Xantrex XPower Inverter 3000 User manual

This guide for use by qualified installers only.
TM
TM
XPower™Inverter 3000
Installation Guide

This guide for use by qualified installers only.
About Xantrex
Xantrex Technology Inc. (www.xantrex.com), a subsidiary of Schneider Electric, is a world leader in
the development, manufacturing and marketing of advanced power electronic products and systems for
the renewable and mobile power markets. The company's products convert and control raw electrical
power from any central, distributed, renewable, or backup power source into high-quality power
required by electronic equipment and the electricity grid. Xantrex is headquartered in Vancouver,
Canada, with facilities in the United States, Germany, Spain, and a joint venture in China.
Trademarks
Xantrex, XPower, and Smart choice for power are trademarks of Schneider Electric International
Services sprl, registered in the U.S. and other countries. Other trademarks, registered trademarks, and
product names are the property of their respective owners and are used herein for identification
purposes only.
Notice of Copyright
XPower Inverter 3000 Installation Guide © January 2010 Xantrex Technology Inc. All rights reserved.
No part of this document may be reproduced in any form or disclosed to third parties without the
express written consent of: Xantrex Technology Inc., 161-G South Vasco Road, Livermore, California,
USA 94551. Xantrex Technology Inc. reserves the right to revise this document and to periodically
make changes to the content hereof without obligation or organization of such revisions or changes
unless required to do so by prior arrangement.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)
(A)MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR
OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;
(B)ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER
SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF
SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’SRISK; AND
(C)REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH
STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE ACCURACY CANNOT
BE GUARANTEED. APPROVED XANTREX CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE
VERSION WHICH IS POSTED AT WWW.XANTREX.COM.
Date and Revision Part Number Product Number
January 2010 Revision A 975-0556-01-01 813-3000-UL
Contact Information
Telephone: [phone] (toll free North America)
1 408 987 6030 (direct)
Fax: [phone] (toll free North America)
Email: [email protected]
Web: www.xantrex.com

iii
This guide for use by qualified installers only.
About This Guide
Purpose
The purpose of this Installation Guide is to provide explanations and
procedures for installing the XPower Inverter 3000.
Scope
The Guide provides safety guidelines and procedures for installing the
inverter. It does not provide details about particular brands of batteries.
You need to consult individual battery manufacturers for this information.
Refer to XPower Inverter 3000 Owner’s Guide (doc. part number: 975-
0555-01-01) for operational instructions.
Audience
The Guide is intended for qualified installers including licensed
technicians and electricians. It is intended for installers with knowledge
and experience in installing electrical equipment, knowledge of the
applicable installation codes, and awareness of the hazards involved in
performing electrical work and how to reduce those hazards.
Organization
This Guide is organized into two chapters.
Chapter 1 describes installation configurations, as well guidelines for
calculating battery requirements, choosing an effective charging system,
location and mounting orientations, cable sizes for your inverter and
selecting correct fuses or circuit breakers.
Chapter 2 describes installation procedures including planning, wiring,
and mounting the XPower Inverter 3000.

About This Guide
iv 975-0556-01-01
This guide for use by qualified installers only.
Conventions Used
The following conventions are used in this guide.
Related Information
You can find more information about Xantrex Technology Inc. as well as
its products and services at www.xantrex.com
WARNING
Warnings identify conditions that could result in personal injury or loss of life
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or
other equipment.
Important: These notes describe things which are important for you to know,
however, they are not as serious as a caution or warning.

