wink haus blueMotion Assembly instructions

winkhaus.de
blueMotion
Motorised Multipoint Locking System (24 V DC)
Installation, Operating and Maintenance Instructions
06/2018

2
3
4
5
6
7
8
9
1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
The blueMotion motorised multipoint locking system conforms to the
requirements established by the directives of the council on the harmonization
of legal regulations of member states regarding electromagnetic compatibility
(89/336/EWG).
The manufacturer shall hereby certify the conformity of this product and
document such by the CE marking according to the CPR (see Appendix).
Berkeser Straße 6
D-98617 Meiningen
Germany
T + 49 (0) 3693 950-0
F + 49 (0) 3693 950-134
www.winkhaus.de
The following information and graphic images provided correspond to the
current status of this product’s development and manufacture.
For the purpose of customer satisfaction and operational reliability of the
blueMotion motorised multipoint locking system, we reserve the right to make
changes to the product.
All information and specifications provided by this operating manual have been
compiled and reviewed with utmost care.
Due to the nature of technical advances made, amendments to legal regulations
and other compulsory changes we do not warrant for the correctness or com-
pleteness of the contents’ statements.
We always do appreciate suggestions or comments.
The blueMotion motorised multipoint locking system can be installed without
any problems, if the instructions provided are followed and the door specifica-
tions indicated have been met.
© Aug. Winkhaus GmbH & Co. KG, All rights reserved. Last revised: 06/2018
Aug. Winkhaus GmbH & Co. KG

2
3
4
5
6
7
8
9
1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
1 Important information
1.1 General information p. 6
1.2 Intended use p. 6
1.3 Use contrary to the intended purpose p. 7
1.4 Explanation of symbols p. 8
1.5 Important safety information p. 9
1.6 Abbreviations/Explanations p. 10
2 Product description
blueMotion motorised multipoint locking system p. 15
Keep rail/extension keep set/single keeps p. 19
Center keep FRA ... AV ... p. 20
Magnetic bush p. 20
Cable transition p. 21
Cable transition sash part T-KÜ-T1 FT p. 21
Cable transition sash part T-KÜ-T1 FT 2M/3,5 M p. 21
Cable transition set T-SET KÜ-T1 FT INTEG-BM p. 22
Cable transition frame part for T-KÜ-T1 p. 23
Cable transition frame part for external power supply p. 23
Cable transition frame part for frame power supply p. 23
5.3 Cable transition T-HT KÜ M1188 p. 23
Power supply p. 24
External power supply p. 24
Frame power supply (optional) p. 25
Battery p. 26
Access control systems p. 27
External control unit in the housing EV-G F24 R12 p. 28
Control for non Winkhaus access control systems p. 28

2
3
4
5
6
7
8
9
1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
3 Installation
3.1 Routing details p. 30
3.2 Magnetic bush p. 32
3.3 Cable transition p. 33
3.3.1 Cable transition T-KÜ-T1 FT (sash- + frame part) p. 33
3.3.2 Cable transition T-HT KÜ M1188 p. 37
3.4 Installations p. 39
3.5 Access control system transponder set p. 49
3.6 Access control system wireless remote control p. 50
3.6.1 Wireless remote control set p. 51
3.6.2 Wireless receiver (separate) p. 53
3.7 Connection of swing door drive p. 55
3.8 Non Winkhaus access control system (ACS) p. 59
3.8.1 Non Winkhaus access control system ACS general
(frame- and sash side) p. 59
3.8.2 Non Winkhaus access control system ACS
fingerprint (sash side) p. 59
3.9 Function switch day/night/reset p. 72
3.10 Control of additional functions p. 72
4 Operation/Programming
4.1 blueMotion p. 73
4.1.1 Locking and unlocking in night service mode p. 73
4.1.2 Locking and unlocking in day service mode p. 74
4.1.3 Use of the day mode for permanently opening
of the door p. 74
4.1.4 Instructions for switch day/night mode p. 74

