner.
• User weight must not
exceed 250 pounds.
, Replace label if
damaged, illegible, or
removed.
• Mal usedeesta maquina
puede resultar en graves
lesiones.
•Leael manual del usuado
antes del use y siga
todas las precauciones
e_nstrucciones.
• No deje a niSos en o
alrededor de la maquina.
• Los pedales eontin_an a
girar cuando usted para
deempujar a los pedales.
•Los pedales al girar
pueden causar heridas.
•Reduzca la velocidad de
los pedales en ferma
controlada,
-El peso del usuarto no
debe exceder 113kg.
•Reemplace la calcomania
si est_ daSada, Jlegible,
WESLO is a registered trademark of ICON IP, Inc.
2

iMPORTANT PRECAUTIONS
,WARNING: Toreducethe.skofseriousnjury,reada.important precautions and
instructions in this manual and all warnings on your elliptical before using your elliptical, iCON
assumes no responsibility for personal injury or property damage sustained by or through the use of
this product.
.
,
Before beginning any exercise program, 9.
consult your physician. This is especially
important for persons over age 35 or
persons with pre-existing health problems. 10.
Use the elliptical only as described in this
manual.
The elliptical should not be used by persons
weighing more than 250 Ibs. (113 kg).
Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the elliptical. Always wear athletic
shoes for foot protection while exercising.
3. it is the responsibility of the owner to ensure
that all users of the elliptical are adequately
informed of all precautions.
11. Hold the handlebars or the upper body arms
when mounting, dismounting, or using the
elliptical.
.
5.
.
The elliptica! is intended for home use only.
Do not use the elliptical in a commercial,
rental, or institutional setting.
Keep the elliptical indoors, away from
moisture and dust. Do not put the elliptical in
agarage or covered patio, or near water.
Place the elliptical on alevel surface, with at
least 3 ft. (0.9 m) of clearance in the front
and rear of the elliptical and 2 ft. (0.6 m) on
each side. To protect the floor or carpet from
damage, place a mat under the elliptical.
12.
13.
14.
The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in
determining heart rate trends in general.
The elliptical does not have afreewheel; the
pedals will continue to move until the
flywheel stops. Reduce your pedaling speed
in a controlled way.
Keep your back straight while using the
elliptical; do not arch your back.
.
.
inspect and properly tighten all parts
regularly. Replace any worn parts
immediately.
Keep children under age 12 and pets away
from the elliptical at all times.
15. Over exercising may result in serious injury
or death, if you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
3

BEFORE YOU BEGIN
Thank you for selecting the new WESLO ®
MOMENTUM CT 5.0 elliptical. The MOMENTUM CT
5.0 provides a selection of features designed to make
your workouts at home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the elliptical, ifyou have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Pulse Sensor
Console
Water Bottle Holder*
Pedal Disc
Leveling Foot
Upper Body Arm
Handlebar
Wheel
Pedal
*Water bottle is not included
4

ASSEMBLY
To hire an authorized service technician to assemble the elliptical, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical in a cleared area and remove all packing mate-
rials; do not dispose of the packing materials until assembly is completed.
in addition to the included tool(s), assembly requires aPhillips screwdriver d_L_=====_, an adjustable
wrench _:_, and a rubber mallet _.
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: Ifapart is not in the hardware kit, check to see if
it has been preassembled. To avoid damaging parts, do not use power tools for assembly.
M5 Split
Washer (28)-6 O]
M8 Washer M10 Split Small Wave Large Wave
(55)-2 Washer (45)-4 Washer (69)-2 Washer (76)-2
M4 x 16mm
Self-tapping
Screw (52)-12
M10
Washer (83)-2
#10 x 16mm
M8 Locknut Screw (27)-6 M8 x 25mm Patch
(38)-8 Screw (56)-2
M8 x 43mm Button
Bolt (50)-6
M10 x 20mm Patch
Screw (7)-4 M10 x 25mm Patch Screw (40)-2
M6 Bolt Set (25)-2
M8 x 80mm Patch
Bolt (79)-2
M10 x 78mm Button
Bolt (34)-4
5

Identify the Front Stabilizer (63), which has a
Wheel (21) on each end.
Orient the Front Stabilizer (63) so that the small
holes face downward.
While a second person lifts the front of the
Frame (1), attach the Front Stabilizer (63) to the
Frame with two M10 x 78mm Button Bolts (34).
21 63
Small
Holes
34
.Insert the Front Stabilizer Cover (68) into the
Front Stabilizer (63).
Attach the Front Stabilizer Cover (68) with two
M4 x 16mm Self-tapping Screws (52).
52
68
63
.While a second person lifts the rear of the
Frame (1), attach the Rear Stabilizer (9) to the
Frame with two M10 x 78mm Button Bolts (34).
34
6

4. 4
Insert the Rear Stabilizer Cover (67) into the
Rear Stabilizer (9).
Attach the Rear Stabilizer Cover (67) with two
M4 x 16mm Self-tapping Screws (52). 67
52
9
.Orient the Upright (2) as shown. Have a second
person hold the Upright near the Frame (1).
See the inset drawing. Locate the wire tie in
the Upright (2). Tie the lower end of the wire tie
to the Wire Harness (73). Then, pull the upper
end of the wire tie until the Wire Harness is
routed through the Upright.
Tip: To prevent the Wire Harness (73) from
falling into the Upright (2), secure the Wire
Harness with the wire tie.
Tip: Avoid pinching the Wire Harness (73).
Slide the Upright (2) onto the Frame (1).
Wire
Avoid pinching the
Wire Harness (73)
2
,Wire Tie
7

,Attach the Upright (2) to the Frame (not shown)
with four M10 x 20mm Patch Screws (7) and
four M10 Split Washers (45). Do not tighten
the Patch Screws yet.
,Attach the Water Bottle Holder (29) to the
Upright (2) with two M4 x 16mm Self-tapping
Screws (52).
52
29
8

8. 8
Identify the Left and Right Handlebars (85, 86),
which are marked with "Left" and "Right" stick-
ers.
Have a second person hold the Left and Right
Handlebars (85, 86) near the Upright (2).
See the inset drawing. Locate the wire tie in
the right side of the Upright (2). Tie the lower
end of the wire tie to the right Pulse Wire (84).
Then, pull the upper end of the wire tie upward
out of the top of the Upright. Repeat this
action on the left side of the Upright.
Tip: Avoid pinching the wires. Attach the Left
and Right Handlebars (85, 86) to the Upright (2)
with two M8 x 80mm Patch Bolts (79) and two
M8 Locknuts (38).
85
38
38
Wire Tie Avoid pinching
84 _, the wires
86
Tie
.The Console (23) requires four AA batteries (not
included); alkaline batteries are recommended.
iMPORTANT: If the Console has been
exposed to cold temperatures, allow it to
warm to room temperature before inserting
batteries. Otherwise, you may damage the
console displays or other electronic compo-
nents. Remove the battery cover and insert the
batteries into the battery compartment, Make
sure to orient the batteries as shown by the
diagram inside the battery compartment.
Then, reattach the battery cover.
23
9

10. Attach the Rear Upright Cover (75) to the Left
and Right Handlebars (85, 86) with two M4 x
16mm Self-tapping Screws (52). Do not fully
tighten the Screws yet.
10
52
86
11. Untie and discard the wire ties on the Wire
Harness (73) and the Pulse Wires (84).
While a second person holds the Console (23)
near the Upright (2), connect the console wires
to the Wire Harness (73), to the Ground Wire
(90), and to the Pulse Wires (84).
Insert the excess wire into the Console (23) or
into the Upright (2).
11
23
84
