woodmizer LT15 AL-KO Guide

D17 Engine
Safety, Operation, Maintenance
& Parts Manual
LT15 rev. E8.12
LT15W rev. A1.13
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
Form #1630

©2018
Printed in the United States of America. All rights reserved. No part of this manual may be
reproduced in any form by any photographic, electronic, mechanical or other means or
used in any information storage and retrieval system without written permission from
Wood-Mizer
8180 West 10th Street
Indianapolis, Indiana 46214

Table of Contents Section-Page
Table of Contents WMdoc080618 iii
SECTION 1 ABOUT THIS MANUAL 1-1
SECTION 2 OPERATION 2-1
2.1 Starting The Engine................................................................................2-1
SECTION 3 MAINTENANCE 3-1
3.1 Safety......................................................................................................3-1
3.2 Air Filter & Pre-Cleaner.........................................................................3-1
3.3 Fuel Filter ...............................................................................................3-2
SECTION 4 REPLACEMENT PARTS 4-1
4.1 Fuel Tank................................................................................................4-1
4.2 Engine Assembly....................................................................................5-1
4.3 Throttle/Clutch Assembly ......................................................................5-3
INDEX I

About This Manual
1
1-1 WMdoc080618 About This Manual
SECTION 1 ABOUT THIS MANUAL
This manual is provided as a supplement to the equipment manufacturer’s manuals. This
manual provides information specific to the use of this equipment on the Wood-Mizer®
sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before
attempting to operate this equipment.
IMPORTANT! Read the sawmill operator’s manual and engine manu-
facturer’s manual for instructions and safety precautions before oper-
ating this equipment.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.

Operation
Starting The Engine
Operation WMdoc080618 2-1
2
SECTION 2 OPERATION
2.1 Starting The Engine
DANGER! Ensure the blade is disengaged and all persons are out of
the path of the blade before starting. Failure to do so will result in death
or serious injury.
DANGER! Operate your engine only in well ventilated areas. The
exhaust gases of your engine can cause nausea, delirium, and poten-
tially death unless adequate ventilation is present.
DANGER! Never operate an engine with a fuel or oil leak. This is a fire
hazard, which may cause serious injury or death.
WARNING! Do not operate engine without proper and operational
spark arrester/muffler. Sparks emitted from the engine exhaust could
ignite surrounding materials, causing serious injury or death.
CAUTION! EPA Compliant Gas Tanks Only: Always relieve all fuel
pressure inside the tank prior to filling or connecting fuel fittings. Fail-
ure to do so may result in fuel spillage.
CAUTION! EPA Compliant Gas Tanks Only: Disconnect the fuel tank
when not in use, or engine flooding or fuel spillage may result.
1. See the engine manufacturer’s manual for lubricating oil recommendations.
2. Use #2 or better quality diesel fuel for above freezing starting. Use a #1 quality diesel fuel
for below freezing starting.
3. Turn the key switch to the start (#2) position and release.
1. Turn fuel shut-off valve to ON position
2. Turn engine on/off switch to ON position
3. Start engine as follows:
Cold engine: Place throttle control midway between SLOW and FAST positions. Place
choke control into ON position.

Operation
Starting The Engine
2
2-2 WMdoc080618 Operation
Warm engine: Place throttle control midway between SLOW and FAST positions. Return
choke to OFF position as soon as engine starts. A warm engine usually does not require
choke on.
4. Slowly pull starter handle until just past compression-STOP! Return starter handle; fi rmly
pull straight out to avoid excessive rope wear from starter rope guide.
5. Gradually return choke control to OFF position after engine starts and warms up.
Engine/equipment may be operated during warm up period, but it may be necessary to
leave choke partially on until engine warms up.
For more information, see the engine manufacturer’s operation manual.
ENGINE SHUTOFF
Turn the key switch to the off (#0) position.
1. Disengage the clutch handle to stop the blade if necessary.
2. Move the throttle control to slow or idle position. Stop the engine.
3. Close the fuel shut-off valve.

Maintenance
Safety
Maintenance WMdoc080618 3-1
3
SECTION 3 MAINTENANCE
Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth-
erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty
conditions.
IMPORTANT! This manual only provides information about additional
procedures or procedures to be performed at different time intervals
than found in the manufacturer's manuals. Refer to the manufacturer's
manual for complete maintenance instructions.
3.1 Safety
Use caution when performing maintenance or service to the engine.
DANGER! Always be aware of and take proper protective measures
against rotating shafts, pulleys, fans, etc. Always stay a safe distance
from rotating members and make sure that loose clothing or long hair
does not engage rotating members resulting in possible injury.
DANGER! Engine components can become very hot during operation.
Avoid contact with any part of a hot engine. The exhaust components
of your engine are especially hot during and following operation. Con-
tact with hot engine components can cause serious burns. Therefore,
never touch or perform service functions on a hot engine. Allow the
engine to cool sufficiently before beginning any service function.
WARNING! Remove the blade before performing any engine service.
Failure to do so may result in serious injury.
WARNING! Always wear proper and necessary safety equipment
when performing service functions. Proper safety equipment includes
eye protection, breathing protection, hand protection and foot protec-
tion.
This symbol identifies the interval (hours of operation) at which each maintenance pro-
cedure should be performed. "AR" signifies maintenance procedures which should be
performed as required.
3.2 Air Filter & Pre-Cleaner
WARNING! Always wear proper and necessary safety equipment
when performing service functions. Proper safety equipment includes
0