2
3
4
5
6
7
8
9
1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
4.2 blueMotion with transponder p. 75
4.2.1 Operation p. 75
4.2.2 Programming p. 76
4.3 blueMotion with wireless remote control p. 78
4.3.1 Operation p. 78
4.3.2 Programming p. 78
4.4 Wireless receiver for additional applications
(e.g. Garage door control units) p. 82
5 Maintenance and Care
6 Errors/Causes/Troubleshooting
7 Technical specifications
7.1 Power supply unit p. 88
7.2 Frame power supply p. 88
7.3 Battery with charging connection p. 88
7.4 Antenna/control unit p. 89
7.5 Wireless remote control p. 89
7.6 Cable transition T-KÜ-T1 FT p. 90
8 Accessories and Classification
9 Declaration of performance

1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
6
Installation, Operating and
Maintenance Instructions
1 Important information
Dear customer!
We would like to thank you for the trust and confidence you have put in us by
purchasing our quality product.
Please carefully read this operating manual to become acquainted with the
installation and use of this security lock and to avoid malfunctions and safety
hazards.
1.1 General information
The blueMotion motorised multipoint locking system and recommended
Winkhaus components are suited to the following areas of application:
• Max. relative humidity 95%
• Ambient temperature between -10°C ... +55°C.
The entire door furniture has been explicitly designed to be used in conjunction
with genuine Winkhaus parts. Other parts, not recommended by Winkhaus, may
adversely eect the given properties of the motorised security lock.
We shall assume you use the lock as intended.
Access control systems and accessories included in the standard Winkhaus
scope of delivery have been inspected for proper performance. If you use
components of another manufacturer and if you have any doubts about the
suitability of the component, you will have to contact the respective manu-
facturer about its fitness for use.
1.2 Intended use
To ensure the intended use:
• the information and instructions required for this purpose must be passed on
to the respective persons,
• only trained professionals should install the door furniture, locking units and
accessory parts according to the installation instructions. Applicable DIN, EN
standards and BauPVO are about to follow.

CAUTION! Exceptions are panicLock blueMotion EN 179/1125.
Only panic free to turn cylinders with FZG anti-barricade
function and cam position max. ± 30 ° can be used!
DANGER! With panicLock blueMotion (BM) a rechargeable
battery with charging connection (item no. 2121455) is to be
installed!
Maintenance instructions/durability, see page 26, observe!
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
7
Installation, Operating and
Maintenance Instructions
1
EN
The stipulations of use as intended have been met, once the Winkhaus fittings
are:
• installed according to their defined purpose and installation specifications,
• not used in another way than described,
• maintained and cared for at regular intervals as instructed,
• is not used longer than the limits set for wear and tear,
• repaired by trained professionals in the event of malfunctions,
• with profile cylinder in accordance with EN 1303 (Corrosion Resistance
Class 3) generally with cam position ± 30°, in each case with smooth-
running „free to turn“ function, the use of a FZG cylinder is recommended.
The locking systems are not designed to absorb or compensate for changes in
shape or changes in the closing mechanism of the door caused by fluctuation in
temperature or in the structure of the building.
Waterproof doors or doors designed to contain aggressive corrosion-promo-
ting air require special door furniture.
The locking systems are incorrectly used – that is used contrary to the terms
described above – in evident in particular, if:
• the instructions on the intended use are not being followed;
• the problem-free operation is hindered due to the installation of external
objects and/or objects that are not purpose-conformant in the opening
zone, the locking system or within the keeps;
• the locking system or the keep is manipulated in such a way that their design,
mode of operation or function is changed;
1.3 Use contrary to the intended purpose

DANGER!
Danger to life or danger of serious injuries.
CAUTION!
Danger of material damage.
Notice:
Useful information and tips.
1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
8
Installation, Operating and
Maintenance Instructions
• the door is drilled through in the area of the lock housings or of the lock rod
once the lock has been installed;
• the dead bolt projection or other locking components are employed
contrary to their intended purpose, as a means to hold the door opened;
• the handle’s pin is driven through the spindle with force;
• the lock components are installed improperly or are tampered with, e.g. by
painting over moveable parts such as the bolt or the latch;
• loads exceeding those of normal manual force are transmitted via the safety
key onto the lock system;
• perform a manual or mechanical locking or unlocking during the motor is
working;
• the handle is turned counterclockwise or if a force greater than 150 N is
exerted on the handle;
• the clearance between the door frame and sash is increased or decreased,
which would for instance result from readjusting the hinge plates or from
lowering the door;
• if auxiliary lifting tools or other tools are used to open or close the lock;
• the handle and key are used at the same time;
• the lock is opened/closed with objects not intended for that purpose;
• the size of the door opening deviates from the specifications prescribed.
Flags are used to identify important information in this operating manual. Flags
such as DANGER or CAUTION indicate the degree of hazard.
It is imperative that you do follow the measures listed to avoid safety hazards!
1.4 Explanation of symbols

