Working Instructions
Translation
Heating element butt welding machine
WIDOS ASM 315 WM
Keep for further use!

Kunststoffschweißtechnik
Product identification
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 2 of 45
Type: WIDOS ASM 315 WM
Serial number: / year of construction: see type plate
Customer entries
Inventory-no.:
Place of working:
Order of spare parts and after sales service:
Address of manufacturer WIDOS
W. Dommer Söhne GmbH
Einsteinstrasse 5
D-71254 Ditzingen-Heimerdingen
Phone: ++49 7152 / 99 39 - 0
Fax: ++49 7152 / 99 39 - 40
[email protected]
http://www.widos.de
Address of the subsidiary companies:
WIDOS
WIDOS GmbH W. Dommer Söhne AG
An der Wiesenmühle 15 St. Gallerstr. 93
D-09224 Grüna / Sachsen CH – 9201 Gossau
Phone: ++49 371 / 8 15 73 - 0 Phone: [phone]
Fax: ++49 371 / 8 15 73 - 20

Kunststoffschweißtechnik
Introduction
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 3 of 45
Purpose of the document
These working instructions give you information about all important questions which refer to
the construction and the safe working of your machine.
Just as we are, you are obliged to engage in these working instructions, as well.
Not only to run your machine economically but also to avoid damages and injuries.
Should questions arise, contact our service team in the factory or in our subsidiary companies.
We will help you with pleasure.
According to our interest to continuously improve our products and working instructions, we
kindly ask you to inform us about problems and defects which occur in exercise.
Thank you.
Structure of the working instructions
This manual is arranged in chapters, which belong to the different using phases of the
machine.
Therefore the searched information can be easily found.
25.03.2014 WIDOS
W. Dommer Söhne GmbH
Einsteinstraße 5
D-71254 Ditzingen-Heimerdingen
All rights reserved.
Reprinting only allowed with permission of the corporation.
Any changes subject to technical innovations.

Kunststoffschweißtechnik
Contents
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 4 of 45
1. DESCRIPTION OF PRODUCT........................................................................................ 6
1.1. Usage and purpose-oriented use............................................................................................6
1.2. Safety measures........................................................................................................................6
1.3. Conformity .................................................................................................................................6
1.4. Marking of the product .............................................................................................................6
1.4.1. Technical Data....................................................................................................................7
1.4.1.1. WIDOS ASM 315 WM General Data........................................................................7
1.4.1.2. Heating element with control unit...............................................................................7
1.4.1.3. Drilling machine .........................................................................................................7
1.4.2. Equipment and accessories (option) ..................................................................................8
1.5. Wear parts (option) ...................................................................................................................8
2. SAFETY RULES.............................................................................................................. 9
2.1. Explanation of the symbols and indications..........................................................................9
2.2. Obligations of the owner........................................................................................................10
2.3. Obligations of the worker.......................................................................................................10
2.4. Measure of organization.........................................................................................................10
2.5. Information about safety precautions...................................................................................10
2.6. Instructions for the staff.........................................................................................................10
2.7. Dangers while handling the machine....................................................................................11
2.8. Specific dangers......................................................................................................................11
2.8.1. Danger of Stumbling over electric wires...........................................................................11
2.8.2. Danger of combustion by heating element and welding area ..........................................11
2.8.3. Danger of crushing and squeezing...................................................................................12
2.8.4. Danger of cutting and drawing-in by drilling device..........................................................12
2.8.5. Danger of injury by chips / remaining pieces / noise........................................................12
2.9. Structural modifications on the machine .............................................................................13
2.10.How to clean the machine......................................................................................................13
2.11.Warranty and Liability.............................................................................................................13
3. FUNCTIONAL DESCRIPTION ...................................................................................... 14
4. OPERATING AND INDICATING ELEMENTS .............................................................. 15
4.1. Elements on the basic machine.............................................................................................15
4.2. Heating element and control..................................................................................................16
4.2.1. How to set the heating element temperature ...................................................................16
4.3. Drill and clamping bracket .....................................................................................................17
4.3.1. How to clamp the drill to the clamping tool.......................................................................17
4.3.2. How to adjust the drill diameter ........................................................................................18
4.3.3. Knife blocks ......................................................................................................................19
4.4. Clamping tool right, for branch pipe.....................................................................................19
4.5. Clamping tool left, for main pipe ...........................................................................................20

