WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 1
Model: W1090
PROFESSIONAL BLUETOOTH SCALE
!Please read carefully this manual before using the scale
EN
3
8
11
9
10
12
11
14
15
13
13
4
General information
Security
Technical specications
Panel and key function
Functions
Internal settings
Power supply
Error messages and solutions
Conformity
Identication labels
Scrapping and waste disposal
Warranty

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 2
By choosing the WUNDER mod. W1090 Bluetooth professional electronic scale,
you have purchased a high precision instrument.
Since over 40 years WUNDER has placed its experience at the service of health.
This instrument is compliant with national standards in hospitals and clinics with
medical class I with measurement function and is calibrated in conformity with
accuracy class IIII. The instrument is characterised by the possibility of xing the
electronic terminal to the weighing platform by means of a column or else instal-
ling the terminal autonomously.
WUNDER reserves the right to modify its products as deemed convenient in order
to approve them without being committed to update this publication.
Conventions: The following symbols have been used in this manual:
0476 EC TYPE APROVAL FOR MEDICAL USE
METROLOGICAL CERTIFICATION AND APPROVAL
ACCURACY CLASS
TYPE B PARTS SUPPLIED
!
ATTENTION!
PLACED BEFORE DETERMINING PROCEDURES. COMPLIANCE FAILURE
CAN HARM THE OPERATOR OR PATIENT OR DAMAGE THE PRODUCT
WASTE DISPOSAL
THERE COULD BE INTERFERENCE NEAR ELECTRONIC APPLIANCES
DUAL INSULATION (CLASS II)

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 3
- These batteries should be kept away from small children.
If swallowed, promptly seek medical assistance.
- Expected Service Life: 5 years
- Don’t leave the baby unattended on scale.
- When using electrical components under increased safety requirements, always
comply with the appropriate regulations.
- Improper installation will render the warranty null and void.
- Ensure the voltage marked on the power supply unit matches your mains
power supply.
- This device is designed for use indoors.
- Observe the permissible ambient temperatures for use
- The device meets the requirements for electromagnetic compatibility.
Do not exceed the maximum values specied in the applicable standards.
- These batteries should be kept away from all children.
If swallowed, promptly seek medical assistance.
ENVIRONMENTAL
- All batteries contain toxic compounds; disposal of batteries should be
delegated to a competent organization, complying with the deposit of
Poisonous Waste Regulation 1972.
- Please do not incinerate batteries.
- The optimum operating temperature for the scale is +5°C to +35°C;
although it will operate at higher and lower temperatures the scales battery life
will be adversely eected.
CLEANING
- We would recommend using alcohol based wipes or similar when cleaning the
scales.
- Please do not use large amounts of water when cleaning the scales as this will
cause damage to the scales electronics, you should also refrain from using
corrosive liquids or high pressure washers.
- Always disconnect the scales from the mains power supply before cleaning.
Before putting the device into use, please read with care the information given
in the operating instructions. They contain important instructions for installa-
tion, proper use and maintenance of the device. The manufacturer shall not be
liable for damages arising out of failure to heed the following instructions:
GENERAL INFORMATION

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 4
WEIGHING OPERATION
- Before reading detailed instructions on how to use all the weighing functions
that are built into your scale, please read the following important guidelines:
- Always be sure that the display shows `Zero` before use, if it doesn’t then
please press the ZERO key.
- The Professional Medical scale is designed to detect when a stable weight
is achieved, the indicator will `bleep` twice to indicate a stable weight value,
your reading should be taken at this point.
DISPOSING OF THE SCALE
- This product is not to be treated as regular household waste, but should be
handed in to an electrical/electronic equipment recycling centre.
- You can obtain further details from your local council, your municipal waste
disposal company or the rm which you purchased the product
Guide and manufacturer’s declaration – Electromagnetic emissions
The scale W1090 is intended for use in the electromagnetic environment speci-
ed below. The customer/user should assure that it’s used in that environment.
Emission test Conformity Guide to electromagnetic
environment
RF Emission CISPR11 Group 1 Class B
W1090 uses RF energy only for its inter-
nal function. Therefore its RF emissions
are very low and probably not cause no
interference in electrical equipment.
RF Emission CISPR11 Group 1 Class B W1090 is suitable for use in all establi-
shments, including domestic establi-
shments and those directly connected
to the public low-voltage power supply
network that supplies buildings used
for domestic purposes.
Harmonic emission
IEC 61000-3-2 Class A
Voltage uctuations/
icker emission
IEC 61000-3-3
Compliance
SECURITY

