Weslo Momentum Ct5.8 Elliptical User manual

Serial
Number
Decal
USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. eep this manu-
al for future reference.
Model No. WMEL32608
Version No. 0
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
If you have questions, or if parts
are damaged or missing, please
contact us.
Importer:
Comercializadora México
Americana, S. de R.L. de C.V.
Av. Nextengo No. 78
Col. Santa Cruz Acayucan
Del. Azcapotzalco
México D.F., C.P. 02770
R.F.C. CMA-910911-9L0
Call: 5899 12 00
Web: www.iconservice.com
Electrical Specifications:
Requires four 1.5V AA batteries
(see page 16)

2
TABLE OF CONTENTS
WARNINGDECALPLACE ENT ..............................................................2
IPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSE BLY ...............................................................................5
HOWTOUSETHEELLIPTICALEXERCISER ..................................................12
AINTENANCEANDTROUBLESHOOTING ...................................................16
EXERCISEGUIDELINES ...................................................................17
PARTLIST ..............................................................................21
EXPLODEDDRAWING ....................................................................22
WESLO is a registered trademark of ICON IP, Inc.
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, go to
www.iconservice.com and request a free replace-
ment decal. Apply the decal in the location shown.
Note: The decal(s) may not be shown at actual size.

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over the age of 35 or
persons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Your elliptical exerciser is intended for home
use only. Do not use your elliptical exerciser
in a commercial, rental, or institutional set-
ting.
4. eep your elliptical exerciser indoors, away
from moisture and dust. Place your elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around your elliptical exerciser to mount,
dismount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. eep children under age 12 and pets away
from your elliptical exerciser at all times.
7. Your elliptical exerciser should not be used
by persons weighing more than 250 lbs.
(113 kg).
8. Wear appropriate exercise clothes when
exercising; do not wear loose clothes that
could become caught on your elliptical exer-
ciser. Always wear athletic shoes for foot
protection.
9. Hold the handgrip pulse sensor or the upper
body arms when mounting, dismounting, or
using your elliptical exerciser.
10. eep your back straight while using your
elliptical exerciser; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the userʼs move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. If you feel pain or dizziness while exercising,
stop immediately and cool down.
14. Use your elliptical exerciser only as
described in this manual.

4
BEFORE YOU BEGIN
Thank you for selecting the WESLO®O ENTU CT
5.8 elliptical exerciser. The O ENTU CT 5.8 is an
incredibly smooth exerciser that moves your feet in a
natural elliptical path, minimizing the impact on your
knees and ankles. Welcome to a whole new world of
natural, elliptical-motion exercise.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the front
cover of this manual. To help us assist you, note the
product model number and serial number before con-
tacting us. The model number and the location of the
serial number decal are shown on the front cover of
this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Pedal Disc
Shield
Leveling Foot
Water Bottle Holder*
*Water bottle is not included
Console
Upper Body Arm
Pulse Sensor
Wheel
Pedal

5
M8 Split
Washer (79)–4
M8 Washer
(64)–4
M10 Split
Washer (78)–4
M4 x 16mm
Screw (60)–4
M8 x 25mm Patch
Screw (70)–2
M8 x 19mm Patch
Screw (73)–4
M8 Locknut
(59)–10
M10 Locknut
(84)–4
M8 x 23mm Button
Screw (65)–4
Large Wave
Washer (20)–4
Wave Washer
(27)–2
M4 x 19mm
Screw (68)–6
M8 Large
Washer (81)–2
Star Washer
(85)–6
M10 x 76mm Button Bolt (74)–2
M10 x 60mm Button Screw (67)–2 M10 x 75mm Carriage Bolt (58)–2
M4 x 22mm
Screw (66)–2
M8 x 45mm Button
Bolt (11)–4
M8 x 38mm Button
Bolt (94)–4
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: Some small parts may have been preassembled.
If a part is not in the hardware kit, check to see if it has been preassembled.

6
1.
Attach the Rear Stabilizer (35) to the Frame (1) with
two 10 x 75mm Carriage Bolts (58) and two 10
Locknuts (84).
Press the Stabilizer Caps (36) onto the Rear
Stabilizer (35) as shown.
2. See the inset drawing. Orient a Wheel (28) so that
the four posts face away from the Front Stabilizer
(3).
Attach the Wheel (28) to the Front Stabilizer (3)
with an 8 Locknut (59). Next, press a Wheel
Cover (29) onto the posts on the Wheel.
Attach the other Wheel (not shown) in the same
way.
84
35
1
3
36
36
28
29
59
58
1
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
2
28
Posts
3. Attach the Front Stabilizer (3) to the Frame (1) with
two 10 x 76mm Button Bolts (74), two 10 Split
Washers (78), two Concave Spacers (13), and two
10 Locknuts (84). Do not tighten the Locknuts
yet.
Insert two 10 x 60mm Button Screws (67) with
two 10 Split Washers (78) and two Concave
Spacers (13) through the Front Stabilizer (3) and
into the Frame (1).
Tighten the M10 Locknuts (84), and then tighten
the M10 x 60mm Button Screws (67). 84
3
78
78
13
13
67
13 78 67
1
74
78
13
3

