Working Instructions
Translation
Heat ring welding device
WIDOS HRG 16, Segment
Keep for further use !

Kunststoffschweißtechnik
Product identification
18.04.11 orking Instructions IDOS HRG 16, Segment Page 2 of 50
Type: IDOS HRG 16, Segment
Serial number: / year of construction: see name plate
Customer entries
Inventory No.:
Place of working:
Order o spare parts / a ter sales service
Address o the Manu acturer WIDOS
ilhelm Dommer Söhne GmbH
Einsteinstr. 5
D-71254 Ditzingen-Heimerdingen
Phone: ++49 7152 9939-0
Fax: ++49 7152 9939-40
Address of subsidiary companies:
WIDOS
IDOS GmbH ilhelm Dommer Söhne AG
An der iesenmühle 15 St. Gallerstr. 93
D-09224 Grüna/Sachsen CH-9201 Gossau
Phone: ++49 371 81573-0 Phone: ++41 71 388 8979
Fax: ++49 371 81573-20 Fax: ++41 71 388 8973

Kunststoffschweißtechnik
Introduction
18.04.11 orking Instructions IDOS HRG 16, Segment Page 3 of 50
Purpose o the document
These working instructions give you information about all important questions which refer to
the construction and the safe working of your machine.
Just as we are, you are obliged to engage in these working instructions, as well.
Not only to run your machine economically but also to avoid damages and injuries.
Should questions arise, contact our service team in the factory or in our subsidiary companies.
e will help you with pleasure.
According to our interest to continuously improve our products and working instructions, we
kindly ask you to inform us about problems and defects which occur in exercise.
Thank you.
Structure o the working instructions
This manual is arranged in chapters which belong to the different using phases of the
machine.
Due to this structure, the searched information can be easily found.
 WIDOS 18.04.2011
. Dommer Söhne GmbH
Einsteinstraße 5
D-71254 Ditzingen-Heimerdingen
All rights reserved
Reprinting only allowed with permission of the corporation.
Any changes prior to technical innovations.

Kunststoffschweißtechnik
Contents
18.04.11 orking Instructions IDOS HRG 16, Segment Page 4 of 50
1. DESCRIPTION OF PRODUCT ...................................................................................... 6
1.1. General .......................................................................................................................................6
1.2. Sa ety measures ........................................................................................................................6
1.3. Con ormity .................................................................................................................................7
1.4. Designation o the product.......................................................................................................7
1.4.1. Technical data ................................................................................................................7
1.4.1.1. IDOS HRG 16, Segment General data...............................................................7
1.4.1.2. Hydraulic aggregate ...................................................................................................7
1.4.1.3. Planer.........................................................................................................................8
1.4.1.4. Heating element.........................................................................................................8
1.4.1.5. Basic frame ................................................................................................................8
1.4.1.6. Reception box ............................................................................................................8
1.5. Equipment and accessories.....................................................................................................9
2. SAFETY RULES .......................................................................................................... 10
2.1. Explanation o the symbols and indications ........................................................................10
2.2. Obligations o the owner ........................................................................................................10
2.3. Obligations o the worker .......................................................................................................11
2.4. Measures o organisation.......................................................................................................11
2.5. In ormation about sa ety precautions ...................................................................................11
2.6. Instructions or the sta .........................................................................................................11
2.7. Dangers while handling the machine....................................................................................11
2.8. Dangers caused by electric energy .......................................................................................12
2.9. Speci ic dangers......................................................................................................................12
2.9.1. Danger of combustion by heating element and welding area ......................................12
2.9.2. Danger of stumbling over electric wires .......................................................................12
2.9.3. Danger of crushing by the guideways ..........................................................................12
2.9.4. Danger of bruising during planing.................................................................................12
2.9.5. Risk of injury by noises.................................................................................................12
2.9.6. Danger of catching clothes by the planer .....................................................................13
2.10. Structural modi ications on the machine..............................................................................13
2.11. Warranty and liability ..............................................................................................................13
3. FUNCTIONAL DESCRIPTION..................................................................................... 14
4. OPERATING AND INDICATING ELEMENTS.............................................................. 15
4.1. Elements o the basic machine..............................................................................................15
4.2. Elements o the hydraulic aggregate ....................................................................................16
4.3. Heating element.......................................................................................................................16
4.4. Planer........................................................................................................................................17

