Wood Stone FIRE DECK 9690 User manual

Toll Free 800.988.8103
Tel [phone]
Fax [phone]
www.woodstone-corp.com
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
COAL-FIRED OVEN
Stone Hearth Speciality Oven
Gas/Coal Combination Models
FIRE DECK 9690 WS-FD-9690-CL
FIRE DECK 11275 WS-FD-11275-CL
FIRE DECK 11290 WS-FD-11290-CL
DOC NO M0045.07 REVISED APRIL 2019
Installation and
Operation Manual

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 2 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
TABLE OF CONTENTS
TABLE OF CONTENTS
Fire Deck Coal-Fired Ovens � � � � � � � � 3
Cautions & Warnings � � � � � � � � � � � � 4
FD-9690-CL Specifications � � � � � � � � 6
FD-11275-CL Specifications � � � � � � � 7
FD-11290-CL Specifications � � � � � � � 8
Unloading & Moving the Oven � � � � � � � 9
Caster Removal� � � � � � � � � � � � � � � 10
Toe Kick Installation � � � � � � � � � � � � 11
Installation Clearances � � � � � � � � � � 12
Venting � � � � � � � � � � � � � � � � � � � � 14
Wood Stone Hoods� � � � � � � � � � � � � 16
Gas Specifications � � � � � � � � � � � � � 18
Gas / Electrical Specifications � � � � � � 19
Controller � � � � � � � � � � � � � � � � � � 20
Initial Start-Up� � � � � � � � � � � � � � � � 21
Daily Oven Operation � � � � � � � � � � � 22
Use of Coal Overview � � � � � � � � � � � 23
Daily Maintenance � � � � � � � � � � � � � 28
Periodic Thermal Cleaning � � � � � � � � 29
Troubleshooting� � � � � � � � � � � � � � � 30
Electrical Diagrams � � � � � � � � � � � � 31
Limited Warranty � � � � � � � � � � � � � � 35

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 3 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
FIRE DECK COAL-FIRED OVENS
INSTALLATION AND OPERATION MANUAL FOR THE
WOOD STONE FIRE DECK COAL-FIRED OVEN
STONE HEARTH COOKING EQUIPMENT
FIRE DECK COAL-FIRED OVEN
WS-FD-9690-(L,R,LL,RR)-IR-CL,
WS-FD-11290-(L,R,LL,RR) CL AND
WS-FD-11275-(L,R,LL,RR)-IR-CL
ADDITIONAL MANUAL COPIES AVAILABLE UPON REQUEST
Shown: Model FD-9690-LL-IR-CL

RETAIN THIS MANUAL FOR FUTURE REFERENCE
Additional copies of this manual at woodstone-corp�com�
For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�
Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 4 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS
INSTALLATION AND OPERATION MANUAL FOR THE
WOOD STONE FIRE DECK OVEN
STONE HEARTH COOKING EQUIPMENT
WS-FD-9690, WS-FD-11275 AND WS-FD-11290 MODELS EQUIPPED FOR COAL BURNING
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE
Please read this entire manual before you install the oven. Failure to follow instructions may result in property
damage, bodily injury or even death. Contact your local building or fire officials about restrictions and installation
inspection in your area.
IF THIS OVEN IS NOT PROPERLY INSTALLED A FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THESE
INSTALLATION INSTRUCTIONS. A MAJOR CAUSE OF OVEN RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF THE UTMOST IMPORTANCE THAT THIS OVEN
BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
COAL FUEL - TO ENSURE CLEANEST EMISSIONS POSSIBLE, USE ONLY ANTHRACITE COAL. MANY VARIETIES
OF COAL CONTAIN CHEMICAL IMPURITIES THAT CAN DAMAGE THE OVEN CERAMIC. USING ANTHRACITE
COAL MINIMIZES THE CHANCE OF CHEMICAL DAMAGE TO THE OVEN CERAMIC. USE OF ANY COAL OTHER
THAN ANTHRACITE COAL WILL VOID THE WARRANTY ON THE OVEN CERAMIC AND MAY LEAD TO INCREASED
PARTICULATE AND OTHER EMISSIONS FROM THE OVEN WHEN COAL IS USED.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death. Read the installation, operation and maintenance instructions thoroughly before installing or
servicing this equipment.
AVERTISSEMENT: L’installation, le réglage, la modification, la réparation ou l’entretien incorrect de cet
appareil peut causer des dommages matériels, des blessures ou la mort. Lire attentivement les instructions
d’installation, de fonctionnement et d’entretien avant de procéder à son installation ou entretien.

