Winix ZERO Pro User manual

User Manual
Model
Use & Care
Guide
ˍPlease read and follow all safety rules and instructions
in this manual before operating.
ˍThe product warranty is printed on the back of this
guide, so please keep it in a safe place for future use.
WINIX AIR PURIFIER
ZERO Pro (AZPU370-IWE)


ZERO ProEnglish
CONTENTS
5-STAGE AIR PURIFICATION3
CONTROLS4
WHERE TO USE5
INSTALLING THE FILTERS6
SAFETY AND CAUTIONS8
INITIAL OPERATION9
AUTO AND SLEEP10
MANUAL MODE, TIMER AND PLASMAWAVE
®
11
CHILD LOCK, AIR QUALITY LED12
FILTER CARE13
PARTICLE SENSOR CARE17
CLEANING CARE18
FREQUENTLY ASKED QUESTIONS19
UNIT SPECIFICATIONS21
PRODUCT WARRANTY 22
▶This product is suitable for 220 ~ 240V only.
French 24
Spanish 47
German 70
Italian  93
Dutch 116
Polish 139


English ZERO Pro
5-STAGE AIR PURIFICATION
Pre-lter
5
4
3
1
AOC™
(Advanced Odor Control)
Carbon Filter
2
replaceable
washable
True HEPA lter
replaceable
Cleancel™
(Anti-microbial coated)
PlasmaWave
Product
User Manual
UserManual
Model
Use&Care
Guide
Please read and follow all safety rules and instructions
inthis manual before operating.
The product warranty is printed on the back of this
guide,so please keep it in a safe place for future use.
WINIX AIR PURIFIER
ZERO Pro (AZPU370-IWB)
Pre-lter/AOC™ Carbon Filter/
True HEPA lter with Cleancel™
(Included with the product.)


English ZERO Pro
CONTROLS
Air Outlet Vent
Light Sensor
Detects the amount of
ambient light within
the environment, to
adjust the brightness
of the LED indicators.
Mode / Fan Speed Button
Every time the Mode button is
pressed, the Mode LED light will
cycle through the settings. (Auto,
Sleep, Low, Medium, High, Turbo)
Timer Indicator
If timer has been set,
the LED light Indicates
the set time of operation.
PlasmaWave Indicator
Indicates whether
PlasmaWave is
enabled or disabled.
Timer / Air Quality Button
Press to cycle through and set
desired length of operation
(1hr, 4hr, 8hr, [NO TIMER]).
Press and hold for 3 seconds to
enable or disable the Air Quality
light.
Smart Sensor
Automatically
detects indoor air
quality.
Child Lock Button
Press and hold for 3 seconds
to enable or disable the Child
Lock mode. LED light indicates
whether Child Lock mode is
enabled or disabled.
Reset Button
After replacing a lter,
press the RESET button
for at least 5 seconds.
Power Button
Turns the unit on
or o.
Check Filter
Indicator
LED light indicates
when it is time to
change the lter.
PlasmaWave Button
Enables or disables
PlasmaWave .


English ZERO Pro
WHERE TO USE
Allow 30 ~ 46 cm. of space between TVs, radios, and other electronic products
electromagnetic interference from certain electronics may cause product malfunction.
Place indoors away from direct sun light
direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
flimsy or slanted surfaces may result in abnormal noise and vibrations.
30~46 cm
30~46 cm
WARNING Follow these instructions to reduce the risk of serious injury
or death and to reduce risk of damaging the unit.
Do not use around mist or fumes from
industrial oil or around large quantities of
metallic dust.
Do not place around heating elements.
Do not install in any sort of motor or
transport vehicle (trucks, boats, ships,
etc.).
Do not place in an area with excessive
amounts of noxious gases.
Do not place near any flammable
materials (aerosols, fuel, gases etc.). Do not have unit facing into wind or draft.
Do not place below any electrical outlet. Do not place in excessively humid areas
where unit may become wet.
※This unit is not intended to be used to preserve documents or in art conservation.