Kunststoffschweißtechnik
Contents
18.04.11 orking Instructions IDOS HRG 16, Segment Page 5 of 50
4.4.1. Protective motor switch at the planer ...........................................................................17
4.4.2. How to work with the planer .........................................................................................18
4.5. Extras: Clamping cylinders with aggregate..........................................................................19
4.6. Extras: Angle setting at the clamping device.......................................................................19
4.7. Special accessory: Stub end holder......................................................................................20
5. STARTING, OPERATING ............................................................................................ 21
5.1. Sa ety indications....................................................................................................................21
5.2. Starting .....................................................................................................................................21
5.3. How to set the heating element temperature .......................................................................22
5.4. Welding process......................................................................................................................22
5.5. How to weld angles .................................................................................................................24
6. WELDING LOG AND TABLES.................................................................................... 25
7. MAINTENANCE / REPAIR / TRANSPORT .................................................................. 29
7.1. In general..................................................................................................................................29
7.2. Basic machine .........................................................................................................................29
7.3. Clamping elements .................................................................................................................29
7.4. How to check and re ill the hydraulic oil...............................................................................29
7.5. Planer........................................................................................................................................30
7.6. Transport..................................................................................................................................30
7.7. Disposal....................................................................................................................................30
8. ELECTRIC AND HYDRAULIC DIAGRAMS ................................................................. 31
9. SPARE PARTS LIST ................................................................................................... 40
9.1. Basic machine .........................................................................................................................40
9.2. Heating element.......................................................................................................................42
9.3. Planer........................................................................................................................................44
9.4. Hydraulic aggregate ................................................................................................................46
9.5. Reception box..........................................................................................................................48
10. DECLARATION OF CONFORMITY......................................................................... 50

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: http://www.widos.de Email: [email protected]e
18.04.11 orking Instructions IDOS HRG 16, Segment Page 6 of 50
1. Description o product
This chapter gives important basic information about the product and its prescribed use.
All technical details of the machine are put together as a general arrangement.
1.1. General
The IDOS HRG 16, Segment has been designed for the heating element butt welding of
pipes and fittings out of PE from OD 1200 mm to OD 1600 mm.
This machine is a light-weight solid heat ring welding machine for usage particularly in
cramped problematic places.
The basic machine HRG 16 can be provided with reducer inserts (1200 - 1400 mm) for
clamping and welding smaller dimensions.
Both welding cylinders are plugged and can be combined with all HRG devices.
A second hydraulic aggregate with hydraulic clamping cylinders is optionally available.
The ring heating element is anti-stick coated, electronically controlled and supervised
according to DVS guideline 2208.
The welding cylinders with hydraulic aggregate, the clamping cylinders with hydraulic
aggregate and the electronic control apparatus for the heating element can be used with all 4
models which is a big economic advantage of the device.
All use going beyond is not purpose-oriented.
The machine is only to be used in a technically perfect condition, as well as purpose oriented,
safety- and danger-conscious in compliance with the working instructions and the relevant
safety regulations (especially the regulations for the prevention of accidents).
The described plastic welding machine may only be operated, maintained and repaired by
persons who are trained and informed about the dangers.
The manufacturer is not responsible for any damages caused by inexpert handling or
operation.
For personal injuries, material and immaterial damages resulting herefrom, only the user is
responsible!
1.2. Sa ety measures
In case of wrong use, wrong operation or wrong maintenance, the machine itself or products
standing nearby can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thoroughly read and the corresponding safety
regulations must be necessarily adhered to.

