Woodard WDC-WOO-9240 User manual

WOODCLIFF DINING TABLE
WDC-WOO-9240
Assembly Instructions
Step 1: Remove protective wrapping and lay all parts on floor. Identify all parts packed in carton
against attached parts list to make sure all parts are present.
Step 2: Lay top (A) upside down on floor, so bottom is facing up. Place a protective soft material on
floor before placing top of table face down on floor.
Step 3: Then attach table legs (B) to the bottom as shown in Diagram 1 , using Bolt(E) and Washer
(F) and Bolt cover(G). Attach Stretch (C) to Leg (B) using Bolt (D) and Washer (F) and Bolt Cover (G)
as shown in Diagram 2.
Step 4: Make sure all bolts are aligned properly and tight and then place bolt covers over bolts.
Then with a second person's assistance, please turn the table over onto its legs carefully using a
flat surface .
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND
TIGHTENED PROPERLY AND SECURELY
BB
Diagram 2
Diagram 1
A
B
F
E
G
A
B
F
E
G
C
G
D
F
A
B
F
E
G
A
B
F
E
G
C
G
D
F
1 of 2

Diagram:
Diagram 3
2 of 2
Ref Part Name Part Image Qty Ref Part Name Part Image Qty
A Table Top 1 EBolt (Long) 8
B Table Leg 2 F Washers 12
C Stretch 1 G Bolt Cover 12
D Bolt (Short) 4 H Hex Wrench 1
WOODARD
Customer Service Hours
8:00am-5:00pm CST Monday to Friday
Phone: [phone] Fax: [phone]
PRINTED IN CHINA
2014-4-11
2 of 2
