Whirlwind K5 User manual

Whirlwind – K5 – User Manual – P. 1
!!
!
!
! !
K5 Manual
!

Whirlwind – K5 – User Manual – P. 2
Table of Contents
1.!Assembly!......................................................................................................................................................!3!
2. Preparation before use!...........................................................................................................................!5!
3.!Instrument Panel!.......................................................................................................................................!6!
4.!General Advice!...........................................................................................................................................!7!
5.!Technical!Parameters!...............................................................................................................................!9!
!
!

Whirlwind – K5 – User Manual – P. 3
1. Assembly
!
Unfolding:
1. With the Kickscooter standing
vertical, pull and hold the toggle down
to release the base from the vertical
body tube. Push the base down to the
floor until you hear a click and the
Kickscooter is at a 90-degree angle.
Folding:
Similarly to unfolding the Kickscooter,
you have to pull and hold the toggle
down and then push down the main
body tube until it becomes parallel to
the base of the scooter. Once again,
you will know it is folded after you hear
a click.
!
!

Whirlwind – K5 – User Manual – P. 4
Attaching Handle Bars:
The Kickscooter will arrive without the
handlebars being attached so this is
something that the user must do.
To do this, align each handle bar to
the grooves found in the left and right
handle bar socket. Rotate each
handle anticlockwise until it is tightly
secured in each groove.
!
Attach Kickstand:
To attach the kickstand to the Kickscooter, use
the Allen Key provided and loosen the small
screws in the area where the kickstand should
go (please refer to the images provided as
reference). Then, insert these screws into the
holes on the kickstand and fasten it again onto
the Kickscooter.

Whirlwind – K5 – User Manual – P. 5
2. Preparation before use
2.1 Charging
Before using the Kickscooter for the first time, please plug the charger in to the power source. Equipped with
high power charger, a full charge usually takes 2-3 hours.When charging, red light indicates charging is
ongoing and green light indicates when the Kickscooter is finished charging. Please try to avoid unplugging
the charger before the device is fully charged.
2.2 Battery indicators
The Kickscooter device has an instrument panel to show the battery status as well as other functions. Please
check the battery status before using.

Whirlwind – K5 – User Manual – P. 6
3. Instrument Panel
The Kickscooter comes with a bright LED display system
that shows the following functions:
Speed: The speed is shown in km/h and is shown in
large red numbers so that it is clearly visible when
driving.
Different modes: Press 2 times in quick
succession.
DIS- shows Kilometers travelled in a single journey
ODO- shows total Kilometers travelled
VOL- shows battery voltage at that given moment
Front Light- after pressing 3 times, the headlamp
signal should appear on the instrument panel. From
here you can manually Power On and Off the Front
Light by pressing the switch on the front of the K5.
Time: The overall time spent on a single trip
Battery Indicator: Shows how much battery is left. The
faster you go the faster you will drain the battery.
Mode Button: The mode button is the middle button
found below the screen. It can change what is displayed
on the screen and show different functions.
Power On and Off- Front Light:press 3 times in quick
succession.
Power On and Off the device:hold down for 3
seconds.
Change Gear:The mode button is used to cycle through
the gears. Press once to increase the gear. When it
reaches gear 3, press again to cycle back to gear 1.
!

Whirlwind – K5 – User Manual – P. 7
4. General Advice
* Riding on vehicle roads is illegal. Do not
ride in water over 2cm. No more than 1
person can ride the vehicle at a time.
Please ride at a low speed (3-10 km/h) or
stop when encountering a speed bump or
pothole.
* It is an entertainment tool rather than a vehicle. But
when you drive it into the public area, it gains the
attributes of a vehicle so please drive according to
the User Manual so you don’t put yourself or others
at risk.
* Once driving on public roads or other
public areas, you might be face with the
risk caused by motoring offences/ improper
operations of other people or vehicles;
even if you do as said in the User Manual.
As with all vehicles, the faster you drive the
longer the braking distance will be.
Emergency braking on the smooth surface
may result in loosing balance because of
wheel slip, so stay alert, maintain a proper
speed, keep a rational safe distance to
other people and vehicles during driving is
very important. Please keep alert and low
speed before driving into unfamiliar terrain
* You must always abide strictly to the User Manual's
safety requirements. We won't take any direct
responsibility and joint liability for any losses in
property, human accidents, legal disputes or other
adverse event caused by the behaviour of the driver
violating the User Manuals guides.
* To avoid injury, please don't lend the Kickscooter to
people who don't know how to it. Please teach them
and tell them to wear a helmet and protective body
gear when driving.

Whirlwind – K5 – User Manual – P. 8
! !
* Please check it before riding. If you find
an obvious abnormality such as parts
loosening, battery life reducing obviously or
excessive wear and so on, please stop
using immediately and please contact our
customer service to speak to a professional
about product maintenance and service.
* When washing, make sure it is
Powered Off, unplug the charging cable
and cover the charging rubber cover,
otherwise it may result serious problems to
the scooter because of flooding water.
* If there are stains on the surface of the vehicle,
wipe it with a soft wet cloth.
* Store the vehicle in a dry and cool room when not
in use; try to avoid keeping it outside for a long time.
Outdoor environmental with sunlight
exposure/overheating/under cooling will accelerate
the ageing of appearance reduce the life time of
batteries.
* When using at normal temperatures,
batteries can exert higher endurance
distance and performance. If using under
0°C, batteries' life and performance will
reduce.
* Don't clean with alcohol, gas, kerosene and other
corrosive and volatile chemical solvent, or it will badly
damage the appearance and internal structure of the
scooter. Pressure washing is highly discouraged.

Whirlwind – K5 – User Manual – P. 9
5.#Technical#Parameters#
Drive mode
High torque 5.5 - inch hub motor
Weight (kg)
7
Max Speed (mph)
15.5
Max Range
>18 miles
Max Climbing Angle
20°
Battery Capacity
25.2V 4.4AH
Battery Type
Lithium
Battery Brand
LG
Charge time (hours)
2-3
Max Loading
120KG
Size (mm)
(H) 1030 x (W) 920 x (D) 428
! !
