Wiseup Wifi04s User manual

WIFI04S

User Guide

I. Product Overview

1. IR LEDs

2. Cameras Lens

3. Mode Button

4. Power Switch

II. What’s in the Box

-1× Mini WIFI DV Camera

-1× USB Cable

-1× AC110-240V to DC5V Power Adapter

-1× Suction Cup Mount

-1× Card Reader

III. Get Camera Ready

3.1. Please make sure the camera is fully charged and the Micro SD card has been formatted

already and is securely fitted into the camera’s SD card slot, or it will not work. We recommend

that you use a SDHC Class 10 Micro SD card.

3.2. Slide the Power Switch to the ON position. When the blue indicator light goes out and the

red one remains solid, it means the camera’s WIFI signal is ready.

3.3. If you need the camera to work 7/24 hours, connect it to an outlet AC power supply using

the USB cable and DC 5V power adapter included. Once the camera is connected to outlet AC

power supply, the red and yellow indicator lights will come on and remain solid whether the

Power Switch lies at the ON position or not.

IV. Network Setup

4.1. Install Plug & Play or P2PCamViewer APP on Smartphone or Tablet PC

Go to your App store or Google Play, search for “9527” and then install “Plug & Play” on your

Android phone or tablet PC, or “P2PCamViewer” on your iPhone or iPad.

4.2. LAN Mode or P2P Setup

4.2.1. Go to the WIFI or WLAN setting page on your phone or mobile device, connect to the

camera’s WIFI signal named “F06887”. The WIFI signal password is “44413”. Wait for the WIFI

to be connected.

[Note]: If the camera’s WIFI signal cannot be found or the camera cannot be enrolled to your phone

after a long time, please recharge the camera or reset it (See VIII).

4.2.2. For Android users, launch the “Plug & Play” APP. For IOS users, run the “P2PCamView-

er” APP.

4.2.3. Tap “LAN” or “Local Cameras” at the bottom of the screen. The camera will pop up in a

few seconds. If the camera shows “Online”, it means the P2P (LAN) setup is successful and

you can check or record video in P2P (LAN) mode.

[Note]: In this P2P (LAN) mode, you can only view video locally within 10 meters (33 feet) open range.

4.2.4. Click the camera icon to get into the live video screen. On the live video screen, gently

put your index finger and thumb on the screen, sliding in and outward directions on a specific

area to zoom in and out.

4.3. WAN Mode or Remote View Setup

>> Please make sure the camera is successfully added to the APP in P2P (LAN) mode and it's

online before you start.

For Android:

Step 1: Launch the “Plug & Play” APP. Tap the arrow icon on the “LAN” page and then go

to “Wi-Fi” page.

Step 2: Turn on “Use wifi” on the “Wi-Fi” page.

Step 3: Tap to search for available networks in the area then select your desired WIFI hotspot

to enroll the camera in.

Step 4: Tap “OK” to complete the remote view setup and the camera will reboot automatically.

Step 5: Exit the “Plug & Play” APP.

For IOS:

Step 1: Launch the “P2PCamViewer” APP. Tap the gear icon on the “Local cameras” page

and then go to “Wireless settings” page.

Step 2: Turn on “WiFi” function. Tap the exclamation mark to search for available networks

in the area then select your desired WIFI hotspot to enroll the camera in.

Step 3: Tap “Done” to complete the remote view setup and the camera will reboot automatical-

ly.

Step 4: Exit the “P2PCamViewer” APP.

Check if the WAN mode or remote view setup works!

1. Back to the WIFI or WLAN setting page on your phone or mobile device, exit your phone or

mobile device from the current WIFI network, enroll your phone or mobile device in another

WIFI hotspot, or you can turn off the WIFI or WLAN function, enable your mobile network data

instead.

2. Launch the “Plug & Play” or “P2PCamviewer” APP again.

3. Tap “WAN” or “My Cameras” at the bottom of the screen. Tap the code icon to scan the QR

code at the back of the camera directly. For Android devices, the camera will pop up in a few

seconds. For IOS devices, the camera UID and password will fill in the blanks and then tap

“Login” to log in the camera. If the camera shows “Online”, the blue indicator light will turn off

while the red one will remain solid, it means the remote view setup is complete and the camera

has entered into WAN mode. You can go ahead to view live or recorded video remotely.

V. Recording Video to Smartphone or Tablet PC

>> Please make sure the camera is successfully added to the APP and it's online before you

start.

5.1. Launch the “Plug & Play” or “P2PCamviewer” APP.

5.2. Tap the camera icon to enter the live streaming screen. Click the Remote Video Recording

Button to start or stop recording video. Click the Audio Button to record video with sound.

5.3. Go back to the “WAN” or “LAN” page and tap “File” icon at the bottom of the screen to

check out the video files or screenshots.

[Note]: Video Resolution: 1280x720P Video Format: AVI, MOV

VI. Motion Detection Recording Setup

>> Please make sure the camera is successfully added to the APP and it's online before you

start.

