Woosim Systems PORTI-KT40 User manual

http://www.woosim.com
MODEL PORTI-KT40
(2inch Desktop Printer)
Rev. 3.0
All specifications are subjected to change without notice

Porti-KT40 Rev. 3.0
http://www.woosim.com
2
 Copyright
PORTI-KT40 2inch Desktop Printer Operator’s Manual.
Copyright ⓒ2017 by Woosim System Inc.
All rights reserved.
The information contained in this manual is the property of Woosim Systems Inc. and may not be
reproduced in whole or in part without
the prior written permission of Woosim System Inc.
 Trademark
a registered trademark of Woosim Systems Inc.
All other trademark are the properties of their respective companies.
 Caution
Some semiconductor devices are easily damaged by static electricity.
You should turn the printer “OFF”, before you connect or removed the cable on the rear side,
in order to guard the printer against the static electricity.
If the printer is damaged by the static electricity, you should turn the printer “OFF”
 Notice
The contents of this manual are subject to change without notice.

Porti-KT40 Rev. 3.0
http://www.woosim.com
3
 Introduction
The Porti-KT40 is the ideal solution for taxi receipt printer, receipt printer, Medical analyzer,
industrial instrument, recorder, geological analyzer, underground analyzer, chemical analyzer,
metallic analyzer, etc.
The general features of Porti-KT40 printer are as follows:
Pocket size(75 x 103 x 44.3mm)
Light weight(179g) for true mobility.
Very silent printing thru direct thermal printing method
High speed(50mm/sec, MAX)
High resolution(203dpi : 8dots/mm).
UART(RS-232C or TTL) or RS-485 interface
Support text and graphic printing.
Low power consumption
Easier paper loading by CLAMSHELL design.
Easier maintenance with self-diagnostics.
In field programming –Update Firmware, Download Fonts and Logos
Microsoft Windows/Windows CE, Linux, Android compatible
Flow control : Software (XON/XOFF)
※ Hardware flow control not supported in printer.
Agency Approvals

Porti-KT40 Rev. 3.0
http://www.woosim.com
4
 Operating Precautions
Please follow the precautions below to enjoy and maintain the full performance of the printer.
Using the Printer
● Be careful not to drop or bump the printer on a hard surface.
● Do not install the printer in direct sunlight or such areas.
Suitable environment for the use of the printer is as follows:
◆ Operating temperature :-10°C to 50°C
◆ Relative humidity : 30% to 80%
● Do not install the printer near devices that generate strong electromagnetic fields
such as a copy machine.
● Do not open the platen cover during printing .
● Do not remove or reinstall the communication cable during printing or transmission.
● Do not touch the connectors of the communication during printing.
● Switch the POWER OFF when not in use.
● Do not use alcohol or other solvent.
Thermal Paper Handling
● Store the thermal paper in a cool, dry and dark place.
● Do not rub the paper with hard object.
● Do not leave the paper with hard object.
● Do not allow plastic film, erasers, or adhesive tape to touch the paper for long periods.
● Do not stack the thermal paper with diazo copies immediately after copying or wet-type copies.
● Do not use chemical glue.
●Always use the clean thermal paper.

Porti-KT40 Rev. 3.0
http://www.woosim.com
5
Federal Communications Commission
Radio Frequency Interference Statement
FCC ID : QDDPORTI-KT40
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
ㆍReorient or relocate the receiving antenna.
ㆍIncrease the separation between the equipment and receiver.
ㆍConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
ㆍConsult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user's authority to operated the equipment
under FCC rules.
This Device has been evaluated to comply with RF exposure requirement for general use
limit in portable condition. It is safe to be used in sold condition.
CE WARNING
ㆍChanges and modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
ㆍIt is desirable that it be installed and operated with at least 20cm or more between the radiator and
person’s body(excluding extremities hand, wrists, feet, and ankles)