v
This guide for use by qualified installers only.
Important Safety Instructions
IMPORTANT: Read and save this Installation Guide
for future reference.
This chapter contains important safety instructions for the XPower
Inverter 3000.
1. Before installing and using the XPower Inverter 3000, read all
instructions and cautionary markings on or provided with the XPower
Inverter 3000, the batteries, and all appropriate sections of this guide.
2. Do not expose the XPower Inverter 3000 to rain, snow, spray, or bilge
water. This product is not intended for marine applications.
3. To reduce risk of fire hazard, do not cover or obstruct the ventilation
openings. Do not install the XPower Inverter 3000 in a zero-clearance
compartment. Overheating may result.
4. To avoid a risk of fire and electric shock, make sure that existing
wiring is in good condition, adequately rated, and not undersized. Do
not operate the XPower Inverter 3000 with damaged or substandard
wiring.
5. Do not install or operate the XPower Inverter 3000 if it has received a
sharp blow, been dropped, or otherwise damaged in any way. If the
XPower Inverter 3000 is damaged, see the Warranty section.
6. Do not disassemble the XPower Inverter 3000. It contains no user-
serviceable parts. See Warranty for instructions on obtaining service.
Attempting to service the XPower Inverter 3000 yourself may result
in a risk of electrical shock or fire. Internal capacitors remain charged
after all power is disconnected.
WARNING: Shock, fire, and heat hazard. Risk of
injury to persons.

Safety
vi 975-0556-01-01
This guide for use by qualified installers only.
7. To reduce the risk of electrical shock, disconnect DC power from the
XPower Inverter 3000 before attempting any maintenance or cleaning
or working on any circuits connected to the XPower Inverter 3000.
Turning off controls will not reduce this risk.
8. The XPower Inverter 3000 must be provided with equipment-
grounding conductors connected to the vehicle chassis as described in
“Chassis Ground Wire Sizing” on page 1–10 and “Chassis Ground
Wire Sizing” on page 1–10.
Precautions When Working With Batteries
1. Follow all instructions published by the battery manufacturer and the
manufacturer of the equipment in which the battery is installed to
reduce the risk of battery explosion.
2. Working in the vicinity of lead-acid batteries is dangerous. Batteries
generate explosive gases during normal operation. Therefore, you
must read this guide and follow the instructions exactly before
installing or using your XPower Inverter 3000.
3. This equipment contains components which tend to produce arcs or
sparks. To prevent fire or explosion, do not install the XPower
Inverter 3000 in compartments containing batteries or flammable
materials, or in locations that require ignition-protected equipment.
This includes any space containing gasoline-powered machinery, fuel
tanks, as well as joints, fittings, or other connections between
components of the fuel system.
4. Make sure the area around the battery is well ventilated.
5. Never smoke or allow a spark or flame near the engine or batteries.
6. Use caution to reduce the risk or dropping a metal tool on the battery.
It could spark or short circuit the battery or other electrical parts and
could cause an explosion.
7. If you need to remove a battery, always remove the ground terminal
from the battery first. Make sure all accessories are off so you don’t
cause a spark.
WARNING: Explosion or fire hazard

Safety
975-0556-01-01 vii
This guide for use by qualified installers only.
8. Remove all metal items, like rings, bracelets, and watches when
working with lead-acid batteries. Lead-acid batteries produce a short
circuit current high enough to weld metal to skin, causing a severe
burn.
9. Have someone within range of your voice or close enough to come to
your aid when you work near a lead-acid battery.
10. Have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.
11. Wear complete eye protection and clothing protection. Avoid
touching your eyes while working near batteries.
12. If battery acid contacts skin or clothing, wash immediately with soap
and water. If acid enters your eye, immediately flood it with running
cold water for at least twenty minutes and get medical attention
immediately.
Precautions for Using Rechargeable Appliances
Most rechargeable battery-operated equipment uses a separate charger or
transformer that is plugged into an AC receptacle and produces a low
voltage charging output.
Some chargers for small rechargeable batteries can be damaged if
connected to the XPower Inverter 3000. Do not use the following with the
XPower Inverter 3000:
• Small battery-operated appliances like flashlights, razors, and night
lights that can be plugged directly into an AC receptacle to recharge.
• Some chargers for battery packs used in power hand tools. These
affected chargers display a warning label stating that dangerous
voltages are present at the battery terminals.
WARNING: Risk of personal injury due to burns or
battery acid
CAUTION: Risk of equipment damage
The output of the XPower Inverter 3000 is not sinusoidal and may not be
compatible with all loads. Follow the recommendations below.