Kunststoffschweißtechnik
Description of product Chapter 1
18.04.11 orking Instructions IDOS HRG 16, Segment Page 7 of 50
1.3. Con ormity
The machine corresponds in its construction to the valid recommendations of the European
Community as well as to the according European standard specifications.
The development, manufacturing and mounting of the machine were made very carefully.
1.4. Designation o the product
The product is designated by a nameplate.
It contains the type, the serial number and the year of construction of the machine.
1.4.1. Technical data
1.4.1.1. IDOS HRG 16, Segment General data
eldable materials: - PE-HD, (PP)
Emissions - Noises exceeding 80 dB (A) may occur; during planing it is
obligatory to wear ear protection!
- hen using the named pipe materials and when welding
below 260° C, no toxicant damp arises.
Ambient conditions in the
welding area
- Take care for cleanness (no dust at the welding area).
- If secured by an appropriate measurement that allowed
conditions for welding are indicated, it is possible to work in
any outside temperature condition as far as the welder is
not constrained in its manual skill.
- Avoid humidity, if necessary use a welding tent.
- Avoid strong sun rays influence.
- Protect from wind, shut the pipe ends.
1.4.1.2. Hydraulic aggregate
Feeding: CEE 32A-Phase converter
Voltage: 400 V
Frequency: 50 Hz (± 10 %)
Power hydraulic-pump: 2 / 1.5 k
Motor speed: 2820 / 1380 rpm
orking pressure: 0 - 160 bar
Max. working pressure: 160 bar
Current hydraulic pump: 5.2 / 4.0 A
eight: 47 kg

Kunststoffschweißtechnik
Description of product Chapter 1
18.04.11 orking Instructions IDOS HRG 16, Segment Page 8 of 50
1.4.1.3. Planer
Feeding: CEE 16A – motor protective
Motor: Three-phase alternomotor
Power: 4.0 k
Voltage: 400 V
Frequency: 50 Hz (± 10 %)
Current: 9.1 A
Number of revolutions of planer disk: appr. 6.4 rpm
eight: 460 kg
1.4.1.4. Heating element
Power: 35 k
Voltage: 400 V
Frequency: 50 Hz (± 10 %)
Current: 152 A
Outside Ø: 1680 mm
Inside Ø: 800 mm
Surface: anti-stick coated
Attached elements: - Electronic temperature control
- Control lamp
- Connecting cable with CEE-plug (63 A)
eight: appr. 245 kg
1.4.1.5. Basic frame
Material of frame: Steel
Material of clamping rings: Steel
Ø of cylinder/piston 63 / 32 mm
Dimension (l x w x h): appr. 2100 x 950 x 910 mm (height excl.
clamping rings)
appr. 2010 mm (height incl. clamping rings)
eight with clamping rings: appr. 1100 kg
1.4.1.6. Reception box
Material: Steel
Dimension (l x w x h): appr. 2050 x 1090 x 1850 mm
eight: appr. 160 kg

Kunststoffschweißtechnik
Description of product Chapter 1
18.04.11 orking Instructions IDOS HRG 16, Segment Page 9 of 50
1.5. Equipment and accessories
Following tools and accessories are part of the first delivery:
1 each Allan key, angle size 6; 14
1 each Ring-fork wrench size 10; 17; 24
1 Tubular hexagon box wrench size 46
1 Torx screw-driver T10
1 Key for switch cupboard
For article numbers and spare parts contact the WIDOS company.

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: http://www.widos.de Email: [email protected]e
18.04.11 orking Instructions IDOS HRG 16, Segment Page 10 of 50
2. Sa ety rules
The base for the safe handling and the fault-free operation of this machine is the knowledge of
the basic safety indications and rules.
• These working instructions contain the most important indications to run the machine
safely.
• The safety indications are to be followed by all persons working on the machine.
2.1. Explanation o the symbols and indications
In the working instructions, following denominations and signs are used for dangers:
This symbol means a possibly danger for the life and the health of persons.
• The disrespect of these indications may have heavy consequences for the
health.
This symbol means a possible dangerous situation.
• The disrespect of these indications may cause light injuries or damages on
goods.
This symbol means a possible dangerous situation due to hot surfaces.
• The disrespect of these indications may conduct to heavy burns, respectively
to self-ignition or even fire.
This symbol means a possible dangerous situation by moving parts of the
machine
• The disrespect of these indications may cause heavy crushing of parts of the
body resp. damages of parts of the machine.
This symbol means a possible risk of injury by noises exceeding 80 dB (A).
• Ear protection is obligatory
This symbol gives important indications for the proper use of the machine.
• The disrespect of these indications may conduct to malfunctions and
damages on the machine or on goods in the surrounding.
Th e r e g u l a t i on s o r t he p r e ve n t i o n o a c c i de n t s a r e va l i d ( UV V ) .
2.2. Obligations o the owner
The owner is obliged only to let persons work at the machine who
• know about basic safety and accident prevention rules and are instructed in the handling of
the machine, as well as who
• have read and understood the safety chapter of this manual and certify this by their
signature.
• The safety-conscious working of the staff has to be checked in regular intervals.