Eco-watch:
Notices on complying with regulations on environmental
protection.
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
9
Installation, Operating and
Maintenance Instructions
1
EN
1.5 Important safety information
Safety information described in this section is to be diligently adhered to
regarding the installation and use of the blueMotion motorised multipoint
locking system.
You are to heed the safety information provided without exceptions!
• Study the installation and maintenance instructions in this operating manual
and keep them in a place where they can be accessed without any problems.
Pass them on to the end customer after having installed the entrance door.
• The manufacturer shall not be held liable for damage caused by use contrary
to the intended purpose of the product.
• For security reasons, the lock has been designed to be used in conjunction
with genuine Winkhaus parts. Using other parts may adversely effect the
given properties of the security lock.
• It must be ensured that the door can be closed without any problems by the
key.
• Installation/repair of electrical equipment requires expertise, thus such work
should only be carried out by on electrician.
• Arbitrary modifications, changes or makeshift repairs are not permitted
due to concerns for safety. You must only use genuine Winkhaus parts for
replacements.
• The manufacturer shall only be held liable for security related properties of
the power lock as stipulated within the bounds of statutory regulations, if the
manufacturer himself or another instructed, authorized agent has carried out
the maintenance and upkeep work or made the changes.
• Winkhaus does not accept liability for any type of damage caused by
inadequate repair, modification or maintenance works made.
• For panicLock blueMotion EN179/1125 only panic free to turn cylinders with
FZG anti-barricade function and cam position max. ± 30 ° can be used!
• With panicLock blueMotion (BM) a rechargeable battery with charging
connection (item no. 2121455) is to be installed!

1
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
10
Installation, Operating and
Maintenance Instructions
The following terms and abbreviations are used in these operating manual:
T- Product range Security door lock
BM blueMotion
Handle Door handle
Grt. Set
SB FRA Center keep - latch/bolt/leveling member
MV means “upper adjustment”
UMV means “lower adjustment”
RS DIN-right-handed
LS DIN-left-handed
GR grey powder coated
EST stainless steel
MC surface mat chrome-plated (silver color)
WS white powder coated
Antenna Antenna of transponder set
Control External control
ACS Access control system
RX/TX Bus cable to exchange data between the exter-
nal control and motor housing
UP-Dose Switch box
LED Light emitting diode
PE Ground wire
N Neutral wire
L Phase
PF Power file
S Control
A Accu/battery
V Power supply
JY(ST)Y Cable type
AC Alternating current
DC Direct current
NO Make contact
NC Break contact
NO-NC Changer contact
USP Uninterruptible power supply
1.6 Abbreviations/Explanations

2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
11
Installation, Operating and
Maintenance Instructions
2 Product description
blueMotion is a state-of-the-art system to security lock entryway doors. Easy-
to-use and convenient. All opening and closing members of the locking mecha-
nism are power-driven.
Figure 2-1: Locking system blueMotion with accessories (e.g. external control
unit in switch box) and external power supply
In the
external
zone around
the entry
door
230 V AC

CAUTION! When using frame power supply 24 V DC no use
as a paniclock in emergency doors possible (due to lack of
combination with battery).
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
12
Installation, Operating and
Maintenance Instructions
Figure 2-2: Locking system blueMotion with accessories (e.g. external control
unit in the housing EV-G in the sash) and frame power supply 24 V DC
230 V AC