Kunststoffschweißtechnik
Contents
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 5 of 45
5. STARTING AND OPERATING...................................................................................... 21
5.1. Starting.....................................................................................................................................21
5.2. Drilling and welding process.................................................................................................22
5.2.1. Drilling...............................................................................................................................22
5.3. Welding process......................................................................................................................23
6. WELDING LOG AND TABLES ..................................................................................... 25
7. MAINTENANCE / STORING / TRANSPORT................................................................ 29
7.1. General.....................................................................................................................................29
7.2. Clamping elements .................................................................................................................29
7.3. How to clean the machine......................................................................................................29
7.4. How to change the knifes.......................................................................................................30
7.5. Transport..................................................................................................................................30
7.6. Disposal ...................................................................................................................................30
8. WIRING DIAGRAM........................................................................................................ 31
9. SPARE PARTS LIST..................................................................................................... 32
9.1. Basic machine with motion....................................................................................................32
9.2. Clamping device right.............................................................................................................35
9.3. Clamping device left ...............................................................................................................37
9.4. Drill............................................................................................................................................39
9.5. Control device .........................................................................................................................41
9.6. Heating element flexibel.........................................................................................................43
10. DECLARATION OF CONFORMITY.............................................................................. 45

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
W. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
Website: www.widos.de Email: [e-mail]
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 6 of 45
1. Description of product
The chapter gives important basic information about the product and its prescribed use.
All technical details of the machine are put together as a general arrangement.
1.1. Usage and purpose-oriented use
The WIDOS ASM 315 WM is intended for the drilling of a hole into main pipes and the heating
element butt welding of pipes out of PE and PP.
Branch pipes with OD = 63 up to OD 250 mm are welded onto main pipes with OD 90 up to
OD 315 mm by means of saddle welding.
All use going beyond is not purpose-oriented.
The machine is only to be used in a technically perfect condition, as well as purpose- oriented,
safety- and danger-conscious in compliance with the working instructions and the relevant
safety regulations (especially the regulations for the prevention of accidents).
The described plastic welding machine may only be operated, maintained and repaired by
persons who are trained and informed about the dangers.
The manufacturer is not responsible for any damages caused by inexpert handling or
operation.
For personal injuries, material and immaterial damages resulting hereof, only the user is
responsible!
Also part of the purpose-oriented use is:
respecting all the indications of the working instructions and
performing the inspection and maintenance works.
1.2. Safety measures
In case of wrong use, wrong operation or wrong maintenance the machine itself or products
being in the surrounding can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thoroughly read and the corresponding safety
advice must necessarily be adhered to.
1.3. Conformity
The machine corresponds in its construction to the valid recommendations of the European
Community as well as to the corresponding European standard specifications.
The development, manufacturing and mounting of the machine were made very carefully.
1.4. Marking of the product
The product is marked by a type plate.
It contains the type, the serial number and the year of construction of the machine.

Kunststoffschweißtechnik
Description of product Chapter 1
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 7 of 45
1.4.1. Technical Data
1.4.1.1. WIDOS ASM 315 WM General Data
Dimensions of main pipes: outside-Ø = 90 - 315 mm (optional)
Dimensions of branch pipes: outside-Ø = 63 - 250 mm (optional)
Material: PP, PE 80, PE 100
Wire cross section: 1.5 mm²
Emissions - Noises exceeding 80 dB (A) may occur; during drilling it is
obligatory to wear ear protection!
- When using the named plastic materials and when welding
below 260 °C no toxicant damp arises.
Ambient conditions in the
welding area
- take care for cleanness (no dust at the welding area)
- if secured by an appropriate measurement that allowed
conditions for welding are indicated, it is possible to work
in any outside temperature condition as far as the welder
is not constrained in its manual skill.
- avoid humidity, if necessary use a welding tent
- avoid strong sun rays influence
- - protect from wind, shut the pipe ends
1.4.1.2. Heating element with control unit
Heating area: 300 x 400 mm
Power: 3,2 kW
Current: 14 A (± 10 %)
Voltage: 230 V (± 10 %)
Frequency: 50 Hz
Fuse protection: 16 A
Surface: anti-stick coated
Interface heating element / control unit: 10-pole plug socket
Attached elements: - electronic temperature control
- on / off switch with control lamp
- connecting cable with plug
1.4.1.3. Drilling machine
Power: 1,05 kW
Current: 4.5 A (± 10 %)
Voltage: 230 V (± 10 %)
Frequency: 50 Hz
Fuse protection: 16 A
Attached elements: - on / off switch
- fixing device
- Start button
- connecting cable with plug