Kunststoffschweißtechnik
Safety rules Chapter 2
18.04.11 orking Instructions IDOS HRG 16, Segment Page 11 of 50
2.3. Obligations o the worker
All persons who are to work at the machine are obliged before working:
• To follow the basic safety and accident protection rules;
• To have read and understood the safety chapter and the warnings in this manual and to
confirm by their signature that they have well understood them;
• To inform themselves about the functions of the machine before using it.
2.4. Measures o organisation
• All equipment required for personal safety is to be provided by the owner.
• All available safety equipment is to be inspected regularly.
2.5. In ormation about sa ety precautions
• The working instructions have to be permanently kept at the place of use of the machine.
They are to be at the operator's disposal at any time and without much effort.
• All safety and danger indications on the machine have to be in a clear readable condition.
• Every time the machine changes hands or is being rent to third persons, the working
instructions are to be sent along with and their importance is to be emphasized.
2.6. Instructions or the sta
• Only skilled and trained persons are allowed to work at the machine.
• It must be clearly defined who is responsible for transport, mounting and dismounting,
starting the operation, setting and tooling, operation, maintenance and inspection, repair
and dismounting.
• A person who is being trained may only work at the machine under supervision of an
experienced person.
2.7. Dangers while handling the machine
The machine IDOS HRG 16, Segment is constructed according to the latest technical
standard and the acknowledged technical safety rules. However, dangers for the operator or
other persons standing nearby may occur. Also material damages are possible.
The machine may only be used
• According to the purpose-oriented usage;
• In safety technical impeccable status.
Disturbances which may affect the safety of the machine must be cleared immediately.

Kunststoffschweißtechnik
Safety rules Chapter 2
18.04.11 orking Instructions IDOS HRG 16, Segment Page 12 of 50
2.8. Dangers caused by electric energy
Only skilled persons are allowed to work at electrical appliances.
• The electrical equipment of the machine has to be checked regularly. Loose connections
and damaged cables have to be replaced immediately.
• Protect the heating element from rain and dropping water (if need be use a welding tent).
• According to VDE 0100, the use on construction sites is only allowed with a power
distributor with a FI-safety switch.
2.9. Speci ic dangers
2.9.1. Danger o combustion by heating element and welding area
You can burn yourself, inflammable materials can be ignited!
The heating element is heated up to more than 200° C!
• Do not touch the surfaces of the heating element.
• Do not leave the heating element unattended.
• Take enough safety distance to inflammable materials.
• ear safety gloves.
2.9.2. Danger o stumbling over electric wires
• Make sure that no person has to step over the wires of heating element, planer and the
hydraulic aggregate.
• Lay the wires in such a way that the danger is kept to a minimum.
2.9.3. Danger o crushing by the guideways
•
••
• Do not stand or put hands between clamped pipe ends.
•
••
• Do not touch the piston rod of the cylinder and the linear guides during
operation.
2.9.4. Danger o bruising during planing
• Remove the sa ety bolt only during inserting the planer into the basic
machine or taking out o the basic machine (Chapter Fehler!
Verweisquelle konnte nicht ge unden werden.)!
•
••
• Do not touch the machine during planing.
2.9.5. Risk o injury by noises
Noises exceeding 80 dB (A) may occur; during planing it is obligatory to wear
ear protection!