Porti-KT40 Rev. 3.0
http://www.woosim.com
6
CONTENTS
1. Outline ................................................................................................................................................................. 7
1.1. Model classifications .................................................................................................................................. 7
1.2. Product Part Number System.................................................................................................................... 7
1.3. Specifications .............................................................................................................................................. 8
2. Setting up the printer....................................................................................................................................... 9
2.1. Printer & Accessories ................................................................................................................................. 9
2.2. Printer Features..........................................................................................................................................10
2.2.1. Part name ..........................................................................................................................................10
2.2.2. Dimensions ........................................................................................................................................10
2.3. Replacing paper roll ..................................................................................................................................11
2.4. Specified power supply.............................................................................................................................11
3. Interface..............................................................................................................................................................12
3.1. Serial............................................................................................................................................................12
4. Using the printer...............................................................................................................................................13
4.1. Control panel..............................................................................................................................................13
4.2. The self test................................................................................................................................................13
5. Consumable Parts.............................................................................................................................................14
5.1. Recommended paper................................................................................................................................14
5.2. Printing position ........................................................................................................................................14
6. Revision History ................................................................................................................................................15

Porti-KT40 Rev. 3.0
http://www.woosim.com
7
1
1. . O Ou ut tl li in ne e
1
1. .1 1. . M Mo od de el l c cl la as ss si if fi ic ca at ti io on ns s
1
1. .2 2. . P Pr ro od du uc ct t P Pa ar rt t N Nu um mb be er r S Sy ys st te em m
PORTI–KT40 ( ) ( )
Model name
Interface
A0 : UART
D0 : RS-485
Power
None : DC 12V
Model name / Interface Spec.
Example) 1. Porti-S40 UART/Bluetooth Part No. ⇒S40/A1
2. Porti-SC30 Bluetooth Only Part No. ⇒SC30/Z1
Note) The above table is the interface format which is supported.
But some of the interfaces are not supported according to the product
and please contact us, if you have any questions regarding the interface.
S40
SC30
W25
.
.
.
Wired
Wireless
A
RS-232C
1
Bluetooth
B
TTL
2
IrDA
C
USB
0
None
D
RS-485
E
Parallel
Z
None

Porti-KT40 Rev. 3.0
http://www.woosim.com
8
1
1. .3 3. . S Sp pe ec ci if fi ic ca at ti io on ns s
Item
Specification
Printing method
Direct thermal line printing
Characters per line
- Font A : 32cpl / Font B : 42cpl / Font C : 48cpl
- KOR, CHN, JPN : 16cpl
Character size
- Font Size A: 12X24 / Font Size B : 9X24 / Font Size C : 8X16
- KOR : 24X24(16X24) / CHN, JPN : 24X24
Optional Characters
Alphanumeric:95, Extended Graphics:128X31 pages, International:10,
Simplified/Traditional Chinese, Japanese, Korean
Resolution
203dpi, 8dots/mm
Print width
2-inch (48mm, 384dots)
Printing speed
50mm / sec (MAX)
Dimensions
75 X 103 X 44.3 mm
Weight (w/o paper)
179g
Interface
UART(RS-232C or TTL) or RS-485
Paper supplied
Thermal roll paper (57mm wide, 40ø)
Barcode supplied
1-dimension : UPC-A, UPC-E, EAN-8, EAN-13, CODE-39, CODE-93,
CODE-128, ITF, CODABAR
2-dimension : PDF417, Micro PDF417, Truncated PDF417, QR-CODE,
DATA Matrix, Maxicode
Etc :GS1 databar
Driver
Microsoft Windows, Linux
H/W Spec
MCU : RX-32bit, RAM : 128M bit, FLASH : 64M bit
Receive buffer size
1M bytes
Input Power
12VDC, Stand by 80mA and Max 3A
Environment
Conditions
Temperature
-10°C ~ 50°C (operating)
-10°C ~ 70°C (storage)
Humidity
30% - 80% (operating)
10% - 90% (storage)
MCBF (Mean Cycle
Between failure)
Mechanical
37,000,000 lines
Head
Approximately 50 Km
< Table 1 >

