Xplore Mini User manual

XPLORER MINI
folding e-bike
User manual

Meet your Ebike
1 saddle
2 charging port
3 seatpost battery
4 seatpost clamp
5 rear wheel
6 rear disc break 7 chain
8 controller
9 power interface
10 foaldabel pedal
11 frame
12 front wheel
13 front disc break 14 motor
15 front fork
16 foldable head stem
17 handlebar
18 break lever
19 LCD display

Paremeter
Product name: Ebike
Model name: QB16F01
Size: 1320*580*980mm
Folded size: 710*360*630mm
Wheel base: 930mm
Net weight: 14kg
Range: PAS>50KM
Standard load: 130KG
Top speed: <25KM/H
Charge time: 3 Hs
Battery type: Lithium-ion
Battery capacity: 36V5.2Ah
Noise: ≤62db(A)
Motor: 250W
Rated output power: 250W
Motor efficiency: ≥80%
Rated RPM: 300r/min
Rated voltage: 36V
Max torque: 40N.m
Overcurrent protection: 12±1A
Low-voltage protection：30±1V
Kwh：≤1.2Kw.h
Ride system: 5 classes PAS
Tire diameter: 16inch
Frame: 16 inch 6061 Al-Alloy foldabel
Front fork: 16 inch inch 6061 Al-Alloy
Break: 160mm disc break
Rim: 16 inch Al-Alloy 13G36H
Tire: Kenda 16*2.125
Chain wheel: Prowheel 52T
Fly wheel: 14T
Rear hub: Sigma Al-Alloy
Chian: KMC
Handle bar: EVA
Display: Kunteng LCD
Controller: Kunteng sine wave FOC
Break lever: Al-Alloy ebike lever
Saddle: KNUS
Pedal: foldabel pedal

Fold your Ebike
1. grab the seat post (important). Loose
the clampe.
2. Push the seatpost till the ground
slowly,tight the seatpost clamp.
3. loose the handle bar clamp.
4. turn the handlebar clockwise till vertical,
tight the clamp

5. release the lock clamp, fold the head
tube.
6. fold the pedal by pushing it level.
7. release the safety cap.
8. pull the lock bar ,fold the main tube.

Operate your Ebike
I Press&hold power button for 3 sec,LCD shows sceen A,data shows as :sigle riding time-
PAS class-speed-single range;
II Press power button,LCD Shows sceen B,data shows as:total riding time-PAS class
–Average speed-total range;
III Press power button twice,LCD shows sceen C,data shows as:total riding time-max
speed-voltage

Operate your Ebike
up power down LCD backlight Slide
1. Slide mode:press&hold DOWN button till flicker, your Ebike will slide at a fixed speed of
6KM/H,release to quit.
2.LCD backlight:press&hold UP button to turn on backlight,press&hold UP button again to turn off.
3.PAS mode:press UP or DOWN button to choose PAS classes from 0~5.

Charge your Ebike
Charging port is right beneth the saddle,covered by a rubber
dust-free cover,uncover it,plug the charger into the port;cover
the port again when charged
If you want to charge your battery separately,roll out the power
port ,release the seatpost clamp,pull out the seatpost
battery,then repat the steps above.

Accessory list
1 front mud fender
2 rear mud fender
3 reflecters
4 ring
5 lamp
Please mount accessories according to your needs

Attention
Battery & Charge
1.Red indicator on the charger means charging,when it turns green ,please stop charging your battery;
2.Do not expose to temperature -20o< or > 35o Fully chare the battery and store separately i f not use for
over 30 days.Fully charge it every 90days,or the battery may
slf-discharge and be damaged.This damage is not covered by the Limited Warranty;
3. Never expose your battery to damp environment or soak into water,never short circuit the battery
terminals, This damage is not covered by the Limited Warranty;
4. Charge with the original charger only;
5. Do not disassemble/punch battery pack.Do not place it in fire or drop from high ,Avoid contacting with
contacts;
6. Turn off Ebike’s power before charge it.Plug the charge port first then the AC plug;
7. Do not cover any items on the charger during chargeing; 8.Pull out charge port before the AC plug;
9.Please keep battery outreach from children.
10.The capacity of Li-battery will decrease when -10o<;
11.Recycle or dispose of in accordance with local regulations

Ride & Maintance
1. Must with your helmet on and follow the local laws and regulations；
2. Read this instruction carefully before riding a Ebike；
3. Start your ride with the 3rd PAS class；
4. Keep the lamp on at night；
5. Fully check break system ,tire pressure ,and battery remain before riding；
6. PLEASE do take front break FIRST；
7. Do not intense riding；
8. Do not ride into water over 15cm；
9. Replace the quick-wear parts(like break pad)in time；
10. Juveniles Pregnant Intoxicated are not allowed to ride Ebike；
11. Keep your Ebike away from damp, high temperature or corrosive environment；
12. Keep your Ebike away from sun-scorched and rain-drenched；
13. Check screws ,chain and other parts regularly.