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 5 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS
SAVE THE INSTRUCTIONS
It is recommended that this oven be installed, maintained and
serviced by authorized professionals.
This product must be installed by a licensed plumber or gas fitter when installed within the Commonwealth
of Massachusetts.
CAUTION: DISCONNECT POWER TO THE OVEN BEFORE SERVICING OR CLEANING.
CAUTION: Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid or similar liquids to
start or freshen up a fire in this oven. Keep all such liquids well away from this oven when in use.
WARNING: In the event of a power failure, no attempt should be made to operate this appliance.
IMPORTANT: Consult your local gas supplier for a statement outlining a procedure to be followed in the
event you smell gas. Post the statement in a prominent location.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or
any other appliance.
ESURE DE SÉCURITÉ: Ne pas entreposer ni utiliser de’essence ni autres vapeurs ou liquides inflammables à
proximté de cet appareil ou de tout autre appareil.
Always keep the area under and around this appliance free and clear of any and all combustible materials.
Wood Stone Fire Deck Coal-Fired ovens
have been tested and approved by Intertek Testing Services and
conform to ANSI Z83.11, UL 2162, UL 737 and CGA 2.17;
are certified to CSA 1.8 and ULC S627;
and to NSF/ANSI 4.
ANSI Z83.11
CSA 1.8
ANSI/NSF 4

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 6 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
FD-9690-CL SPECIFICATIONS
Front viewSide view
Plan view
UTILITY SPECIFICATIONS
Gas
1" FNPT gas inlet
347,000 BTU/hr Natural Gas (NG)
OR
369,000 BTU/hr Propane (LP)
Decorative flame adds
15,000 BTU/hr to total rated output
Maximum gas inlet pressure:
1/2 psi (14 inches W�C�)
Venting
This oven may be vented with a Listed Type 1 exhaust hood OR directly connected at the
12-inch ID oven flue collar to a power-ventilated, grease-rated chimney OR an exhaust
hood constructed in accordance with NFPA 96 and all relevant local and national codes�
The oven must be vented in accordance with all relevant local and national codes, and in
a manner acceptable to the authority having jurisdiction�
IMPORTANT: This model must be vented as a solid fuel appliance�
Electrical
120 VAC, 4 A, 50/60 Hz
Utility connections made
on left side of oven as
shown�
VERY IMPORTANT!
Oven is shipped with casters
which add 1-1/2"� Height with
casters to the top of the flue
collar is 87-3/4"� Once the
oven is in place the casters
must be removed�
Utility connections are made
underneath the oven; they
are shown on the plan view to
illustrate geographic location only�
Unit weight:
10,000 lbs.
REV:
LEGEND:
PART #:
001-509690-CL-R
9690 Coal Burner
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-9690-CL_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
347,000 BTU, NG
369,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
59 3/4"
1520mm
96 1/4"
2450mm
9 3/4"
250mm
24 1/2"
620mm
9 1/2"
240mm
36 1/2"
930mm
92"
2330mm
48 1/4"
1230mm
31 3/4"
810mm
58 3/4"
1490mm
84 1/4"
2140mm
33 1/4"
840mm
20 3/4"
530mm
15"
380mm
18"
460mm 86"
2180mm
1 3/4"
50mm 2 1/4"
60mm
97 1/2"
2480mm
7 1/2"
190mm
62 1/4"
1580mm
8 1/4"
210mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
12"
300mm OD
1 1/2"
40mm
REV:
LEGEND:
PART #:
001-509690-CL-R
9690 Coal Burner
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-9690-CL_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
347,000 BTU, NG
369,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
59 3/4"
1520mm
96 1/4"
2450mm
9 3/4"
250mm
24 1/2"
620mm
9 1/2"
240mm
36 1/2"
930mm
92"
2330mm
48 1/4"
1230mm
31 3/4"
810mm
58 3/4"
1490mm
84 1/4"
2140mm
33 1/4"
840mm
20 3/4"
530mm
15"
380mm
18"
460mm 86"
2180mm
1 3/4"
50mm 2 1/4"
60mm
97 1/2"
2480mm
7 1/2"
190mm
62 1/4"
1580mm
8 1/4"
210mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
12"
300mm OD
1 1/2"
40mm
REV:
LEGEND:
PART #:
001-509690-CL-R
9690 Coal Burner
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-9690-CL_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
347,000 BTU, NG
369,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
59 3/4"
1520mm
96 1/4"
2450mm
9 3/4"
250mm
24 1/2"
620mm
9 1/2"
240mm
36 1/2"
930mm
92"
2330mm
48 1/4"
1230mm
31 3/4"
810mm
58 3/4"
1490mm
84 1/4"
2140mm
33 1/4"
840mm
20 3/4"
530mm
15"
380mm
18"
460mm 86"
2180mm
1 3/4"
50mm 2 1/4"
60mm
97 1/2"
2480mm
7 1/2"
190mm
62 1/4"
1580mm
8 1/4"
210mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
12"
300mm OD
1 1/2"
40mm
Air intake: Do not
facade or cover over
Must be left
removable for service
ID

