Whalen O'nin Espresso Room Divider User manual

1
Date 2015-11-19 Rev. 1 Factory: RIDHUA (17148)
E
O’nin Espresso Room Divider
Model # DMRD-E
ASSEMBLY INSTRUCTIONS
IMPORTANT, RETAIN FOR FUTURE REFERENCE:
READ CAREFULLY
If you have any questions regarding assembly or if parts are missing, DO NOT return this item
to the store where it was purchased. Please call our toll-free customer service number and
have your instructions and parts list ready to provide the model name, part name or factory
number:
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to
Friday (in the US, Canada and Mexico only)
LOT NUMBER:
DATE PURCHASED: / /

2
E
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: O’nin Espresso Room Divider (DMRD-E)
MADE IN CHINA
CAM LOCK SYSTEM OPERATION
HOW THE ASSEMBLY SYSTEM WORKS
1. Screw Cam Bolt into the threaded insert on panel.
2. Insert Cam Lock into pre-drilled hole on panel.
3. Make sure Cam Lock pointed arrow is pointed towards the entry of Cam Bolt.
4. Connect both panels together; making sure Cam Bolt goes into pre-drilled hole on the end
of panel with Cam Lock.
5. Once Cam Bolt is connected inside Cam Lock, take a Phillips screwdriver and tighten Cam
Lock clockwise. You are now ready to assemble the unit.
MAXIMUM LOAD 45.4 kg / 100 lb
MAXIMUM LOAD 9.1 kg / 20 lb
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM
WEIGHTS INDICATED. USE WITH LOAD HEAVIER THAN THE MAXIMUM WEIGHTS
INDICATED MAY RESULT IN INSTABILITY
,
CAUSING POSSIBLE INJURY.
MAXIMUM LOAD 90.7 kg / 200 lb
MAXIMUM RECOMMENDED WEIGHT L
OADS

3
E
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware
are present before beginning assembly.
A- Top/Bottom Panel (Qty. 2) B- Side Panel (Qty. 2)
C- Large Divider Panel (Qty. 2) D- Center Divider (Qty. 1)
(With Cam lock holes)
E- Small Divider Panel (Qty. 4) F- Storage Basket (Qty. 8) G- Basket Flooring (Qty. 8)
AA- Bolt (Qty. 8+1 extra) BB- Lock Washer (Qty. 8+1 extra) CC- Flat Washer (Qty. 8+1 extra)
DD- Cam Lock (Qty. 4+1 extra) EE- Cam Bolt (Qty. 4+1 extra) FF- Large Wood Dowel (Qty. 12+1 extra)
GG- Small Wood Dowel HH- Cam Lock Cover II- Wood Plug JJ- Plastic Cap
(Qty. 40+1 extra) (Qty. 4+1 extra) (Qty. 8+1 extra) (Qty. 8+1 extra)
Allen Wrench (Qty. 2) Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty. 2)
(Inside Plastic Bag)
Tools required: Allen wrench (included), Phillips screwdriver and rubber mallet (not included).

4
E
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts.
2. Lay the Side Panels (B) on a level and protected surface with the pre-drilled holes facing up. Screw 2
Cam Bolts (EE) into the plastic bushings included on the center of each Side Panel. Fully tighten with a
Phillips screwdriver.
3. Insert 4 Small Wood Dowels (GG) half way into the pre-drilled holes on the Large Divider Panel (C) by
tapping lightly with a rubber mallet, if necessary. Position 2 Small Divider Panels (E) onto the inserted
Wood Dowels and press them together.
EE
B
B
C
EGG
E
C
E
E

5
E
Assembly Instructions
4. Attach the Center Divider (D) and one Small Divider Panel (E) to the assembled Small Divider Panel (E)
using 4 Small Wood Dowels (GG).
5. Repeat the last step to install the remaining Large Divider Panel (C) and Small Divider Panel (E) to the
last assembly. Make certain they are located on the other end of Center Divider (D).
6. Insert 20 Small Wood Dowels (GG) into the end holes of Large Divider Panels (C) and Center Divider
(D). DO NOT put dowels into the Cam Bolt holes.
7. Insert 4 Cam Locks (DD) into the side holes of the Center Divider (D) making sure the arrow on the face
of Cam Lock points out and towards the entry of Cam Bolt.
8. Position the Side Panels (B) onto the inserted Small Wood Dowels (GG). Press them together and
secure in place by connecting the Cam Locks (DD) (Refer to page 2 on Cam lock system operation
supplement). Once locked in place, insert the Cam Lock Covers (HH) to conceal the Cam Locks.
DD
HH
GG
EE
D
B
B
B
C
E
C
E
D
C
GG
B
C
E
DEC
E
EC
E
D
C/D
EGG
E
E