Porti-KT40 Rev. 3.0
http://www.woosim.com
9
2
2. . S Se et tt ti in ng g u up p t th he e p pr ri in nt te er r
2
2. .1 1. . P Pr ri in nt te er r & & A Ac cc ce es ss so or ri ie es s
Your printer box should include these items. If any items are damaged or missing, please
contact your dealer for assistance.
PORTI-KT40
Thermal roll paper

Porti-KT40 Rev. 3.0
http://www.woosim.com
10
2
2. .2 2. . P Pr ri in nt te er r F Fe ea at tu ur re es s
2
2. .2 2. .1 1. . P Pa ar rt t n na am me e
2
2. .2 2. .2 2. . D Di im me en ns si io on ns s

Porti-KT40 Rev. 3.0
http://www.woosim.com
11
2
2. .3 3. . R Re ep pl la ac ci in ng g p pa ap pe er r r ro ol ll l
2
2. .4 4. . S Sp pe ec ci if fi ie ed d p po ow we er r s su up pp pl ly y
1. Make sure that the printer is not receiving data; otherwise, data may be lost.
2. Open the paper cover using finger on both side of printer, and remove the remaining paper.
3. Insert the paper roll as shown.
4. Tear the excess paper off using the edge of paper door as a tear bar.
The following specifications are requested for Power supply.
Input : DC 12V/ Max 3A
Avoid using power supply which its power capacity of power current is extremely high.
Note : Be sure to use paper rolls that meet the specifications.
Do not use paper rolls that have the paper glued to the core because the printer can not
detect the paper end correctly.

Porti-KT40 Rev. 3.0
http://www.woosim.com
12
3
3. . I In nt te er rf fa ac ce e
3
3. .1 1. . S Se er ri ia al l
The Porti-KT40 printer has a serial(RS-232C or RS-485) interface is connected by means of a 9 pin
D-sub(Female Type) connector. In the following table, the signals present on the connector are
listed:
Pin No.
Signal Name
Direction
Function
2
TxD
Output
Transmit Data
3
RxD
Input
Receive Data
5
GND
Ground
9
Vpp
12VDC / 3A
<D-Sub 9p Female >

Porti-KT40 Rev. 3.0
http://www.woosim.com
13
4
4. . U Us si in ng g t th he e p pr ri in nt te er r
4
4. .1 1. . C Co on nt tr ro ol l p pa an ne el l
4
4. .2 2. . T Th he e s se el lf f t te es st t
Button
FEED Button : Use feed button to feed the paper continuously.
Power & Error Lamp
Power (Green) : Printer is ON and ready to receive data.
Error (Red) : Indicates a fault condition or a printer error.
(details: no paper, paper cover opened. etc.)
Self-Test prints out the current setting value of printer. The way of self-test is as follows.
1. Insert proper paper into the printer.
2. Power on while pressing feed button to start self-test.
3. Printer will print out the current status. (F/W version and set contents)
4. And then pattern of characters will be printed out.
5. Self-test will be finished automatically and turned to the standby status.
※In case printer does not work properly, please contact Woosim customer service center.

Porti-KT40 Rev. 3.0
http://www.woosim.com
14
5
5. . C Co on ns su um ma ab bl le e P Pa ar rt ts s
5
5. .1 1. . R Re ec co om mm me en nd de ed d p pa ap pe er r
5
5. .2 2. . P Pr ri in nt ti in ng g p po os si it ti io on n
Type : Thermal Paper
Paper width : 57mm
Paper thickness : 60±5 ㎛
Outer diameter : Ø40mm or less
Recording side : Outside of roll
Cautions
1. Do not paste the paper to the core. And the roll paper which has
Near end mark printing on its near end is recommended.
2. Chemicals or oil may change the color of paper, or printed Characters may fade.
3. Change of paper color starts from approx 70 ℃.
Pay attention to heat, humidity and sun light.
4. Color of paper may be changed by being scratched by nail or hard metal, etc

Porti-KT40 Rev. 3.0
http://www.woosim.com
15
6
6. . R Re ev vi is si io on n H Hi is st to or ry y
Date
Version
Comments
Jun. 06. 2017
3.0
RX version renewal
* Change page layout (B5→A4)
* Delete address