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 7 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
FD-11275-CL SPECIFICATIONS
Front view
Side view
Plan view
UTILITIES REQUIRED
Gas
1" FNPT gas inlet
315,000 BTU/hr Natural Gas (NG)
OR
310,000 BTU/hr Propane (LP)
Decorative flame adds
15,000 BTU/hr to total rated output
Maximum gas inlet pressure:
1/2 psi (14 inches W�C�)
Venting
This oven may be vented with a Listed Type 1 exhaust hood OR directly connected at the
12-inch ID oven flue collar to a power-ventilated, grease-rated chimney OR an exhaust
hood constructed in accordance with NFPA 96 and all relevant local and national codes�
The oven must be vented in accordance with all relevant local and national codes, and in
a manner acceptable to the authority having jurisdiction�
IMPORTANT: This model must be vented as a solid fuel appliance�
Electrical
120 VAC, 4 A, 50/60 Hz
Utility connections made
on back of oven
Unit weight:
9,500 lbs.
VERY IMPORTANT!
Oven is shipped with casters
which add 1-1/2"� Height with
casters to the top of the flue
collar is 87-3/4"� Once the
oven is in place the casters
must be removed�
Utility connections are made
underneath the oven; they
are shown on the plan view to
illustrate geographic location
only�
REV:
LEGEND:
PART #:
001-5011275-CL-R
11275 Fire Deck - Coal Right
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-11275-CL_General Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
295,000 BTU, NG
282,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
9 3/4"
250mm
59 3/4"
1520mm
112 1/4"
2850mm
108"
2740mm
17 1/2"
440mm 36 3/4" 940mm
74 3/4"
1900mm
82 1/2"
2100mm
7 1/2"
190mm
62 1/4"
1580mm
8 1/4"
210mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
2 1/4"
50mm 2 1/4"
60mm
48 1/4"
1230mm
31 3/4"
810mm
18"
460mm 70 3/4"
1800mm
15"
380mm
20 3/4"
530mm
33"
840mm
84"
2130mm
12"
300mm OD
1 1/2"
40mm
REV:
LEGEND:
PART #:
001-5011275-CL-R
11275 Fire Deck - Coal Right
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-11275-CL_General Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
295,000 BTU, NG
282,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
9 3/4"
250mm
59 3/4"
1520mm
112 1/4"
2850mm
108"
2740mm
17 1/2"
440mm 36 3/4" 940mm
74 3/4"
1900mm
82 1/2"
2100mm
7 1/2"
190mm
62 1/4"
1580mm
8 1/4"
210mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
2 1/4"
50mm 2 1/4"
60mm
48 1/4"
1230mm
31 3/4"
810mm
18"
460mm 70 3/4"
1800mm
15"
380mm
20 3/4"
530mm
33"
840mm
84"
2130mm
12"
300mm OD
1 1/2"
40mm
Air intake: Do not
facade or cover over
Must be left
removable for service
REV:
LEGEND:
PART #:
001-5011275-CL-R
11275 Fire Deck - Coal Right
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-11275-CL_General Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
295,000 BTU, NG
282,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
9 3/4"
250mm
59 3/4"
1520mm
112 1/4"
2850mm
108"
2740mm
17 1/2"
440mm 36 3/4" 940mm
74 3/4"
1900mm
82 1/2"
2100mm
7 1/2"
190mm
62 1/4"
1580mm
8 1/4"
210mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
2 1/4"
50mm 2 1/4"
60mm
48 1/4"
1230mm
31 3/4"
810mm
18"
460mm 70 3/4"
1800mm
15"
380mm
20 3/4"
530mm
33"
840mm
84"
2130mm
12"
300mm OD
1 1/2"
40mm
27"
ID