6.1. Launch the “Plug & Play” or “P2PCamviewer” APP.

6.2. Set up motion detection recording function.

For Android:

Step 1: Tap the arrow icon on the “WAN” or “LAN” page and then select “Alarm settings”.

Step 2: On the “Alarm settings” page, you can enable “Motion detection”, “PIR” and “Sdcard

Record.

Step 3: Tap “OK” to confirm the motion detection recording setting.

For IOS:

Step 1: Tap the gear icon on the “WAN” or “LAN” page and then select “Alarm settings”.

Step 2: Go to “Alarm settings” page, there, you can enable “Motion detection” and “SD-Card

Alarm Record. And you get to choose alarm sensitivity level.

Step 3: Tap “Done” to confirm the motion detection recording setting.

6.3. When motion is detected, the camera will push an alarm message to your phone or mobile

device and capture a video to the Micro SD card automatically.

6.4. The video files will be saved in the Micro SD card on your camera. Power off the camera,

remove the Micro SD card and use the card reader provided to access the video footage. You

are recommended to copy all video files to your PC computer before playing them back.

[Note]: Video Resolution: 1280x720P Video Format: AVI, MOV

VII. Recording to Local Micro SD Card Continuously

>> Please make sure the camera is successfully added to the APP and it's online before you

start.

7.1. Follow the steps below to set up SD card recording.

For Android:

Step 1: Launch the “Plug & Play” APP.

Step 2: On the “WAN” or “LAN” page, tap the arrow icon and then go to “SD-Card Settings”

page.

Step 3: Enable “Start automatic recording” and “Voice recording”, then choose the file size

for each video clip. At last, click “OK” to confirm the SD card recording setting.

For IOS:

Step 1: Launch the “P2PCamViewer” APP.

Step 2: On the “Local cameras” or “my cameras” page, tap the arrow icon and select

“SD-Card Settings”.

Step 3: Enable “Start automatic recording” and “Voice recording”, choose the file size for

each video clip. At last, click “Done” to confirm the SD card setting.

7.2. Follow 5.5 to check out your video footage.

[Note]: If “Format Micro SD card” appears on the “SD-Card setting” page, it means the Micro SD card

has been read successfully.

VIII. Changing WAN Login Password

>> Make sure that the camera is added successfully to the APP in WAN mode and it’s online

before you start.

8.1. On the “WAN” or “My cameras” page, tap the plus icon or “Options” and then select

“Update login password” or “Change login Password”.

8.2. Enter the new password and confirm it. At last, click “OK” or “Done” to confirm the change.

IX. Resetting to Factory Default Settings

If for any reason, the camera stops working or isn’t working properly, a quick reset will restore

it back to factory default settings.

Operation: When the camera is powered on, press the Mode Button for 5 seconds to reset the

camera to factory default settings. Both red and blue indicator lights will be illuminated for about

5 seconds and then flash alternately for 30 seconds, then the blue one will turn off while the red

one will be illuminated. The camera will restart automatically to factory default settings in 5 sec-

onds.

X. Charging

10.1. Connect the camera to an outlet AC power supply using the power adapter and USB

cable included.

10.2. It will take 1 hour to obtain a full charge.

10.3. The camera can record video up to 1 hour on a single charge.

Frequently Asked Questions

Q1: Why Camera WIFI signal is not appearing on my WIFI page?

A1: There are 4 solutions to this question:

1. Reset the camera (See VIII).

2. Keep your phone or mobile device within the camera’s WIFI hotspot range, refreshing the

WIFI signal page. It may take up to 2 minutes for the hotspot to become recognizable on your

phone or mobile device's WIFI setting page.

3. Shut off your phone or mobile device’s WIFI function for a while, then turn it on to search

again.

4. The camera is in low battery, connect it to an outlet AC power supply using the USB cable

and power adapter included.

Q2: Why does the camera show offline right after I login it on the “WAN” or “My camer-

as” page?

A2: The remote view setup or WAN mode takes 1-3 minutes to complete. Please wait a while.

If the camera still shows offline, check if the camera has been enrolled in a good WIFI network

successfully. Plus, the WIFI network the camera is configured with can’t be the same with one

you connect your phone to.

Q3: How do I share my camera with family members?

A3: First, please make sure your camera is in WAN mode already and your family members

have installed the “Plug & Play” or “P2PCamViewer” on their phones or mobile devices.

Second, input the camera UID (a unique combination of numbers and letters specific to your

camera) or the QR code that sticks on the body of the DV camera. Finally, tap “Login” to add

the camera to the APP.

Q4: How many cameras can I add to the existing application?

A4: No limit.

Q5: The camera did not record any video?

A5: Make sure the Micro SD card has been fitted well. If not, you need to take out the SD card,

format it on your PC computer and try it again.

Q6: Why the video footage shows a fuzzy screen during playback on my computer?

A6: Please copy the video footage to your computer before playing them back.

Q7: Is there any PC client software I can use on my PC computer?

A7: Yes. PC client software supports windows and IOS operating system. Download link:

http://www.wiseupshop.com/download?name=wifi04s&Submit=++++++++

5. USB Port

6. Micro SD Card Slot

7. Blue/Red/Yellow Indicator Lights