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 5
Guide and Statement of manufacturer – Electromagnetic immunity
The scale W1090 is intended for use in the electromagnetic environment speci-
ed below. The customer/user should assure that it’s used in that environment.
Immunity test IEC 60601
Test level Compliance Level Guide to electromagnetic environment
Electrostatic
discharge(E-
SD)
IEC/EN61000
- 4 - 2
± 6kV contact
± 8kV air
± 6kV contact
± 8kV air
The oors should be made
of wood, concrete or cera-
mic. If the oors are covered
in synthetic material, the
relative humidity should be
maximum 30%.
Electrical fast
transient/
burst
IEC/EN61000
- 4 - 4
± 2kV for
power
supply lines +
1kV for
input/output
lines
± 2kV for power
supply lines Not
applicable
Mains power quality should
be that of a typical commer-
cial or hospital environment.
Surge IEC/EN
61000 - 4 - 5
± 1kV line(s) to
line(s)
± 2kV line(s) to
earth
± 1kV dierential
mode Not
applicable
Mains power quality should
be that of a typical commer-
cial or hospital environment.
Voltage dips,
short inter-
ruption and
voltage
variation
IEC/EN61000 -
4 - 11
<5% UT for 0,5
cycle
40% UT for 05
cycles
70% UT for 25
cycles
<5% UT for 5s
<5% UT for 0,5
cycle
40% UT for 5
cycles
70% UT for 25
cycles
<5% UT for 5 s
The power supply should be
of the type used typically in
commercial or hospital envi-
ronments.
Power fre-
quency
Magnetic eld
IEC/EN61000
- 4 - 8
3A/m 3A/m
W1090 power frequency
magnetic elds should be
at levels characteristic of a
typical location in a typical
commercial or hospital
environment.
Note=UT is the value of the voltage of the feed.

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 6
Manufacturer’s guide and declaration - Electromagnetic emissions
The scale W1090 is intended for use in the electromagnetic environment speci-
ed below. The customer/user should assure that it’s used in that environment.
Emission test IEC/EN60601
test level
Compliance
level
Guide to electromagnetic
environment
Conducted RF
IEC/EN 61000
- 4 - 6
3 Vrms
150 KHz to 80
MHz (for ap-
pliances that
are not life sup-
porting)
3Vrms Equipment in RF communications
and mobile laptops should ot be
used near any part of the tooth,
including cables, except when
they meet the recommended se-
paration distance calculated by
the frequency applied to the tran-
smitter. Recommended separa-
tion distance d = 1.2 √ P d = 1.2 √ P
from 80 MHz to 800 MHz d = 2.3 √
P from 800 MHz to 2.5 GHz where
the P and maximum rated power
output of the transmitter in Watts
(W) according to the manufactu-
rer of the transmitter and the re-
commended separation distance
in meters (m). The intensity of the
eld of a xed RF transmitters, as
determined by an electromagnetic
site, it could be lower than the le-
vel of compliance of each range of
frequency b. You can check inter-
ference in proximity of equipment
marked with the following symbol:
Radiated RF
IEC/EN 61000
- 4 - 3
3 V/m 80MHz
to 2,5 GHz
3 V/m
With 80 MHz and 800 MHz is applied the higher frequency range. These guidelines
may not apply in all situations. Electromagnetic propagation is aected by absorp-
tion and reection from structures, objects and people.
a) The intensity of the eld for xed transmitters such as base stations for radiote-
lephone mobile and cordless phones) and land radio mobile, amateur radio equi-
pment, radio transmitters in the AM and FM and TV transmitters cannot be made
theoretically and with precision. To establish an electromagnetic environment due
to xed RF transmitters, it should consider the electromagnetic survey of the site.
If the eld strength measured at the place where you use the device, exceeds the
applicable level of compliance of the above, it should be placed under observation
normal operation of the tooth. If you notice abnormal performance, it may take
additional measures as a dierent orientation or position of device.
b) Over the frequency range from 150 kHz to 80 MHz should be less than 3 V / m.

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 7
Manufacturer’s guide and declaration - Electromagnetic emissions
The W1090 scale is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The customer/user of the W1090 scale
can help prevent electromagnetic interference by maintaining a minimum di-
stance between portable and mobile RF communications equipment (transmit-
ters) and the W1090 scale as recommended below, according to the maximum
output power of the communications equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter m
150 kHz to 80 mHz
d =1,2√P
80 MHz to 800 MHz
d =1,2√P
800 kHz to 2,5 GHz
d =2,3√P
0,01 0,12 0,12 0,23
0,1 0,38 0,38 0,73
1 1,2 1,2 2,3
10 3,8 3,8 7,3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the
recommended separation distance d in metres (m) can be estimated using the
equation applicable to the frequency of the transmitter, where p is the maximum
output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic
propagation is aected by absorption and reection from structures, objects
and people.