English ZERO Pro
This product comes with all of the required filters. The protective plastic wrap must be
removed from the filters before use.
※Operating the unit without removing the plastic wrap may result in product failure.
※Unplug and make sure the unit is turned off before installing filters.
※The unit will automatically power off when front panel is opened.
① Remove the front panel by grasping its
upper edge and gently pulling towards
yourself.
ˍTo remove the front panel, the latch at
the lower edge of the panel must be
released from its position.
Latch
② Remove the filters from the unit, they are
protected inside a plastic wrap.
③ Remove filters from protective plastic wrap.
ˍOperating the unit without removing
filters from plastic may cause abnormal
noise, deformation, or fire as a result of
overheating.
Note
ˍRefer to pages 15 - 18for detailed information on filter care
and how to replace them.
INSTALLING THE FILTERS


English ZERO Pro
INSTALLING THE FILTERS
④ Install the filters until they fit securely in
place.
Filters must be installed in this order:
3 , 4 True HEPA filter with Cleancel™ (rear)
2 AOC™ Carbon Filter (middle)
1 Pre-filter (front)
ˍTo install the pre-filter, insert bottom tabs
into the slots on either side of the lower part
of the unit, then rotate upward to insert the
upper tabs into the slots at the top part of
the unit until both sides audibly click into
place.
Pre-lter
True HEPA
lter with
Cleancel™
AOC
TM
Carbon
Filter
3
1
2
4
⑤ Replace the front panel by first inserting
the latch at the bottom edge into the
base of the unit, then rotate the panel
upward toward the top of the unit until it
magnetically snaps closed.
⑥ When to service and replace filters:
Filter Indicator Light When to
service
When to
replace
1 Pre-filter none Clean once every
14days Permanent
2 AOC™ Carbon Filter Clean once every
3months Lasts up to
6~12months
3 , 4 True HEPA filter
with Cleancel™
Can NOT be
WASHED
※Intervals between filter replacement may vary depending on environment.
※For optimal use, Pre-filter can be cleaned every 14days which can extend the life of
other filters.
FILTER
ITEM: 1712-0093-01
T
This unit
is compatible
with
filter


English ZERO Pro
SAFETY AND CAUTIONS
Before operating this equipment, carefully read and follow these safety cautions and
instructions to avoid damage and ensure safe use.
Ensure filters are inserted before running unit
running unit without filters can shorten the units life and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the vents on the unit
objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with wet hands
the high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become blocked
blockage may lead to increased internal temperatures causing product failure and
deformation.
Do not use the unit as a step stool or place heavy objects on it
personal injury may occur or product failure and deformation.
WARNING Follow these instructions to reduce the risk of serious
injury or death and to reduce risk of damaging the unit.
Do not pull on the power cord when
unplugging the unit.
Do not tie or knot power cord when unit
is in operation.
If the unit becomes submerged in water,
unplug it and contact customer service.
Do not unplug or move the unit while in
operation.
Do not plug additional appliances into
the same outlet or power supply. Do not touch the plug with wet hands.
Unplug unit when not in operation for
extended periods of time.
Cord can become damaged by forcefully
bending, pulling, twisting, bundling,
pinching or placing heavy objects on it.
※If the supply cord is damaged, it must be replaced by a special cord or assembly
available from the manufacturer or its service agent.
※This appliance is not intended for use by a person (including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
※Children should be supervised to ensure that they do not play with the appliance.


English ZERO Pro
INITIAL OPERATION
① Insert the unit plug into an electrical outlet.
ˍThe Control Panel lights will turn on and
off.
② Press the‘Power’button.
Note
ˍDuring the first 4minutes of power up, the Air Quality light
will flash as the Smart Sensors measure the air quality in the
environment, after which normal operation will begin.
③ By default, when the unit first powers on, the
mode will be set to Auto with PlasmaWave
®
enabled.
ˍWhen in Auto Mode the fan speed will
be automatically adjusted according to
the environments air quality.
ˍPlasmaWave
®
works to remove harmful
airborne contaminants.
Note
ˍIn Auto mode, as the indoor air quality improves, the fan
speed will automatically be reduced to Low.
ˍWhen the unit is running, you may hear a chirping or buzzing
sound. The sound is from large particles passing through
PlasmaWave
®
, it is normal and does not signify product
failure. To disable PlasmaWave
®
, see page 11.


