SAVOY SECTIONAL Coffee Table
WDC-SAV-SEC-1
Assembly Instructions
Step 1: Remove protective wrapping first. Then lay all parts on floor and identify all parts packed in
carton against attached parts list.
Step 2: Lay tabletop (A) upside down on floor, so bottom is facing up. Place a protective soft
material on floor before placing tabletop of table face down on floor.
Step 4: Make sure all bolts are aligned properly and tighened. Then place bolt covers over bolts.
Then with a second person's assistance if needed, turn the table over onto it's legs carefully resting
it on flat floor surface .
Step 3: Then attach each of four legs (B) to the bottom as shown in Photo 1, using Bolt(E) and
Washer (F) and Bolt cover(G). Attach Stretcher (C) to Leg (B) using Bolt (D) and Washer (F) and Bolt
Cover (G) as shown in Diagram 2.
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND
TIGHTENED PROPERLY AND SECURELY.
Diagram 2
Diagram 1
1 of 2

Diagram 3
Ref
Part Name
Part Image
Qty
Ref
Part Name
Part Image
Qty
PARTS LIST
2 of 2
Ref
Part
Name
Part
Qty
Ref
Part
Name
Part
Qty
A Table Top 1 EBolt (Long) 8
B Leg 4 F Washer 16
C Stretcher 1 G Bolt Cover 16
D Bolt (Short) 8 H Hex Wrench 1