Kunststoffschweißtechnik
Safety rules Chapter 2
18.04.11 orking Instructions IDOS HRG 16, Segment Page 13 of 50
2.9.6. Danger o catching clothes by the planer
You can cut yourself or even get bones broken!
• ear clothes tight to the body.
• Do not wear rings or jewellery during the work.
• If necessary, wear a hair-net.
• Always put the planer back into the reception box after and before each use.
• Transport the planer by means of a crane. Do not touch the surfaces.
• Always secure the planer by means of the safety bolt when planing or when it is placed in
the reception box.
• Switch the planer on only for usage.
If the planing pressure is too high, there is the danger that the planer tilts! For that reason
do not press the pipe ends stronger than necessary against the planer.
2.10. Structural modi ications on the machine
• No modifications, extensions or reconstructions may be made on the machine without
permission of the manufacturer.
• Machine parts which are not in a perfect condition are to be replaced immediately.
• Only use original IDOS spare and wear parts.
• In case of purchase orders please always state the machine number!
2.11. Warranty and liability
Fundamentally our "General Sales and Delivery Conditions" are valid.
They are at the owner's disposal latest when signing the contract.
Guarantee and liability demands referring to personal injuries or damages on objects are
excluded if they are caused by one or several of the following reasons:
• Not using the machine according to the prescriptions;
• Inexpert transport, mounting, starting, operating, and maintenance of the machine;
• Running the machine with defective or not orderly mounted safety appliances;
• Ignoring the information given in this manual;
• Structural modifications on the machine without permission;
• Unsatisfactory checking of parts of the machine which are worn out;
• Repairs performed in an inexpert way;
• In case of catastrophes and force majeure.

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: http://www.widos.de Email: [email protected]e
18.04.11 orking Instructions IDOS HRG 16, Segment Page 14 of 50
3. Functional description
B a s i c a l l y , t h e i n t e r n a t i o n a l a n d n a t i o n a l g u i d e l i n e s a r e t o b e
o l l o w e d !
The plastic pipes are clamped in the clamping rings.
If the pipe ends are not plane and parallel, the front sides of the pipes should be cut plane and
parallel by means of a planer and the misalignment of the pipes is to be checked.
Then the heating element is inserted and the pipes are pressed against the heating element
under defined adjusting pressure. This process is called "adjusting".
After the prescribed bead height being reached, pressure is reduced, the heating time
begins. The function of this time is to heat up the pipe ends.
After expiration of the heating time, the slides are opened, the heating element is removed
quickly and the pipes are driven together again.
The time gap from the removal of the heating element to joining the pipes is called change
over time.
The pipes are joined under prescribed welding pressure and then cool down under pressure
(cooling time).
The welded joint can be unclamped, the welding process is finished.
Heating element heats the pipe
up to welding temperature
Finished welding with
internal and exte
rnal bead

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: http://www.widos.de Email: [email protected]e
18.04.11 orking Instructions IDOS HRG 16, Segment Page 15 of 50
4. Operating and indicating elements
4.1. Elements o the basic machine
No. Name Function
1 Locking fork - Heating element and planer are laid with their supporting
forks onto the clamping devices.
2 Clamping screw - Tight clamping of the pipes during the welding process.
Hydraulic clamping cylinders replacing the clamping
screws are available on request (see chapter 4.5)
3 Clamping cylinder
(left/right)
- Application of the welding force.
- Easy dismounting and mounting of the cylinders by
detaching or attaching the locking cotter pins.
1
2
3

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
18.04.11 orking Instructions IDOS HRG 16, Segment Page 16 of 50
4.2. Elements o the hydraulic aggregate
4 Pressure gauge - Display of the hydraulic pressure
5 Push-button - By pressing the push-button the motor switches over from
1380 rpm up to 2820 rpm (high speed)
6 Control valve Opening and closing of the movable clamping ring, there are four
different positions:
- To the left side: movable clamping ring closes.
- In the middle (usual position): the pressure which is currently
achieved is kept (also by means of the built-in hydraulic
accumulator)
- Slightly to the right side (position depressurized): a possibly
existing pressure is released without opening the machine.
Due to the hydraulic accumulator, it takes about 10 s until the
pressure is completely released
- To the right side: movable clamping ring opens.
7 Set screw for pressure
relief valve
- Limitation of the pressure to the desired value.
8 Couplings - Connect the hydraulic hoses
9 Screw with oil dipstick - To check the oil level and to refill the oil
10 16 A-socket - Connection for planer
4.3. Heating element
6
4
7
8
5
9
10
Fuse to regulate the temperature
Regulator of tempera
ture
On/off switch
Connecting cable

