Xplore Ambassador 8" User manual

e-scooter
AMBASSADOR 8”
User manual

Contents
Names and instructions of major parts
Safety Instruction
Product Presentation
Unfolding/ picture
Folding/ picture
Basic Operation
Display and Throttle
Brake controlling
Riding Operation
Get ready to start
Riding
Parking
Charger and battery
Maintenance
Lubricating
Battery
Place& Daily care
General troubleshooting
Product specification and parameters
Scope of warranty

Major Parts of Scooter
1 Handle bar
2 Accelerator
3 T bar
4 Front Tube
5 Quick release clamp
6 Display and Throttle
7 Brake Lever
8 Folding lever
9 Charger Socket 10 Hub Brake
10 Hub Brake

Safety Instruction
1 This device is designed for single use, please do not carry any passenger during any riding;
Children and juveniles can not play it.
2 Please wear the helmet and other protective equipment during riding this device.
3 Do not ride on the unsafe or unqualified road.
4 Please practice in open space and get familiar with the control method before riding.
5 Please do not do dangerous actions or put single hand in riding. Keep the feet on the device.
6 Do not turn off the power during riding.
7 Do not attempt to directly go through a stair which is 3cm or higher, as may make the device tip over, causing injury or damage the
device.
8 Slow down and proceed with caution when user rides the device through a rough or uneven pavement.
9 Users must adjust the product height to the proper position before using to ensure safety.
10 Do not ride the device through the water, oil, and ice on the ground.
11 Do not use the device under -5*C.
12 Do not place the device in the water depth of 5cm or deeper. It would cause a short-circuit fault of the motor and drcurt.
13 Try to avoid riding on bad weather.
14 Please charge the device at least once every 30 days.

Product Presentation
3 Do not ride on the unsafe or unqualified road.
6 Do not turn off the power during riding.

Product Presentation

1. Power Switch
2. Mode setting button
3. Speed Control Throttlee
4. Power Display
5. Speed Show
6. Distance Show
Warning: Please keep the throttle and brake free brfore turning on

Function:
1. Display function: speed, battery capacity, fault reason, distance
2. Control setting function: Power switch control, wheel diameter setting, dormancy
setting, backlight setting, boot setting, driving mode setting, voltage grade setting, the limit of controller setting.
3.Communication protocol: UART display all the content (starting up 1S display all the content)
KeyPress introduction function:
1. Long press ON/OFF button to start/turn off the scooter.
2. For S1, please long press the MODE button to open the head light, and you will see the backlight of display be enlightened, too. For
S4, please press the red LED button on the handle bar to open the head light.
3. Short press the mode button to change speed mode, you will see SLO,MID,FAS or 1,2,3 three speed modes.
4.After press the throttle and reach a speed, hold it for 5 seconds, then the scooter can keep this speed even you take off the finger
from throttle.
5.Please long press ON/OFF+MODE button at the same time into settings ,then short press the ON/OFF button to select which
parameter you wanna set,after a certain parameter setting selected,you can modify the parameter as per below 2 methods:
(1) Please long press the ON/OFF button until number flashing ,then short press the ON/OFF button to decrease the value or short
press the MODE button to increase the value,after modification done,you can long press ON/OFF button or long press MODE button
to stop number flashing and save the modification, then short press the ON/OFF button again you can switch to other parameters
you wanna modify, other steps are the same as described above, long press ON/OFF+MODE button to exit setting interface.
(2) Please short press MODE button until number flashing, then short press the ON/OFF button to decrease the value or short press
the MODE button to increase the value, after modification done, you can long press ON/OFF button or long press MODE button to
stop number flashing and save the modification, then short press the ON/OFF button again you can switch to other parameters you
wanna modify, other steps are the same as described above, long press ON/OFF+MODE button to exit setting interface.

RIDING OPERATIONS
Get ready to start
1 Choose an open space.
2 Unfold the device by previous steps
3 Adjust the height of the tiller.
Riding
1 Press <!.> button to tum on the power, the speed mode defaults to the 1irst level.
2 The device has safe-start function. Place one foot on the pedal, the other foot on the ground and glide slowly while gently pull the
throttle; Start riding.
3 You can choose different speed levels according to different road conditions to adjust riding speed; and you can control speed by
pulling the throttle.
4 When riding, if someone or barriers in front of you, please use the brake lever to cut off the motor power to decelerate or stop the
device, and at the same time, using the bell to remind others.
Parking
Pull back the brake lever would cut off the power supply and decelerate immediately. Place one foot on the ground after the speed is
proper Avoid emergency braking to prevent skidding fall, or will worn the tire and lead to instability in riding.
Notice: Do not use this device during the raining day or freezing weather. If necessary , user has to keep the speed under 10 km/h and
avoid the emergency braking to prevent sudden fall.

