Wiseup W8200 User manual

W8200

User Guide

I. Product Overview

1. Knob Cover for Mini USB Port

2. Camera Lens

3. Power Button

4. Green/Red Indicator Light

5. Time Adjustment Knob

6. Blue Indicator Light

7. Mode Button

8. Micro SD Card Slot

II. What’s in the Box

-1 × Watch Camera

-1 × USB Cable

-1 × AC110-240V to DC 5V Power Adapter

-1× 8GB Micro SD Card (fitted into the Micro SD card slot already)

III. Operation

>> Before using, please make sure your camera is fully charged.

>> Please make sure the Micro SD card has been formatted already and is securely

fitted into the camera’s SD card slot, or it will not work. We recommend you use a

SDHC Class 10 Micro SD card.

[Note]: If no Micro SD card is fitted into the camera, both blue and green indicator lights will be illumi-

nated for 3 seconds, then the green one will turn off and the blue one will flash 2 seconds and turn off.

After that, the green one will come on and flash 3 times then turn off. The camera will shut down auto-

matically.

3.1. POWER ON/OFF

3.1.1. Power on the camera by pressing the Power Button for 2 seconds. Both blue

and green indicator lights will be illuminated for 2 seconds and then the green one

will turn off while the blue one will stay illuminated, indicating the camera has en-

tered into standby mode automatically.

3.1.2. Power off the camera by pressing the Power Button for 2 seconds again in

standby mode. The green indicator light will flash 3 times and then turn off together

with the red one.

[Note]: The camera will shut down automatically if it is in standby mode without any operation more

than 3 minutes.

3.2. VIDEO RECORDING

3.2.1. Power on the camera by pressing the Power Button for 2 seconds. Both blue

and green indicator lights will be illuminated for 2 seconds and then the green one

will turn off while the blue one will stay illuminated, indicating the camera has en-

tered into standby mode automatically.

3.2.2. Press the Power Button once to start video recording. The blue indicator light

will flash 3 times and turn off.

3.2.3. Press the Power Button once again to stop video recording. The blue indicator

light will come on and stay illuminated, indicating the camera is back to standby

mode.

[Note]:

1). A video clip will be generated and saved every 5 minutes automatically.

2). The camera can record video for 120 minutes continuously on a full charge.

3). Each video clip will take up about 380-400MB storage space of the Micro SD card.

4). Video Resolution: 1920x1080P, 1280x720P, 640x480 Optional Video Format: AVI

5). Loop recording is supported.

6). If the battery is low during the video recording process, the green indicator light will flash 15 times

fast then blink 3 times slowly and turn off. Then the camera will save video files then shut down auto-

matically.

3.3. CAMERA/STILL PHOTOGRAPHY

3.3.1. Power on the camera by pressing the Power Button for 2 seconds. Both blue

and green indicator lights will be illuminated for 2 seconds and then the green one

will turn off while the blue one will stay illuminated, indicating the camera has en-

tered into standby mode automatically.

3.3.2. Press the Mode Button twice to enter into still photograph mode. Both green

and blue indicator lights will stay illuminated.

3.3.3. Press the Power Button once to take a photo. Every time you take a photo,

both green and blue indicator lights will flash once.

3.4. AUDIO RECORDING

3.4.1. Power on the camera by pressing the Power Button for 2 seconds. Both blue

and green indicator lights will be illuminated for 2 seconds and then the green one

will turn off while the blue one will stay illuminated, indicating the camera has en-

tered into standby mode automatically.

3.4.2. Press the Mode Button once to enter into audio recording mode. The blue

indicator light will turn off while the green indicator light will come on and remain

solid.

3.4.3. Press the Power Button once to record audio only. The green indicator light

will flash 3 times and turn off.

3.4.4. Press the Power Button once again to stop audio recording. The green indica-

tor light will come on and remain solid.

[Note]:

1). An audio clip will be generated and saved every 30 minutes automatically.

2). Audio Format: WAV

IV. Video/Image/Audio File Uploads

4.1. Power off the camera, remove the Micro SD card and insert it into a card reader.

4.2. Insert the card reader into a proper PC computer USB port.

4.3. The camera will be recognized as a removable disk drive.

4.4. All the files can be accessed in the drive.

V. Setting Time/Date Stamp

5.1. Power off the camera, remove the Micro SD card and insert it into a card reader.

5.2. Insert the card reader into a proper PC computer USB port.

5.3. The camera will be recognized as a removable disk drive.

5.4. Click on the drive in the root directory and inside the root directory, open the file

named “time.txt”.

5.5. Write the current date and time in the “time.txt” file with the correct format:

[date]

YYYY-MM-DD HH:MM:SS Y 1

For example:

[date]

2017-04-12 14:24:32 Y 1

Save this file.

5.6. If you need the camera to record video at a lower resolution, you can change 1

into 2 or 3 in the “time.txt” file. 1 stands for 1920x1080P, 2 for 1280x720P and 3 for

640x480.

5.7. If you don’t need the time stamp on the video footage, change “Y” into “N” in the

“time.txt” file.

For example:

[date]

2017-04-12 14:24:32 N 2

5.8. Restart the camera and the system will upgrade the program automatically.

VI. Charging

6.1. Power off the camera and connect the camera to an outlet AC power supply

using the DC5V power adapter and the USB cable provided.

6.2. Both red and blue indicator lights will stay illuminated during the charging pro-

cess.

6.3. It will take 40 minutes to obtain a full charge.

6.4. The red indicator light will turn off and the blue one will stay illuminated when the

camera is fully charged.

VII. Resetting

If for any reason, the camera stops responding or isn’t working properly, a quick

reset will restore it back to normal operation.

Operation: When the camera is powered on, press the Power Button and Mode

Button simultaneously once; the camera will shut down automatically. Then you can

restart the camera with factory default settings.

VIII. Time Setting

8.1. Pull the Time Adjustment Knob until you hear a click. Both hour and minute

hands will be stopped.

8.2. Rotate the Time Adjustment Knob to set time.

8.3. Push the Time Adjustment Knob back after the time set is completed.