XPLORER MINI
e-sklopivi bicikl
Priručnik za korisnike

Upoznajte svoj novi sklopivi e-bicikl
1 Sjedište
2 Priključak za punjenje
3 Baterija
4 Ručica za namještanje visine
5 Stražnji kotač
6 Stražnja disk kočnica
7 Lanac
8 Kontroler
9 Indikator snage
10 Sklopive pedale
11 Rama
12 Prednji kotač
13 Prednja disk kočnica
14 Motor
15 Vilica
16 Sklopivi upravljač
17 Ručke
18 Ručica kočnice
19 LCD ekran

Specifikacije
Naziv proizvoda: Xplorer Mini
Šifra modela: QB16F01
Veličina: 1320*580*980mm
Veličina (sklopljeno): 710*360*630mm
Veličina točkova: 930mm
Težina: 14kg
Domet: PAS > 50km
Max težina korisnika: 130kg
Max brzina: <2 5km/h
Vrijeme punjenja: 3h
Baterija: Litij-ionska
Kapacitet baterije: 36V 5.2Ah
Zvuk: ~62db(A)
Motor: 250W brushless geared DC motor
Nominalna snaga: 250W
Efikasnost motora: ~80%
Nominalni RPM: 300r/min
Nominalna snaga: 36V
Max okretni moment: 40Nm
Nadstrujna zaštita: 12±1A
Niskonaponska zastita:30±1V
Kwh ~1.2Kw .h
Ride system: 5 classes PAS
Guma: 16inch
Rama: 16 inch 6061 Al-Alloy sklopljiva
Vilica: 16 inch 6061 Al-Alloy
Kočnice: 160mm disk
Preklopna točka: 16 inch Al-Alloy 13G36H
Gume: Kenda 16*2.125
Lančanik: Prowheel 52T
Zamašnjak: 14T
Rear hub: Sigma Al-Alloy
Lanac: KMC
Drške: EVA
Ekran: Kunteng LCD
Kontroler: Kunteng sine wave FOC
Ručice kočnice: Al-Alloy
Sedište: KNUS
Pedale: sklopljive

Sklapanje
1. Povucite stup sjedišta (važno) i otpustite
ručicu
2. Gurnite stup sjedišta prema dolje i zatim
zategnite ručicu
3. Otpustite ručicu na upravljaču.
4. Rotirajte upravljaču smjeru kazaljke na
satu, dok ne bude vertikalan. Zatim zategnite
ručicu.

5. Otpustite ručicu na prednjem dijelu i
sklopite stup od upravljača.
6. Sklopite pedale
8. Otpustite ručicu na rami.
9. Povucite polugu za zaključavanje i
sklopite ramu

Korištenje e-bicikla
~ Pritisnite Power tipku i držite 3 sekunde. LCD prikazuje ekran A (trenutno vrijeme vožnje, PAS razina,
brzina, trenutna udaljenost).
~ Pritisnite Power tipku jednom. LCD prikazuje ekran B (ukupno vrijeme vožnje, PAS razina, prosječna
brzina, ukupna udaljenost).
~ Pritisnite Power tipku dva puta. LCD prikazuje ekran C (ukupno vrijeme vožnje, PAS razina, maksimalna
brzina, napon). Pritisnite i držite power tipku da isključite e-bicikl.

1.Slide način rada: pritisnite i držite tipku ‘’Dolje’’ dok se ne pojavi ikona E-bicikl će voziti konstantnom
brzinom od 6km/h. Pustite tipku za prekid.
2.LCD osvjetljenje: Pritisnite i držite tipku ‘’Gore’’ za uključenje pozadinskog osvjetljenja na ekranu. Ponovno
pritisnite isti tipku i držite za iskljućenje osjetljenja.
3.PAS način rada: Pritisnite jednom tipke ‘’Gore’’ ili ‘’Dolje’’ za regulaciju razine (0-5). PAS je sustav koji pomaže
pri ubrzavanju i održavanju brzine. Intenzitet PAS sustava se označava razinama od 0 (bez pomoći) do 5
(najveće ubrzanje i brzina).
Način rada
gore power dole LED svijetlo Slide način rada

Punjenje baterije
Priključak za punjenje se nalazi ispod sjedišta. Zaštićen je
gumenim poklopcem. Otvorite priključak za punjenje, spojite
u njega punjač i nakon što se baterija napuni, opet pokrijte
otvor gumenim poklopcem.
Ako želite ukloniti bateriju iz e-bicikla, prvo otključajte nosač
baterije. Zatim otpustite ručicu stupa ispod sjedišta i izvucite
bateriju. Sada beteriju možete napuniti bilo gdje i vratiti u e-bicikl.

Popis dodatnih dijelova
1 Prednji blatobran
2 Zadnji blatobran
3 Reflektori
4 Prsten
5 Svetiljka
Dodatne dijelove korisitite prema potrebi.