60mm
350mm
350mm
90mm
WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 8
MANUFACTURER Wunder Sa.Bi. Srl
MODEL W1090 BT
CODE 00071BT
CAPACITY : DIVISION 200kg : 200g
ACCURACY 200g
UNITS OF MEASURE kg
FUNCTION KEYS ON/OFF, ZERO/TARE, HOLD/BMI
STABILISATION TIME 1-2 seconds
OPERATING TEMPERATURE
AND HUMIDITY 5°C - 35°C | 15% - 85% RH
POWER SUPPLY 4x 1.5V AA size alkaline batterie
Adaptor type: 12V
INDICATOR DISPLAY 1’’ LCD display with 5 active digits
DIMENSIONS (w)350 x (L) 355 x (H)60 mm
WEIGHT Net: 3,0kg | Gross: 3,3kg
TECHNICAL SPECIFICATIONS

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 9
PANEL AND KEY FUNCTION
Symbol Description
Stable Indicator
Minor Weight Value
0Zero
BT wireless transmission (Optional)
Key Function description
ON
OFF
To power ON and OFF the scale.
When the scale is powered ON for the 1st time, the weighing
direction will be on patient’s side.
ZERO
TARE
Press to tare weight.
Wireless trasmission function long press TARE button to enter in
the test mode as following.
HOLD
BMI
Press this key to lock the displayed weight. It is designed for
locking the weight when the person is standing on the scale.
To disable the Hold function, press the HOLD button and the
display will return to zero.
A. Off biuEt End

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 10
FUNCTIONS
HOLD FUNCTION
BMI FUNCTION
1. Press HOLD key to enter into weighing lock mode.
3. The person now stand on the scale can be weighed.
The scale will take the average weight and lock it on the display
4. After the weight value has been locked on the display, press HOLD key to
disable the lock function (the arrow pointing at the HOLD symbol will disappear
and return to normal mode.)
A. When the HOLD function has been activated, all other keys and functions can
not be operated.
1. Switch ON the scale and have the person to be weighed stand on the platform.
2. Press and hold BMI key for three seconds to enter into BMI mode.
3. Display shows last inputted height and an arrow starts ashing. Press TARE key
4. Use BMI key to increase the value and TARE key to decrease the value.
5. Once the height is set, press BMI key
6. The scale will register the weight of the person and calculate BMI according to
height set up before.
7. Display shows BMI, weight and height of the person in rotation mode
8. Press BMI key to disable BMI function.
B. *After a weight value is locked and the person is still on the scale*
Press HOLD key to disable the HOLD function or press TARE key to disable the
HOLD function and perform TARE function.
C. Before a weight value is locked, pressing TARE key will only perform TARE
function, but the HOLD function is not disabling.
NOTE:
2. The arrow pointing at the HOLD symbol will start to ash and the display will
show:
HoLd
Category BMI (kg/m2) Risk of diseases
Underweight < 18.5 Low
Normal weight 18.5 - 24.9 Average
Preobesity
I degree of obesity
II degree of obesity
III degree of obesity
25 - 29.9
30 - 34.9
35 - 39.9
≥ 40
Slightly increased
Increased
High
Very High
BMI Categories
Classication of weight for adults
over 18 years on the basis of Body
Mass Index according to WHO,
2000 EK IV and WHO 2004.
WHO (World Health Organisation)

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 11
INTERNAL SETTINGS
sEtUP
P-102 OFF
A_OFF
AdP0F
biuEt
HoLd5
tArE
End
0n
0n
0n
t= 0
0FF
0FF
0FF
t=160
60 5 120 5 180 5 240 5 300 5
Long press TARE/ZERO key for 6 seconds, to enter into setting mode
ZERO
TARE
HOLD
BMI
POWER SUPPLY
1. W1090 Scale uses 4x AA size alkaline batteries (optional)
2. Low battery indication will be displayed on the LCD when the battery power
is insucient to perform the weighing
3. When is displayed, please change batteries.
LobAt
4. ATTENTION! Follow the instructions below to proper install batteries
Adaptor plug
Unit switch
4x AA size alkaline batteries 1.5V
You can also use the adaptor (included)

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 12
ERROR MESSAGES AND SOLUTIONS
ERROR REASON SOLUTION
lo Low Battery:
Means that the charge of the bat-
tery is too low to use
Please replace a new battery or
plug the AC adaptor
Err Overload:
The total load exceeds the maxi-
mum capacity
Please reduce the load
weight and try again
Err.H Counting error (too high):
Indicates that the signal from the
load cell/s is too high
This error is normally caused
by a serious fault on the sca-
le such as a faulty load cell or
wiring. Please contact the local
service representative.
Err.L Counting error (too low):
Indicates that the signal from the
load cell/s is too low
This error is normally caused
by a serious fault on the sca-
le such as a faulty load cell or
wiring. Please contact the local
service representative.
00000 Zero count over calibration
zero range +10%
while power ON
Please re-calibrate the scale
00000
Zero count under calibration
zero range -10%
while power ON
Please re-calibrate the scale
Err.P EEPROM Error:
Indicates that there is a fault with
the scales software
This error is normally caused
by a serious fault on the sca-
le such as a faulty load cell or
wiring. Please contact the local
service representative.
Self-checking Tips:
Some functional defects can be identied and maintained by users as listed below:
Power-ON failure
1. Check if the main power adaptor has not plugged onto the scale properly
2. Check if the battery power is running low - Replace with new batteries