Kunststoffschweißtechnik
Description of product Chapter 1
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 8 of 45
1.4.2. Equipment and accessories (option)
The following tools and accessories are part of the first delivery:
Unit Denomination
1 set each Reducer insert eccentric for main pipe with OD 90 / 110 / 125 / 140 / 160 /
180 / 200 / 225 / 250 / 280 mm
1 set each Reducer insert for branch pipe with OD 63 / 75 / 90 / 110 / 125 / 140 / 160 /
180 / 200 / 225 mm
1 Center drill Ø 10 mm, 170 mm long
1 Knife box Ø 16 with one knife angular and one knife circular
3 Knife box Ø 16 with knife circular
1 Knife box Ø 12 with knife angular
3 Knife box Ø 12 with circular knife
1 Ring fork wrench size 13
1 Socket spanner size 13
1 Torx screw driver T15
1 each Allen key with T-grip size 4 / 5 / 6
1 Star screw M 8x20, for deactivating the spring load of the basic machine.
1.5. Wear parts (option)
Unit/
mach. Denomination Article no.:
1 Heating element flexible HASM315KP
1 set each Reduction insert eccentric (main pipe) with OD 090 / 110/ 125
/ 140 / 160 / 180 / 200 / 225 / 250 / 280 mm
3888…*
1 set each Reduction insert (branch pipe) with OD 63 / 75 / 90 / 110 /
125 / 140 / 160 / 180 / 200 / 225 mm
0918…*
2 Knife SCGT 90T304FN-ALU AK 10 on request
4 Knife RDLT 1604MOSN-AK10F on request
3 Knife 12T3MOSN-AL360 on request
5 Flat-head screw 3,5 x 8 with Torx drive on request
4 Flat-head screw 4 x 8 with Torx drive on request
1 Center drill Ø 10 mm 3814307
* For ordering necessarily give the dimensions!
See spare parts list for order numbers and single parts. In case of an order please always
indicate the machine number!

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
W. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
Website: www.widos.de Email: [e-mail]
25.03.14 Working Instructions WIDOS ASM 315 WM Page 9 of 45
2. Safety rules
The base for the safe handling and the fault-free operation of this machine is the knowledge of
the basic safety advises and rules.
These working instructions contain the most important indications to run the machine
safely.
The safety indications are to be followed by all persons working on the machine.
2.1. Explanation of the symbols and indications
In the working instructions, following denominations and signs are used for dangers:
This symbol means a possibly danger for the life and the health of persons.
The disrespect of these indications may have heavy consequences for the
health.
This symbol means a possible dangerous situation.
The disrespect of these indications may cause slight injuries or damages on
goods.
This symbol means a possible dangerous situation by moving parts of the
machine
The disrespect of these indications may cause severe crushing of parts of
the body resp. damages of parts of the machine.
This symbol means a possible dangerous situation due to hot surfaces.
The disrespect of these indications may conduct to heavy combustion,
respectively to self-ignition or even fire.
This symbol gives important indications for the proper use of the machine.
The disrespect of these indications may conduct to malfunctions and
damages on the machine or on goods in the surrounding.
This symbol means a possible risk of injury by noises exceeding 80 dB (A).
It is obligatory to wear ear protection.
This symbol means a possible danger of injury by drilling chips.
It is obligatory to wear safety glasses.
Under this symbol you get user tips and particularly useful information.
It is a help for using all the functions on your machine in an optimal way and
helps you to make the job easier.
The regulations for the prevention of accidents are valid (UVV).