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 8 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
FD-11290-CL SPECIFICATIONS
Front view
Plan view
Side view
UTILITIES REQUIRED
Gas
1" FNPT gas inlet
347,000 BTU/hr Natural Gas (NG)
OR
369,000 BTU/hr Propane (LP)
Decorative flame adds
15,000 BTU/hr to total rated output
Maximum gas inlet pressure:
1/2 psi (14 inches W�C�)
Venting
This oven may be vented with a Listed Type 1 exhaust hood OR directly connected at the
12-inch ID oven flue collar to a power-ventilated, grease-rated chimney OR an exhaust
hood constructed in accordance with NFPA 96 and all relevant local and national codes�
The oven must be vented in accordance with all relevant local and national codes, and in
a manner acceptable to the authority having jurisdiction�
IMPORTANT: This model must be vented as a solid fuel appliance�
Electrical
120 VAC, 4 A, 50/60 Hz
Utility connections made
on left side of oven as
shown�
VERY IMPORTANT!
Oven is shipped with casters
which add 1-1/2"� Height with
casters to the top of the flue
collar is 87-3/4"� Once the
oven is in place the casters
must be removed�
Utility connections are made
underneath the oven; they
are shown on the plan view to
illustrate geographic location
only�
REV:
LEGEND:
PART #:
001-5011290
11290 Fire Deck
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-11290-CL_General Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
347,000 BTU, NG
369,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
17 1/4"
440mm
36 3/4"
930mm 74 3/4"
1900mm
24"
610mm
9 3/4"
250mm
59 3/4"
1520mm
108"
2740mm
112 1/4"
2850mm
84"
2130mm
33"
840mm
20 3/4"
530mm
15"
380mm 18"
460mm 85 3/4"
2180mm
48 1/4"
1230mm
31 3/4"
810mm
2 1/4"
50mm
2 1/4"
60mm
97 1/2"
2480mm
7 1/2"
190mm
12"
300mm OD
62 1/4"
1580mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
1 1/2"
40mm
REV:
LEGEND:
PART #:
001-5011290
11290 Fire Deck
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-11290-CL_General Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
347,000 BTU, NG
369,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
17 1/4"
440mm
36 3/4"
930mm 74 3/4"
1900mm
24"
610mm
9 3/4"
250mm
59 3/4"
1520mm
108"
2740mm
112 1/4"
2850mm
84"
2130mm
33"
840mm
20 3/4"
530mm
15"
380mm 18"
460mm 85 3/4"
2180mm
48 1/4"
1230mm
31 3/4"
810mm
2 1/4"
50mm
2 1/4"
60mm
97 1/2"
2480mm
7 1/2"
190mm
12"
300mm OD
62 1/4"
1580mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
1 1/2"
40mm
REV:
LEGEND:
PART #:
001-5011290
11290 Fire Deck
General Arrangement
5/23/2014 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-11290-CL_General Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 4A
GAS INLET: 1" NPT
347,000 BTU, NG
369,000 BTU, LP
1 of 1
AIR INTAKE
AIR INTAKE
G
G
87 3/4"
2230mm
17 1/4"
440mm
36 3/4"
930mm 74 3/4"
1900mm
24"
610mm
9 3/4"
250mm
59 3/4"
1520mm
108"
2740mm
112 1/4"
2850mm
84"
2130mm
33"
840mm
20 3/4"
530mm
15"
380mm 18"
460mm 85 3/4"
2180mm
48 1/4"
1230mm
31 3/4"
810mm
2 1/4"
50mm
2 1/4"
60mm
97 1/2"
2480mm
7 1/2"
190mm
12"
300mm OD
62 1/4"
1580mm
20"
510mm
27"
690mm
4"
100mm
20"
510mm
1 1/2"
40mm
ID
Unit weight:
11,500 lbs.
Air intake: Do not
facade or cover over
Must be left
removable for service