2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
13
Installation, Operating and
Maintenance Instructions
No. Name MUST!
Manda-
tory *
Available
as on
accessory
or as on
option
Supplied
by
customer/
not
included
in delivery
blueMotion motorised multipoint locking
system including motor housing (T-BM )
X
Keep rail T-SLExtension keep set
T-Grt SLSingle keeps T-SB
X X
Center keep T-SB FRA  AV  X X
Magnetic bush MV X X
Cable transition X
Cable transition sash part T-KÜ-T FT X
Figure - T-KÜ-T FT MM Cable
Cable at the sash side  m or  m long
plug for motor housing included
Figure - Cable transition set T-SET
KÜ-T FT INTEG-BM including cable
Sash part with cable  m cable ends
with -pole plug for housing EV-G
 connecting cable EV-G motor  m
(st Cable end with plug for housing
EV-G nd Cable end with plug for motor
housing BM)
Cable transition frame part
(suitable the sash part T-KÜ-T FT )
X
Figure - T-KÜ-T RT KABEL M
including cable  m for connection of
external access controls eg intercom
potential-free contact
Figure - T-KÜ-T RT KABEL M
RNT with plug connection to the frame
power supply  V DC (optional)

2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
14
Installation, Operating and
Maintenance Instructions
No. Name MUST!
Manda-
tory *
Available
as on
accessory
or as on
option
Supplied
by
customer/
not
included
in delivery
Power supply X
Figure - T-HT NETZTEIL  V DC A
Figure - T-NETZTEILRAHM**  V DC
 A
( A S) (optional)
including cable for connection of
external access controls eg intercom
potential-free contact
Battery T-HT BATTERY WITH CHARGING
CONNECTION
X
Access control system
shown antenna from the control unit 
transponder set
Notice Only install the antenna from
the transponder set in the external zone
around the entry door!
X
External control unit in the housing EV-G
F R
X
External control unit (for mounting eg
in a switch box)
X X
Open button X
DayNight service switch *** X
Switch box for () X
Handle X
* remaining components recommended for use, or should be used
alternatively
** when using frame power supply 24 V DC no use as a paniclock in
emergency doors possible (due to lack of combination with battery)
*** Realization of the day function in conjunction with daytime latch, electric
strike with day release or with roller latch

CAUTION! The panicLock
blueMotion EN 179/1125
anti-panic version must
generally be designed with a
free to turn cylinders with FZG
anti-barricade function and
mounted in conjunction with a
battery (Article No. 2121455)
for system zeroing.
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
15
Installation, Operating and
Maintenance Instructions
blueMotion is a fully motorized triple-point-lock
(including motor housing, sensor, can be used
DIN-right-handed/DIN-left-handed), which en-
sures a comfortable locking and unlocking of
doors with high safety and tightness.
They are profile cylinder in accordance with EN
1303 (Corrosion Resistance Class 3) generally
with cam position ± 30°, in each case with smoo-
th-running "free to turn" function, the use of a
FZG cylinder is recommended.
blueMotion motorised multipoint locking system

2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
16
Installation, Operating and
Maintenance Instructions
blueMotion motorised multipoint locking system
Part description Part-no.
Standard
T-BM-F L  M MC 5045967
T-BM-F L  M MC 5045837
T-BM-F L  M MC 4997359
T-BM-F L  M MC 5045838
T-BM-F L  M MC 5045839
T-BM-F L  M MC 5046014
T-BM-F L  M MC 5006975
T-BM-F L  M MC 5046015
T-BM-F L  M MC 5046016
T-BM-F L  M MC 4940335
T-BM-F L  M MC 4985948
T-BM-F L  M GR 2219719
T-BM-F L  M MC 2515260
T-BM-F L  M GR 4937767
T-BM-F L  M MC 4940336
T-BM-F L  M MC 4985949
T-BM-F L  M GR 2130343
T-BM-F L  M GR 2130351
T-BM-F L  M EST 2194515
T-BM-F L  M MC 5046017
T-BM-F L  M EST 29 41082
T-LA BMO-F L  M MC 4986470
T-BM-F L  M MC 5051573
T-BM-F L  M MC 5046018
T-BM-F L  M EST 2194929