BATTERY AND CHARGER
Each scooter is equipped a specific lithium battery and a specific charger.
Please do not charge the battery by the other charger and do not charge other battery by the charger either, or it will be
dangerous. Our company is not responsible for the damage of the battery or charger if users do not do as the instruction.
Lithium Battery
Please full charge the battery before using when you get a new scooter.
You'd better charge the battery when the battery capacity is lower than 2 levels to avoid influencing your trp. When the battery is not
used for a long bme, please charge at least once per month; the battery can handle 1000-1500 chargings
The battery protection will be trggered when the device is not used for a bng bme, users could contact us for support . The battery is
damaged because of some abnormal factors like water, crash and so on, the warranty will be void.
Charger
The charger is damaged because of some abnormal factors like water, crash and so on, the warranty will be void.
Charging instruction
1 Open the rotation protection cover of the charger socket; connect the charger plug to charging socket on the frame.
2 Plug the charger into general power dock (AC1OOV-240V).
3 The charging process is running when the illustration light is red, the charging process is completed when the light turns green,
power is full at this stage.
4 Please place the charger in dry and ventilated environment.

Maintenance
General Troubleshooting
Lubricating: To add a small amount of white grease or lubricant to the handle every three months.
Tire: Rubber elastic tire is used in the product. The tires need to be changed immediately when it has obvious rupture.
Please contact the dealer to replace the original tires. Please check the scooter every month, to see if there are screw loose, tighten
them.
Brake: Disc brake is applied in the product. Any wear of brake pad could impact brake performance, please contact the dealer to
adjust the brake line tightness; need to change the brake pad when serious condition occur.
Battery: The equipped lithium battery has charging cycle at least 500 times, the normal use of the general can reach more than 600
times. When the battery is full of electricity, driving mileage only half of the factory mileage, rt is recommended to replace the lithium
battery.
Placement and daily care: Please don`t expose the scooter to the sun or other serious damp places for a long time; please keep
clean scooter.
When the product is not working properly, please check if the following work has been completed:
a-power is turned on
b-Check the battery power through the screen c-To check the left brake
d-Whether all sockets and connectors are correctly connected
If the steps above are completed, still not in normal operation, please contact the manufacturer or local dealer

Product specification paramer list
Folding size 98*18*36cm
Unfolding size
98*50*114cm
Materials Aluminium alloy
Batterycapacity 24V 8.0AH
Motor 8" 250W
Max speed
25km/h
Maxdistance 25km
Suspension Yes.also with inflatable tyre
LEDfunction Yes
With metal stander Yes
Speed modes 3
Brake system
Drum brake
Charging time
5-{i hours
Maxclimbingangle 15°
Max load
120 kg
Product weight
12kg

e-scooter
AMBASSADOR 8”
Priručnik
za korisnike

Sadržaj
Glavni dijelovi romobila
Sigurnosne upute
Pezentacija proizvoda
Rasklapanje
Sklapanje
Osnove korištenja
Display
Kočenje
Vožnja
Priprema
Vožnja
Kočenje
Punjač i baterija
Održavanje
Podmazivanje
Baterija
Svakodnevno održavanje
Rješavanje problema
Specifikacije i parametri proizvoda

Glavni dijelovi romobila
Sadržaj
Kočenje
Vožnja
Vožnja
Kočenje
Punjač i baterija
Održavanje
Svakodnevno održavanje
Specifikacije i parametri proizvoda
1. Ručke
2. Gas
3. T-cijev
4. Prednja cijev
5. Quick release kopča
6. Display
7. Ručica kočnice
8. Ručica za preklapanje
9. Konektor za punjenje
10. Nožna kočnica

Sigurnosne upute
1. Ovaj proizvod je namijenjen za trnasport samo jedne osobe, nije namijenjen za djecu
2. Molimo nosite kacigu i štitnike tijekom vožnje
3. Ne vozite po izrazito neravnim terenima
4. Prije prve vožnje vježbajte na otvorenom prostoru
5. Vozite s obje ruke
6. Nemojte isklučivati romobil tijekom vožnje
7. Nemojte prelaziti prepreke više od 3 cm
8. Prilagodite brzinu uvjetima vožnje
9. Prije vožnje obavezno podesite visinu ručki
10. Nemojte voziti po vodi, masnima podlogama i ledu
11. Ne koristite romobil na temperaturama nižim od -5*C
12. Ne uranjajte romobil u vodu, to može dovesti do kratkog spoja
13. Izbjegavajte vožnju po lošem vremenu
14. Napunite bateriju barem jednom u 30 dana

Prezentacija proizvoda

Prezentacija proizvoda

1. Prekidač napajanja
2. Tipka za postavke načina rada
3. Kontroler brzine
4. Status baterije
5. Brzina
6. Duljina
Upozorenje: Ručice gasa i kočnice trebaju biti otpuštene tijekom paljenja.

Funkcije:
1. Funkcije displaya: brzina, razina baterije, greška, udaljenost.
2. Kontrole: veličina kotača, način rada, max. brzina.
Kontrola pomoću tipki
1. Pritisnite i držite ON/OFF kako bi uključili romobil.
2. Na Ambassadoru pritisnite i držite tipku MODE za ukljućivanje prednjeg svijetla i pozadinskog svjetla, na Grand Cruiseru pritisnite
crvenu LED tipku za ukljućivanje prednjeg svjetla.
3. Kratkim pritiskom na MODE tipku mijenjate postavke max. brzine (SLO, MID, FAS, 1, 2, 3).
4. Nakon što ste dosegli željenu brzinu, držite ručicu gasa još 5 sekundi i nakn toga ju možete pustiti, romobil će nastaviti tom brzinom.