Kunststoffschweißtechnik
Safety rules Chapter 2
25.03.14 Working Instructions WIDOS ASM 315 WM Page 10 of 45
2.2. Obligations of the owner
The owner is obliged only to let persons work at the machine who
know about basic safety and accident prevention rules and are instructed in the handling of
the machine, as well as who
have read and understood the safety chapter of this manual and certify this by their
signature.
The safety-conscious working of the staff has to be checked in regular intervals.
2.3. Obligations of the worker
All persons who are to work at the machine are obliged before working:
to follow the basic safety and accident protection rules.
to have read and understood the safety chapter and the warnings in this manual and to
confirm by their signature that they have well understood them.
to inform themselves about the functions of the machine before using it.
2.4. Measure of organization
All equipment required for personal safety is to be provided by the owner.
All available safety equipment is to be inspected regularly.
2.5. Information about safety precautions
The working instructions have to be permanently kept at the place of use of the machine.
They are to be at the operator's disposal at any time and without much effort.
In addition to the manual, the common valid and the local accident protection rules and
regulations for the environmental protection must be available and followed.
All safety and danger indications on the machine have to be in a clear readable condition.
Every time the machine changes hands or is being rent to third persons, the working
instructions are to be sent along with and their importance is to be emphasized.
2.6. Instructions for the staff
Only skilled and trained persons are allowed to work at the machine.
It must be clearly defined who is responsible for transport, mounting and dismounting, and
starting the operation.
A person who is being trained may only work at the machine under supervision of an
experienced person.

Kunststoffschweißtechnik
Safety rules Chapter 2
25.03.14 Working Instructions WIDOS ASM 315 WM Page 11 of 45
2.7. Dangers while handling the machine
The machine WIDOS ASM 315 WM is constructed according to the latest technical standard
and the acknowledged technical safety rules.
However, dangers for the operator or other persons standing nearby may occur. Also material
damages are possible.
The machine may only be used
according to the purpose-oriented use
in safety technical impeccable status
Disturbances which may affect the safety of the machine must be cleared immediately.
Only skilled persons are allowed to work at electrical appliances.
The electrical equipment of the machine has to be checked regularly.
Loose connections and damaged cables have to be replaced immediately.
Protect the heating element and drill from rain and dropping water.
According to VDE 0100, the use on construction sites is only allowed with a power
distributor with a FI-safety switch.
2.8. Specific dangers
2.8.1. Danger of Stumbling over electric wires
Make sure that no person has to step over the wires of the heating element and the drill.
2.8.2. Danger of combustion by heating element and welding area
You can burn yourself, inflammable materials can be ignited.
The heating element temperature is heated up to more than 250° C !
Do not leave the heating element unsupervised.
Do not touch the surfaces of the heating element.
Take enough safety distance to inflammable materials.
Do wear safety gloves.
Hang up the heating element on the bolt of the right side of machine and take care that no
person can touch the heating element.
When cleaning the hot heating element with detergents (e.g. with PE cleaner) there is the
danger of inflammation. For this reason take care that the inflammation point is above the
actual temperature of the heating element. Do not bring any fire sources (e.g. cigarettes)
close thereto.

Kunststoffschweißtechnik
Safety rules Chapter 2
25.03.14 Working Instructions WIDOS ASM 315 WM Page 12 of 45
2.8.3. Danger of crushing and squeezing
You may encounter considerable harm by crushing and squeezing:
While swiveling drill in and out.
Only swivel drill into the machine if no body part is within the swiveling area.
During driving drill and clamping tool back and forth.
Only drive branch clamping tool and drill back and forth if no body part is
within the driving area.
Do not touch the guiding rods at the machine.
During drilling if the main pipe is not clamped or not tightly clamped.
Check prior to drilling whether the main pipe is properly clamped into the left
clamping tool.
You may crush your fingers resp. be beaten by the turret upon release of the
clamping lever during which the machine is under pressure.
Hold the turret with one hand and only then release the clamping lever.
During the transport of the machine.
Swivel in the drill, fix it within the clamping tool and shut machine table.
2.8.4. Danger of cutting and drawing-in by drilling device
You may encounter cutting injuries and even fractures, the knives are very
sharp!
Wear safety gloves, especially while removing the chips.
Only remove chips if the drilling machine is switched off.
Wear tight-fitting clothes.
Do not wear rings or jewelry during work.
If necessary wear snood-type cap.
Keep away others from the drilling area.
Do not reach between drill and clamped pipe ends.
Make sure that the drill does not draw-in any clothes.
Take special attention during the transport of the machine; necessarily swivel
in drill and close machine table.
2.8.5. Danger of injury by chips / remaining pieces / noise
Do wear safety glasses during drilling!
Never remove chips if the drilling machine is running.
Do wear an ear protection during drilling!