2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
17
Installation, Operating and
Maintenance Instructions
blueMotion motorised multipoint locking system
Part description Part-no.
T-BM-F L  M MC 5046019
T-BM-F L  M MC 2400083
T-BM-F L  M MC 5000479
T-BM-F L  M MC 5046030
T-BM-F L  KABA M MC 2971329
T-BM-F L  M MC 4990890
T-BM-U L  M GR 2228869
T-BM-U L  M MC 5026882
T-BM-U L  M MC 5046032
T-BM-U L  M MC 5046031
T-BM-U L  M GR 2130360
T-BM-U L  M EST 2195075
T-BM-U L  M MC 5046033
T-BM-U L  M GR 2342813
T-BM-U L  M MC 4990393
T-BM-U L  M MC 5046034
T-BM-U L  M GR 5006557
T-BM-U L  M EST 293 0 0 41
T-BM-U L  KABA M MC 5028572
T-BM-U L  M MC 286 4101
T-BM-U L  M EST 2842199
T-BM-U L  M MC 5046035
T-BM-U L  M EST 2857243
T-BM-U L  M MC 5046036
T-BM-U L  M EST 2196799
T-BM-U L  M MC 4940872

2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
18
Installation, Operating and
Maintenance Instructions
blueMotion motorised multipoint locking system
Part description Part-no.
EN 179
T-BM-EN-F LS  M MC 5045963
T-BM-EN-F LS  M MC 5055868
T-BM-EN-F LS  M MC 5045964
T-BM-EN-F LS  M MC 5055869
T-BM-EN-U LS  M MC 5045965
T-BM-EN-U LS  M MC 5047897
T-BM-EN-U LS  M MC 5047023
T-BM-EN-U LS  M MC 5052536
T-BM-EN-U LS  M MC 5045966
EN 1125
T-BM-EN-F LS  M MC 5047043
T-BM-EN-U LS  M MC 5047898
T-BM-EN-U LS  M MC 5047899
T-BM-EN-U LS  M MC 5033 451

Notice: The magnetic bush has
to be ordered separately. In
keep rail/extension keep set a
bore diameter of 13.5 mm is to
be drilled (see figure 3.1-1).
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
19
Installation, Operating and
Maintenance Instructions
Keep rail/extension keep set/single keeps + ma-
gnetic bush separately. The magnetic bush has
to be installed in the frame and gives a signal to
the reedsensor in motor housing.
Keep rail/extension keep set/single keeps
Select the appropriate frame components (keep
rail/extension keep set/single keeps) in the cur-
rent program manual:
Program manual
timber / PVC / ALU
4934767
Program overview keep timber Chapter 2
Program overview keep PVCu
Vinyl
Chapter 2
Program overview keep aluminum Chapter 2
Example: profile INOUTIC System Prestige 
T-Grt. SL U26-192 ...
Please always do include the following specifica-
tions when placing your order: DIN-right-
handed or left-handed

Notice: The magnetic bush has to be ordered separately.
If you are using stainless door furniture, use the "EST"
magnetic bush. It is identified by a black magnet.
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T [phone] - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMotion 5044745
20
Installation, Operating and
Maintenance Instructions
Center keep FRA ... AV ...
Center keep for latch and deadbolt, provided
for retrofitting a T-TAGESFALLE "TAFA", of
PVCu/Vinyl, aluminum and timber/composite
entrance doors.
Select the respective keeps according to the
profile systems in the current program manual
(see program overview keep - Chapter 2).
Magnetic bush
Magnetic bush (adjustable, color grey) to trigger
motorised locking
• for timber entryway doors with on airgap of
4 mm
• for lower adjustments
•
for UMV2 extension keep sets/UMV2 keep rails
Magnetic bush UMV/H4
T-MAGNETIC BUSH UMVH KS
RAL TGR
2126723
T-MAGNETIC BUSH F EST-UMVH
KS RAL TGR
2174101
Magnetic bush (adjustable, color grey) to trigger
motorised locking
• for upper adjustments
• for MV2 extension keep sets/MV2 keep rails
Magnetic bush MV
T-MAGNETIC BUSH MV KS
RAL TGR
2126715
T-MAGNETIC BUSH F EST-MV KS
RAL TGR
21740 47
