Wittkopp Primor 2600 User guide

Primor 2600
Installer manual
Installation and commissioning instructions
en_02 P2600-Part 2b-Installer manual V1.01
1 / 6
Note:
On the cover sheet you can find warning information, and an explanation of the symbols and
terms used, together with the exclusion of liability.
Contents
General................................................................................................................................. 2
Preparation for installation..................................................................................................... 3
Installation dimensions - lock P2600.................................................................................. 3
Preparation of the boltwork / door...................................................................................... 3
Installation............................................................................................................................. 4
Wiring / installation................................................................................................................ 4
Connection of an analogue keypad ................................................................................... 5
Function test.......................................................................................................................... 5
Input of the opening code.................................................................................................. 6
Keypad test ....................................................................................................................... 6
Mount the keypad before installing the electronic lock. All the keypads of the Primor series
which support axis drive (RO, RE) can be used. All input units from the series basically
have thisfunction, however an additional handleor something similar is required to operate
the lock’s bolt drive. For information on how to install the keypads, please refer to "APxxxx
Part 2a- Keypad installer manual".

Primor 2600
Installer manual
Installation and commissioning instructions
en_02 P2600-Part 2b-Installer manual V1.01
2 / 6
General
P2600 series locks have standard
installation dimensions and can be installed
in all 4 installation positions (right, left, top,
bottom). They are designed for "scissor-
bolt" movements, i.e. for force absorption
by the bolt flanks.
They are intended to be installed in safes
made of metal.
Depending on the version, additional
locking elements (e.g. angle rail with bolts)
can optionally be attached to the bolt using
the existing holes. Proper functioning of the
lock and its connection must be ensured.
The electronic lock requires no
maintenance in a normal residential or
office environment. We recommend a
security and function test of the electronic
lock after around 10,000 closings.
The opening for the axle must not exceed
11.4 mm.
It is essential that the lock is protected
against attacks from outside. It is
recommended to protect the security-
relevant parts of the high-security lock
against access even when the safe door is
open.
Do not apply any lubricants or other
substances to the lock.
Always follow the following sequence for installation:
•Check the preconditions for installation
•Wiring / installation of the cables
•Disconnect the power supply
•Function test of the locking mechanism
•Perform all settings (user installation, delay time)
Ensure that the limit loads are not exceeded at any time.
You can find the corresponding values in Annex C "Technical data".

Primor 2600
Installer manual
Installation and commissioning instructions
en_02 P2600-Part 2b-Installer manual V1.01
3 / 6
Preparation for installation
Installation dimensions - lock P2600
Preparation of the boltwork / door
To install the lock, there must be three
threaded holes for fastening on the
boltwork or inside the safe door. The
electronic lock must be fastened with the
supplied screws or M6 or 1/4” cylinder
screws (min. strength class 8.8). The screw
length should be measured so that a
minimum screw-in depth of 5 mm is
possible.

Primor 2600
Installer manual
Installation and commissioning instructions
en_02 P2600-Part 2b-Installer manual V1.01
4 / 6
Installation
The retaining screws must be tightened in
such a way that a permanent and firm hold
is ensured.
Tighten the fastening screws with a
maximum torque of 3.5 - 5 Nm. To prevent
the screws from becoming loose, we
recommend using screw locking agents
(adhesive).
There must be no tension or pressure on
the lock bolt after installation.
Make sure there is sufficient clearance to
the locking point.
Wiring / installation
If the lock is operated outside the area of
validity of the VdS,then signal boxes,
external power supplies, etc. can be used
with the Anchor in addition to all the
analogue keypads that are compatible with
the Primor series.
The VdS approval is limited to operation
with input units fromthe Primor FS, FL, RO,
RE and Anchor LC series.
If the cable connection isnot routedthrough
the drive axis, the required hole / cable
route must be selected so that no access to
the lock body is possible through it by tools,
sensors or similar.
Holes for the cable aperture must be at
least 8 mm and a maximum of 11.4 mm.
Disconnect the power supply, including that from batteries, before starting any work or
making any changes to the wiring between the lock, keypad or signal boxes.

Primor 2600
Installer manual
Installation and commissioning instructions
en_02 P2600-Part 2b-Installer manual V1.01
5 / 6
Connection of an analogue keypad
Instructions for inserting the battery can be found in the operating instructions for the
corresponding Primor keyboard.
Function test
Carry out a function test after completing all
the mounting and installation work.With the
door open, you should open and close the
lock several times using the master code
that had been set at the factory.
To open the lock after release, turn the
keypad (RO) or operate the control knob
(RE):
The relationship between easy opening and
reliable closing can be set via the operating
lever of the boltwork.
The locking check is done by the position of
the input unit (RO) or, for input units with
operating toggle (RE), by the position of the
operating lever.
analogue keypad
e.g. Primor RO

Primor 2600
Installer manual
Installation and commissioning instructions
en_02 P2600-Part 2b-Installer manual V1.01
6 / 6
Input of the opening code
e.g. master factory code


=✓
→

The opening code can be entered
directly as described above, without
selection. The bolt is released for
approx. 3 seconds after a valid
code has been entered. Open the
safe within this period after entering
the code.
=

Keypad test
To make sure that all numeric keys are working properly, it is recommended to perform a final
keypad test using the function Menu 5.
 ☼Checking the menu system
Press the keys in the
sequence
…

=✓
Press each numeric key once. A
functional key is indicated by a
double signal tone.
A key that is not recognised is
indicated by a long signal tone and
the function test is terminated. The
system must be checked.