7
4. While another person holds the Upright (2) near the
Frame (1), connect the Upper Wire Harness (18) to
the Lower Wire Harness (38).
Tip: Avoid pinching the Wire Harnesses (18, 38).
Carefully slide the Upright (2) onto the Frame (1).
Attach the Upright with four 8 x 19mm Patch
Screws (73) and four 8 Split Washers (79). Do
not tighten the Patch Screws yet.
4
2
73
73
1
73
79
38
18
79
79
5
5. Identify the Left Pedal Arm (21), which is marked
with a “Left” sticker. Attach a Pedal (19) to the Left
Pedal Arm with three 4 x 19mm Screws (68) and
three Star Washers (85).
Attach the other Pedal (not shown) to the Right
Pedal Arm (not shown) in the same way.
19
21
68
85
85
Avoid pinching the
Wire Harnesses (18, 38)

8
6. Apply a generous amount of the included grease to
the Pivot Axle (16) and to two Wave Washers (27).
Identify the Left and Right Upper Body Legs (6, 7),
which are marked with “Left” and “Right” stickers.
While another person aligns the Left and Right Upper
Body Legs (6, 7) with the Upright (2) as shown, insert
the Pivot Axle (16) through the Upper Body Legs and
the Upright. Tip: Avoid damaging the Upper Wire
Harness (18) with the Pivot Axle.
Slide a Wave Washer (27) onto each end of the Pivot
Axle (16). Make sure that the Wave Washers
remain on the ends of the Pivot Axle.
6
7
18
6
27
16
Grease
27
Grease
Hexagonal
Holes
2
7. Tighten an 8 x 23mm Button Screw (65), an 8
Washer (64) and a Pivot Cover (14) into each end
of the Pivot Axle (16).
7
14
7
6
65
64
65
64
14
2
Avoid damaging
the Upper Wire
Harness (18)
16

9
8. Apply a generous amount of grease to the axle on
the Left Upper Body Leg (6). Then, apply grease to a
Large Wave Washer (20), and slide it onto the axle.
Apply a generous amount of grease to the Left
Crank Arm (42). Orient a Crank Arm Spacer (45) so
that the flat side is facing away from the Left Crank
Arm. Then, slide the Crank Arm Spacer onto the Left
Crank Arm.
Then, gradually work the Left Pedal Arm (21) onto
the Left Upper Body Leg (6) while at the same time
working the Left Pedal Arm onto the Left Crank Arm
(42).
Repeat this step for the other side of the elliptical
exerciser.
8
6
21
20
Grease
Grease
42
45
73
9. Attach the Left Pedal Arm (21) to the Left Upper
Body Leg (6) with an 8 x 23mm Button Screw
(65), an 8 Washer (64), and a Pedal Leg Cover
(23).
Apply grease to a Large Wave Washer (20), and
slide it onto the Left Crank Arm (42). Then, attach
the Left Pedal Arm (21) to the Left Crank Arm with
an 8 x 25mm Patch Screw (70) and an 8 Large
Washer (81).
See step 4. Tighten the four M8 x 19mm Patch
Screws (73).
Repeat this step for the other side of the elliptical
exerciser.
9
Grease 42
20
81
70
23
64
21
6
65

10
11
11. The Console (10) can use four AA batteries (not
included); alkaline batteries are recommended.
IMPORTANT: If the Console has been exposed
to cold temperatures, allow it to warm to room
temperature before inserting batteries.
Otherwise, you may damage the console dis-
plays or other electronic components. Remove
the battery cover, insert the batteries into the battery
compartment, and reattach the battery cover. Make
sure to orient the batteries as shown by the dia-
gram inside the battery compartment. Do not
combine old and new batteries or alkaline and
rechargeable batteries.
10
Batteries
Screw
Battery
Cover
10. Identify the Left Pulse Bar (90), which is marked
with a “Left” sticker. Orient the Left Pulse Bar so
that the hexagonal holes are in the indicated
location.
Have another person hold the Left Pulse Bar (90)
near the Upright (2).
See the inset drawing. Locate the wire tie in the
Upright (2). Tie the lower end of the wire tie to the
left Pulse Wire (96). Next, pull the upper end of the
wire tie upward out of the top of the Upright. Then,
untie and discard the wire tie.
Tip: Avoid pinching the wires. Slide the Left
Pulse Bar (90) onto the left side of the Upright (2).
Attach the Left Pulse Bar with two 8 x 38mm
Button Bolts (94) and two 8 Locknuts (59). Make
sure that the Locknuts are in the hexagonal
holes.
Repeat this step for the Right Pulse Bar (91).
10
Wire Ties
Hexagonal
Holes
91
59
94
90
Wire Tie
96
96
96
2
Avoid pinching
the wires