Maintenance
Fuel Filter
3
3-2 WMdoc080618 Maintenance
eye protection, breathing protection, hand protection and foot protec-
tion.
Service the pre-cleaner every four hours of operation. Service by gently shaking excess
sawdust and debris from the foam piece.
Clean the air filter (air cleaner element) and pre-cleaner (element wrapper) every eight
hours of operation. See the engine manual for further instructions.
Replace the air filter (cleaner) every 200 hours of operation.
Replace the pre-cleaner (element wrapper) every 2000 hours of operation.
3.3 Fuel Filter
Replace the fuel filter every 100 hours of operation or as required for engine perfor-
mance.
4
8
200
2000
100

Replacement Parts
Fuel Tank
Replacement Parts 15Ddoc080618 4-1
4
D17
SECTION 4 REPLACEMENT PARTS
4.1 Fuel Tank
REF DESCRIPTION (Indicates Parts Available In Assemblies Only) PART # QTY.
TANK ASSEMBLY, 5 GALLON DIESEL 074828 1
1Weldment, Fuel Tank Tray 103802 1
2Cover, Fuel Tank 103867 1
Tank, 5 Gallon Low Pro Diesel 103928 1
3Cap, Fuel Tank Diesel 080185BE 061257 1
4Fitting, Pick-Up/Tube Diesel 468871A 061255 1
5Grommet, Shut Off 046881 061250 2
6Fitting, Return/tube Diesel 468489 061256 1
7Bolt, 5/16-18 x 3/4” Hex Head w/Flat&Lock Washer F05006-101 4
8Bolt, 3/8-16 x 3” Hex Head Grade 5 F05007-73 2
9Nut, 3/8-16 Hex Nyloc F05010-10 2
10 Washer, 3/8” Flat SAE F05011-3 2
Hose, Fuel 5/16" EPA 15G CARB R02423-3 8 Ft.
Hose, Fuel 1/4" EPA 15G CARB R02423-2 8 Ft.
Weldment, Fuel Tank Tray 103802 1
Clamp, 7/32in-5/8in Hose P649 2
Clamp, 1/2EMT Coated P07584 1
1
2
3
4
5
6
7
8
9
10
150245B

Replacement Parts
Engine Assembly
4
5-1 15D17doc080618 Replacement Parts
D17
4.2 Engine Assembly
REF DESCRIPTION (Indicates Parts Available In Assemblies Only) PART # QTY.
ENGINE ASSEMBLY, LT15 18HP DIESEL 007333 1
1Engine, 18HP Kohler Diesel Model KDW702 007332 1 
2Filter Assembly, Kohler #ED0037004550-S 007401 1
Filter, Kohler Secondary Air #ED0021751250-S 007613 1
Filter, Kohler Primary Air #ED0021751240-S 007408 1
Motor, Kohler Starter #ED0058402240-S 007614 1
Alternator, Kohler 65A #ED0011572700-S 065408 1
Belt, Kohler Fan #ED0024403160-S 065409 1
Filter, Kohler/Lombardini Oil #ED0021752830-S 061187 1
Filter, Kohler/Lombardini Fuel #ED0021752880-S 061188 1
Switch Kit, Oil Pressure w/Gasket 014557 1
Switch, Diesel Fuel Shut-Off 014279 1
Pump, Diesel Fuel 014289 1
Plug, Diesel Glow 014278 2
1
3
2
4
5
5
6
7
8
9
8
7
10
11
12
13
14
15
16
17
18
20
21
22
19
23
25
26
27
28
29
30
30
34
38
39
40
40
41
42
35
36
37
150174-4
24
31
32
33