Kunststoffschweißtechnik
Safety rules Chapter 2
25.03.14 Working Instructions WIDOS ASM 315 WM Page 13 of 45
2.9. Structural modifications on the machine
No modifications, extensions or reconstruction may be made on the machine without
permission of the manufacturer.
Machine parts which are not in a perfect condition are to be replaced immediately.
Only use original WIDOS spare and wear parts.
For ordering necessarily give the machine type and version number.
2.10. How to clean the machine
The used materials and tissues are to be handled and disposed of properly, especially:
when cleaning with solvents
when lubricating with oil and grease
2.11. Warranty and Liability
Fundamentally our „General Sales and Delivery Conditions“ are valid.
They are at the owner's disposal latest when signing the contract.
Guarantee and liability demands referring to personal injuries or damages on objects are
excluded if they are caused by one or several of the following reasons:
Not using the machine according to the prescriptions.
Inexpert transport, starting and operation of the machine and maintenance.
Ignoring the information given in this manual.
Structural changes on the machine without permission.
Unsatisfactory checking of parts of the machine which are worn out.
Repairs performed in an inexpert way.
In case of catastrophes and force majeure.

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
W. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
Website: www.widos.de Email: [e-mail]
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 14 of 45
3. Functional description
Basically, the international and national process guidelines are to be
followed.
Drilling:
Clamp the main pipe into the left clamping tool.
In order to carry out drilling swivel the drill between both clamping tools and fix it into the right
clamping tool.
The spring load of the basic machine is deactivated.
Now drill the hole into the main pipe by means of the drill.
Afterwards, drive the drill backwards and remove it from the clamping tool.
The spring load of the basic machine is activated again.
Welding:
Put the branch pipe into the right clamping tool, align it to the main pipe and clamp it.
The cleaned and heated heating element is brought in and the pipes are pressed against the
heating element under defined adjusting force. This process is called "adjusting".
The applied force can be read on the scale.
After the prescribed bead height being reached, the force is reduced, the heating time begins.
The function of this time is to heat up the pipe ends.
After expiration of the heating time, the slide is opened, the heating element is removed out
quickly and the pipes are driven together again. The time gap from the removal of the heating
element to joining the pipes is called change over time.
The pipes are joined under prescribed welding force and then cool down under pressure
(cooling time).
The welded pipes can be released, the welding process is finished.
Completed welding joint with
in- and outside bead
Heating element flexible
Heating element heats the pipes
up to welding temperature
Branch pipe
Main pipe

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone [phone] - 0
W. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
Website: www.widos.de Email: [e-mail]
25.03.2014 Working Instructions WIDOS ASM 315 WM Page 15 of 45
4. Operating and indicating elements
4.1. Elements on the basic machine
No. Denomination Function
1 Clamping device left-hand - to clamp the main pipes
2 Drill - to drill a hole for the branch into the main pipe
3 Star screw - to activate / deactivate the spring for table
4 Scale and needle - Display of the applied welding force
- max. display: 150 kp
5 Tension lever - to arrest the support
6 Clamping device right-hand - to clamp the branch pipe
- to fix the drill
7 Heating element flexible - to heat up the pipes
- is manually inserted between the pipes and
removed
8 Cross handle - to open / shut the support.
- Application of the adjusting force and of the
jointing force
9 Control for heating element - electric power supply and controlling
2
4
5
1 6
7
9
8
3

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
25.03.14 Working Instructions WIDOS ASM 315 WM Page 16 of 45
4.2. Heating element and control
No. Denomination Function
10 On / off switch red
illuminated
- as soon as the heating element is switched on, it is
heated up.
11 Temperature regulator - to set and control heating temperature
12 10-pole power socket with
cap + safety bracket
- Connection to the heating element, plug should always
be retained by the safety bracket
13 cable with plug 10-pole - Connection to control
14 Connecting cable - Connection with power supply 230 V / 16 A / 50 Hz
15 Bolt - holder for heating element
16 Heating area - to heat up the main pipe and branch pipe
17 Grip on heating element - to transport the heating element
- to move the heating area
4.2.1. How to set the heating element temperature
Display = Display of the actual value
Push shortly the button P (1), the display shows <SP>,
change desired value with buttons ▲(3) ▼(2).
Push shortly the button P (1), actual temperature is
displayed again (or automatic change after 30s).
During heating up to desired value, the control lamp K2 (4)
is on, having reached the desired temperature, the control
lamp K2 (4) is blinking.
11
12
14
10
15
16
17
13