viii

975-0556-01-01 ix
This guide for use by qualified installers only.
Important Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -v
1Installation Codes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4
Calculating Battery Requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4
Choosing an Effective Charging System - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–5
Choosing an Appropriate Location and Mounting Orientation - - - - - - - - - - - - - 1–5
Selecting Cable Sizes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–8
DC Input Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–8
Selecting a DC Input Fuse or Circuit Breaker - - - - - - - - - - - - - - - - - - - - - 1–9
Chassis Ground Wire Sizing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–10
Output Conductor Selection for Hardwire Installation - - - - - - - - - - - - - - 1–10
2Installing the Inverter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Installation Tools and Materials - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Tools - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Materials - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Overview of Installation Steps - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–3
Installing the Remote On/Off Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–3
Mounting the Inverter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–4
Connecting the Chassis Ground - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–4
Connecting the AC Output - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–5
Connecting the DC Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–8
Contents

x

1–1
This guide for use by qualified installers only.
1Designing Your Installation
Before doing anything else, you need to determine how you are going to
use your inverter, and then design a power system that will give you
maximum performance. The more thorough your planning, the better
your power needs will be met. In particular, you will need to:
• Be aware of installation codes
• Calculate your battery requirements
• Choose an effective charging system
• Choose an appropriate location and mounting orientation
• Calculate the cable size for your inverter
• Select the correct fuses or circuit breakers
Study Figures “Configuration for Normal Loads” on page 1–2 and
“Configuration for Heavy Loads” on page 1–3 for an example of a setup
for normal or heavy loads in a vehicle. When you have decided upon your
configuration, then you can calculate battery requirements.

1–2 975-0556-01-01
This guide for use by qualified installers only.
Figure 1-1 Configuration for Normal Loads
12V
12V

975-0556-01-01 1–3
This guide for use by qualified installers only.
Figure 1-2 Configuration for Heavy Loads
12V
12V
12V
12V

1–4 975-0556-01-01
This guide for use by qualified installers only.
Installation Codes
Governing installation codes vary depending on the location and type of
installation. Electrical installations must meet local and/or national wiring
codes and should be performed by a qualified electrician.
An example of a national wiring code is the US National Electrical Code
(NEC, NFPA70) article 551 governing electrical installations in RVs. In
other geographical regions or for other applications, other codes will
apply. It is the installer's responsibility to identify and apply all
applicable codes.
Calculating Battery Requirements
Battery type and battery size strongly affect the performance of the
inverter. Therefore, you need to identify the type of loads your inverter
will be powering, and how much you will be using them between charges.
Once you know how much power you will be using, you can determine
how much battery capacity you need. We recommend that you purchase
as much battery capacity as possible.
For information on calculating battery capacity, go to www.xantrex.com,
click “Support”, choose the product “Xpower Inverters”, and click
“Battery Calculator” under Calculators & Problem Solvers.
CAUTION: Equipment damage
The inverter must only be connected to a 12 V battery system. It will not operate
if connected to a 6 V battery and will be damaged if connected to a 24 V battery.

975-0556-01-01 1–5
This guide for use by qualified installers only.
Choosing an Effective Charging System
The charging system must be appropriate for your particular installation.
A well-designed charging system will ensure that power is available when
you need it and that your batteries remain in top condition. Inadequate
charging will degrade system performance, and the wrong type of charger
will reduce battery life.
For information about choosing an effective battery charging system, go
to www.xantrex.com, click “Support”, choose the product “Xpower
Battery Chargers”, and click “Selecting the Right battery Charger” under
Tech Notes.
NOTE: If the main charging source will be the vehicle's alternator, then its
voltage and current ratings must be appropriate for the size and type of
battery that is selected.
Choosing an Appropriate Location and Mounting Orientation
WARNING: Fire or explosion hazard
The inverter contains components which tend to produce arcs or sparks. To
prevent fire or explosion, do not install the XPower Inverter 3000 in
compartments containing batteries or flammable materials, or in locations that
require ignition-protected equipment. This includes any space containing
gasoline-powered machinery, fuel tanks, as well as joints, fittings, or other
connections between components of the fuel system.
WARNING: Fire hazard
To reduce the risk of fire, do not cover or obstruct the ventilation openings. Do
not install the inverter in a zero-clearance compartment. Overheating may result.
WARNING: Shock hazard
Do not install the Inverter 3000 in a wet environment or in any other environment
where moisture can occur and enter the inverter enclosure through the ventilation
openings. This unit is not intended for marine applications.