Replacement Parts
Engine Assembly
Replacement Parts 15D17doc080618 4-2
4
D17
3Bracket, Air Filter Mount 074939 1
4Bolt, 5/16-18 x 1 1/4” Hex Head Full Thread F05006-18 2
5Washer, 5/16” SAE Flat F05011-17 4
6Nut, 5/16-18 Self-Locking Hex F05010-20 2
7Clamp, 2 1/2” Hose P09895 4
8Elbow, 90° x 2” ID Rubber 007394 2
9Tube, 1 3/4” ID x 2” OD x 4” 007395 1
10 Cable, LT15 D18 007392 1
11 Guard Weldment, D18 Radiator 007465 1
12 Washer, 1/4” SAE Flat F05011-11 6
13 Washer, 1/4” Split Lock F05011-14 6
14 Bolt, M6 x 1.0 x 16mm Hex Head F05004-219 6
15 Bracket Weldment, Rear D18 Mount 007427 1
16 Bolt, M12 x 1.75 x 20mm Hex Head Full Thread F05004-251 2
17 Washer, 3/8” SAE Flat F05011-3 8
18 Bolt, 3/8-16 x 1 1/4” Hex Head Grade 5 F05007-123 4
19 Nut, 3/8-16 Hex Nylon Lock F05010-10 4
20 Bracket, D18 Front Mount 007426 1
21 Bolt, 5/16-18 x 1” Hex Head Grade 5 F05006-27 2
22 Nut, 5/16-18 Hex Nylon Lock F05010-58 2
23 Shaft, Diesel Engine Drive 014024 1
24 Washer, 10mm Split Lock F05011-88 8
25 Bolt, M10-1.5 x 24mm Hex Head Grade 8.8 F81003-11 8
26 Sheave, 3V5.6 x 2-SH 047742 1
27 Bushing, SH - 1 9/16” 007338 1
28 Guard Weldment, Motor Pulley 007336 1
29 Cover, Engine Pulley Guard 007344 1
30 Bolt, 1/4-20 x 3/4” Hex w/Conical Washer Head F05005-134 4
31 Fitting, M18 x 3/8” NPT Adapter 065163 1
32 Hose, 3/8” NPT x 9 5/8” Rubber P10082 1
33 Fitting, 3/8” Galvanized Pipe Cap P04332 1
34 BELT, 2/3VFL900 DRIVE 047751 1
35 SUPPORT WELDMENT, DRIVE BELT 048237 1
36 BOLT, 3/8-16 X 3/4” HEX HEAD GRADE 5 F05007-118 1
37 NUT, 3/8-16 SELF-LOCKING HEX F05010-19 1
MOUNT ASSEMBLY, LT15D17 CONTROL 074942 1
38 Plate, LT15D17 Control Mount 074938 1
39 Bolt, 5/16-18x3/4 HH Gr5 F05006-102 2
40 Bolt, 5/16-18x1 Gr5 HH F05006-27 2
41 Nut, 5/16-18 Nylok Hex F05010-58 2
42 Washer, 5/16 Split Lock F05011-13 2
43 Washer, 5/16 SAE Flat F05011-17 6

Replacement Parts
Throttle/Clutch Assembly
4
4-3 15D17doc080618 Replacement Parts
D17
4.3 Throttle/Clutch Assembly
REF DESCRIPTION (Indicates Parts Available In Assemblies Only) PART # QTY.
1 KNOB, 5/8-11 BALL P04211 1
2 HANDLE, LT15 CLUTCH 062313 1
3 SCREW, 3/8-16 X 3/8” SOCKET HEAD CUP PT SET F05007-68 2
4 ACTUATOR WELDMENT, THROTTLE LT15D&G 034815 1
5 LINKAGE, THROTTLE LT15D&G 034818 1
6 BOLT, 1/4-20 X 1/2” HEX HEAD F05005-15 1
7 NUT, 1/4-20 SWAGED F05010-21 1
8 BUSHING, 5/8” ID X 7/8” OD X 1 1/8” LONG FL BRONZE 016486 2
9 BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 065572 1
10 PIN, 3/16” X 1 1/4” ROLL F05012-16 1
LINKAGE ASSEMBLY, W/BEARING 034605 1
11 Link Weldment, Clutch/Brake 034604 1 
12 Bushing, 5/8” ID x 7/8” OD x 1 1/8” Long Fl Bronze 016486 1
13 NUT, 1/2-13 FREE HEX, ZINC F05010-35 1
14 WASHER, 1/2” SPLIT LOCK F05011-9 1
15 NUT, 1/2-13 JAM F05010-31 1
16 PIVOT WELDMENT, CLUTCH/BRAKE 034608 1
1
2
3
4
8
8
910
11
12
13
14
15
32
33
16
17
17
18
19
20
21 22
23
24 25
5
7
6
26
26
27
28
31 30 29
150174-2F

Replacement Parts
Throttle/Clutch Assembly
Replacement Parts 15D17doc080618 4-4
4
D17
17 BUSHING, 1” X 1 1/4” X 3/4” FLG BRONZE P737 2
BRAKE/CLUTCH ASSEMBLY, LT15 065874 1
18 Arm Weldment, Clutch/Brake LT15 065873 1
19 Bolt, 3/8-16 x 2” Hex Head Gr5 F05007-124 1
20 Nut, 3/8-16 Hex Nylon Lock F05010-10 1
21 Block, LT15 Brake 016488 2
22 Screw, 10-24 x 1” Socket Head F05004-2 4
23 Nut, #10-24 Keps F05010-14 8
24 Idler, 4" O.D. x 3/8” Bore 034602 1
25 Bolt, 3/8-16 x 2-3/4” Hex Head Gr5 Full Thread F05007-230 1
26 Washer, 3/8 Flat F05011-3 2
27 Nut, 3/8-16 Swaged Lock F05010-25 2
28 Spring, Idler Arm LT15D/E/G 034810 1
29 Screw, 10-24 x 5/8” FSHC F05004-282 4
30 Plate, Brake Adjustment 065872 2
31 Washer, #10 SAE Flat F05011-18 4

i 15D19doc080618 Index
M
maintenance 3-1
fuel filter 3-2
P
parts list
engine assembly 5-1
fuel tank 4-1
S
starting 2-1
INDEX