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
25.03.14 Working Instructions WIDOS ASM 315 WM Page 17 of 45
4.3. Drill and clamping bracket
No. Denomination Function
18 Button - to switch the drill on / off only if the drill has been activated
with switch <24> and locked with locking switch <25>
19 Grip - to swivel the drill in / out of the machine
20 Drill plate - retainer for drill and knife blocks
21 Knife holder - to adjust the drill diameter (outer reading edge)
22 Scale - to adjust the drill diameter
23 Centering drill - to drill the centering drill hole into the main pipe
24 On / Off switch - to switch drill on / off, drilling is carried out with button <18>
25 Locking knob - to hold switch <24> on „ON“; the locking knob is released by
a short lifting of switch <24>
4.3.1. How to clamp the drill to the clamping tool
You must fix the drill into the right clamping tool in
order to carry out drilling (right image). Use the
turnstile to travel the drill afterwards.
Shift the swiveled-out drill into the machine
center.
Swivel the drill into the machine between main
pipe and right clamping tool.
Open the right clamping tool for branch pipe .
Shift the drill to the right with the cover of the
drill towards the ledge of the clamping tool.
Shut the clamping tool and fix the drill into the
clamping tool.
18
19
20
23
21
22
24 25
Cover of drill
Ledge

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
25.03.14 Working Instructions WIDOS ASM 315 WM Page 18 of 45
4.3.2. How to adjust the drill diameter
You must carry out the adjustment of the drilling diameter steadily on all four knife plates.
A knife block consists of: knife plate, knife holder, knife and screws.
Release the four pan-head screws on the knife plate.
Shift the knife plate until the dimension for the inner diameter of branch pipe has been
reached on the scale.
Fix the knife plate in this position.
The centering drill must always be mounted in the middle of the drill plate during
drilling with the knife plates!
Knife plate
Pan-head screw
Center drill
Knife holder
Knife
Reading edge
Scale

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
25.03.14 Working Instructions WIDOS ASM 315 WM Page 19 of 45
4.3.3. Knife blocks
The machine features two knife block sizes.
The small knife blocks are intended for drillings up to 110 mm.
The large knife blocks are intended for drillings larger than 110 mm and for main pipes with
large wall thickness.
4.4. Clamping tool right, for branch pipe
Clamp pipes with OD 250 mm into the clamping tool.
Screw reducer inserts into the clamping tool for pipes with OD 63 – OD 225 mm.
In order to insert the pipes detach the spindle nut and swivel it out (arrow).
You may now swivel out the upper clamping tool (arrow) and insert the branch pipe.
In order to clamp the pipe swivel in the spindle nut again and tighten it.
Small knife
block
Circular knife
(3 pieces)
A
ngular knife
(1 piece)
Large knife
block
Circular knife
(3 pieces)
A
ngular and circula
r
knife (1 piece)
Spindle nut
Clamping tool upper part
Clamping tool lower part
Reducer insert
Attachment screws for
reducer insert

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
25.03.14 Working Instructions WIDOS ASM 315 WM Page 20 of 45
4.5. Clamping tool left, for main pipe
You may adjust the clamping of the claws by slightly turning in and out the adjusting screws.
The main pipes must always be clamped tightly using the levers.
Clamp pipes with OD 315 mm into the clamping tool.
Screw reducer inserts into the clamping tool for pipes with OD 90 – OD 280 mm.
The reducer inserts have a dimension marking.
They may be screwed to the clamping claws from the in and outside.
You may shift the clamping tool on the machine table if necessary.
For this purpose detach the two pan-head screws and shift the clamping tool to the requested
position. Please observe that the outer slot nut is still well-guided in the table.
Rear clamping claws
shut, lever clamped
Front clamping claws
shut, lever not clamped
Open clamping
claw
Reducer insert
Hexagon-head screw
Fixing screw for
reduction inserts
A
d
j
ustin
g
screw