1–6 975-0556-01-01
This guide for use by qualified installers only.
Appropriate
Location The inverter must only be installed in a location that is:
:
Dry Do not allow water or other liquids to drop or splash on it.
Cool Ambient air temperature should be between 0 and 40ºC
(32 and 105ºF)—the cooler the better within this range.
Ventilated Allow at least 3" (76 mm) of clearance around the inverter
for air flow. Ensure that the ventilation openings on each
end of the inverter are not obstructed.
Safe Do not install the inverter in the same compartment as
batteries or in any compartment capable of storing
flammable liquids like gasoline.
Close to
battery Do not use excessive DC cable lengths: they increase wire resistance which leads to voltage drop and heating.
Consequently, they reduce available power and run-time.
Longer AC wires are preferable to longer DC wires: voltage
drop is less of an issue and the cost is lower.
Protected
from battery
gases
Do not mount the inverter where it will be exposed to gases
produced by batteries. Battery gases are corrosive, and
prolonged exposure to battery gases will damage the
inverter.

975-0556-01-01 1–7
This guide for use by qualified installers only.
Mounting
Orientation The inverter must be oriented in one of the following ways:
• Horizontally on a vertical surface. (Do not mount with the fan
pointing up or down.)
• On a horizontal surface.
• Under a horizontal surface.
Mounting
Dimensions Use the measurements below to plot the holes in the surface where you want to anchor the inverter and permanently mount it into place.
Figure 1-3 Approved Mounting Orientations
RESE T
REMOTE
POWER
PUISSANCE FAULT FAUTE
Non-sinusoidal
outp ut only.
Non seu le ment de
sortie sinusoïdale.
RESET
REMOTE
POWER
PUISSANCE FAULT
FAU TE
Non-sinusoidal output only. Nonseulement de sortie sinusoïdale.
RESET
REMOTE
POWER
PUISSANCE FAULT FAUTE
Non-si nusoi dal
outp ut only.
Nonseulement de
sortie sinusoïdale.
Figure 1-4 Mounting Dimensions (Not to scale)
450 mm (17.7 in.)
225 mm
(8.9 in.)
91.5 mm
(3.6 in.)
mounting hole Ø 5 mm (0.2 in.)
126.5 mm
(5 in.)

1–8 975-0556-01-01
This guide for use by qualified installers only.
Selecting Cable Sizes
To operate safely and effectively, the XPower Inverter 3000 needs proper
cables and fuses. The XPower Inverter 3000 has low-voltage and high-
current input, so it is essential that you use low-resistance wiring between
the battery and the inverter. This means using the largest gauge and
shortest DC cables. The goal is to deliver the maximum amount of usable
energy to your load.
For safe and efficient operation, you will need to calculate cable sizes for
your:
• DC input cables from the battery to inverter, and
• Chassis ground cable from the vehicle chassis to the chassis ground
lug on the inverter’s DC panel.
DC Input Cables
• Keep all cables as short as possible, and ensure that each cable
between the inverter and the battery is no longer than 10 feet (3 m).
• Do not use aluminum cable. It has about 1/3 more resistance than
copper cable of the same size, and it is difficult to make good, low-
resistance connections to aluminum wire.
• Some installation codes require and we recommend use of oil-
resistant cable rated for damp or wet locations.
• For installations subject to the US NEC, the minimum cable size
required is No. 4/0 AWG 75 °C1, with a maximum fuse size of
400 Adc.
• For other installations, other codes may apply, but in no case should
you use DC cables smaller than No. 2/0 AWG, protected by a
250 Adc fuse, but note that the five-minute 3000 W rating requires a
350 Adc fuse, which will require a minimum No. 4/0 AWG cable.
WARNING: Fire hazard
Use only copper wire rated 75 °C minimum. Never use a DC input cable longer
than specified in “DC Input Cables” below. A longer cable can potentially
generate enough heat to start a fire or result in poor inverter performance.
1.Based on US NEC, 2008, table 310-17, 75C copper wire.

