WUNDER AGS-1500 User manual

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 1
www.wunder.it
STAINLESS ELECTRONIC SCALE MOD. AGS
User Manual
Read this manual carefully before using the instrument
CONTENTS
1. INSTALLATION
2. SPECIFICATIONS
3. KEYBOARD LAYOUT AND DESCRIPTION
4. INITIAL SETUP
5. INSTRUCTION FOR USE
6. TROUBLE SHOOTING
7. DAILY CARE AND MAINTENANCE
CAUTIONS
1. This unit is legal for trade only when it is sealed (and/or stamped) and bearing a serial number. Do not attempt to
break the seal (or stamp) affixed to this scale or remove the serial number. Contact your dealer for more
information and after sales service.
2. For most accurate weighing result, do not use this scale in where or when the environment condition falls beyond
as those listed on SPECIFICATIONS.
3. Do not attempt to open this unit or conduct any trouble shootings other than those listed on TROUBLE SHOOTING.
4. Do not use this scale for chemical substances or in any environment that contains chemical vapor.
5. Precision measuring instrument, handle with care.
6. Do not open scale. No user serviceable parts inside.

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 2
1. INSTALLATION
1.1 Check and make sure that the following accessories are included:
Operation Manual x 1
Scale x 1
Stainless steel platter x 1
Power adaptor x 1
Dust Cover x 1
Contact your dealer if any item is missing.
1.2 Place the stainless steel platter on the scale.
1.3 Power on the scale
a. Before charging the scale or power on with the adaptor supplied. Please make sure the input voltage listed
on the back of the adaptor matches with the local voltage. If not, do not use it and contact your dealer
immediately.
b. Before first time use, charge the scale for at least 8 hours to ensure the best performance.
2. SPECIFICATIONS
Model No.
Capacity
(Max)
Division (e)
OIML
Non-OIML
Extended
AGS-1500
1500g
0.5g
0.2g
0.05g
AGS-3000
3000g
1g
0.5g
0.1g
AGS-6000
6000g
2g
1g
0.2g
AGS-15K
15kg
0.005kg
0.002kg
0.0005kg
AGS-30K
30kg
0.01kg
0.005kg
0.001kg
Tare Range
Full Tare Range
Power-onZero Range
±10% Max
Zero Range
±2% Max
Min. Load
20e*
Power Source
By Built-in Rechargeable Battery or AD/DC Power Adaptor
Operating
Environment
0o~40oC (32o~104oF),
Non-condensed. R.H.≦85%
Specifications subject to change without notice
NOTE 1:
OIML = Legal for trade (1/3000)
Non-OIML = Not legal for trade (1/6000~1/7500)
NOTE 2:
Extended Display Function does not support avoirdupois weight units (lb/lb and lb/oz)

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 3
3. KEYBOARD LAYOUT AND DESCRIPTION
1. OFF KEY
Press this key to turn scale off
2. ON/ZERO KEY
Press this key to turn scale on or set weight to zero
3. MODE KEY
Press this key to shift among different weight units and/or turn backlight on/off
4. TARE KEY
Press this key to tare off the weight of a container.
5. FUNCTION KEY
Press this key to enter counting function or percentage function
6. SAMPLE KEY
Press this key to sample the weight place on the platter and engage the counting function or percentage function
7. MODE INDICATOR
This indicator shows current weight unit or operating mode engaged
8. ZERO INDICATOR
This indicator appears to indicate a zero weight status
9. NET INDICATOR
This indicator appears to indicate the tare function is in operation and weight displayed is net weight
10. LO-BAT INDICATOR
When this indicator appears, recharge the scale immediately. Failure to do so may cause unrecoverable damage to the
rechargeable battery inside scale
4. INITIAL SETUP
4.1 PLACING THE SCALE
In order to obtain an accurate weighing result, the scale must be placed on a strong and level surface.
If required, adjust the adjustable feet underneath scale to obtain a level position. Refer to the bubble indicator for
leveling condition.