6
E
Assembly Instructions
9. Insert the Small Wood Dowels (GG) into the end holes of both Small Divider Panels (E) and insert 3
Large Wood Dowels (FF) into each end of the Side Panels (B).
10. Using the Wood Dowels as a guide, attach Top and Bottom Panels (A) to both Side Panels (B) by
screwing the Bolts (AA) with Lock Washers (BB) and Flat Washers (CC) into the countersunk holes on
Top/Bottom Panel. Tighten the bolts with the provided Allen Wrench. Cover the countersunk holes by
inserting the Wood Plugs (II) or Plastic Caps (JJ) provided. Gently tap the Wood Plugs or Plastic Caps
with a rubber mallet to ensure they are fully seated.
11. Ask for assistance to stand the unit upright and position at the desired location in your room.
12. Unfold the Storage Baskets (F) and then place the Basket Flooring (G) inside the open basket to ensure
it remains square. Position the Storage Baskets onto the compartments, as shown.
13. You can combine two or more units to create an attractive storage wall for your home.
EGG
B
B
E
E
A
A
AA BBCC
II
FF
B
A
A

7
E
TIPPING RESTRAINT HARDWARE
NOTE: We have included two sets of Tipping Restraint Hardware for this unit. You must install
this hardware to prevent accidents or injuries from falling unit.
When properly installed, this restraint can provide protection against the unexpected tipping of
the unit due to small tremors, bumps or climbing. We strongly recommend mounting this
hardware to a wall stud and your unit.
Please carefully read the instructions printed on the plastic bag containing tipping restraint
hardware to attach the tipping restraints to the unit and the wall.
NOTE: Young children can be seriously injured by tipping furniture. You must install the
Tipping Restraint Hardware with the unit to prevent the unit from tipping, causing any
accidents or damage. The tipping restraint is intended only as a deterrent, they are not a
substitute for proper adult supervision. The tipping restraint is not an earthquake restraint. If
you wish to add the extra security of earthquake restraints, they must be purchased and
installed separately.
Tools required: Phillips screwdriver, rubber mallet, power drill, and 9.5 mm drill bit.

8
E
Care and Maintenance
Use a soft, clean cloth that will not scratch the surface when dusting.
Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous
area.
Using solvents of any kind on your furniture may damage your furniture’s finish.
Never use water to clean your furniture as it may cause damage to the finish.
Always use coasters under beverage glasses and flowerpots.
Liquid spills should be removed immediately. Using a soft clean cloth, blot the spill gently. Avoid
rubbing.
Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may
create spotting within the furniture finish.
Stains or marks from crayons or ink markers will be difficult to remove.
In the event that your furniture is stained or otherwise damaged during use, we recommend that you
call a professional to repair your furniture.
Further advice about wood furniture care
It is best to keep your furniture in a climate controlled environment. Extreme temperature and humidity
changes can cause warping, shrinking and splitting of wood. It is advised to keep furniture away from
direct sunlight as may damage the finish.
Proper care and cleaning at home will extend the life of your purchase. Following these important and
helpful tips will enhance your furniture as it ages.
A Touch-up Pen has been provided to repair any small nicks or scratches that may occur
during assembly or shipping.
We hope you enjoy your purchase for many years.
Thank you for your purchase!
QUALITY GUARANTEE
We are confident that you will be delighted with your Whalen Furniture purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will repair or
replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed
to meet your highest expectations. We guarantee that you will immediately see the value of our fine
furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from State
to State.
AUSTRALIA: Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
Customer Service: 1-877-494-2536 (English, French, Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to
Friday (in the US and Canada only)
MADE IN CHINA / FABRIQUÉ EN CHINE / HECHO EN CHINA