975-0556-01-01 1–9
This guide for use by qualified installers only.
Selecting a DC Input Fuse or Circuit Breaker
The DC cables from the battery to the inverter need to be provided with
overcurrent protection, in the form of a fuse or circuit breaker, located as
close as possible to the DC positive battery terminal.
Because your batteries can provide thousands of amps of short-circuit
current, you need a DC-rated fuse or circuit breaker that can safely
interrupt the short-circuit current that the batteries can produce.
DCDisconnects
and Over-
Current Devices
The DC circuit from the battery to the inverter must be equipped with a
disconnect and over-current device. This usually consists of a circuit
breaker, a “fused-disconnect,” or a separate fuse and DC disconnect. Do
not confuse AC circuit breakers or fuses with DC-rated ones. They are not
interchangeable. The rating of the fuse or breaker must be matched to the
size of cables used in accordance with the applicable installation codes.
The breaker or disconnect switch and fuse should be located as close as
possible to the battery, in the positive cable. Applicable codes may limit
how far the protection can be from the battery.
To select the correct fuse type and size:
1. Determine the total short-circuit current rating for each battery, based
on the battery manufacturer's published short-circuit current sourcing
ratings for the battery. Then determine the total for your battery bank.
For example:
• If you are using one battery to power your inverter and its short-
circuit current rating is 500 A, the total short-circuit current rating
is 500 A.
• If you are powering your inverter with two 12 V batteries
connected in parallel, and each battery has a short-circuit current
rating of 500 A, the total short-circuit current rating is 1000 A.
• If you are powering your inverter with two 6 V batteries
connected in series, and each battery has a short-circuit current
rating of 500 A, the total short-circuit current rating is 500 A.
Important: For batteries connected in parallel, the total short-circuit current
rating is the sum of the short-circuit current ratings of all of the batteries
connected in parallel. For batteries connected in series, the total short-circuit
current rating is equal to the short-circuit rating of the battery with the highest
short-circuit rating. It is not the sum of all the short-circuit current ratings taken
from each connected battery.

1–10 975-0556-01-01
This guide for use by qualified installers only.
2. Once you have determined the total short-circuit current rating of
your batteries, select a fuse or circuit breaker that has:
• a short-circuit interrupting capacity at least equal to the total
short-circuit current rating of your battery bank, and
• a DC voltage rating of at least 16Vdc, and
• a current rating no more than the values given above.
3. If a fuse is used rather than a circuit breaker, a disconnect switch
located between the battery and the fuse is recommended, to allow the
circuit to be de-energized when replacing the fuse.
Fuses and circuit breakers can be bought at any RV supply store or
electrical products store.
Chassis Ground Wire Sizing
Connect a minimum No. 8 AWG1copper wire from the vehicle chassis to
the chassis ground terminal on the inverter DC panel.
Output Conductor Selection for Hardwire Installation
The inverter may be used by connecting cord-connected loads to the
receptacles on the front panel, and/or by connecting loads or a load circuit
to the AC output hardwire terminal block. If making connections to the
AC output hardwire terminal block, use jacketed No. 10 AWG2copper 2-
wire plus ground cable. Conductors may be solid or stranded.
Some installation codes require and we recommend use of oil-resistant
cable rated for damp or wet locations.
Color code for conductors:
Black = [L]ine (hot)
White = [N]eutral
Bare or green = [G]round
1.Based on US NEC 2008 article 551-20(c). Other codes may require larger
chassis ground cable, in some cases as large as the DC power cables.
2.Based on US NEC 2008, table 310-16, 75C copper wire.