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 4
4.2 INTERNAL SETTING
4.2.1 Display Segment Check
User can enter this function to check to see if the display and backlight (if purchased) are functioning properly.
a. Scale is off
b. Press and hold TARE, then press ON/ZERO
c. Scale displays F.1
d. Press TARE once
e. Scale displays F.2
f. Press MODE and all segments will light up to allow user to check the condition of display
g. Press TARE for next function setup or ON/ZERO to restart the scale
4.2.2 Select Auto Power Off Setting
The scale is equipped with Auto Power Off Function. The scale will power off automatically if it is not used for 4 minutes.
Follow the below steps to enable/disable Auto Power Off Function.
a. Scale is off
b. Press and hold TARE, then press ON/ZERO
c. Scale displays F.1
d. Press TARE three times
e. Scale displays F.4
f. Press MODE to shift between 0._OFF and 4._OFF
-To enable Auto Power Off Function, press TARE when 4._OFF appears
-To disable Auto Power Off Function, press TARE when 0._OFF appears
g. Press ON/ZERO to restart the scale or TARE for next function setup
4.2.3 Select Auto Tare Function
This scale is equipped with auto tare function which tares off the initial weight automatically when this function is
engaged. The tare weight is automatically cleared when everything is removed from platter.
a. Scale is off
b. Press and hold TARE, then press ON/ZERO
c. Scale displays F.1
d. Press TARE six times
e. Scale displays F.9
f. Press MODE to select between “Tr_on” or “TroFF”
-To enable Auto Tare Function, press TARE when Tr_on appears
-To disable Auto Tare Function, press TARE when TroFF appears
g. Press ON/ZERO to confirm and restart the scale or TARE for next function setup

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 5
5. INSTRUCTION FOR USE
5.1 BEFORE WEIGHING
Make sure that:
a. The stainless steel platter is placed correctly on top of load receptor.
b. The scale is placed on a level and strong surface.
c. The scale is turned on.
d. The ZERO INDICATOR is on. If not, press ON/ZERO to set display to zero.
5.2 WEIGHING
a. Always place an object onto the platter gently. Excessive force applied to platter may cause damages to sensor
inside scale.
b. The weight of the object would be displayed automatically.
c. It is a good practice to remove all loads from platter after weighing. It would prolong the lifetime of scale.
5.3 SELECT WEIGHT UNIT
Press MODE to shift between metric or avoirdupois weight units. The weight unit used before power off would be
employed when the is turned on again.
NOTE:
To comply with the law of certain countries and certain approval requirements, the avoirdupois weight units may be
disabled. Contact your dealer for more information.
5.4 SET BACKLIGHT
Follow the below steps to turn on and off backlight (if purchased).
a. Scale is on
b. Press and hold ON/ZERO until backlight is activated; or press MODE to shift between metric and avoirdupois
weight to turn on and off backlight
5.5 SMART POWER SAVING FUNCTION
The backlight function will turn off when constant/zero weight is detected and remains stable for about 20/10 seconds.
Backlight will be automatically turned on again when a new weight is detected.
5.6 SET DISPLAYED VALUE TO ZERO WHEN UNLOADED
By pressing ON/ZERO, a positive or negative weight displayed will be set to zero and ZERO INDICATOR appears.
Refer to SPECIFICATIONS for maximum zero range.
NOTE:
-When scale is set at OIML and application is legal for trade. User only needs to press ON/ZERO once when setting the
value to zero. The re-zero function will take place when reading is stabled
-When scale is set at Non-OIML and application is not legal for trade. User can set the value to zero at anytime when

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 6
pressing ON/ZERO
5.7 TARE OFF THE WEIGHT OF A CONTAINER
When a container is used, follow the below steps to manually tare off the weight of container and get the net weight.
a. Remove all loads away from platter
b. Make sure that the ZERO INDICATOR is on
c. Place the container on the platter
d. Press TARE
After TARE is pressed, the NET INDICATOR would appear.
Refer to 5.2 for weighing procedures. Weight displayed under is the net weight of the subject matter. Refer to
SPECIFICATIONS for maximum tare range.
NOTE:
- When scale is set at OIML and application is legal for trade. User only needs to press TARE once when tare off a weight.
The tare function will take place when reading is stabled
- When scale is set at Non-OIML and application is not legal for trade. User can tare off the weight anytime when
pressing TARE
5.8 CLEAR THE TARE FUNCTION
a. Remove all loads from platter
b. The tare effect will be cancelled:
-Automatically if automatic tare function is employed, or
-By pressing TARE
c. After TARE is pressed, the NET INDICATOR would disappear.
5.9 MEMORY FUNCTION
5.9.1 How to Accumulate a Weighing Result to Memory
a. Refer to 5.2 to 5.3 for weighing
b. Press M+ to save and accumulate the result to memory.
c. Scale will display “P. X” and then follow by the accumulated weighing result stored while both M+ INDICATOR and
MEMORY RECALL INDICATOR appear pointing to M+ and MR on the overlay respectively
d. Scale return to normal after 2 seconds and MEMORY RECALL INDICATOR will turn off automatically but M+
INDICATOR will remain on display to indicate that memory contains a stored data
e. NOTE 1: “P. X” means the total number of transactions accumulated to memory
f. NOTE 2: No weighing result will be stored to memory if it is less than the minimum load. Please refer to
SPECIFICATIONS for more information