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 9 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
UNLOADING & MOVING THE OVEN
DELIVERY NOTE.
The customer will receive an Oven Shipping Notification when the oven leaves the Wood Stone factory� This will include a PRO# and
a trucking company contact number� Wood Stone recommends that you confirm the delivery date/time with the trucking company
before committing to heavy equipment and/or labor� Our goal is a smooth and safe delivery�
USING A FORKLIFT.
Use a forklift with adequate fork lengths and lifting
capacity� When using a forklift, always use the forklift
pockets; lifting the oven any other way may result in
damage� There are fork pockets only at the front and
back of the oven� The oven may also be rolled across
a smooth, flat surface on the temporary casters�
WARNING: THE OVEN IS EXTREMELY TOP HEAVY.
DO NOT ATTEMPT TO MOVE THE OVEN WITHOUT THE PROPER EQUIPMENT AND EXPERIENCE. BE SAFE.
ALWAYS USE A FORKLIFT OR CRANE TO LIFT THIS OVEN.
DO NOT ATTEMPT TO USE A LEVER OF ANY TYPE TO RAISE THIS OVEN.
THE OVEN IS EQUIPPED WITH CASTERS AND CAN BE ROLLED ACROSS A SMOOTH, FLAT SURFACE ONLY.
Once the oven is in place, the casters must be removed. See the CASTER REMOVAL section of the manual.
DO NOT DROP THIS OVEN ABRUPTLY.
USING A CRANE.
When craning a Wood Stone oven, use a Spreader Bar with a two-legged sling
rigged on each end� Suitable lifting straps can be run through the fork lift pockets
on the oven� The Spreader Bar should be of a sufficient length to keep the sling
from contacting the oven and oriented as shown in (fig� 1)�
IF YOU ARE PLANNING TO USE A CRANE TO UNLOAD THE OVEN,
SPECIFY A FLATBED TRUCK DELIVERY!
Minimum Required Forklift Capacities
8' FORKS MINIMUM
Model Shipping Weight Lifting from Front or Rear
FD-9690-CL 10,000 lbs 24,000 lbs
FD-11275-CL 9,500 lbs 20,000 lbs
FD-11290-CL 11,500 lbs 26,000 lbs
WARNING
fig. 1
NOTE: Remove Oven Mantle
before lifting the
oven with a crane.
Shown:
FD-11290-CL
Moving a Wood Stone Fire Deck oven can present challenges to even the most experienced riggers� Make sure to secure the proper
equipment and make safety your first priority� Please don’t hesitate to call the factory for technical support at 1-800-988-8103.

Fire Deck 9690, 11275 & 11290 Coal-Fired Oven
Installation and Operation Manual
PG 10 OF 36
M0045.07 APRIL 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CASTER REMOVAL
Position a scissor jack under the oven
frame near the caster to be removed�
Use the jack to raise the caster so that it
clears the floor slightly (1/4" should be
sufficient)� Remove the nuts and bolts
retaining the caster to the oven frame�
Rotate the caster in the direction of the
fork legs to remove from oven, then
lower the jack and proceed to the next
caster and repeat procedure�
TO MAINTAIN THE OVEN WARRANTY, SHIPPING CASTERS MUST BE REMOVED WHEN THE OVEN IS INSTALLED.
The oven should be installed on a smooth, flat level surface� The weight of the oven is carried by the full perimeter of the oven
stand� If it is necessary to shim the oven for leveling purposes, it is critical that the shim material be metal, and that the shims
are installed in such a way that the full perimeter of the stand is solidly supported� Any gaps created by shimming between the
oven and the floor must be sealed to prevent airflow issues beneath the oven� Failure to solidly support the full perimeter
of the oven stand can result in costly damage to the oven and will void the warranty.
The floor design and construction must be adequate to handle the weight of the oven� Floor load information is available on the
Wood Stone website�
IMPORTANT: DO NOT JACK THE FRAME ANY HIGHER THAN THE MINIMUM NECESSARY TO REMOVE THE CASTER.