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 13
Indicator showing “0000“ ZERO SPAN out of range
1. Incorrect weighing result - Avoid damages by external environment force such
as free-drop to the ground, collision by external objects, etc.
2. Re-calibration procedure required to correct the setting of weighing accuracy.
3. Interference due to RF disturbance, ground vibration…
4. Unstable platform feet adjustments according to bubble level indication
5. Incorrect position or other external objects within weighing area
6. The scale is not in a solid and rm ground area, such as carpet oor or lawn.
Connection failure for data transmission to PC or printer
1. Wrong connection wires or faulty wires for transmission between the digital
indicator and load cells.
2. Wrong indicator model
3. Wrong internal wiring or wire broken
WUNDER MODEL W1090 ELECTRONIC SCALE SERIAL N°..............................
We certify that this instrument has been inspected and has successfully passed
the functional test. It complies with the following standards and directives:
EN 45501 / EN60601-1-2 / EN60601-1
93/42/EEC – Medical Devices Directive
CONFORMITY
IDENTIFICATION LABELS
In the metrological label applied it’s displayed the year of manufactur ex. 17=2017 and so..

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 14
If set aside for a long period, protect those parts which could be damaged due to
dust build-up
Scrapping
When you decide to no longer use this item, we recommend making it unusable
and making those parts which could be sources of danger harmless
Waste disposal EU 2012/19/UE
This product complies with the Directive 2012/19/UE. The symbol of the cros-
sed-out waste bin on the appliance indicates that the product, needing to be
treated separately from household waste, at the end of its useful life must be
completed in a separate collection facility for electric and electronic appliances
or returned to the dealer upon purchase of a new equivalent appliance. The user
is responsible for bringing the appliance to an appropriate collection structure at
the end of its life. Appropriate separate collection and sending the appliance for
recycling, treatment and environmentally compatible waste disposal contributes
to avoid possible negative eects on the environment and health and favours the
recycling of the materials the product is made of.
For more detailed information regarding available collection systems, contact
your local waste disposal service or the shop where the product was purchased.
As consumers, you are obliged by law to return used or dead batteries. You may
deposit old batteries at public collection spots in your town or else with any bat-
tery dealer who has placed specic collectors for this purpose. Even when scrap-
ping electric and electronic appliances, they must be removed and deposited in
specic collectors.
NOTE: The following symbols indicate the presence of harmful substances
Pb Pb = batteries containing Lead
Cd Cd = batteries containing Cadmium
Hg Hg = Batteries containing Mercury
SCRAPPING AND WASTE DISPOSAL

WUNDER SA.BI. SRL USER MANUAL
Model: W1090 rev.00 20/10/2018 15
This certicate must be kept until the warranty has expired. It must be presen-
ted together with the invoice, tax receipt or delivery note providing the name of
the dealer and date of purchase whenever a technical intervention is required.
Otherwise the user will lose any warranty rights. The warranty takes eect from
the date of purchase and is valid during the entire period foreseen by the current
catalogue/pricelist. By warranty we mean the replacement or repair free of charge
of parts making up the appliance which, at the discretion of the manufacturer, are
deemed faulty from the origin; Wunder therefore has the faculty of repairing or
replacing the item.
The warranty does not cover:
- Shipping faults, damage caused by falls, carelessness or tampering
- Damage caused by incapability of using the appliance and of its improper use
- Damage caused by an insucient or inadequate electrical system or
alterations resulting from environmental, climatic or other types of conditions
- Damage due to incorrect installation of the appliance and repairs carried out
by unauthorised personnel
- Interventions at home for convenience controls or presumed defects
- Routine maintenance and that which can be considered normal wear from use
- Consumables such as: power supplies, batteries, keyboards, plates, wheels,
heads, rolls, load cells faulty due to blows or overloads. Service can also be
refused when the appliance has been changed or transformed in any way.
In case of interventions at one's home, the customer must pay the xed fee;
if however the appliance is repaired at an authorised Wunder Service Centre,
expenses and relative travel risk are borne by the user.
Wunder will not be held liable for damage of any nature caused directly or indi-
rectly to persons, animals or objects resulting from failure to comply with all the
instructions indicated in this manual or anyway resulting from improper use.
The Court of Bergamo has jurisdiction in case of any dispute.
WARRANTY
