Winners Only C1-DF364SN-F Series User manual

PART NO FIGURE DESCRIPTION Q'TY
CUSHION
CHAIR BACK
PARTS LIST
1 Pc
SEAT FRAME 1 Pc
1 Pc
1 Pc
2 Pcs
HARDWARE BAG
C1DF364SN--F-01
C1DF364SN--X-01
C1DF364SN--F-02
C1DF364SN--X-02
C1DF364SN--F-02
C1DF364SN--X-02
C1DF364SN--F-03
C1DF364SN--X-03
C1DF364SN--F-03
C1DF364SN--X-03
C1DF364SN--F-04
C1DF364SN--X-04
C1DF364SN--F-04
C1DF364SN--X-04
C1DF364SN--F-05
C1DF364SN--X-05
C1DF364SN--F-05
C1DF364SN--X-05
FRONT LEG (LEFT/RIGHT)
LADDERBACK SIDE CHAIR
C1- DF364SN- -F / C1-DF364SN- -X
ALR-08168A-SCNWC MADE IN MALAYSIA
PAGE 1 OF 2

HARDWARE PARTS :
STEP 1
Allen Key
JCBC Bolt (70 mm)
Lock Washer
Flat Washer
Allen Key
JCBC Bolt (40 mm)
Lock Washer
Flat Washer
(Fig.1.1)
(Fig.1.2)
Flat Washer
Lock Washer
JCBC Bolt (70 mm)
Allen Key
(Fig.2)
STEP 2
Assemble front leg as shown.
STEP 3
Turn the chair upright. Check its balance and tighten all screws and bolts to complete the assembly.
Chair Back
Dowel
ASSEMBLY:
MADE IN MALAYSIA
PAGE 2 OF 2
1. Position the chair back on a soft surface such as a carpet. Place the Box system assembly (Hardseat is pre-attached
to the seat frame in assembly) on to the middle rail of the chair back with the dowel fully inserted into the pre-drilled hole.
1.1 Insert JCBC Bolt (70 mm) through a Lock Washer and a Flat Washer into the pre-drilled holes on the apron frame at
rear corners.
1.2. Insert the JCBC Bolt (40 mm) through a Lock Washer and a Flat Washer into the pre-drilled holes on the apron frame
at rear rail.
2. Insert the JCBC Bolt (70 mm) through a Lock Washer, a Flat Washer and the pre-drilled holes of corner block into the
pre-drilled holes on the front leg, tighten the JCBC Bolt with Allen Key provided.
CARE INSTRUCTION
~ Be sure to use the same type of polish consistenly.
Your furniture will appear cloudy or streaky if oil
based or wax based polishes are interchanged.
~ Spray your furniture surface evenly. Wipe in a
circular motion with a soft clean cloth.
IMPORTANT NOTE :
~ Please keep all hardware out of the reach of
children.
JCBC Bolt
8 pcs
JCBC Bolt
2 pcs
Lock Washer
10 pcs
Flat Washer
10 pcs
Allen Key
1 pce
M6x40mm M6x70mm M6x13x2mm M6.5x16.5x1.2mm
LADDERBACK SIDE CHAIR
C1- DF364SN- -F / C1-DF364SN- -X
Box
System
Assembly
ALR-08168A-SCNWC