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
18.04.11 orking Instructions IDOS HRG 16, Segment Page 17 of 50
4.4. Planer
No. Name Function
10 Movable supporting
fork
- To insert / lift-off the planer. After removing the safety
bolt, the supporting fork moves into direction of the arrow
11 Safety bolt with chain - Is axially secured by means of a grub screw. In order to
remove the safety bolt, turn it until the lever shows almost
vertically upwards, then remove it.
12 Supporting bolt - Insert the planer with the supporting bolts in the locking
forks of the clamping rings / reception box
13 Vent screw - Attention! Never put the planer on its side, there is the
risk of oil slick at the vent screw
14 Screw for chain
tightening
- Release the screw and move it in the slot for tightening or
releasing the planer chain. Tighten again firmly the screw
15 Switch on/off - The on/off switch of the planer is located at the planer
plug
w/o
no.
Protective motor
switch
- Overload protection at the plug of the planer
4.4.1. Protective motor switch at the planer
Always activate/deactivate the planer with the switch at the motor.
Switching-off the planer at the motor protective plug should only happen in exceptional
circumstances since the red push button works as overload protection at the same time.
10
11
12
14
13
15
On
Control lamp
Off

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
18.04.11 orking Instructions IDOS HRG 16, Segment Page 18 of 50
This means if e.g. the pressure of the planer is too high, it shuts off automatically.
In this case reduce the pressure on the planer and start the planer by the power switch at the
protective motor switch.
If the red control lamp lightens, the planer turns in the wrong direction.
Necessarily change the turning direction.
4.4.2. How to work with the planer
The flexible supporting fork of the planer is locked by the security bolt.
Prior to inserting the planer into the basic machine you
must turn the safety bolt for the planer support upwards
(left image)
Remove the safety bolt by pulling-out, the supporting fork is
now hanging downwards.
Suspend the planer from the ring bolt e.g. by a crane and
put it between the clamping tools in a way that the
supporting forks of the planer are locked in the supporting
forks of the basic machine.
Necessarily put the safety bolt again into the drill hole
(upon releasing the safety bolt, the handle must turn
downwards otherwise it is not applied correctly)
Switch the planer on/off by the on/off switch.
Turn and remove the safety bolt again before you remove
the planer from the basic machine and put the safety bolt
back in before inserting the planer into the reception box.
Safety bolt
Flexible
supporting fork

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
18.04.11 orking Instructions IDOS HRG 16, Segment Page 19 of 50
4.5. Extras: Clamping cylinders with aggregate
4.6. Extras: Angle setting at the clamping device
In order to weld angles, each clamping ring can be turned by max. 7,5°.
For that purpose, detach both hexagon screws (15) on the adapter plate, set the clamping ring
to the desired angle (up to 7,5°) and tighten again the hexagon screws (15).
Take care that the clamping rings do not touch each other at the top.
Clamping cylinder
Additional aggregate for
clamping cylinders.
2 or 4 clamping cylinders
can be connected.
Valve lever for max.
4 clamping cylinders
15

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
18.04.11 orking Instructions IDOS HRG 16, Segment Page 20 of 50
4.7. Special accessory: Stub end holder
In order to weld a cap or flange to a pipe you must use the stub end holder to fix the pieces.
Clamp the stub end e.g. into the left clamping tool with its front face towards the center of the
machine.
• Open the clamping tool.
• Pick up the stub end holder with belts from a
crane and place it with its stub end into the
lower clamping tool.
• Fix the stub end holder to the lower clamping
tool by three countersunk screws.
• Shut and tighten the clamping tool again.
• Fix the cap/flange onto the stub end holder
by the clamping claws.
• Mount the clamping claws according to the
outer diameter of the cap/flange onto the
stub end holder.
Drill holes to hang up
Clamping claws to
clamp the pieces
Countersunk
drilling to fix to
the clamping tool
Stub end to clamp
Put cap / flange here
Hexagon socket nut for the clamping
Screw to adjust the distance of clamping
claw to stub end holder