English ZERO Pro
AUTO AND SLEEP
Every time the Mode button is pressed, the Mode LED light will cycle through the
settings. (Auto, Sleep, Low, Medium, High, Turbo)
1. Auto Mode
Enables Auto operation based on the unit's air quality Smart Sensors.
① Press the Mode button to select Auto mode.
ˍThe mode LED light will indicate when
‘Auto’mode has been selected, and
operation will begin.
ˍEach time the Mode button is pressed,
the modes will be cycled. (Auto, Sleep,
Low, Medium, High, Turbo).
Note
ˍWhen in Auto Mode the fan speed is automatically adjusted
according to the indoor air quality. As the indoor air quality
improves, the fan speed will automatically be reduced. If the
indoor air quality decreases the fan speed will automatically
be increased.
ˍWhen unit is first started, Auto Mode is enabled and set to
Low fan speed.
2. Sleep Mode
① Press the Mode button to select Sleep mode.
ˍThe mode LED light will indicate when
‘Sleep’ mode has been selected, and
operation in that mode will begin.
Note
ˍWhen Sleep mode is selected, the fan speed is automatically
set to Low. Fan speed can be changed by pressing the Fan
Speed (Mode) Button.
ˍWhen Sleep Mode is enabled, the Air Quality light is disabled.


English ZERO Pro
MANUAL MODE, TIMER AND PLASMAWAVE®
Every time the Mode button is pressed, the Mode LED light will cycle through the
settings. (Auto, Sleep, Low, Medium, High, Turbo)
3. Manual Mode (setting fan speed)
Users can opt to manually set the fan speed to Low, Medium, High or Turbo.
① Press the Mode button to select the desired
fan speed.
ˍThe mode LED light will indicate the
selected fan speed, and operation will
begin.
Note
ˍWhen Manual Mode is in use, Auto and Sleep modes are
automatically disabled.
4. Timer
The timer can be set for when you want the unit to run for a specified period of time.
① Select the desired period by pressing the
Timer button.
ˍThe Timer LED light will indicate the
selected length of operation.
ˍEvery time the Timer button is pressed
the Timer LED light will cycle through
the settings.
(1hr, 4hr, 8hr, [NO TIMER]).
Note
ˍThe WINIX SMART app will display how much time is
remaining on the timer.
5. PlasmaWave
®
By default, PlasmaWave
®
is enabled whenever the unit is powered on.
① Press the Plasma button when the power is
on to enable or disable this feature.


English ZERO Pro
CHILD LOCK, AIR QUALITY LED
6. Child Lock
This feature prevents children from tampering with the control panel.
① Press and hold the Child Lock button for
3seconds to enable or disable the feature.
ˍWhen the Child Lock indicator is lit, the
feature is enabled.
ˍWhen Child Lock is enabled, the
control panel is locked and the settings
cannot be changed.
ˍTo disable, press and hold the Child
Lock button again for 3seconds.
7. Air Quality LED Light
The Air Quality LED light may be turned on or off.
① To turn the Air Quality LED light on or
off, press and hold the Timer button for
3seconds.
ˍWhen on, the LED light will indicate
the current indoor air quality according
to four levels BLUE (good), GREEN
(average), AMBER (fair), RED (poor).
3 seconds
Air Quality Indicator
Note
ˍWhen Auto Mode is enabled the Air Quality LED light may or
may not be on, depending on the amount of ambient light
in the room.
ˍWhen Sleep Mode is activated, the Air Quality Indicator light
is turned off.


English ZERO Pro
FILTER CARE
1. Changing Filters
When the Check Filter indicator LED is on, it is time to replace both the True HEPA filter
with Cleancel™ and AOC™ Carbon filters.
Filter Indicator Light When to
service
When to
replace
1 Pre-filter none Clean once every
14days Permanent
2 AOC™ Carbon Filter Clean once every
3months
Lasts up to
6~12months
3 , 4 True HEPA filter
with Cleancel™
Can NOT be
WASHED
※Intervals between filter replacement may vary depending on environment.
※For optimal use, Pre-filter can be cleaned every 14days which can extend the life
of other filters.


English ZERO Pro
FILTER CARE
2. Removing Filters
Ensure the unit is turned off and unplugged before removing filters.
※The unit will automatically power off when front panel is opened.
① Remove the front panel by grasping its
upper edge and gently pulling towards
yourself.
ˍTo remove the front panel, the latch at
the lower edge of the panel must be
released from its position.
Latch
② Press the tabs on the top edge to remove
the 1 Pre-filter.
Tabs
③ First remove the 2 AOC™ Carbon Filter
and then the 3 , 4 True HEPA filter with
Cleancel™ by pulling on the numbered tags
at the top of each filter.
NOTICE
ˍFor optimal performance, only genuine Winix filters should
be used with this unit.