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 7
g. NOTE 3:
h. - When scale is set at OIML and application is legal for trade. User only needs to press M+ once when trying to store
a value to memory. The weight accumulation function will take place when reading is stabled
i. - When scale is set at Non-OIML and application is not legal for trade. User can save the shown value to memory at
anytime when pressing M+
j. 5.9.2 Memory Recall
k. a. Press MR
l. b. Scale displays “P. X” and then follow by the accumulated weighing result while MEMORY RECALL INDICATOR
appears pointing at MR
m. c. Scale return to normal after 2 seconds and MEMORY RECALL INDICATOR will switch off with only M+
INDICATOR remain on display.
5.9.3 Memory Clear
a. Press MR and TARE at the same time
b. Scale displays “P. 0” and MR INDICATOR at the same time and return to normal after 2 seconds and M+ INDICATOR
will switch off
5.10 EXTENDED DISPLAY
This scale is equipped with extended display function for reference purpose only. To activate the function, press and
hold MODE for 2 seconds and display will flash the extended digit for 5 seconds before return to normal.
5.11 RECHARGE THE SCALE
The scale is equipped with a built-in rechargeable battery. When the LO-BAT INDICATOR appears, recharge the scale
immediately. Failure to do so may cause unrecoverable damage to the rechargeable battery.
6. TROUBLE SHOOTING
Syndrome Scale cannot be turned on
Check: Is the scale charged?
Action: Recharge the scale for at least 8 hours before first time use or plug in the power adaptor before power
on the scale.
Check Is the power adaptor inserted properly into both the electricity outlet and the DC inlet of scale.
Action: Secure both ends of the power adaptor and try again.
Syndrome Scale turned off automatically
Check Is Auto Power Off Function employed?
Action Refer to 4.2.2 to disable Auto Power Off Function.

WUNDER SA.BI.SRL USER MANUAL
AGS INOX REV.01 04/12/2016 8
Check Is the LO-BAT INDICATOR on?
Action Apply the power adaptor
Syndrome Rated capacity cannot be reached
Check Is the NET INDICATOR on?
Action: Turn the scale off. Remove all loads from platter and turn on again.
Check Is there anything obstructing the platter?
Action Remove all obstacles.
Syndrome Weighing result is not accurate
Check Is the scale placed in a level condition?
Action Adjust the adjustable feet to a level condition.
Check Is the scale affected by airflow, vibration or RFI?
Action: Place the scale away from all disturbances.
Check Is the scale calibrated correctly?
Action Contact your dealer.
Check Is the correct weight unit employed?
Action Refer to 5.3 for weight unit setting and usage.
Syndrome Display shows 00000 after counting down
Check Is the load applied to platter excess the rated capacity of scale?
Action Remove all loads from platter and try again.
7. DAILY CARE AND MAINTENANCE
7.1 Clean the scale with a soft and damp cloth. If necessary, apply a mild detergent.
7.2 Do not use any harsh, abrasive material, acetone, volatile solvent, thinner or alcohol for cleaning.
7.3 Verify the accuracy of scale periodically. Re-calibrate the scale if necessary.
NOTE: In some countries, calibration requires authorized/qualified agent. Contact your dealer for more information.
7.4 It is a good practice to apply the dust cover when operating the scale.
7.5 The scale must be placed horizontally during transportation or long time storage.
7.6 Remove platter from scale before transportation or long time storage.
7.7 Store scale in a dry and clean place.