English ZERO Pro
FILTER CARE
3. Filter Assembly and Replacement
Filters should be re-installed in the reverse order of their removal.
① Insert the replacement
3 , 4 True HEPA filter with Cleancel™ (rear)
2 AOC™ Carbon Filter (middle)
ˍRemove the protective plastic wrap from
new filters. Operating the unit without
removing the protective plastic wrap
may cause abnormal noise, deformation,
or fire as a result of overheating.
True HEPA
lter with
Cleancel™
AOC
TM
Carbon Filter
3
4
2
② Insert the 1 Pre-filter (front)
ˍTo install the pre-filter, insert bottom
tabs into the slots on either side of
the lower part of the unit, then rotate
upward to insert the upper tabs into
the slots at the top part of the unit until
both sides audibly click into place.
③ Replace the front panel by first inserting
the latch at the bottom edge into the
base of the unit, then rotate the panel
upward toward the top of the unit until it
magnetically snaps closed.
④ After replacing the filters, turn the power
back on and then use a thin object, such as
a paper clip, to press the RESET switch for
5seconds.


English ZERO Pro
FILTER CARE
4. Cleaning the Pre-filter
Intervals between filter cleanings may vary depending on the air quality.
① Use a vacuum cleaner or soft brush to clean
the Pre-filter. If it is excessively dirty, wash
with room temperature water.
ˍUse only water, do not use volatile
substances such as alcohol or acetone.
※If the pre-filter becomes damaged
or in any way needs replacement:
Please contact your local
dealer
NOTICE
ˍDo not use benzene, alcohol, or other volatile fluids, which
may cause damage or discoloration.
ˍThe Pre-filter is reusable after cleaning.
ˍDo not use hot water over 40°C or volatile fluids such as
paint thinner.
ˍAfter washing the pre-filter, allow it to dry completely in a
wellventilated area. Otherwise, it may develop a bad odor.


English ZERO Pro
PARTICLE SENSOR CARE
Particle Sensors Care
For optimal performance of the Particle Sensor, which detects airborne dust and
ultrafine particles, clean it every two months. Clean it more frequently when the unit is
running in a place with high dust levels.
① Open the Particle Sensor cover.
② Use a damp cotton swab to wipe the lens
and intake area of the Particle Sensor.
ˍTo clean the sensor area, use only water.
Do not use volatile substances such as
alcohol or acetone.
Lens
Cotton swab
③ Wipe away any remaining moisture with a
dry cotton swab.
④ Close the Particle Sensor cover.
ˍThe Particle Sensor cover may be
cleaned using a vacuum cleaner.


English ZERO Pro
CLEANING CARE
Cleaning the exterior and interior
Cleaning the exterior
Wipe with a soft damp cloth using room
temperature water. Afterwards, wipe it down
with a clean dry cloth.
ˍFor optimal performance, clean the front
panel 1-2times a month.
Cleaning the interior
Open the front panel and clean the interior with
a vacuum cleaner.
ˍFor optimal performance, clean the interior
1-2times a month.
NOTICE
ˍWhen cleaning the unit, always unplug the power cord first
and then wait until the unit has cooled off.
ˍNever disassemble, repair or modify this unit yourself.
ˍDo not use flammable sprays or liquid detergents.
ˍDo not allow children to clean or maintain the unit
ˍBefore cleaning or maintaining, ensure unit is off and
unplugged.


English ZERO Pro
FREQUENTLY ASKED QUESTIONS
Problem Check / Actions to take
It does not turn on
at all.
ˍIs there a power outage?
Check to see if other lights and electrical
equipment are working and try again.
It doesn’t work in
Auto mode.
ˍHas Auto mode been selected?
Press the Mode button until Auto mode is
selected.
ˍIs the sensor blocked or clogged?
Clear the sensor using a vacuum cleaner. view
page 19.
It vibrates and
makes a lot of
noise.
ˍIs it running on a slanted surface?
Move the unit to a hard, flat area of the floor.


English ZERO Pro
FREQUENTLY ASKED QUESTIONS
Problem Check / Actions to take
The power plug
and outlet feel
hot.
ˍIs the plug securely plugged in?
Make sure the plug is properly plugged into the
outlet.
There is a strange
smell.
ˍIs it being used in a place with a lot of smoke, dust,
or odors?
Clean the air intakes on the front sides of the
unit and clean the pre-filter.
Contact customer service to confirm the exact
cause.
Replace the AOC™ Carbon filter and True HEPA
filter with Cleancel™.
The product is not
purifying the air
enough.
ˍIs the Check Filter indicator light on?
Replace the filters as required.
